AOC LE32M1570 User manual

Service Manual
LE32M1570
(32L82F-DVB)
Product Specification Sheet (P1-3)
User Manual part (P4-20)
Factory Mode(P21-22)
Software Upgrades (P23-24)
Troubleshooting Procedure (P25-29)
Circuit Diagrams (P30-37)

Product Specification Sheet
32" HD DLED DTV (32L82F-DVB)
Series name LE32M1570
Set Product Mana
g
er
Platform/Chipset T4C1-3463 DVB-T2
Processor type (CPU) / GPU
Picture/Display
RC TBC
Backlight Type (Panel Supplier) DLED
Diagonal Screen Size 31.5"
Perfect Motion Rate
Panel Frequency (Native) 60HZ
Chasis Frequency 60HZ
Backlight Dimming PWM
Scanning Segments (amount) 48.25--863.25MHZ
Panel Resolution 1366*768
Aspect ratio 16:9
Brightness (Home Vivid Mode) cd/m² Min:200cd/m2， Typ:240cd/m2
Panel contrast ratio 1200:1
Viewing Angle - H (L+R) 178°
Viewing Angle - V 178°
Response Time (ms) 8ms
Analog + PWM dimming YES
2D/3D Logic (2D/3D Active/3D Passive ) 2D
Color Gamut NTSC 65%
PQ engine Digital Crystal Clear
Supported Display Resolution (Computer Inputs) 720*400@70HZ
640*480@60HZ
800*600@60HZ
1024*768@60HZ
1360*768@60HZ
Supported Display Resolution (Video Inputs) 480i, 480p,576i, 576p,720p,1080i,1080p(24/25/30/50/60Hz)(anything
larger than display size will be reduced to HD format)
Brightness (Shop Vivid mode: 10% boost) YES(1% boost)
Sound (TV)
Sound (Internal)
Output Power (10% THD) RMS 12W
Speaker configuration 6W+6W
Speaker system 2.0
Speaker type built-in(normal)
Auto Volume Levelier / Auto Volume Levelier + YES
Sound Claim (Incredible Surround/Cinema Surround/Clear
Sound/AmbiwOOx/3D Movie/Incredible Surround 3D)
N/A
Bass (Bass control/DBE/Ultra Bass/Ultra Bass II ) N/A
Wireless Sound Interface N/A
Dolby Digital DecoderType YES
DTS Studio Sound N/A
DTS 2.0+ Digital out N/A
Acoustic Compensation Filters N/A
Dynamic Treble Enhancement N/A
Programmable Bass And Treble Curve N/A
Visible Sound N/A
Sound (External)
External Sound device type N/A
Output Power (10% THD) RMS N/A
Design Specs
Stand type (Swivel/non Swivel) Metal Bridge
1

I/O port to be clearly indicated TV*1/USB*1/VGA*1
/HDMI*2/YPBPR*1/AV-IN*1/Earphone*1
Local Keyboard YES
Philips wordmark AOC
Leading Edge #7
Vesa Wall Mount Compatible YES
Compatible Wall Mount 100mm×100mm
Connectivity (I/O)
HDMI Number HDMI1.4(*2)
HDMI 1.4a HDMI(Under-out)
HDMI 2.0 N/A
HDMI/DVI YES
HDMI ARC HDMI-2
EasyLink (HDMI-CEC) YES
Scart (EU) Connections N/A
YPbPr/CVI (EU/Latam) Connections N/A
CVBS (EU/Latam) Connections *1
Audio L/R in *1
CI+ slots N/A
Antenna *1
Satellite (for K&S only) N/A
USB USB2.0(*1)
USB Harddisk Format (Power) FAT/NTFS (500mA)
VGA YES
VGA/DVI Audio Input share AV audio input
Digital audio out (SPDIF) N/A
Headphone *1
Ethernet-LAN RJ-45 N/A
Service Connector VGA connectable
MHL (HDMI+power+return channel) YES
UI & Interaction
Ux (Basic: without Dashboard, Advanced: with
Dashboard)
Basic
Text Entry (Basic : Text Entry via HID and/or On-screen
Keyboard)
Basic
Multi-view N/A
Multi-task N/A
Screen Format Adjustments 4:3,16:9,film,PC Mode(HDMI)
Dual Screen (TV and TeleText) N/A
Teletext YES
8 Days Electronic Program Guide YES
Live Setting Assistant (include PQ level) N/A
Signal Strength Indication YES
Pause TV/USB recording (PVR) YES
Two simultaneous recordings in stdby N/A
UI Languages English， Malaysia, Indonesian, Thai, Vietnamese,Chinese
Memory Profile (DRAM) 128M
Menu Layout Update N/A
Wizards (Ease of Installation) N/A
Single Sign On (google a/c only) N/A
Personalized Dashboard N/A
Face recognition N/A
Shopmode 2015 YES
CloudTV app content in search and Dashboard (on TV) N/A
Firmware Upgradeable YES
Multimedia Applications
Video Playback Formats MPEG-2/MPEG-4 /H.264
Subtitles Formats Support SRT、ASS
Music Playback Formats MP3，AAC
Picture Playback Formats JPEG、BMP、PNG
2

Broadcast/Certification
DVB-T/C N/A
DVB-S/S2 N/A
DVB-T/T2 YES
DVB-C2 N/A
SBTVD-T (Brazil) N/A
SATVD-T (Argentina) N/A
Analog (LATAM/APMEA) PAL SECAM
Sustainability/Power
PVC / BFR Free N/A
Mercury Free N/A
Cabinet Resin ABS
Eco-Flower Certified N/A
ECO Mode N/A
Mains Power AC 100-240V 50/60Hz
Standby Power <0.5W
Quick Startup NA
Network Standby mode (max 6W) NA
Off Mode Power <0.5W
On Mode Power (Consumption Power) 55W (max.)
Auto Switch-Off Timer YES
Green packaging (Non-EPS) YES
Accessory
Accessory Bag YES
Mains Cord (EU/UK/Brazil/APMEA ) YES
Remote Control + 2x Philips Batteries YES
Printed QSG YES
EDFU (APMEA) YES
Safety Legal Leaflet (EU) - 3D Health Advise and Ukraine
requirement
N/A
Philips Warranty Leaflet YES
Dimensions (WxHxD)
Unit with stand 730*472*193mm
Unit without stand 730*430*71mm
Carton 825*514*128
Wall-mount 100*100 mm
Weight
Product without Stand 3.7Kg
Product with Stand 4Kg
Product in Packaging 5Kg
3
