AOC 2236VW User manual

2236Vw
2236Vw
Cabinet Color Piano-black Glossy Finish
Panel
TFT Active Matrix LCD
Panel
TFT Active Matrix LCD
22" Class Widescreen, 16:9 Aspect Ratio
21.5" Viewable Image Size, Diagonal
Pixel Pitch 0.248 x 0.248mm
Display Area 476.6mm x 268.1mm
Brightness 300 cd/m2 (typ)
Contrast Ratio 60,000:1 (dynamic)
Response Time
5ms (typical)
Response Time
5ms (typical)
Viewing Angle Horizontal: 170 Degrees (CR>10)
Vertical: 160 Degrees (CR>10)
Scanning Frequency Horizontal: 30K~80KHz
Vertical: 55~75 Hz
Pixel Frequency 148.5MHz
Maximum Resolution
Recommended Resolution
1920x1080x60Hz
1920x1080@60Hz
Recommended Resolution
1920x1080@60Hz
Supported Resolutions
640x480@60/67/72/75Hz, 720x400@70Hz, 800x600@56/60/72/75Hz,
1024x768@60/70/72/75Hz, 1280x1024@60/75Hz,
1440x900@60/75Hz, 1680x1050@60Hz, 1920x1080@60Hz
Color 16.7M
Signal Input Analog: 0.7Vp-p(standard), 75 OHM, Positive
Digital Input DVI-D with HDCP*
Connectors Analog RGB Signal: 15-pin D-sub Male
Digital Signal: 24-pin DVI-D
Power Source Universal 100~240VAC, 50/60Hz
Power Consumption 35Watts ( Max. )
Plug & Play DDC/2B, DDC/CI
User Control
Menu, Up, Down, Power
User Control
Menu, Up, Down, Power
OSD Languages 15 Languages including English, French and Spanish
Regulations cULus, FCC, CE, TUV/S, ROHS, Certified for Windows Vista Logo,
EPEAT Gold
Other Features Touch Sensitive Controls, USB Pass-thru, User Friendly Graphical
OSD Menu, VESA 100mm Wall Mount Compliant**, Kensington
Security Slot, includes AOC proprietory i-Menu software OSD
Dimensions (WxHxD mm)
Monitor: 582x425x206, Carton: 590x391x131
Dimensions (WxHxD mm)
Monitor: 582x425x206, Carton: 590x391x131
Dimensions (WxHxD inches) Monitor: 22.9x16.7x8.1, Carton: 23.2x15.4x5.2
Weight 10.12 lbs (4.6 kgs) Net
14.30 lbs (6.5 kgs) Gross
Loading Qty w/pallet 20' = 810 pcs.; 40' Std = 1800 pcs.
UPC Code 685417024384
Note: Specifications are subject to change without notice. *High-bandwidth Digital Content Protection: Enables viewing of High-Definition contents. **Wall mount
arm & bracket not included. Windows Vista and the Windows logo are trademarks or registered trademarks of Microsoft Corporation in the United States and/or
arm & bracket not included. Windows Vista and the Windows logo are trademarks or registered trademarks of Microsoft Corporation in the United States and/or
other countries. A02/09
