Service Manual
LE40M1571
(40L82F-DVB)
Product Specification Sheet (P1-3)
User Manual part (P4-21)
Factory Pattern Adjustment(P22-23)
Troubleshooting Procedure (P24-28)
Software Upgrades (After Service (P29-3 ))
Circuit Diagrams (P - )

Product Specification Sheet
40" FHD DLED DTV (40L82F-DVB)
Series name LE40M1571
Platform/Chipset T4C1-3463 DVB-T2
Processor type (CPU) / GPU
Picture/Display
RC TBC
Backlight Type (Panel Supplier) DLED
Diagonal Screen Size 39.5”
Perfect Motion Rate
Panel Frequency (Native) 60HZ
Chasis Frequency 60HZ
Backlight Dimming PWM
Scanning Segments (amount) 48.25--863.25MHZ
Panel Resolution 1920*1080
Aspect ratio 16:9
Brightness (Home Vivid Mode) cd/m² Min:180cd/m2,Typ:210cd/m2
(LCM:Min:220cd/m2,Typ:260cd/m2)
Panel contrast ratio 5000:1
Viewing Angle - H (L+R) 176°
Viewing Angle - V 176°
Response Time (ms) 8.5ms
Analog + PWM dimming YES
2D/3D Logic (2D/3D Active/3D Passive ) 2D
Color Gamut NTSC 65%
PQ engine Digital Crystal Clear
Supported Display Resolution (Computer
Inputs)
720*400@70HZ
640*480@60HZ
800*600@60HZ
1024*768@60HZ
1360*768@60HZ
1280*720@60HZ
1280*960@60HZ
1280*1024@60HZ
1600*900@60HZ
1920*1080@60HZ
Supported Display Resolution (Video Inputs) 480i, 480p,576i,
576p,720p,1080i,1080p(24/25/30/50/60Hz)
Brightness (Shop Vivid mode: 10% boost) YES(1% boost)
Sound (TV)
1

Sound (Internal)
Output Power (10% THD) RMS 12W
Speaker configuration 6W+6W
Speaker system 2.0
Speaker type built-in(normal)
Auto Volume Levelier / Auto Volume Levelier + YES
Sound Claim (Incredible Surround/Cinema
Surround/Clear Sound/AmbiwOOx/3D
Movie/Incredible Surround 3D)
N/A
Bass (Bass control/DBE/Ultra Bass/Ultra Bass
II )
N/A
Wireless Sound Interface N/A
Dolby Digital DecoderType YES
Design Specs
Stand type (Swivel/non Swivel) Metal Bridge
I/O port to be clearly indicated TV*1/USB*1/VGA*1
/HDMI*2/YPBPR*1/AV-IN*1/Earphone*1
Local Keyboard YES
Philips wordmark logo AOC
Leading Edge #7
Vesa Wall Mount Compatible YES
Compatible Wall Mount 100mm×200mm
Connectivity (I/O)
HDMI Number HDMI1.4(*2)
HDMI 1.4a HDMI(Under-out)
HDMI 2.0 N/A
HDMI/DVI YES
HDMI ARC HDMI-2
EasyLink (HDMI-CEC) YES
CVBS (EU/Latam) Connections *1
Audio L/R in *1
CI+ slots N/A
Antenna *1
USB USB2.0(*1)
USB Harddisk Format (Power) FAT/NTFS (500mA)
VGA YES
VGA/DVI Audio Input share AV audio input
Digital audio out (SPDIF) N/A
Headphone *1
Ethernet-LAN RJ-45 N/A
Service Connector VGA connectable
HDCP v2.2 (on HDMI 2.0 port) N/A
MHL (HDMI+power+return channel) YES
UI & Interaction
Ux (Basic: without Dashboard, Advanced: with
Dashboard)
Basic
Text Entry (Basic : Text Entry via HID and/or
On-screen Keyboard)
Basic
Screen Format Adjustments 4:3,16:9,film,PC Mode(HDMI)
Dual Screen (TV and TeleText) N/A
Teletext YES
8 Days Electronic Program Guide YES
Live Setting Assistant (include PQ level) N/A
2

Signal Strength Indication YES
Pause TV/USB recording (PVR) YES
UI Languages English， Malaysia, Indonesian, Thai,
Vietnamese,Chinese
Memory Profile (DRAM) 128M
Shopmode 2015 YES
CloudTV app content in search and Dashboard
(on TV)
N/A
Firmware Upgradeable YES
Multimedia Applications
Video Playback Formats MPEG-2/MPEG-4 /H.264
Subtitles Formats Support SRT、ASS
Music Playback Formats MP3，AAC
Picture Playback Formats JPEG、BMP、PNG
Broadcast/Certification
DVB-T/T2 YES
DVB-C2 N/A
Analog (LATAM/APMEA) PAL SECAM
Sustainability/Power
Cabinet Resin ABS
Mains Power AC 100-240V 50/60Hz
Standby Power <0.5W
Off Mode Power <0.5W
On Mode Power (Consumption Power) 75W (max.)
Auto Switch-Off Timer YES
Green packaging (Non-EPS) YES
Accessory
Accessory Bag YES
Mains Cord (EU/UK/Brazil/APMEA ) YES
Remote Control + 2x Philips Batteries YES
Printed QSG YES
EDFU (APMEA) YES
Safety Legal Leaflet (EU) - 3D Health Advise
and Ukraine requirement
N/A
Philips Warranty Leaflet YES
Optional accessories
Dimensions (WxHxD)
Unit with stand 904x569x227mm
Unit without stand 904x521x82mm
Carton 1015x622x150mm
Wall-mount 100mm×200mm
Weight
Product without Stand 6.2Kg
Product with Stand 6.5Kg
Product in Packaging 8.5Kg
