Angekis RS232 User manual

Declaration
Parameter:
This manual might be not accurate technically or contain minor typo.
The contents of this manual about production description and program
will be updated aperiodically without notification.
Note：
§ the LCD is fragile, no crash or long exposed under strong light.
§ The joystick is fragile, please make sure the product is packed in
original packing material when you send it back for repairation..
§ The keyboard controller shall be used in specified environment
where the temperature and humidity is suitable.
§ Please follow the connection method defined in this manual.
Item
Power supply
Working temperature
Working humidity
Communication
Baud rate
Ports
Display
Size
Parameter
DC 12V±10%
-10℃~55℃
≤90% RH
RS485, RS422, RS232
2400bps, 4800bps, 9600bps, 19200bps
RS422 and RS232 port
blue LCD screen
420mm(L)*260mm(W)*170mm(H)
Accessories:
1
1
1
DC 12V adapter
<user manual>
name
connecter
unit
pc
pc
pc
note
N/A
Input: 100-240vac, 50/60Hz
N/A
2user manual
quantity

Contents
1. Front panel and rear panel introduction ...................4
1.1 All keys’ function introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
1.2 LCD screen. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
1.3 Joystick function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
1.4 Rear panel introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
1.5 Function item specification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
2. Operation introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
2.1 Single function key and combined function key introduction . . . . . . . . . 9
2.2 Combined function key specification . . . . . . . . . . . . . . . . . . . . . . . . . . 9
2.3 Camera ID setup. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
2.4 Preset setup and recall. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
2.5 Menu setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
3. keyboard controller’s parameter setup and inquiry .........14
3.1 system parameter setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
3.2 parameter setup framework . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
3.3 system parameter inquiry . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
4. typical wiring diagram . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
5. FAQ . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
3
user manual
Contents

Near Far
WideTele
Open Close
LR-STD LR-REV
speed dome Function key
Function key
number key
basic function keys
Address key
Data
Screen
Back
Light
Home
Power
P-T
Reset
Auto Manual Preset
Call
Menu
CamSetID CLR
4user manual
1. Front panel and rear panel introduction1. Front panel and rear panel introduction
1.1 All keys’ function introduction
introduction
1.1.1 keyboard controller function keys:
【Esc】 back to previous menu.
【Setup】 press and hold for 3s, get into setup menu.
【Search】 inquiry the keyboard controller’s model number, S/N,
key-press sound and operation lock.
1.1.2 Sony video conference camera function setup/recall keys:
【Auto】 enable auto focus

【Manual】 Enable manual focus.
【Data Screen】 open/close data screen.
【Back Light】 turn on/turn off back light.
【Home】 control the camera toward ahead.
【P-T Reset】 reset the camera.
【Power】 power on/off the camera.
【SetID】 camera ID setup.
【Preset】 camera’s preset setup, it shall be used together with number
key and 【Cam】key.
【Call】 recall camera’s preset, it shall be used together with number
key and 【Cam】key.
【Menu】 get into camera menu.
【Cam】 select the camera’s ID.
5
user manual
introduction

1.1.3 Number keys:
【CLR】 delete key: delete all information which is keyed in.
【0】～【9】 number key: 0, 1, 2, 3, 4, 5, 6, 7, 8, 9.
【Enter】 confirm key: confirm and save all information which is keyed in.
1.1.4 Video conference camera basic function keys:
【Near】 in manual focus mode, focus near.
【Far】 in manual focus mode, focus far.
【Tele】 zoom near in slow speed, enlarge the magnification, reduce
the view angle, enlarge the object (note: screw the joystick
clockwise, zoom near in high speed).
【Wide】 zoom far in slow speed, reduce the magnification, enlarge the
view angle, reduce the object (note: screw the joystick
counterclockwise, zoom far in high speed).
【Open】 in manual aperture mode: enlarge camera aperture.
【Close】 in manual aperture mode: reduce camera aperture.
【LR-REV】 press this key, camera will move toward opposite direction
when operate the joystick.
6user manual
introduction

1.3 Joystick function
【LR-STD】 press this key, camera will move toward correct direction when
operate the joystick.
1.2 LCD screen
All operation of the keys or joystick will have corresponding information showed
on the LCD screen. LCD screen will get into power saving mode if user do not
operate the keyboard controller over 30s ( its brightness reduce to lowest,
information which showed on the screen will back to initial status).
7
user manual
operation Output
control operation Output control operation Output control
operation Output
control operation Output control operation Output control
up down left
right Zoom near Zoom far
introduction

1.5 Function item specification:
RS-422
①
②
③
④
⑤
⑥
Ground
TXD
RXD
PW
DC-12V
1.4
indicate light. Details as below:
Rear panel introduction
Rear panel: 5 ports for RS422, 1 RS232 port, 1 DC 12V input port, 3 status
2 3 4 5 61
8user manual
item mark interface description
Control command
output port:
Connecter 1-4
Control line
ground port
Send command
indicator
Receive command
indicator
Power input
indicator
Power input port
Connect to RS422 port of video
conference camera:
Ta to RXD IN-, Tb to RXD IN+
Ra to TXD IN-, Rb to TXD IN+
Control line ground port
Flicking and green denote
it is sending commands
Flicking and green denote
it is receiving commands
It will be always on and red when
keyboard controller is powered on
DC 12V input port
introduction

2.1 Single function key and combined function key introduction
Single function keys:
【P-T Reset】、【Tele】、 Wide Open
【Close】、【LR-STD】、【LR-REV】、 Joystick.
2.1.2 Combined function key means: need to press and hold for over 2s then
camera will recall a function.
Combined function keys: 【Manual】、【Preset】、【Call】、【Menu】、
【Cam】、【Power】、【SetID】、【CLR】。
2.2 Combined function key specification
2.2.1 get into control status:
If LCD screen display: , denote keyboard controller is in
control status. If it display other information, please press【Esc】key back to
control status.
2.2.2 Select camera ID:
Press 【Cam】key, key in camera ID number, press 【Enter】.
For example: select camera ID “2”
2.1.1 Single function key means: press this key, camera will recall a function.
【Auto】、【Data Screen】、【Home】、【Back Light】、
【 】、【 】、
CAM : 001
P:VISCA BR :960 0
9
user manual
2. Operation introduction2. Operation introduction
Operation

CAM : 001
CAM :
CAM : 001
CAM : 2
CAM : 002
P:VISCA BR :960 0
CAM : 001
SET CAM ID : 001
CAM : 001
SET CAM ID : 001
CAM : 001
SET PRES ET :
10 user manual
Operation: press 【Cam】key, LCD screen will display:
Press ‘2’ key, LCD screen will display:
press 【Enter】,LCD screen will display:
2.3 Camera ID setup:
Sony D70/D100 video conference camera ID will be set as ‘1’ automatically
after power on each time, so it shall be set by keyboard controller.
2.3.1 There is only one video conference camera
Connect camera to keyboard controller properly, press and hold 【SetID】
key for 2s, LCD screen will display ,denote the camera ID
has been set as ‘1’.
2.3.2 there are more than one video conference camera(max. 7)
Connec t came ra to keyboard cont rol ler properl y, all cameras shall be
connec ted in cascade mode, press and hold 【SetID】key for 2s, LCD
screen will display , denote the cameras’ ID have been
set in sequence as ‘1’, ‘2’, ‘3’…, the ID of the camera which directly connect
to keyboard will be set as ‘1’, and so on.
2.4 preset setup and recall
Preset setup: select the camera ID, then press【Preset】key , LCD screen
will display, after adjusting the camera’s direction and
zoom near/far, key in a number as this preset’s number, for example: ‘6’,
then press 【Enter】, setup finish. Repeat above steps for other preset
setup, or press 【Esc】key to exit.
Operation

CAM : 001
CALL PRESE T:
SONY MEN U
DzoomM ode :co mbin e
CAM : 001
CALL PRESE T: 6
SONY MEN U
Dzoom : on
SONY MEN U
af sensi tivi ty: low
SONY MEN U
af mode : norm al
11
user manual
Preset recall: select the camera ID, then press 【Call】key, LCD screen
will display , key in preset number.
For example ‘6’, LCD screen will display , press【Enter】,
one preset is recal led. Repea t above steps for reca lling other preset,
press 【Esc】key to exit.
2.5 Menu setup
Following operation can change parts of camera’s functions, for camera’s
detail functions, please refer to camera’s user manual.
Note: move joystick up/down to select different sub-menu, move joystick
left/right to set the sub-menu.
2.5.1 when keyboard controller is in control mode, press 【Menu】key:
1: CAM_DZoomModeInq, LCD screen display ,move joystick
left/right to select D-Zoom ON or D-Zoom OFF.
2: CAM_DZoomC/SM odeInq, LCD screen display , move
joystick left/right to select Combine Mode or Separate Mode.
3: CAM_AFSensitivityInq,LCD screen display ,move joystick
left/right to select AF Sensitivity Normal or AF Sensitivity Low.
4: CAM_AFModeInq, LCD screen display , move joystick
left/right to select Normal AF or Interval AF.
Operation

SONY MEN U
WB MODE :AUTO
SONY MEN U
AE MODE :AUTO
SONY MEN U
SHUTTE R MODE : AUTO
SONY MEN U
expcomp mode : off
SONY MEN U
SPOTAE m ode : of f
SONY MEN U
lr rev mod e : on
SONY MEN U
freeze m ode : of f
SONY MEN U
pic effe ct : off
12 user manual
Operation
5: CAM_WBModeInq, LCD screen display , move joystick
left/right to select Auto, In Door, Out Door, One Push WB, ATW or Manual.
6: CAM_AEModeInq, LCD screen display , move joystick
left/right to select Full Auto, Manual, Shutter Priority, Iris Priority, Bright.
7: CAM_SlowShutterModeInq, LCD screen display , ,move
joystick left/right to select Auto, Manual.
8: CAM_E xpCom pModeInq, LCD screen d isplay , move
joystick left/right to select On, Off.
9: CAM_S potAE MModeInq, LCD screen d isplay , move
joystick left/right to select On, Off.
10: CAM_LR_ReverseModeInq, LCD screen display ,move
joystick left/right to select On, Off.
11: C A M _ F ree z e M odeIn q , LCD s cre en display , move
joystick left/right to select On, Off.
12: CAM_PictureEffectModeInq, LCD screen display ,move
joystick left/right to select Off, Neg.Art or B&W.

SONY MEN U
ICR MODE : o N
SONY MEN U
autoIC R MODE : oN
SO NY MENU
save chang ed?
13
user manual
Operation
1. the k e y b o a r d co n t r o l will r e c e i v e answer c o d e f rom c ame ra w hen p erform above
op erati on, i f the a nsw er co de is n ot co rre ct, t he keyboard con tro lle r ’s LCD s creen
will display “RE DATA UNKNOWN”.
2. When finish setup for sub-menu, press【Esc】key, LCD screen display ,
if press 【Esc】key again, setup will be saved at present, after power off, it will be deleted.
If press【Enter】key, setup will be saved forever till it is modified by user next time.
13: CAM_ICRModeInq, LCD screen display , move joystick
left/right to select On, Off
14: CAM_AutoICRModeInq, LCD screen display , move
joystick left/right to select On, Off
Note:

[KEYBOARD SET]
PASSWORD:
14 user manual
3. parameter setup and inquiry3. parameter setup and inquiry
Setup
3.1 system parameter setup
the keyboard controller ’s system parameter include: password, default
factory, key-press sound on/off, ID, lock. Please refer to following setup
description of ‘default factory setup’ and ‘keyboard lock setup’ for setup
method.
3.1.1 default factory setup
press and hold 【Setup】key for 3s, LCD screen display ,
key in password(default is 8888), press【Enter】key, LCD screen display
,
move joystick right, LCD screen display ,
press【Enter】key, LCD screen display ,
press【Enter】key again, buzzer will sound for about 1s, LCD screen display,
setup is finished(press【Esc】key to quit and setup will
not be saved),
press【Esc】key for 2 time back to normal mode.
3.1.2 Keyboard lock on/off setup
press and hold 【Setup】key for 3s, LCD screen display
SET >> SYS 1 2 3 4 5
EDIT PW
SET >> SYS 1 2 3 4 5
FACTORY
SET >> SYS >> FACTORY
SURE?
SET >> SYS >> FACTORY
Set succ ess
[KEYBOARD SET]
PASSWORD:

SET >> SYS >> LOCK SET
set succ ess
SET >> SYS >> LOCK SET
LOCK PW:
Locked
LOCK PW:
Locked
Locked
open LOC K :
SET >> SYS >> LOCK SET
LOCK OFF
SET >> SYS >> LOCK SET
LOCK ON
SET >> SYS 1 2 3 4 5
EDIT PW
SET >> SYS >> 6
LOCK SET
15
user manual
key in password, press【Enter】key, LCD screen display ,
move joystick to select item 6, LCD screen display ,
press【Enter】key, LCD screen display ,it means the
keyboard lock function is off,
move joystick left or right, LCD screen display ,
press【Enter】key, LCD screen display ,
key in 4 digit password (please keep it in mind), press【Enter】key again,
LCD screen display ,
press【Esc】key for 2 times to quit and back to normal mode.
3.1.3 use method of keyboard lock function
in normal mode, press 【Esc】key, LCD screen display ,
key in password, press【Enter】key,LCD screen display ,
it means keyboard controller is locked now.
press each key, LCD screen display ,
key in password, pres s【Enter】key, keyboa rd contro ll er will back to
unlock mode.
Setup

LOAD ISP
SOUND
Number【0】-【15】
KB ID
LOCK SET
KB ID: XXX
SN：XXXXXXXX
MODLE:XXXXXXXXXX
LOCK(ON/OFF)
SOUND(ON/OFF)
>SYSTEM Setup
>LOAD DEFAULT
>SET PASSWORD
SURE?
AGAIN PW：
NEW PW：
SURE?
OLD PW：
3.2 parameter setup framework
16 user manual
Setup
ON
OFF
ID
ON
OFF
4 digit
4 digit
【Enter】to confirm
【Esc】to quit
Move joystick to select,
【Enter】to confirm
Move joystick to
select,【Enter】to
get into sub-menu
4 digit
【Enter】to confirm
【Esc】to quit
3.2 system parameter inquiry
Press 【Search】 key, following information will display:
Maximum 10 digit
8 digit
2 digit
Keyboard lock status(on or off)
Key-press sound status(on or off)
System inquiry

123 4 56 7 8 9
TXD IN+TXD IN-RXD IN+RXD IN- GND TXD
OUT+
TXD
OUT-
RXD
OUT+
RXD
OUT-
9
VISCA RS422
1 2 3456 7 8 9
VISCA RS422
VISCA RS422
1
1
2
2
3
3
4
4
5
5
6
6
7
7
8
8
9
9
VISCA RS422VISCA RS422
112233445566778899
VISCA RS422
VISCA RS422
1
1
2
2
3
3
4
4
5
5
6
6
7
7
8
8
9
9
wiring
17
user manual
4. Typical wiring diagram4. Typical wiring diagram
4.1 Typical wiring diagram
Refer to table 1 for
Detail definition
Max. 7 pcs camera
Table 1. VISCA RS422 port definition:
item
definition

Keyboard controlle camera
RXD TXD
TXD RXD
GND GND
18 user manual
wiring
4.2 specification:
4.2.1 connection between keyboard controller and camera
When adopt RS422 control bus, the 3rd port of keyboard controller(Ra)
connec t to the 3rd p ort of camera( TXD IN-) , the 4 th port of keyboard
controller(Rb) connect to the 4th port of camera(TXD IN+), the 1st port
of keyboard controller(Ta) connect to the 1st port of camera(RXD IN-),
the 2nd port of keyboard controller(Tb) connect to the 2nd port of camera
(RXD IN+).
Ra TXD IN-
Rb TXD IN+
Ta RXD IN-
Tb RXD IN+
Keyboard controller camera
Wh e n a d opt RS 2 3 2 cont r ol bus , the 1st conn ecter (RXD ) of keybo ard
controller RS232 port connect to the 3rd connecter(TXD) of camera RS232
port, the 2nd connecter(TXD) of keyboard controller RS232 port connect
to the 5th connecter(RXD) of camera RS232 port, the 3rd connecter(GND)
of keyboard controller RS232 port connect to the 4th connecter(GND) of
camera RS232 port(or use a standard RS232 cable to connect both devices).
Client can select each of above connection method.

VISCA Equipment
IN
OUT
IN
OUT
IN
OUT
TXD RXD
RXD TXD
GND GND
TXD OUT+ RXD IN+
TXD OUT - RXD IN-
RXD OUT+ TXD IN+
RXD OUT - TXD IN-
19
user manual
4.2.2 connection between cameras
When adopt RS422 control bus, the 1st camera’s output port connect to
the 2nd camera’s input port, the 2nd camera’s output port connect to the
3rd camera’s input port, and so on. Please refer to following figure:
Camera 1 Camera 2 Camera 3
When adopt RS232 control bus, connection method is almost same, the
1st camera’s output port connect to the 2nd camera’s input port, the 2nd
camera’s output port connect to the 3rd camera’s input port, and so on.
Please refer to following figure:
Camera 1 Camera 2 Camera 3
wiring
