Anritsu MT1810A User manual

Document No.: M-W2748AE-15.0
ANRITSU CORPORATION
MT1810A
4 Slot Chassis
Installation Guide
For safety and warning information, please read this
manual before attempting to use the equipment.
Keep this manual with the equipment.
15th Edition

ii
Safety Symbols
To prevent the risk of personal injury or loss related to equipment malfunction, Anritsu Corporation uses the
following safety symbols to indicate safety-related information. Ensure that you clearly understand the meanings of
the symbols BEFORE using the equipment. Some or all of the following symbols may be used on all Anritsu
equipment. In addition, there may be other labels attached to products that are not shown in the diagrams in this
manual.
Symbols used in manual
This indicates a very dangerous procedure that could result in serious injury or
death if not performed properly.
This indicates a hazardous procedure that could result in serious injury or death if
not performed properly.
This indicates a hazardous procedure or danger that could result in light-to-severe
injury, or loss related to equipment malfunction, if proper precautions are not taken.
Safety Symbols Used on Equipment and in Manual
The following safety symbols are used inside or on the equipment near operation locations to provide information
about safety items and operation precautions. Ensure that you clearly understand the meanings of the symbols and
take the necessary precautions BEFORE using the equipment.
This indicates a prohibited operation. The prohibited operation is indicated
symbolically in or near the barred circle.
This indicates an obligatory safety precaution. The obligatory operation is
indicated symbolically in or near the circle.
This indicates a warning or caution. The contents are indicated symbolically in or
near the triangle.
This indicates a note. The contents are described in the box.
These indicate that the marked part should be recycled.
MT1810A
4 Slot Chassis
Installation Guide
27 November 2006 (First Edition)
20 March 2015 (15th Edition)
Copyright © 2006-2015, ANRITSU CORPORATION.
All rights reserved. No part of this manual may be reproduced without the prior written permission of the
publisher.
The contents of this manual may be changed without prior notice.
Printed in Japan
DANGER
WARNING
CAUTION

For Safety
iii
WARNING
ALWAYS refer to the operation manual when working near locations
at which the alert mark shown on the left is attached. If the advice in
the operation manual is not followed, there is a risk of personal injury
or reduced equipment performance. The alert mark shown on the left
may also be used with other marks and descriptions to indicate other
dangers.
Overvoltage Category
This equipment complies with overvoltage category II defined in IEC
61010. DO NOT connect this equipment to the power supply of
overvoltage category III or IV.
Laser radiation warning
NEVER look directly into the cable connector on the equipment
nor into the end of a cable connected to the equipment. There is a
risk of injury if laser radiation enters the eye.
The Laser Safety label is attached to the equipment for safety use
as indicated in "Laser Safety" later in this section.
To ensure that the equipment is grounded, always use the supplied
3-pin power cord, and insert the plug into an outlet with a ground
terminal. If power is supplied without grounding the equipment, there
is a risk of receiving a severe or fatal electric shock or causing
damage to the internal components.
Only qualified service personnel with a knowledge of electrical fire and
shock hazards should service this equipment. This equipment cannot
be repaired by the operator. DO NOT attempt to remove the
equipment covers or unit covers or to disassemble internal
components. There are high-voltage parts in this equipment
presenting a risk of severe injury or fatal electric shock to untrained
personnel. In addition, there is a risk of damage to precision
components.
Repair
Electric Shock
Repair

For Safety
iv
WARNING
The performance-guarantee seal verifies the integrity of the equipment.
To ensure the continued integrity of the equipment, only Anritsu
service personnel, or service personnel of an Anritsu sales
representative, should break this seal to repair or calibrate the
equipment. Be careful not to break the seal by opening the
equipment or unit covers.If the performance-guarantee seal is
broken by you or a third party, the performance of the equipment
cannot be guaranteed.
This equipment should always be positioned in the correct manner. If
the cabinet is turned on its side, etc., it will be unstable and may be
damaged if it falls over as a result of receiving a slight mechanical
shock.
Always set up the equipment in a position where the power switch
can be reached without difficulty.
Falling Over
Calibration

For Safety
v
CAUTION
Always remove the main power cable from the power outlet before
cleaning dust around the power supply and fan.
Clean the power inlet regularly. If dust accumulates around the
power pins, there is a risk of fire.
Keep the cooling fan clean so that the ventilation holes are not
obstructed. If the ventilation is obstructed, the cabinet may
overheat and catch fire.
Use two or more people to lift and move this equipment, or use a
trolley. There is a risk of back injury, if this equipment is lifted by one
person.
Never input a signal of more than the indicated value between the
measured terminal and ground. Input of an excessive signal may
damage the equipment.
This instrument is designed for an industrial environment.
In a residential environment this instrument may cause radio
interference in which case the user may be required to take adequate
measures.
Exposure to corrosive gases such as hydrogen sulfide, sulfurous acid,
and hydrogen chloride will cause faults and failures.
Note that some organic solvents release corrosive gases.
Cleaning
Check Terminal
Use in a residential
environment
Use in Corrosive
Atmospheres

For Safety
vi
Class 1 indicates the danger degree of the laser radiation specified
below according to IEC 60825-1:2007.
Class 1: Lasers that are safe under reasonably foreseeable
conditions of operation, including the use of optical
instruments for intrabeam viewing.
CAUTION
Use of controls or adjustments or performance of procedures other than
those specified herein may result in hazardous radiation exposure.
The use of optical instruments with this product will increase eye
hazard.

For Safety
vii
The laser in this equipment is classified as Class 1 according to the IEC
60825-1:2007 standard.
Table 1 Laser Safety Classifications Based on IEC 60825-1:2007
Model Name
Recommended
Module Model
Name or Option
Model Name/Part
Name
Class
Max. Optical
Output Power
(mW)*1
Pulse Width
(s)/Rep-etition
Rate
Emitted Wave-
length (nm)
Beam
Divergence (deg)
Laser Aperture
MU181600A
G0174A
850 nm XFP module 1 0.78 CW 840-860 36.9 Figure
2, [1]
G0175A
1310 nm XFP module 1 0.8 CW 1290-1330 11.5
Figure
2, [1]
G0176A
1550 nm XFP module 1 1.58 CW 1530-1565 11.5 Figure
2, [1]
MU181601A
G0177A
850 nm SFP module 1 0.56 CW 830-860 36.9 Figure
3, [1]
G0178A
1310 nm SFP module 1 1.0 CW 1270-1360 11.5
Figure
3, [1]
G0179A
1550 nm SFP module 1 1.0 CW 1430-1590 11.5
Figure
3, [1]
MU181620A
Optionx01
1310nm Reference 1 5.0 CW 1290-1330 11.5
Figure
4, [1]
Optionx02
1550nm Reference 1 5.0 CW 1530-1565 11.5
Figure
4, [1]
Optionx03
1310nm/1550nm
Reference
1 5.0 CW
1290-1330
or
1530-1565*2
11.5 Figure
4, [1]
Optionx11
1310nm Stressed
Eye
1 5.0 CW 1290-1330 11.5
Figure
4, [1]
Optionx12
1550nm Stressed
Eye
1 5.0 CW 1530-1565 11.5
Figure
4, [1]
Optionx13
1310nm/1550nm
Stressed Eye
1 5.0 CW
1290-1330
or
1530-1565*2
11.5 Figure
4, [1]
*1: Indicates the possible optical output power when each and every
reasonably foreseeable single-fault condition is included.
*2: A light of either wavelength will be emitted.
Laser Safety

For Safety
viii
Table 2 Incorporated Laser Specification
Model Name
Recommended
Module Model
Name or Option
Model Name/Part
Name
Max. Optical
Output Power
(mW)*1
Pulse Width
(s)/Rep-etition
Rate
Emitted Wave-
length (nm)
Beam
Divergence (deg)
MU181600A
G0174A
850 nm XFP module 0.78 CW 840-860 36.9
G0175A
1310 nm XFP module 0.8 CW 1290-1330 11.5
G0176A
1550 nm XFP module 1.58 CW 1530-1565 11.5
MU181601A
G0177A
850 nm SFP module 0.56 CW 830-860 36.9
G0178A
1310 nm SFP module 1.0 CW 1270-1360 11.5
G0179A
1550 nm SFP module 1.0 CW 1430-1590 11.5
MU181620A
Optionx01
1310nm Reference 10.0 CW 1290-1330 11.5
Optionx02
1550nm Reference 10.0 CW 1530-1565 11.5
Optionx03
1310nm/1550nm
Reference
12.5 CW
1290-1330
or
1530-1565*2
11.5
Optionx11
1310nm Stressed
Eye
10.0 CW 1290-1330 11.5
Optionx12
1550nm Stressed
Eye
10.0 CW 1530-1565 11.5
Optionx13
1310nm/1550nm
Stressed Eye
12.5 CW
1290-1330
or
1530-1565*2
11.5
*1: Indicates the possible optical output power when each and every
reasonably foreseeable single-fault condition is included.
*2: A light of either wavelength will be emitted.

For Safety
ix
Table 3 Labels on Product
Type Label Affixed to: Model Name
1 Explanation Figure 1, A MT1810A
2 Certification Figure 1, B MT1810A
3 Identification Figure 1, C MT1810A
4 Explanation Figure 2, A
Figure 3, A
MU181600A
MU181601A
5 Explanation Figure 4, A MU181620A

For Safety
x
Laser Radiation Markings
Figure 1 MT1810A appearance
B
C
A

For Safety
xi
Laser Radiation Markings
A
[1]
Figure 2 Front Panel of MU181600A Module
A
[1]
Figure 3 Front Panel of MU181601A Module
A [1]
Figure 4 Front Panel of MU181620A Module
A
A

xii
Equipment Certificate
Anritsu Corporation certifies that this equipment was tested before shipment
using calibrated measuring instruments with direct traceability to public
testing organizations recognized by national research laboratories, including
the National Institute of Advanced Industrial Science and Technology, and
the National Institute of Information and Communications Technology, and
was found to meet the published specifications.
Anritsu Warranty
Anritsu Corporation will repair this equipment free-of-charge if a malfunction
occurs within one year after shipment due to a manufacturing fault.
However, software fixes will be made in accordance with the separate
Software End-User License Agreement. Moreover, Anritsu Corporation will
deem this warranty void when:
The fault is outside the scope of the warranty conditions separately
described in the operation manual.
The fault is due to mishandling, misuse, or unauthorized modification or
repair of the equipment by the customer.
The fault is due to severe usage clearly exceeding normal usage.
The fault is due to improper or insufficient maintenance by the customer.
The fault is due to natural disaster, including fire, wind, flooding,
earthquake, lightning strike, or volcanic ash, etc.
The fault is due to damage caused by acts of destruction, including civil
disturbance, riot, or war, etc.
The fault is due to explosion, accident, or breakdown of any other
machinery, facility, or plant, etc.
The fault is due to use of non-specified peripheral or applied equipment
or parts, or consumables, etc.
The fault is due to use of a non-specified power supply or in a
non-specified installation location.
The fault is due to use in unusual environments(Note).
The fault is due to activities or ingress of living organisms, such as
insects, spiders, fungus, pollen, or seeds.
In addition, this warranty is valid only for the original equipment purchaser. It
is not transferable if the equipment is resold.
Anritsu Corporation shall assume no liability for injury or financial loss of the
customer due to the use of or a failure to be able to use this equipment.

xiii
Note:
For the purpose of this Warranty, "unusual environments" means use:
In places of direct sunlight
In dusty places
Outdoors
In liquids, such as water, oil, or organic solvents, and medical fluids, or
places where these liquids may adhere
In salty air or in place chemically active gases (sulfur dioxide, hydrogen
sulfide, chlorine, ammonia, nitrogen dioxide, or hydrogen chloride etc.)
are present
In places where high-intensity static electric charges or electromagnetic
fields are present
In places where abnormal power voltages (high or low) or instantaneous
power failures occur
In places where condensation occurs
In the presence of lubricating oil mists
In places at an altitude of more than 2,000 m
In the presence of frequent vibration or mechanical shock, such as in
cars, ships, or airplanes
Anritsu Corporation Contact
In the event of this equipment malfunctions, contact an Anritsu Service and
Sales office. Contact information can be found on the last page of the printed
version of this manual, and is available in a separate file on the CD version.

xiv
Notes On Export Management
This product and its manuals may require an Export License/Approval by
the Government of the product's country of origin for re-export from you
r
country.
Before re-exporting the product or manuals, please contact us to confirm
whether they are export-controlled items or not.
When you dispose of export-controlled items, the products/manuals need
to be broken/shredded so as not to be unlawfully used for military purpose.
Notice
The following actions are strictly prohibited for all of the software
installed in this product or otherwise provided by Anritsu:
1. Copying, except for archival purposes.
2. Transferring to a third party separately from this product.
3.
A
nalyzing the incorporated software including but not limited to
modifying, decompiling, disassembling, and reverse engineering.

xv
Software End-User License Agreement (EULA)
Please read this Software End-User License Agreement (hereafter this EULA) carefully before using
(includes executing, copying, registering, etc.) this software (includes programs, databases, scenarios,
etc., used to operate, set, etc., Anritsu electronic equipment). By reading this EULA and using this
software, you are agreeing to be bound by the terms of its contents and Anritsu Corporation (hereafter
Anritsu) hereby grants you the right to use this Software with the Anritsu-specified equipment
(hereafter Equipment) for the purposes set out in this EULA.
1. Grant of License and Limitations
1. Regardless of whether this Software was
purchased from or provided free-of-charge by
Anritsu, you agree not to rent, lease, lend, or
otherwise distribute this Software to third
parties and further agree not to disassemble,
recompile, reverse engineer, modify, or create
derivative works of this Software.
2. You may make one copy of this Software for
backup purposes only.
3. You are not permitted to reverse engineer
this software.
4. This EULA allows you to install one copy of
this Software on one piece of Equipment.
2. Disclaimers
To the extent not prohibited by law, in no
event shall Anritsu be liable for personal
injury, or any incidental, special, indirect or
consequential damages whatsoever,
including, without limitation, damages for
loss of profits, loss of data, business
interruption or any other commercial
damages or losses, arising out of or related
to your use or inability to use this Software.
3. Limitation of Liability
a. If a fault (bug) is discovered in this Software,
preventing operation as described in the
operation manual or specifications whether
or not the customer uses this software as
described in the manual, Anritsu shall at its
own discretion, fix the bug, or exchange the
software, or suggest a workaround,
free-of-charge. However, notwithstanding
the above, the following items shall be
excluded from repair and warranty.
i) If this Software is deemed to be used for
purposes not described in the operation
manual or specifications.
ii) If this Software is used in conjunction with
other non-Anritsu-approved software.
iii) Recovery of lost or damaged data.
iv) If this Software or the Equipment has been
modified, repaired, or otherwise altered
without Anritsu's prior approval.
v) For any other reasons out of Anritsu's direct
control and responsibility, such as but not
limited to, natural disasters, software virus
infections, etc.
b. Expenses incurred for transport, hotel, daily
allowance, etc., for on-site repairs by Anritsu
engineers necessitated by the above faults
shall be borne by you.
c. The warranty period for faults listed in
article 3a above covered by this EULA shall
be either 6 months from the date of purchase
of this Software or 30 days after the date of
repair, whichever is longer.

xvi
4. Export Restrictions
You may not use or otherwise export or
re-export directly or indirectly this Software
except as authorized by Japanese and
United States law. In particular, this
software may not be exported or re-exported
(a) into any Japanese or US embargoed
countries or (b) to anyone on the Japanese or
US Treasury Department's list of Specially
Designated Nationals or the US Department
of Commerce Denied Persons List or Entity
List. By using this Software, you warrant
that you are not located in any such country
or on any such list. You also agree that you
will not use this Software for any purposes
prohibited by Japanese and US law,
including, without limitation, the
development, design and manufacture or
production of missiles or nuclear, chemical or
biological weapons of mass destruction.
5. Termination
Anritsu shall deem this EULA terminated if
you violate any conditions described herein.
This EULA shall also be terminated if the
conditions herein cannot be continued for
any good reason, such as violation of
copyrights, patents, or other laws and
ordinances.
6. Reparations
If Anritsu suffers any loss, financial or
otherwise, due to your violation of the terms
of this EULA, Anritsu shall have the right to
seek proportional damages from you.
7. Responsibility after Termination
Upon termination of this EULA in
accordance with item 5, you shall cease all
use of this Software immediately and shall
as directed by Anritsu either destroy or
return this Software and any backup copies,
full or partial, to Anritsu.
8. Dispute Resolution
If matters of dispute or items not covered by
this EULA arise, they shall be resolved by
negotiations in good faith between you and
Anritsu.
9. Court of Jurisdiction
This EULA shall be interpreted in
accordance with Japanese law and any
disputes that cannot be resolved by
negotiation described in Article 8 shall be
settled by the Japanese courts.

xvii
Crossed-out Wheeled Bin Symbol
Equipment marked with the Crossed-out Wheeled Bin Symbol complies with
council directive 2012/19/EC (the “WEEE Directive”) in European Union.
For Products placed on the EU market after August 13, 2005, please contact
your local Anritsu representative at the end of the product's useful life to
arrange disposal in accordance with your initial contract and the local law.

xviii
CE Conformity Marking
Anritsu affixes the CE conformity marking on the following product(s) in
accordance with the Council Directive 93/68/EEC to indicate that they
conform to the EMC and LVD directive of the European Union (EU).
CE marking
1. Product Model
Model: MT1810A 4 Slot Chassis
2. Applied Directive
EMC: Directive 2004/108/EC
LVD: Directive 2006/95/EC
3. Applied Standards
EMC: Emission: EN 61326-1: 2013 (Class A)
Immunity: EN 61326-1: 2013 (Table 2)
Performance Criteria*
IEC 61000-4-2 (ESD) B
IEC 61000-4-3 (EMF) A
IEC 61000-4-4 (Burst) B
IEC 61000-4-5 (Surge) B
IEC 61000-4-6 (CRF) A
IEC 61000-4-8 (RPFMF) A
IEC 61000-4-11 (V dip/short) B, C
*: Performance Criteria
A: The equipment shall continue to operate as intended
during and after the test. No degradation of
performance or loss of function is allowed below a
performance level specified by the manufacturer, when
the equipment is used as intended. The performance
level may be replaced by a permissible loss of
performance. If the minimum performance level or the
permissible performance loss is not specified by the
manufacturer, either of these may be derived from the
product description and documentation and what the
user may reasonably expect from the equipment if used
as intended.

xix
B: The equipment shall continue to operate as intended
after the test. No degradation of performance or loss of
function is allowed below a performance level specified
by the manufacturer, when the equipment is used as
intended. The performance level may be replaced by a
permissible loss of performance. During the test,
degradation of performance is however allowed. No
change of actual operating state or stored data is
allowed. If the minimum performance level or the
permissible performance loss is not specified by the
manufacturer, either of these may be derived from the
product description and documentation and what the
user may reasonably expect from the equipment if used
as intended.
C: Temporary loss of function is allowed, provided the
function is self-recoverable or can be restored by the
operation of the controls.
Harmonic current emissions:
EN 61000-3-2: 2006 +A1:2009 A2:2009
(Class A equipment)
LVD: EN 61010-1: 2010 (Pollution Degree 2)
4. Authorized representative
Name: Murray Coleman
Head of Customer Service EMEA
ANRITSU EMEA Ltd.
Address, city: 200 Capability Green, Luton
Bedfordshire, LU1 3LU
Country: United Kingdom

xx
C-Tick Conformity Marking
Anritsu affixes the C-Tick mark on the following product(s) in accordance
with the regulation to indicate that they conform to the EMC framework of
Australia/New Zealand.
C-Tick marking
1. Product Model
Model: MT1810A 4 Slot Chassis
2. Applied Standards
EMC: Emission: EN 61326-1: 2013 (Class A equipment)
