User Manual
AtlonA
HDMI 1.4 OVER SINGLE CAT5/6/7
EXTENDER
WITH BI-DIRECTIONAL IR and
RS232 TRANSMITTER & RECEIVER
AT-HD4-100SR

www.atlona.com | toll free: 1-877-536-3976
For International: 1-408-962-0515 2
TABLE OF CONTENTS
1. Introduction .................................................. 3
2. Package Contents .................................................. 3
3. Features .................................................. 3
.................................................. 4
5. Panel Descriptions .................................................. 4
5.1. Transmitting Module .................................................. 4
5.1.1. Front Panel .................................................. 4
5.1.2. Rear Panel .................................................. 5
5.2. Receiving Module .................................................. 5
5.2.1. Front Panel .................................................. 5
5.2.2. Rear Panel .................................................. 4
6. Installation .................................................. 6
7. Note .................................................. 6
8. RS-232 Wiring Diagram .................................................. 6
9. Troubleshooting .................................................. 7
10. Atlona Product Registration .................................................. 7
11. Safety Information .................................................. 8
12. Warranty .................................................. 9

www.atlona.com | toll free: 1-877-536-3976
For International: 1-408-962-0515 3
INTRODUCTION:
The HDMI over Cat5/6/7 Extender kit is designed to be HDMI 1.4 compatible, enabling the transfer of high quality
extender allows for audio/video transmission up to a distance of 330ft in 1080p HD (even 2k/4k resolutions and
3D format).
Because the AT-HD4-100SR is HDMI 1.4 compatible it allows you to take full advantage of the new technology
by supporting much higher resolutions than 1080p or 1440p including 2k (2048x1080p) and 4k (4096×3072)
resolutions. Additionally the device supports an Ethernet data channel, allowing other HDMI 1.4 enabled devices
to share a network connection for internet connectivity. Furthermore, the audio return channel which will send
the audio signal back from the display to a receiver or other audio device.
Since the AT-HD4-100SR has bi-directional IR, it is the perfect device for multi-room applications and third party
control systems. With bi-directional communication from a remote control or control system, commands can be
sent from the remote location back to the main equipment center or the other way around.
Note: The maximum usable distance depends on the quality and characteristics of the cables. Higher resolutions
and longer transmission distances require low skew cables (<25ns/100m) for the best performance. Unshielded
Cat6/7 with metal RJ-45 connectors and 568-B termination is recommended.
PACKAGE CONTENTS:
• HDMI Transmitter x 1
• HDMI Receiver x 1
• 5V Switching Power Supply x 2
• User’s Manual x 1
FEATURES:
• Compatible with HDMI 1.4, DVI 1.0 and HDCP 1.2
• Full HD and 3D support
• Umcompressed video 1080p@ 50/60Hz, 2k (2048x1080p) and 4k (4096×3072) resolutions
• Supports high resolution video: 480i, 480p, 720p, 1080i, 1080p, 2k (2048x1080p) and 4k (4096×3072)
• Enables 10.2Gbps of HDMI 1.4 (including HDCP) over 330ft Cat5/6/7 cable.
•Audio: Dolby TrueHD & DTS Master Audio 7.1 compliant
• Supports Refresh Rates: 24Hz, 30Hz, 60Hz
• Supports Bi-directional IR transmission (38Khz only)
• LED indicators for operation modes
• Supports transmission distances up to 330ft @ 1080p 50/60Hz
• Easy to install, simple to operate and the most effective solution for long signal extension.
• Ideal for whole house a/v, video broadcasting, remote monitoring, presentations and educational facilities.

www.atlona.com | toll free: 1-877-536-3976
For International: 1-408-962-0515 4
HDMI Version 1.4
HDMI Connector 19 pin type female connector
HDMI Source Input Port 1
HDMI Sink Output Port 1
Source Port Connector Standard 19 pin HDMI
Display Device Port Connector Standard 19 pin HDMI
Link Connector RJ-45 Shielded
HDCP Compliant Yes
LED Indicators 3
Input TMDS signal 1.2 volts (peak-to-peak)
Input DDC signal 5 volts (peak-to-peak)
Resolution 1080p / 1920x1200 / 2k (2048x1080p) and 4k (4096×3072)
Deep Color 24-48 bits
Video Bandwidth Up to 10.2GHz
Vertical Frequency Range 50 ~60 Hz
Audio Performance PCM (7.1ch), Dolby Digital, True HD, DTS-HD & Master Audio
Lip Sync Correction Yes
3D enabled Yes
Power Consumption (max.) 15 Watts
Operation Temperature 0°C to 70°C.
Power Supply 5V 2A (universal)
Housing Metal
Dimension (in) 7 x 4.45 x 1
Weight (lb) 2.2
SPECIFICATIONS:
PANELDESCRIPTIONS:
5.1. Transmitting Module
5.1.1. Front Panel
1. IR Eye
2. HDCP Indicator
3. Activity Indicator
4. Power Indicator
1 2 3 4

www.atlona.com | toll free: 1-877-536-3976
For International: 1-408-962-0515 5
5.1.2. Rear Panel
5.2. Receiving Module
5.2.1. Front Panel
1. RS-232 Jack 5. HDMI Output
2. DC 5V Power Jack 6. IR Receiver
3. RJ45 Jack 7. IR Transmitter
4. HDMI Input (local loop)
1. IR Eye
2. HDCP Indicator
3. Activity Indicator
4. Power Indicator
5.2.2. Rear Panel
1. RS-232 Jack
2. DC 5V Power Jack
3. RJ45 Jack
4. HDMI Output
5. IR Transmitter
6. IR Receiver
1 2 3 4 5 6 7
1 2 3 4
1 2 3 4 5 6

www.atlona.com | toll free: 1-877-536-3976
For International: 1-408-962-0515 6
INSTALLATION
NOTE:
RS-232 WIRING DIAGRAM
How to connect / set up:
1. Connect your HDMI source (eg., Blu-ray, HD set top box, DVD Player) to the transmitter.
2. Connect your HDMI Display (eg., Plasma or LCD HDTV) to the receiver.
3. Use Cat5/5e/6 cables to link the transmitter and the receiver.
4. Make sure that the source, the transmitter, the receiver and the displays are all properly connected.
5. Plug in the DC Power adapters to the power jack of the transmitter and the receiver.
Since the AT-HD4-100SR has bi-directional IR, it is the perfect device for multi-room applications and third
party control systems. With bi-directional IR, commands from a remote control or control system can be sent
from the remote location back to the main equipment center or the other way around. This is useful for ap-
plications where the user may still be using the factory remote controls for their products and those IR signals
need to be routed to another room where the components are located. This also allows for the use of 3rd party
remote control systems where the IR information needs to be sent from the component location to the remote
location to control devices in that location such as the display.
Note: If TX/RX (transmit & receive) are mistakenly connected in the wrong connections, the IR eye can get
damaged.
Note: Please only use IR Emitter/Blasters which are included in the package. If you are using any 3rd party IR
Emitters/Blasters, they have to be able to handle up to 60KHz
RS232 male connector looking towards the camera
3.5 mm stereo plug
ring
ring-2
tip
tip-3
sleeve
sleeve-5

www.atlona.com | toll free: 1-877-536-3976
For International: 1-408-962-0515 7
TROUBLESHOOTING
Problems Solutions
Loop-Out doesn’t work Please make sure the display connected to the loop-out can support the
same resolutions as remote display. If not, please lower the resolution of
the source to one acceptable by both displays.
No picture/signal or poor Please test CAT5/6/7 cable and make sure it is 568B
Performance Guide for HDMI over LAN Cable Transmission
Performance rating Type of LAN cable
Wiring Shielding CAT5 CAT5e CAT6
Solid Unshielded (UTP) *** **** *****
Shielded (STP) *** *** ****
Stranded Unshielded (UTP) * ** **
Shielded (STP) * * **
Termination Please use EIA/TIA-568-B termination (T568B) at any time
ATLONA PRODUCT REGISTRATION
Thank you for purchasing this Atlona product — we hope you’ll enjoy it.
We also hope that you’ll take a few moments to register your new purchase. Registration creates an ownership
updates.
At Atlona, we respect and protect your privacy and assure you that your registration information is completely
secure. Of course, Atlona product registration is totally voluntary and failure to register will not diminish your limited war-
ranty rights.
To register go to www.atlona.com/registration

www.atlona.com | toll free: 1-877-536-3976
For International: 1-408-962-0515 8
SAFETY INFORMATION:
Safeguards
To reduce the risk of electric shock, do not
expose this product to rain or moisture.
power socket, hire an electrician to replace
your obsolete socket.
Do not modify the wall plug.
Doing so will void the warranty and safety
features.
This equipment should be installed near
the socket outlet and the device should
be easily accessible in case it requires
disconnection.
Precautions
FCC Regulations state that any
this equipment not expressly approved by
the manufacturer could void the
user’s authority to operate this
equipment.
Operate this product using only the
included external power supply. Use of
other power supplies could impair
performance, damage the product or cause
In the event of an electrostatic discharge,
this device may automatically turn off. If this
occurs, unplug the device, and plug it back
in.
Protect and route power cords so they will
not be stepped on or pinched by anything
placed on or against them. Be especially
careful of plug-ins, or cord exit points from
this product.
Avoid excessive humidity, sudden
temperature changes or temperature
extremes.
Keep this product away from wet locations
such as bathtubs, sinks, laundries, wet
basements and swimming pools.
Use only accessories recommended by
hazards.
Unplug the product before cleaning. Use
a damp cloth for cleaning. Do not use
electrical shock. Some substances may
Never open or remove unit panels or make
any adjustments not described in this
manual. Attempting to do so could expose
you to dangerous electrical shock or other
hazards. It may also cause damage to your
AT-HD4-100SR. Opening the product will
void the warranty.
Do not attempt to service the unit. Instead
disconnect it and contact your Authorized
ATLONA reseller or contact ATLONA
directly.

www.atlona.com | toll free: 1-877-536-3976
For International: 1-408-962-0515 9
1. LIMITED WARRANTY
Atlona Technologies warrants that (a) its products (the “Product”) will perform substantially in accordance with the ac-
companying written materials for a period of 3 YEARS from the date of receipt and (b) that the Product will be free from
defects in materials and workmanship under normal use and service for a period of 3 years. In the event applicable law
imposes any implied warranties, the implied warranty period is limited to 3 years from the date of receipt. Some jurisdic-
tions do not allow such limitations on duration of an implied warranty, so the above limitation may not apply to Customer.
2. CUSTOMER REMEDIES
Atlona Technologies and its suppliers’ entire liability and Customer’s exclusive remedy shall be, at Atlona Technologies’
option, either return of the price paid for the Product, or repair or replacement of the Product that does not meet this
Limited Warranty and which is returned to Atlona Technologies with a copy of Customer’s receipt. This Limited Warranty
is void if failure of the Product has resulted from accident, abuse, or misapplication. Any replacement Product will be war-
ranted for the remainder of the original warranty period or 3 year, whichever is longer.
3. NO OTHER WARRANTIES
TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, ATLONA TECHNOLOGIES AND ITS SUPPLIERS
DISCLAIM ALL OTHER WARRANTIES, EITHER EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED TO IM-
PLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE, WITH REGARD TO
THE PRODUCT AND ANY RELATED WRITTEN MATERIALS. THIS LIMITED WARRANTY GIVES CUSTOMER SPE-
CIFIC LEGAL RIGHTS. CUSTOMER MAY HAVE OTHER RIGHTS DEPENDING ON THE JURISDICTION.
4. NO LIABILITY FOR DAMAGES
TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, IN NO EVENT SHALL ATLONA TECHNOLOGIES OR
ITS SUPPLIERS BE LIABLE FOR ANY DAMAGES WHATSOEVER (INCLUDING WITHOUT LIMITATION, SPECIAL, IN-
CIDENTAL, CONSEQUENTIAL, OR INDIRECT DAMAGES FOR PERSONALINJURY, LOSS OF BUSINESS PROFITS,
BUSINESS INTERRUPTION, LOSS OF BUSINESS INFORMATION, OR ANY OTHER PECUNIARY LOSS) ARISING
OUT OF THE USE OF OR INABILITY TO USE THIS PRODUCT, EVEN IF ATLONA TECHNOLOGIES HAS BEEN AD-
VISED OF THE POSSIBILITY OF SUCH DAMAGES. IN ANY CASE, ATLONA TECHNOLOGIES’ AND ITS SUPPLIERS’
ENTIRE LIABILITY UNDER ANY PROVISION OF THIS AGREEMENT SHALL BE LIMITED TO THE AMOUNT ACTU-
ALLY PAID BY YOU FOR THE PRODUCT. BECAUSE SOME JURISDICTIONS DO NOT ALLOW THE EXCLUSION OR
LIMITATION OF LIABILITY FOR CONSEQUENTIALOR INCIDENTALDAMAGES, THE ABOVE LIMITATION MAY NOT
APPLY TO YOU.
