i2267Fw
Cabinet Color Black & Silver
Panel TFT Active Matrix LCD, WLED Backlight, IPS panel
22" Class Widescreen, 16:9 Aspect Ratio
21.5" Viewable Image Size, Diagonal
Pixel Pitch 0.248mm*0.248mm
Display Area 476.06mm（H）*267.78mm（V)
Brightness 250 cd/m2 (typ)
Contrast Ratio 50,000,000:1 (dynamic)
Response Time 5ms (typical)
Viewing Angle Horizontal: 178 Degrees (CR>10)
Vertical: 178 Degrees (CR>10)
Scanning Frequency Horizontal: 30K~83KHz
Vertical: 55~75 Hz
Pixel Frequency 148.5MHz
Maximum Resolution
Recommended Resolution
1920x1080@60Hz
1920x1080@60Hz
Supported Resolutions 640×480@60/67/72/75Hz 720×400@70Hz
800×600@56/60/72/75Hz 832×624@75Hz
1024×768@60/70/75Hz 1280×1024@60/75 Hz
1280x720@60Hz 1280x960@60Hz
1440x900@60Hz 1680x1050@60Hz
1920x1080@60Hz
Color 16.7M
Analog Input Analog: 0.7Vp-p(standard), 75 OHM, Positive
Digital Input DVI-D with HDCP*
Connectors Analog RGB Signal: 15-pin D-sub Male
Digital Signal: 24-pin DVI-D
Power Source Universal 110~240VAC, 50/60Hz
Power Consumption On: <45 Watts, Standby: <0.5W
Plug & Play DDC/2B, DDC/CI
User Control Menu, Up/Volume, Down/ECO, Auto/Source, Power
OSD Languages 16 Languages including English, French and Spanish
Regulations FCC, cCSAus, CE, EPA Energy Star, EPEAT Silver
Other Features Ultra Slim, Bezel-less, Detachable Multi-purpose Stand (Standard or
Photo Frame type), User Friendly OSD Menu, Includes AOC's e-
Saver, Screen+, and iMenu Software
Dimensions (WxHxD mm) Monitor: 498x375x121, Carton: 580x389x131
Dimensions (WxHxD inches) Monitor: 19.6x14.8x4.8, Carton: 22.8x15.3x5.2
Weight 3.5 Kg, 6.1 Lbs Net
5.2 Kg, 11.4 Lbs Gross
Loading Qty w/pallet 20' = 900 pcs.; 40' Std = 1890 pcs.
UPC Code 685417062188
Note: Specifications are subject to change without notice. *High-bandwidth Digital Content Protection: Enables viewing of High-Definition contents.
A01/13
