AOC E950SW User manual

e950Sw
Cabinet Color Piano-black Glossy Finish
Panel TFT Active Matrix LCD, WLED Backlight
19" Class, 16:9 Aspect Ratio
18.5" Viewable Image Size, Diagonal
Pixel Pitch 0.3 x 0.3mm
Display Area 409.8mm x 230.4mm
Brightness 250 cd/m2 (typ)
Contrast Ratio 20,000,000:1 (dynamic)
Response Time 5ms (typical)
Viewing Angle Horizontal: 170 Degrees (CR>10)
Vertical: 160 Degrees (CR>10)
Scanning Frequency Horizontal: 30K~60KHz
Vertical: 55~75 Hz
Pixel Frequency 85MHz
Maximum Resolution
Recommended Resolution
1366x768x60Hz
1366x768@60Hz
Supported Resolutions
640x480@60/67/72/75Hz, 800x600@56/60/72/75Hz,
1024x768@60/70/72/75Hz, 1360x768@60Hz, 1366x768@60Hz
Color 16.7M
Signal Input Analog: 0.7Vp-p(standard), 75 OHM, Positive
Connectors Analog RGB Signal: 15-pin D-sub Male
Power Source Universal 110~240VAC, 50/60Hz
Power Consumption On: <15 Watts, Standby: <0.5W
Plug & Play DDC/2B, DDC/CI
User Control Auto, Left, Right, Menu, Power
OSD Languages 15 Languages including English, French and Spanish
Regulations cCSAus, FCC, CE, TUV/S, ROHS, EPA 5.0, EPEAT Gold
Other Features
User Friendly Graphical OSD Menu, VESA 100mm Wall Mount
Compliant*, Kensington Security Slot, Direct-Insert Horizontal
Connectors
Dimensions (WxHxD mm) Monitor: 342x444x175, Carton: 496x346x117
Dimensions (WxHxD inches) Monitor: 13.5x17.5x6.9, Carton: 19.5x13.6x4.6
Weight 2Kg, 4.4 Lbs Net
2.5 Kg, 5.5 Lbs Gross
Loading Qty w/pallet 20' = 1280 pcs.; 40' Std = 2688 pcs.
UPC Code 685417036486
Note: Specifications are subject to change without notice. *Wall mount arm & bracket not included.
A01/11
