AOC LE32S1865 User manual

Servive Manual for LE32S1865
Product Specification sheet....Page 1-2
User Manuel Part...............Page 3-16
Fatory Mode Adjustment.........Page 17-19
Troubleshooting Procedure......Page 20-25
Software Upgrades..............Page 26-36
Main Board Circuit Diagram.....Page 37-45

LE32S1865/55 32S91F-DVB HD DLED Smart TV
Columbia
Size and backlight 32" DLED
Resolution HD 1366x768, Widescreen 16:9 Aspect Ratio
Refresh Rate 60Hz
Brightness 200~240cd/m2(max:240cd)
Dynamic Contrast Ratio ≥200,000:1
Response Time 8ms
Horizontal: 176 Degrees
Vertical: 176 Degrees
ATV System PAL+NTSC+SCEAM
DTV system DVB-T2
Sound system D/K,B/G,I,L/L'
Nicam Yes
Composite + L/R Auido 1*mini AV IN
Component + L/R Audio N/A
TV 1
HDMI 2
USB 2.0 2
PC Input Analog RGB (Dsub)
RJ-45 1
Buit-in Speakers 10 Watts Total*2
Headphone Output N/A
Line Output 1*audio out
Digital Audio Output (S/PDIF) N/A
Normal Input range Universal 100~240 VAC 50/60Hz (Internal)
Ambient Temperature 5 to 40 deg C
Consumption 55Watts ( Max.)
Standby power consumption ≤0.5W
Energy Efficiency Class A
Languages English(default)
multi-language optional
Picture Mode Vivid,Standard,Soft,Personal
Sound Mode Standard,Music,Cinema,Personal
Sleep Timer Off ,10 to 180 Min (10 min per adjust)
Chipset MSD6A628 T4C2(Android 4.4; 512MB DDR3 RAM+4G ROM)
Picture Enhancement 3D Comb Filter, 3D Color Management, Cross Color Reduction,MPEG Noise
Reduction, Montion Adaptive De-interlacer
Video playback PAL+NTSC+SCEAM
Music Support MP3、M4A(AAC)
Picture Support JPEG、BMP、PNG
Description
Region
Panel
TV System
Signal Input
Audio Output
Power
OSD Function
Viewing Angle
1

Containers AVI, MKV, H.264, MPEG-1, MPEG-2, MPEG-4,Motion JPEG
dat, mpg, mp4, mjpeg, ts,trp, mkv、avi
Screen adjustment format Widescreen, 4:3, Movie 16:9,Subtitle Zoom
Treble
Bass
AVL
Virtual Surround
Computer inputs up to 1920 x 1080 @ 60hz
(anything larger than display size will be reduced to HD format)
Video inputs 24,25,30,50,60Hz up to 1920x1080p
ID mental frame, Super slim, plastice wing base
Regulations /
Unit with stand 732*472*193mm
Unit without stand 732*430*73mm
Carton 835*514*140mm
Wall-mount 100*100mm
Product without Stand 3.88KG
Product with Stand 4KG
Product in Packaging 5.5KG
Loading Qty w/pallet 384pcs(20") /768pcs(40") / 864pcs(40"HIGH)
685417107285
Note: There are related wall-mount can be selected, specific dimension need further evaluation.
UPC code
Dimensions
(WxHxD)
Weight
Video support
Sound Enhancement
Features
2

3

4

5

6

7

8

9

10

11

12

13

14

15

16

Enter into factory menu by signal source+left-right-left-right
Level 1 menu Level 2 menu Level 3 menu Value ，note
Factory reset Factory reset initialization
EEPROM Settings
Aging mode
Preset
channel
power-up
mode
Secondary/Memory/
Direct
Mboot
upgrade
Are you sure
Upgrade ?
选项：confirm/Cancel Update Mboot
Main upgrade
Are you sure
Upgrade ?
Option：confirm and
Cancel
Update main procedure
Type in MAC
address
Data
debugging
ADC ADJUST
ADC adjustment
Source VGA(RGB),component(SD,H
D) choice
R-GAIN
The front-end gain adjustmentG-GAIN
B-GAIN
R-OFFSET
Clamp level adjustmentG-OFFSET
B-OFFSET
Phase phase
Auto Tune
White Balance
Color temperature adjustment
Color Temperature
R Gain White level adjustment
G Gain
B Gain
R Offset Black level adjustment
G Offset
B offset
Picture Mode Image pattern adjustment
Brightness Brightness
Constrast Contrast
Saturation Saturation
Hue hue
17

Sharpness Definition
Backlight Brightness
Test Pattern
Non_linear
Various curve adjustmentOSD_0
OSD_25
OSD_50
OSD_75
OSD_100
OverScan
Repetition rate adjustment
Source Various signal source
H size H adjustment
H position The center position of horizon
V size Field adjustment
V position The center position of field
PEQ
PEQ adjustment；
Fo：Setting the center
frequency point of the gain
frequency band
Fo1 coarse Range 0~16000，step is
100HZ
Fo1 fine Range 0~16000，step is 1HZ
Fo2 coarse Range 0~16000，step is
100HZ
Fo2 fine Range 0~16000，step is 1HZ
Fo3 coarse Range 0~16000，step is
100HZ
Fo3 fine Range 0~16000，step is 1HZ
Fo4 coarse
Fo4 fine
Fo5 coarse
Fo5 fine
Uart Enable （switch Uart）On/off
Uart Debug Debug tool can be used to read
COM port
EfficiencyBk
EfficiencyBk_Max
AVC
CEC/ARC
Other
Screen model
18

PQ
Software
version
Barcode code
19
