Anntlent AN-L50VA-01 User manual


1/9

AN-L50VA-01
Cell Phone Signal Booster
User Manual


2/9

Introduction
With the popularity of mobile communications, people want to make a call anytime, anywhere,
so the coverage requirement of communication network is higher and higher, but the reality is
not so, sometimes mobile phone signal is not very good, you want to make a smooth call, even in
some places cell phone cannot dial out. in this cases, cell phone signal booster can solve this
problem in a certain extent.
Features
■ AGC(Automatic Gain Control): When the downlink output signal is too strong or self- oscillated,
the uplink and downlink can automatically reduce the gain and reduce the interference signal
■ Self- Oscillation elimination: The system detects self- Oscillation, first reduces the link
gain, then detects the loop, and finds that the self- oscillation is eliminated, the system returns
to normal working state, otherwise, the power is turned off to prevent interference signal.
■ Inactivity Mode: When no user calls, the device is in standby mode, the uplink power amplifier
is switched off, and the static power is decreased by 30%, so as to achieve the purpose of energy
saving.
SAFETY WARNINGS
WARNING:
This equipment should be installed and operated with minimum
distance 20cm （8 inches）between the radiator& your body.
FCC Cautions:
Any changes or modifications not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment.
Operation is subject to the following two conditions: (1) this device may not cause
harmful interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
This equipment complies with FCC radiation exposure limits set forth for an
uncontrolled environment. End users must follow the specific operating instruction
for satisfying RF exposure compliance.
This transmitter must not be co-located or operating in conjunction with any other
Antenna or transmitter.
SAFTY WARNING:


3/9

End users must follow the specific operating instruction for satisfying RF exposure
compliance.
Do not remove the covers during working.
Do not try to repair or replace any components inside of the equipment. Alteration
or abuse of the equipment or other components will void this product’s warranty,
and could be dangerous to the user.
PACKAGE CONTENTS
(1) Packages include the following：
①1Pcs AN-L50VA-01 Booster with FME Male connectors.
②DC Car Charge.
③Screws Mounting Kits.
④User manual (this document).
(2) Booster interface description:
LED light：
The corresponding LED on the right is used to indicate the following different working
conditions of the booster.
LED Indicator Booster working conditions
LED LIGHT Continuous GREEN @normal；
Twinkly GREEN @input signals may be not enough；
Continuous YELLOW @ stronger input signals, AGC is working；
Twinkly YELLOW@ self–oscillation happen ,AGC is working.
Continuous RED@ power supply is shut down；
Twinkly RED@ self–oscillation happen but power supply is NOT shut down.
②Power supply jack: The booster uses a power input range of DC 5-12V.
③INDOOR and OUTDOOR port：The two ports are used to connect outdoor and indoor
antennas.
(3)Antennas and Cables:
In order to use the Booster, you still need the corresponding indoor antenna 1pcs,
outdoor antenna 1pcs, outdoor cable 1pcs and indoor cable 1pcs.


4/9

Antennas and cables kitting information are as follows
Name Model Gain/Loss
Indoor Antenna Patch Antenna PTE-PA-800-2500 3dbi @698-787MHz
Indoor Panel
Antenna
PTE-PN-800-2500 7dbi @698-787MHz
Outdoor
Antenna
Magnet Antenna PTE-MA-800-2500 3dbi @698-787MHz
Omni Tube Antenna PTE-GF-700-2500 3dbi @698-787MHz
Indoor Cable 20feet 3D-FB
Coaxial cable with
N male connector
PTE-3D-FB-5NB 2.19db@698-787MHz
Outdoor Cable 40feet 3D-FB
Coaxial cable with
N male connector
PTE-3D-FB-10NB 5.21db@698-787MHz
Notes：The above model antennas are suitable for AN-L50VA-01 booster.
Warning：Unauthorized antennas，cables and/or coupling devices are prohibited
by FCC rules. Please contact FCC for details：1-888-CALL-FCC
The antenna, cables, and other accessories of the booster kits shall not be
modified without the approval of the ANNTLENT Company, otherwise it shall be
deemed invalid.
INSTALLATION INSTRUCTIONS
（1）Installation of Outdoor Antenna
The outside antenna comes with a strong magnet, simply put it on the roof of your
vehicle. Run the cable of the outside antenna from the nearest door to the booster


5/9

and connect the connectors by hand, please do not use any tools, otherwise it will
be over installed to break the connectors.
Note: Place the antenna at least 6 inches away from any windows including
sunroofs, and 12 inches away from any antennas on the vehicle.
（2）Installation of Indoor Antenna
The inside patch antenna should be stuck on the back of the front seat and face
the space you need to use your phone.
Note: Please don’t mount it on any metal surface. The vertical installation is better
than the horizontal way. The inside antenna and outside antenna should be at least
6ft (2m) apart, if possible.
（3）Connect the Power Cord:
Connect the DC power cord into the vehicle's DC power source, verify that all of
the connections to the booster are tight and secure, plugging the power cord to the
booster, the green LED light will glow, indicating that the booster is ready to use.
WARNING: The booster is rated for DC 5~12V input voltage. DO NOT use the
booster with a high-voltage power supply. This could damage the booster or cause
personal injury.
（4）Mounting the booster (optional):
Select a location to install the booster that is away from excessive heat, direct
sunlight or moisture and that has proper ventilation. Recommended installation
locations are:
TROUBLESHOOTING AND SUPPORT
Problem Resolution


6/9

LED is not light 1.Find an alternate DC Car Charge and try again.
2.Check the power outlet, the power adapter plug maybe is poor
connected.
3.If the problem is still not solved, please contact our company support
at [e-mail]
Booster has no
effect
1. Check whether the direction of the booster is worng connected.
2. Make a call to your mobile phone operator to determine if the
frequency band is correct.
3. Check whether the indoor and outdoor antenna is installed correctly
4. At the location where the outdoor is installed, if your mobile phone is
able to receive a stable 2 bars cell phone signal, If not, find a location
where the mobile phone can receive a better signal to install the outdoor
antenna.
Booster has
effect ,but the
effect is not ideal
Check if your outdoor signal is very weak. If you can only receive one or
two bars cell phone signal in the outdoor.
If so, contact our customer service and ask to replace the booster or
antenna with a higher gain alternative.
Mobile phone
can receive full
signal, but can
not normally
make a call
It Usually means that the booster is self-oscillated, please make the
distance between the indoor and outdoor antenna as far as possible, it is
better to use a wall or metal to Separate the indoor antenna and the out
door antenna.
During using your Booster, if the Booster interferes with your radio or other electronic
device, move the Booster further away from those devices, you might be able to solve it
yourself.
If necessary，please contact your local dealer or send e-mail to our support team by the
following methods:
E-mail: [e-mail]
If you want to know about ANNTLENT Company and products for more information,
please visit at: www.ANNTLENT.com
Consumer booster warning label:


7/9

Asubscriber must have the consent of a wireless provider to operate a Consumer Signal
Booster. Subscribers may obtain provider consent in a variety of ways. For example,
AT&T, Sprint, T–Mobile, and Verizon Wireless have voluntarily committed to allow their
subscribers to use properly certificated Consumer Signal Boosters (i.e., boosters that
meet the new rules) on their networks. Also, a signal booster manufacturer could seek
authorization for use of a particular booster model on behalf of all subscribers of
individual providers. Alternatively, a provider may specify a testing protocol that if
satisfied would result in licensee consent to specific booster models. A subscriber may
also seek a licensee’s express consent to operate a signal booster, e.g., by phone call or
e-mail
The following selected information about wireless providers’ Consumer Booster
registration mechanisms supplements the requirements and information，and the FCC
Signal Boosters website (http://wireless.fcc.gov/signal-boosters/).
Sprint Nexte l will allow consumers to register their signal boosters by calling their
toll-free number. They have already trained their calling center and have designated an
engineer to handle inquiries. They may eventually allow consumers to register on their
website but they want to gauge how the process works via phone first.
●T-Mobile online registration link: (www.T-Mobile.com/BoosterRegistration);
(https://saqat.t-mobile.com/sites/SignalBooster#).


8/9

●Verizon’s online registration link:
(http://www.verizonwireless.com/wcms/consumer/register-signal-booster.html).
●AT&T will allow online registration and will inform OET Lab with the weblink when it is
ready.
●U.S.Cellular :
(http://www.uscellular.com/uscellular/support/fcc-booster-registration.jsp).
WARRANTY
Warranty information applicable to your Booster
Warranty Period: 2 year.
Type of Warranty Service: Customer Replaceable Unit and Customer Carry-In or
Mail-In Service.
ANNTLENT Company is not responsible for Shipping Cost.
For Warranty service consult the telephone list at www.ANNTLENT-tech.com/contact us.
What this Warranty Covers
ANNTLENT warrants that each Machine 1) is free from defects in materials and
workmanship and 2) conforms to ANNTLENT's Official Published Specifications which
are available on request.
The warranty period for the Machine starts on the original date of installation. The date
on your invoice or sales receipt is the date of installation unless ANNTLENT or your
reseller informs you.
This warranty does not cover the following:
Failure resulting from misuse, accident, modification, unsuitable physical or operating
environment, or improper maintenance by you;
The warranty is voided by removal or alteration of identification labels on the Machine or
its parts.
Copyright Information


9/9

© 2020 Copyright ANNTLENT Technology (Shenzhen) Co., Ltd.
The information contained in this document is subject to change without notice.
Edition 5, 6/2020
