Anova L1440A User manual

anovafurnishings.com
888.535.5005 tel
ASSEMBLY INSTRUCTIONS
L1440A 4  Latitude Bench
L1441A 6  Latitude Bench
Model No. L1441P
Segmented Seating
TOOLS NEEDED:
9/16” Open-end or Box-end Wrench•
1/2” Open-end or Box-end Wrench•
5/8” Open-end or Box-end Wrench•
Ratchet with 1/2” Socket•
Ratchet with 9/16” Socket•
Ratchet with 5/8” Socket•
3/16” Allen Wrench•
Level•
ASSEMBLY HARDWARE:
8 x
5/16”
Washer
4 x
5/16”
Flanged Hex Nut
4 x
5/16” X 1.25”
Hex Head Bolt
ASSEMBLY:
The assembly is a two-person operation.
1. Inspect the shipping container contents for damage and to determine that all components and hardware are present.
2. Place the Bench Seat on the shipping packaging or
other so surface to avoid scratching the product.
Note: Before assembling the Nuts to the Bolts, it is
recommended that a light oil or petroleum jelly be
applied to the screw threads
3. Align the mounting holes in one of the Bench Legs
with the holes in the appropriate end of the Bench Seat
support. Insert one of the provided 3/8” Bolts, with a
Washer, through both parts, with the Bolt head on the
outside surface of the Bench Seat support. Install a
Washer and Nut on the inside end of the Bolt.
Leave the hardware nger tight so that adjustments
can be made later to level the Bench Seat.
Install a Bolt with Washer through the other mounting
hole in that Bench Leg and Bench Seat Support and
add a Washer and Nut to the end of the Bolt. Again,
leave the hardware nger tight.
4. Repeat this for the other Bench Leg. Leave the
hardware nger tight so adjustments can be made to
level the Bench Seat.
Model L1440A shown.
BENCH COMPONENTS:
1 x Bench Seat 2 x Bench Legs
2 x Cross Braces
2 x Arm Rests
8 x
3/8”
Washer
4 x
3/8”
Flanged Hex Nut
4 x
3/8” X 1.5”
Hex Head Bolt
Model No. L1441P
Segmented Seating
Bench Leg
Bench Seat
Support
Washer
3/8” Bolt Washer
Nut
Shipping cardboard
and plastic or other
so surface
8 x
5/16”
Breakaway Nut
8 x
5/16” X 1.0”
Socket Head Bolt
16 x
5/16”
Washer

Do not drag the assembled unit across any surface.•
This product requires only periodic cleaning with a sponge and a solution of mild detergent and water to•
remove surface dirt. Do not clean with a solvent or petroleum based products.
Furniture must not be used other than for its intended purpose and should be inspected regularly for loose,•
missing, or broken hardware, and general instability.
Furniture that is damaged or appears to be unstable must be removed from service and be repaired or replaced.•
Repairs must be made using only factory authorized parts and methods.•
WARNING
CARE AND
MAINTENANCE
211 North Lindbergh Blvd.
St. Louis, MO 63141
tel: [phone]
web: anovafurnishings.com
11/2012
Model No. L1441P
Segmented Seating
The feet of the Bench Legs feature a
.40” diameter mounting hole for
surface mount applications using customer
supplied surface mount hardware.
Model No. L1441P
Segmented Seating
Model No. L1441P
Segmented Seating
Model No. L1441P
Segmented Seating
Bench Leg
Cross Brace
Nut
Washer
Washer
5/16” Bolt
Bench Seat
Arm Rest
Breakaway
Nut
Washer
Washer
5/16” Socket
Head Bolt
Model No. L1441P
Segmented Seating
5. Attach the Cross Braces between the Bench
Legs and the Bench Seat supports using the
5/16” Hex Head Bolts and Nuts with a Washer
on each side as shown.
6. Aer the Leg Ends and Cross Braces have been
attached to the Bench Seat, turn the bench
upright and tighten all hardware while checking
with the level.
7. Attach the Arm Rests using the 5/16”
Socket Head Bolts with Washers and
Breakaway Nuts as shown. Orient the
Breakaway Nut so the cone shape is
toward the Washer. Do not tighten the
Nut; leave room to allow for adjustments.
Aer all the fasteners have been installed
in the Arm Rests, torque the Nuts until the
hex head breaks o.
8. Retighten all hardware two weeks aer
initial assembly.
