717Vwx
717Vwx
Cabinet Color
All Glossy Black
Panel TFT Active Matrix LCD
VIS: 17"wide , Diagonal
Hard Coating, Anti-glare Treatment
Pixel Pitch 0.255mm x 0.255mm
Display Area
367.2mm x 229.5mm
Display Area
367.2mm x 229.5mm
Brightness 250 cd/m2 (typ)
Contrast Ratio 5000:1 (DCR)
Response Time 5ms (typ)
Viewing Angle Horizontal: 160 Degrees (CR>10)
Vertical: 160 Degrees (CR>10)
Compatibility VESA VGA,XGA,SVGA, SXGA,WXGA+
Mac® Equipped With Analog VGA Dsub
Mac® Equipped With Analog VGA Dsub
Scanning Frequency Horizontal: 31K~75KHz
Vertical: 55~75 Hz
Pixel Frequency 135MHz
Maximum Resolution
Recommended Resolution
Resolutions Supported
1440x900@60Hz
1440x900@60Hz
640x400@70Hz, 640x480@60/72/75Hz, 720x400@70Hz,
800x600@56/60/72/75Hz, 832x624@75Hz,
800x600@56/60/72/75Hz, 832x624@75Hz,
1024x768@60/70/75Hz, 1280x960@60Hz, 1280x1024@60/75Hz,
1440x900@60/75Hz
Color 16.2 Million
Signal Input Video: 0.7Vp-p, RGB Analog
Separate Sync: TTL Level
H/V Sync: Positive / Negative
Connectors RGB Signal: 15-pin D-sub
(3-Pin Plug CEE22)
Power Source Universal 100~240VAC, 50/60Hz,
Power Consumption 37W Max
Plug & Play DDC 1/2B/CI
EPA ENERGY STAR® Yes
User Control
Eco/Up, Auto/Down, Contrat/Left, DCR/Right, Menu/Power
OSD Function Brightness, Contrast, Eco Mode, Gamma, DCR, H/V Position,
Phase, Clock, Color Temperature, Color Boost, Picture Boost, OSD
Phase, Clock, Color Temperature, Color Boost, Picture Boost, OSD
Setup (H/V Position, Timeout, Transparency, Language Selection),
Auto Config, DDC-CI, Reset, Information, Exit
Language Supported English/French/German/Spanish/Italian/Portuguese/Russian/Simplif
ied Chinese
Compliance
cULus, FCC, CE, TUV-S, Works with Windows Vista Logo
Other Features
VESA 100mm Wall Mountable*, 5-scene Dynamic Color Boost,
Navigation Key
Other Features
Navigation Key
Dimensions (WxHxD mm) 400x337x210mm
Dimensions (WxHxD inches) 15.7x13.3x8.3in
Carton (WxHxD mm/inches) 454x378x132mm, 17.9x14.9x5.2in
Weight 7.04 lbs (3.2kgs) Net
11.0 Lbs (5.0kgs) Gross
Loading Qty w/pallet 20' = 1152 pcs.; 40' Std = 2496 pcs.
UPC Code
685417019281
UPC Code
685417019281
Note: Specifications are subject to change without notice. *Wall mount arm & bracket not included.
Windows Vista and the Windows logo are trademarks or registered trademarks of Microsoft Corporation in the United States and/or other countries. A04/08
