Anton/Bauer Interactive 2000 PowerCharger User manual

The power behind the best cameras capturing the best images in the world.sm
TM
FULLY READ ALL INSTRUCTIONS BEFORE USE
ATTACH BATTERY TO CAMERA
(1) Charge battery fully (see “CHARGING” section)
(2) Remove shoe mount from battery
(3) Attach shoe to bottom of camera – tighten securely
(4) Pull back on battery slide lock
(5) Attach battery to shoe mount on bottom of camera, release slide lock
(6) Connect faux battery end of camera cable to camera battery connection
(7) Connect ELIPZ connector end of camera cable to ELIPZ 10k battery
OPERATION OF BATTERY
The “blue” LED (battery at >7.2V)
generally indicates that the battery has
sufficient power to operate. The “yellow” LED (batter
y
<7.2V) generally indicates that the battery should be re-
charged before using. If neither LED is lit, the batter
y
should be placed on the charger and allowed to remain
there until the charger indicates a steady “green” LED.
IMPORTANT: Discharging the ELIPZ battery at loads
greater than 6 amps (approx. 42 watts) will decrease the
service life of the battery and will cause the internal batter
y
fuse to trip causing an interruption of power. If the batter
y
fuse opens due to excessive power drawn from the
battery, the battery fuse will automatically reset within a
few minutes after the load has been removed.
TRANSPORTATION NOTICE
–
lithium ion battery pack
The ELIPZ 10k battery is suitable for air travel as a non-hazardous article under the regulations of the International Air Transport
Association (IATA), the International Civil Aviation Organization (ICAO) and the United Nations (UN). The ELIPZ 10k battery
pack contains aggregate lithium equivalence not exceeding 8 grams. This quantity is in compliance with Section A45-2* of the
Hazardous Substance Standards of the IATA and ICAO and is thus suitable for air transport as a non-hazardous article.
® The worldwide standard
®
ELIPZ Battery specifications
Electrical:
Nominal Capacity: 10,500 mAH
Nominal Voltage: 7.2 Volts
Nominal Charging Time (with ELIPZ charger): 6-7 Hours
Rated Maximum Discharge Current: 6 Amperes
End of Discharge Voltage: 5.4 Volt
Environmental:
Operating Temperature Range:
Charging: 10ºC to 40ºC
Discharging: -20ºC to 60ºC
Storage Temperature Range:
Less than one month: -30ºC to 30ºC
Recommended long term storage temp: 10ºC
Physical:
Dimensions: 6.43 x 3.17 x 1.70 inches (16.3 x 8.0 x 4.3 cm)
Weight: Approx. 1.25 lbs (567 grams)

World Headquarters 14 Progress Drive, Shelton, CT U.S.A. Tel [phone] s[email protected]
Europe Eurode Business Center, Eurode-Park1, 6461KB Kerkrade, The Netherlands Tel [phone]
[email protected]
Singapore Office-Anton/Bauer 6 New Industrial Road, #02-02 Hoe Huat Ind. Bld., Singapore 536199 (65)2975784 Fax [phone]
www.antonbauer.com 7595-0303 Rev J
Charging Batter
y
(1) Remove ELIPZ cable from battery if attached to camera.
(2) Remove battery from camera.
(3) Attach charger to AC mains source (100-240 VAC 50-60 Hz). Blue LED should light on charger (If blue LED does not
light, check mains source).
(4) Attach ELIPZ connector from charger to battery.
(5) Red light on charger will begin to flash within 10 seconds. This means the battery is charging.
(6) Red light will go out (approximately 4 hours) and Green LED will flash. Battery is now at least 80% full.
(7) Green LED will glow steadily (approximately 6 hours) when battery has completed full charge cycle.
Note: If battery is not removed from charger for longer than 1 week, charger will automatically re-initiate charge program.
CAUTION: DO NOT OBSTRUCT VENTILATION TO CHARGER. DO NOT COVER DURING OPERATION.
The charger power supply cord plug and appliance coupler are relied upon as the disconnect devices and shall remain readily
accessible.
ELIPZ Charger specifications
Electrical:
Rated Input voltage: 100-240VAC
Rated Power: 30 watts
Line Input Frequency: 50-60Hz
Output Voltage: 8.4V
Output Current: 2.3A
Environmental:
Operating Temperature Range: 0ºC to 40ºC
Storage Temperature Range: -20ºC to 60ºC
Humidity: <80% relative humidity
Physical:
Size: Approximately 5.42 L x 3.10 W x 2.17 H
Weight: .85 lbs (385 grams)
