ANTIFERENCE CONEXER DMSD01B User manual

B
USER MANUAL

Congratulations on your purchase of the DMSD01B
This ‘state of the art’ product is an SD encoder. The video and audio can be taken from
CVBS inputs and compressed into MPEG 2 video and AAC or MPEG1-L2 audio. The output is
congured as DVB-T transport stream.
Standalone conguration is made easy through three tactile switches and ergonomic menus
To make the congurations of the DMSD01B is very simple as special DMSDiFace software is
available for you to download from our website:
www.antiference.co.uk/ product/dmsd01b-conexer-single-av-dvbtc-modulator/
CONTENTS
1 Safety considerations page 2
2 Installation page 3
3 Description of the di󰀨erent elements page 4
4 Setting Up the DMSD01B page 5
4.1 Quick Menu page 5
4.2 Advanced Menu page 6
The DVB-T settings menu page 6
The DVB-C settings menu page 6
The TS settings menu page 7
The Video & Audio settings menu page 8
5 Programming using a PC page 9
6 Technical specications page 9
7 Declaration of Conformity page 9
1. SAFETY CONSIDERATIONS
1.1. Connecting to the mains supply
This product has to be connected to the mains supply. If there is the slightest doubt concerning
the type of connection available on the installation, please contact your supplier of electricity.
Before carrying out maintenance operation or modication of the installation, the modulator
has to be disconnected.
N.B. Only use the supplied power adaptor.
1.2 Overvoltage
An overvoltage on the mains supply can cause short circuits or re. Never overload the power
lines.
2
DMSD01B

1.3. Liquids
This module should be protected from splashes. Please ensure that no containers containing
liquids are placed on this module. Be aware of other persons splashing liquids on the module.
1.4. Cleaning
Disconnect the module before cleaning. Use only a damp cloth and do not use solvents.
1.5. Ventilation
In order to assure an adequate air circulation and to prevent overheating, the ventilation
holes should not be obstructed. The module may not be installed in a hermetically sealed
environment. Other electronic products or heat producing items may not be placed upon or
near the module.
1.6. Accessories
The use of accessories not manufactured by the manufacturer can cause damage to the
module.
1.7. Installation of the module
The module must be installed in a place well protected from direct sunlight.
All measures have to be taken to avoid installation in humid or sunny places.
Do not install near heating elements or other devices producing heat.
Ensure that the module is placed at least 10 cm from other equipment which is susceptible
to electromagnetic radiation. Do not install the module on unstable items, a fall can cause
physical or material damage.
2. INSTALLATION
Please nd a typical connection and installation layout for the DMSD01B.
3
DMSD01B

4
3. DESCRIPTION OF THE DIFFERENT ELEMENTS
Cancel/Return/
Enter button
Digital Display
Backward/Up
button
Forward/Down
button
RF Output
RF Input
USB for PC connection CVBS input
5V/2A Power supply
DMSD01B

5
4. SETTING UP THE DMSD01B
The DMSD01B has a quick menu to allow for quick basic settings. For more detailed settings
an advance menu is also available
4.1. The Quick Menu
To enter the quick menu please press the following sequence of buttons:
When entered successfully, the quick menu becomes available, use the buttons to move
between the di󰀨erent menu options. Press and hold the to select that option and use
to change the value to that option. Changes are automatically saved.
DMSD01B

6
DMSD01B
4.2. The Advanced Menu
To enter the advanced menu please press the following sequence of button:
When entered successfully, the advanced menu becomes available, use the buttons to
move between the di󰀨erent menu options. Press and hold the to select that option and use
to change the value to that option. Changes are automatically saved.

7
DMSD01B

DMSD01B
8

6. TECHNICAL SPECIFICATIONS
7. DECLARATION OF CONFORMITY
We, ANTIFERENCE LIMITED herewith declare that the modulator CONEXER DMSD01B complies with all essential
requirements and any other applicable conditions set forth on directive 2014/30/EU.
According to the WEEE (Waste Electrical and Electronic Equipment) EU Directive, do not dispose of this product as household
waste or commercial waste. Waste Electrical and Electronic Equipment should be appropriately collected and recycled as
required by practices established for your country. For information on recycling of this product, please contact your local
authorities, your household waste disposal service or the shop where you purchased the product.
Date of issue: April 2023
Video input Input CVBS composite video RCA
Resolution modes 480p - 576p
Compression MPEG2-SD, MPEG2, H.264
Audio input Input CVBS composite audio stereo RCA’s
Audio bitrate 100...20 Mbit/s
Compression AAC-LC / MPEG1 - L2 – bitrate 128-320 Kb/s
DVB Processing Table insertion PAT, PMT, SDT, NIT
Conguration Channel/network name, SID, LCN, TSID, ONID, NID, versions, audio, video PIDs.
DVB-T output Output frequency / level 170-230 MHz + 470-862 MHz / > 80 dBμV
Constellation - FEC QPSK/16QAM/64QAM - 1/2, 2/3, 3/4, 5/6, 7/8
Guard interval 1/4, 1/8, 1/16, 1/32
Mode - MER - bandwidth 2K/8K - > 35 dB - 6/7/8 MHz
Power DC 2.1 mm connector +5V 2A
Consumption 10 Watts
Dimensions LxWxH 150x130x35mm
Weight 0.9kg
5. PROGRAMMING USING A PC
The settings of the DMSD01B can also
be changed using a PC. First, please
install the software DMSDiFace on your
PC. You can download this software from
our internet site www.antiference.co.uk.
After installing the software, connect
the DMSD01B using a USB cable (not
included) to your computer. Then launch
the program DMSDiFace. On the display
of the DMSD01B the message <USB>
appears, indicating that programming
is now performed through your PC. The
following window appears on your screen.
All the functions can now be edited and
modied using DMSDiFace.
DMSD01B
9
www.antiference.co.uk
