AOC 1619Sw User manual

1619Sw
1619Sw
Cabinet Color
All Glossy Black
Panel TFT Active Matrix LCD
16" Widescreen, Diagonal
VIS: 15.6" Widescreen , Diagonal
Hard Coating, Anti-glare Treatment
Pixel Pitch
0.252mm (H)x0.252mm(V)
Pixel Pitch
0.252mm (H)x0.252mm(V)
Display Area 344.2mmx193.5mm
Brightness 250 cd/m2 (typ)
Contrast Ratio 1500:1 (DCR)
Response Time 8ms (typ)
Viewing Angle Horizontal: 90 Degrees (CR>10)
Vertical: 45 Degrees (CR>10)
Compatibility
VESA VGA,XGA,SVGA,WXGA
Compatibility
VESA VGA,XGA,SVGA,WXGA
Mac® Equipped With Analog VGA Dsub
Scanning Frequency Horizontal: 30K~60KHz
Vertical: 50~75 Hz
Pixel Frequency 85MHz
Maximum Resolution
Recommended Resolution
Resolutions Supported
1366x768@60Hz
1366x768@60Hz
640x350@70,640x480@60/72/75,720x400@70,
Resolutions Supported
640x350@70,640x480@60/72/75,720x400@70,
800x600@60/75,832x624@74.5,1280x720@60,1360x768@60
Color 16.7 Million
Signal Input Video: 0.7Vp-p, RGB Analog
Separate Sync: TTL Level
H/V Sync: Positive / Negative
Connectors RGB Signal: 15-pin D-sub
(3-Pin Plug CEE22)
(3-Pin Plug CEE22)
Power Source Universal 100~240VAC, 50/60Hz,
Power Consumption 28W Max
Plug & Play DDC 1/2B/CI
EPA ENERGY STAR® Yes
User Control
AUTO, Left, Right, Menu, Power
OSD Function Brightness, Contrast, Eco Mode,Gammar,DCR,H/V Position, Phase,
Clock, Color Temperature, Color Boost,Picture Boost, OSD
Clock, Color Temperature, Color Boost,Picture Boost, OSD
Language Selection, Timeout, Menu Position, Auto Config, DDC-CI,
Reset, Information
Language Supported English, Spanish, French, Portoguese, German, Russian, Italian,
Simple Chinese
Compliance
CCC/cUL/FCC/CE/TUV-S/EPA,Windows Vista
Other Features
VESA 75mm Wall Mountable*, Aesthetic iconic OSD, 5-scene
Dynamic Color Boost
Other Features
Dynamic Color Boost
Dimensions (WxHxD mm) 376x304x190mm
Dimensions (WxHxD inches) 14.8x12.0x7.5in
Carton (WxHxD inches) 17.2x11.9x4.6in
Weight 5.94 Lbs (2.7kgs) Net
8.14 Lbs (3.7kgs) Gross
Loading Qty w/pallet 20' = 1632 pcs.; 40' Std = 3536 pcs.
UPC Code
685417019380
UPC Code
685417019380
Note: Specifications are subject to change without notice. *Wall mount arm & bracket not included.
Windows Vista and the Windows logo are trademarks or registered trademarks of Microsoft Corporation in the United States and/or other countries. A01/08
