15.6"LCDColorMonitor AOCT16
Service
Service
Service
Horizontal Frequency
30-60 kHz
Table of Contents
Description Page Description Page
SAFETY NOTICE
ANY PERSON ATTEMPTING TO SERVICE THIS CHASSIS MUST FAMILIARIZE HIMSELF WITH THE CHASSIS
AND BE AWARE OF THE NECESSARY SAFETY PRECAUTIONS TO BE USED WHEN SERVICING
ELECTRONIC EQUIPMENT CONTAINING HIGH VOLTAGES.
Table of Contents.......……..............................……........1
Revision List.…........................................…………........2
Important Safety Notice.……............................……......3
1.Monitor Specification..............................………..........4
2.LCD Monitor Description……………………………......5
3.Operation Instruction…………...............……..............6
3.1.General Instructions...........................…...................6
3.2.Control Button…………….…..............……...............6
3.3.OSD Menu…………….…...........................…...........8
4.Input/Output Specification............……………............10
4.1.Input Signal Connector............………….................10
4.2.Factory Preset Display Modes…….........................10
4.3.Panel Specification.....………...…………................11
5.Block Diagram…….....................………….................13
5.1.Main Board…….…………...………………....….......13
5.2.Power Board……………..……………...….......14
6.Schematic……………........................................15
6.1.Main Board………...........................................15
6.2.Power Board...…….........................................20
6.3.Key Board...…….............................................21
7.PCB Layout..………….......................................22
7.1.Main Board………...........................................22
7.2.Power Board…...............................................26
7.3.Key Board…………….....................................28
8.Maintainability……….........................................29
8.1.Equipments and Tools Requirement...............29
8.2.Trouble Shooting…………..............................30
9.White-Balance, Luminance Adjustment.............34
10.Monitor Exploded View………..…….…............36
11.BOM List…………………………………............38
CAUTION: USE A SEPARATE ISOLATION TRANSFOMER FOR THIS UNIT WHEN SERVICING

2
Revision List
Version Release Date Revision History TPV Model Name
A00 Aug.9,2011 Initial release T6BMN32EW11UNN
A01 Dec.5,2011 Add new model T6BAN32EW11UNN

3
Important Safety Notice
Proper service and repair is important to the safe, reliable operation of all AOC Company Equipment. The service
procedures recommended by AOC and described in this service manual are effective methods of performing service
operations. Some of these service operations require the use of tools specially designed for the purpose. The
special tools should be used when and as recommended.
It is important to note that this manual contains various CAUTIONS and NOTICES which should be carefully read in
order to minimize the risk of personal injury to service personnel. The possibility exists that improper service
methods may damage the equipment. It is also important to understand that these CAUTIONS and NOTICES ARE
NOT EXHAUSTIVE. AOC could not possibly know, evaluate and advise the service trade of all conceivable ways in
which service might be done or of the possible hazardous consequences of each way. Consequently, AOC has not
undertaken any such broad evaluation. Accordingly, a servicer who uses a service procedure or tool which is not
recommended by AOC must first satisfy himself thoroughly that neither his safety nor the safe operation of the
equipment will be jeopardized by the service method selected.
Hereafter throughout this manual, AOC Company will be referred to as AOC.
WARNING
Use of substitute replacement parts, which do not have the same, specified safety characteristics may create shock,
fire, or other hazards.
Under no circumstances should the original design be modified or altered without written permission from AOC.
AOC assumes no liability, express or implied, arising out of any unauthorized modification of design.
Servicer assumes all liability.
FOR PRODUCTS CONTAINING LASER:
DANGER-Invisible laser radiation when open AVOID DIRECT EXPOSURE TO BEAM.
CAUTION-Use of controls or adjustments or performance of procedures other than those specified herein may
result in hazardous radiation exposure.
CAUTION -The use of optical instruments with this product will increase eye hazard.
TO ENSURE THE CONTINUED RELIABILITY OF THIS PRODUCT, USE ONLY ORIGINAL MANUFACTURER'S
REPLACEMENT PARTS, WHICH ARE LISTED WITH THEIR PART NUMBERS IN THE PARTS LIST SECTION OF
THIS SERVICE MANUAL.
Take care during handling the LCD module with backlight unit
-Must mount the module using mounting holes arranged in four corners.
-Do not press on the panel, edge of the frame strongly or electric shock as this will result in damage to the screen.
-Do not scratch or press on the panel with any sharp objects, such as pencil or pen as this may result in damage to
the panel.
-Protect the module from the ESD as it may damage the electronic circuit (C-MOS).
-Make certain that treatment person’s body is grounded through wristband.
-Do not leave the module in high temperature and in areas of high humidity for a long time.
-Avoid contact with water as it may a short circuit within the module.
-If the surface of panel becomes dirty, please wipe it off with a soft material. (Cleaning with a dirty or rough cloth may
damage the panel.)

4
1. Monitor Specifications
Driving system TFT Color LCD
LCD Panel Size 395mm
Pixel pitch 0.252mm( H )x 0.252mm( V )
Video R,G,B Analog Interface
Input Separate Sync. H/V TTL
H-Frequency 30kHz – 60kHz
V-Frequency 60Hz
Display Colors 16.7M Colors
Dot Clock 85.5MHz(typ)
Max. Resolution 1366x 768@60HZ
Plug & Play VESA DDC2BTM
Power consumption ON Mode ≤18W
OFF Mode ≤1W
Input Connector D-Sub 15pin
Input Video Signal Analog:0.7Vp-p(standard), 75 OHM, Positive
Maximum Screen Size Horizontal :344.3mm
Vertical :193.5mm
Power Source 100-240VAC,50/60Hz
Environmental Considerations
Operating Temp: 0° to 40°C
Storage Temp.: -20° to 60°C
Operating Humidity: 10% to 85%
Weight (N. W.) 1.7kg
Dimensions 373.0 (W) x 301.2 (H) x 139.6(D)mm
Switch
•Auto Adjust Key / Exit
•-/ECO
•+/Image Ratio
•MENU / ENTER
•Power Button
External Controls: Functions
•Contrast
•Brightness
•ECO
•DCR
•Focus
•Clock
•Image Ratio
•OSD location & Time
•Language
•Warm
•Normal
•Cool
•sRGB
•User Color temperature
•DDC/CI
•Information
•Reset
•Exit
Regulatory Compliance FCC,CE

5
2. LCD Monitor Description
The LCD monitor will contain a main board, a power board and a key board which house the flat panel control logic,
brightness control logic and DDC.
The power board will provide AC to DC Inverter voltage to drive the backlight of panel and the main board chips
each voltage.
Monitor Block Diagram
Video signal, DDC
Adapter Board
Flat Panel and
LED backlight
Main Board
RS232 Connector
For white balance
adjustment in
factory mode
HOST Computer
LED Drive.
AC-IN
100V~240V
Key board

6
3. Operating Instructions
3.1 General Instructions
Press the power button to turn the monitor on or off. The other control buttons are located at front panel of the
monitor. By changing these settings, the picture can be adjusted to your personal preferences.
•The power cord should be connected.
•Connect the Signal cable from the monitor to the VGA card.
•Press the power button to turn on the monitor position. The power indicator will light up.
3.2 Control Buttons
1. Auto Config / Exit
2. -/ ECO
3. +/ Image Ratio
4. MENU / ENTER
5. Power Button
FRONT PANEL CONTROL
•Power Button /Power Indicator:
Press this button to switch ON/OFF of monitor’s power.
Blue — Power On mode.
Orange — Power saving mode.
•MENU / ENTER:
Active OSD menu or function adjust confirm or Exit OSD menu when in volume OSD status.
•- /ECO:
Activates the ECO control when the OSD is OFF or navigate through adjustment icons when OSD is ON or adjust
a function when function is activated.

7
•+ /Image Ratio:
Activates the Imagic Ratio control when the OSD is OFF or navigate through adjustment icons when OSD is ON
or adjust a function when function is activated.
•Auto Adjust button / Exit:
1. When OSD menu is in active status, this button will act as EXIT-KEY (EXIT OSD menu).
2. When OSD menu is in off status, press this button to activate the Auto Adjustment function.
The Auto Adjustment function is used to optimize the HPos, VPos, Clock and Focus.
•OSD Lock Function:
To lock the OSD, press and hold the MENU button while the monitor is off and then press power button to turn the
monitor on. To un-lock the OSD - press and hold the MENU button while the monitor is off and then press power
button to turn the monitor on.
NOTES:
•Do not install the monitor in a location near heat sources such as radiators or air dusts, or in a place subject to
direct sunlight, or excessive dust or mechanical vibration or shock.
•Save the original shipping box and packing materials, as they will come in handy if you ever have to ship your
monitor.
•For maximum protection, repackage your monitor as it was originally packed at the factory.
•To maintain the cleanness of your LCD display, wipe it periodically with clean and soft cloth. The screen may be
damaged by any liquid splash.
•To keep the monitor looking new, periodically clean it with a soft cloth. Stubborn stains may be removed with a
cloth lightly dampened with a mild detergent solution. Never use strong solvents such as thinner, benzene, or
abrasive cleaners, since these will damage the cabinet. As a safety precaution, always unplug the monitor before
cleaning it.

8
3.3 OSD Menu
1. Press the MENU-button to activate the OSD window.
2. Press + or - to navigate through the functions. Once the desired function is highlighted, press the MENU-button
to activate it. If the function selected has a sub-menu, press + or - again to navigate through the sub-menu
functions. Once the desired function is highlighted, press MENU-button to activate it.
3. Press + or - to change the settings of the selected function.
4. To exit and save, select the exit function. If you want to adjust any other function, repeat steps 2-3.
The OSD Message
ADJUSTING THE PICTURE
The descriptions for function control
Main Menu Item Main Menu Icon Sub Menu Item Sub Menu Description
Luminance
Brightness Backlight Adjustment
Contrast Contrast from Digital-register.
Eco
Standard Standard Mode
Text Text Mode
Internet Internet Mode
Game Game Mode
Movie Movie Mode
Sports Sports Mode
DCR
Off Disable dynamic contrast ratio
On Enable dynamic contrast ratio
Image Setup
Clock
Adjust Picture Clock to reduce Vertical-Line
noise.
Focus
Adjust Picture Phase to reduce Horizontal-Line
noise
H.Position Adjust the horizontal position of the picture.
V.Position Adjust the vertical position of the picture.
Image Ratio Full/4:3

9
Main Menu Item Main Menu Icon Sub Menu Item Sub Menu Description
Color Temp.
Warm Recall Warm Color Temperature from EEPROM.
Normal Recall Normal Color Temperature from EEPROM.
Cool Recall Cool Color Temperature from EEPROM.
sRGB Recall SRGB Color Temperature from EEPROM.
User
User-B Blue Gain from Digital-register
User-G Green Gain Digital-register.
User-R Red Gain from Digital-register
Color Boost
Full Enhance on or off Disable or Enable Full Enhance Mode
Nature Skin on or off Disable or Enable Nature Skin Mode
Green Field on or off Disable or Enable Green Field Mode
Sky-blue on or off Disable or Enable Sky-blue Mode
AutoDetect on or off Disable or Enable AutoDetect Mode
Demo on or off Disable or Enable Demo
Main Menu Item Main Menu Icon Sub Menu Item Sub Menu Description
Picture Boost
Frame Size Adjust Frame Size
Brightness Adjust Frame Brightness
Contrast Adjust Frame Contrast
H.Position Adjust the horizontal position of Frame
V.Position Adjust the vertical position of Frame
Bright Frame on or off Disable or Enable Bright Frame
OSD Setup
H.Position Adjust the horizontal position of OSD
V.Position Adjust the vertical position of OSD
Timeout Adjust the OSD Timeout
Language Select the OSD language
Extra
DDC/CI Turn ON/OFF DDC/CI Support
Reset Reset the menu to default
Information Show the information of the main image and
sub-image source

10
4. Input/Output Specification
4.1 Input Signal Connector
15
610
11 15
PIN NO. Description PIN NO. Description
1. Red 9. +5V
2. Green 10. Ground
3. Blue 11. Ground
4. Ground 12. DDC-Serial Data
5. VGA-CON 13. H-Sync
6. R-Ground 14. V-Sync
7. G-Ground 15. DDC-Serial Clock
8. B-Ground
4.2 Factory Preset Display Modes
Standard Resolution Horizontal Frequency (kHz) Vertical Frequancy (Hz)
VGA
720 x 400 31.47 70.0
640 × 480 31.47 60.0
WXGA
1360 × 768 47.712 60.0
1366 × 768 47.712 60.0
XGA 1024 × 768 48.363 60.0
XGA 800 × 600 37.879 60.0

11
4.3 Panel Specification
4.3.1 General Features
N156B6-L0B is a 15.6″(15.547″diagonal) TFT Liquid Crystal Display module with LED Backlight unit and 40 pins
LVDS interface. This module supports 1366 x 768 HD mode and can display 262,144 colors. The optimum viewing
angle is at 6 o’clock direction.
4.3.2 Display Characteristics
4.3.3 Electrical Characteristics
1. TFT LCD MODULE
2. BACKLIGHT UNIT

12
4.3.4 Optical Characteristics
1. TEST CONDITIONS
2. OPTICAL SPECIFICATIONS

13
5. Block Diagram
5.1 Main Board
Panel Interface
(CN409)
Key Control Interface
(CN402)
Flash Memory
Pm25LD020C-SCE
(U402)
Crystal
12MHZ
(X401)
Scaler NT68620FG/B
(Include MCU, ADC, OSD)
(U401)
D-Sub Connector
(CN101)
RGB
H sync
V sync
DDC1_SCL
DDC1_SD
A
EEPROM
CAT24C02WI
(U101)

14
5.2 Power Board
EMI filter
Start Resistor
(R920,R921,R922)
PWM Control
(IC901)
Transformer
AC input
14.5V
Bridge
Rectifier
and Filter
Feedback
Circuit
Rectifier
diodes
Photo coupler
(IC902)
5V

15
6. Schematic
6.1 Main Board
715G4870M01000004L
VGA_5V
U101
CAT24C02WI -GT3
1
2
3
45
6
7
8A0
A1
A2
VSSSDA
SCL
WP
VCC
C182
22pF 50V
R0-
BIN0-
CN 101 D-SU B 15P
1
6
2
7
3
8
4
9
5
11
12
13
14
15
10
17 16
DDCSCL1
SOG_DET 5
GIN 0-
R101
100R 1/16W 5%
R114 4K7 1/16W 5%
C108
47N16V
+5V
C102
47N16V
C114
10N 50V
R126
2K2 1/16W 5%
U103
AZC399-04S
1
2
3 4
5
6
I/O1
GND
I/ O2 I/O3
VDD
I/O4
C113
10N 50V
VGA_5V
ESD_VGA
R108
100R 1/16W 5%
G0- 5
R102 100R 1/16W 5%
BIN0
C101
220N16V
R118
0R05 1/16W
R109
0R05 1/16W
RIN0-
DET_VGA
VSIN0
DD C SDA_A
DDCSDA_A
R106
100R 1/16W 5%
ESD_VGA
C109
5PF 50V
R113
100R 1/16W 5%
B
B
15Wednes day , April 27, 2011
715G4870-M0C-000-0040-2D-SUB I/O
715G4870-M0C-000-0040-1-110321
OEM MODEL Size
Rev
Date Sheet of
TPV MOD EL
PCB NAME
称爹
T P V ( Top Victory Electronics Co . , Lt d. )
Key Component
絬 隔 瓜 絪 腹
ZD 101
RLZ5.6B
HSIN0
BIN0-
GIN 0
BIN0
C103
5PF 50V
VSIN0
R0- 5
R142
470R 1/16W 5%
VGA_5V
C110
47N16V
HSIN0
RIN0
C104
47N16V
DDCSCL_A
B0-
HSIN0
RIN0
C111
NC/22pF 50V
DDCSCL15
+5V4,5, 7
VSIN0
R115 4K7 1/16W 5% R116 22K 1/16W 5%
R122 0R05 1/ 10W
DDCSDA_A
C106
5PF 50V
DDCSCL1
B0+ 5
BIN0
R107
75R 1/16W 1%
GIN 0
DDCSCL_A
R112
75R 1/16W 1%
R124 100R 1/16W 5%
R105
100R 1/16W 5%
R104
0R05 1/16W B0+
C105 47N 16V
EDI D _W P
R0+ 5
RIN0-
RIN0
G0-
EDID_WP5
HSIN0
C107
47N16V
DDCSCL_A DET_VGA
R119
100R 1/16W 5%
AHS0 5
RIN0
R103
0R05 1/16W
VGA_5V
C112
NC/22pF 50V
CN103
NC/DB15
1
6
2
7
3
8
4
9
5
11
12
13
14
15
10
17 16
R110
0R05 1/16W
DDCSDA1
DD C SDA15
U102
AZC399-04S
1
2
3 4
5
6
I/O1
GND
I/O2 I/O3
VDD
I/O4
D101
BAV70
3
1 2
R117
0R05 1/ 16W
GIN 0
DDCSDA1
GIN 0-
GIN0-
R125
2K2 1/16W 5%
C181
22pF 50V
AVS0 5
ESD_VGA
R0+
VSIN0
BIN0-
R120
75R 1/16W 1%
RIN0-
VGA_CABLE_DET
R121
100R 1/16W 5%
G0+ 5
R123 100R 1/16W 5%
GIN0
B0- 5
C120
1N50V
DET_VGA VGA_CABLE_DET 5
G0+
BIN0
R111
100R 1/16W 5%

16
R131 NC/4K7 1/16W 5%
R140 NC/10R 1/16W 5%
U106
NC/AZC399-04S
1
2
3 4
5
6
I/O1
GND
I/O2 I/O3
VDD
I/O4
DCLK-
HPD
C119
NC/10N 50V
R129 NC/100R 1/16W 5%
DVI_CABLE_DET 5
DET_DVI DVI5V
ESD_DVI
R128 NC/100R 1/16W 5%
C115
NC/10N 50V
RX0+ 5
DDCSCL2 5
R130 NC/10K 1/16W 5%
DDCSDA2 5
ESD_DVI
DAT0-
EDID_WP 5
R137 NC/10R 1/16W 5%
RX0- 5
U105
NC/CAT24C02WI-GT3
1
2
3
45
6
7
8A0
A1
A2
VSSSDA
SCL
WP
VCC
+5V3,5,7
R141 NC/10R 1/16W 5%
ZD 102
NC/RLZ5.6B
R134 NC/10R 1/16W 5%
DVI5V
R135 NC/10R 1/16W 5%
C118
NC/10N 50V
Q101NC
DCLK+
ESD_DVI
DVI5V
RX2+ 5
RXC+ 5
CN102
NC/JACK
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
26 25
DAT2-
DAT2+
2/4shield
DAT4-
DAT4+
DDC SCL
DDC SDA
VSY N C
DAT1-
DAT1+
1/3shield
DAT3-
DAT3+
+5V
SYNC GND
HPD
DAT0-
DAT0+
0/5shield
DAT5-
DAT5+
clk shield
clk+
clk-
GND GND
DVI_HPD 5
SCL_DVI
DAT1+
DAT0+
R133 NC/22K 1/16W 5%
DAT1-
C117
NC/10N 50V
ESD_DVI
C116
NC/220N16V
DDC_WP
R127
NC/100R 1/16W 5%
R139 NC/10R 1/16W 5%
DAT2+
D102
NC/BAV70
3
1 2
U104
NC/AZC399-04S
1
2
3 4
5
6
I/O1
GND
I/O2 I/O3
VDD
I/O4
RXC- 5
B
B
25Wednesday , April 27, 2011
715G4870-M0C-000-0040-1DVI
715G4870-M0C-000-0040-1-110321
OEM MOD EL Si ze
Rev
Date Sheet of
TPV MODEL
PCB N AME
称爹
T P V ( Top Victory Electronics Co . , Ltd. )
Key Component
絬 隔 瓜 絪 腹
+5V
DAT2-
R138 NC/10R 1/16W 5% RX1- 5
SDA_DVI
U107
NC/AZC399-04S
1
2
3 4
5
6
I/O1
GND
I/O2 I/O3
VDD
I/O4
ESD_DVI
R132 NC/4K7 1/16W 5%
R136 NC/10R 1/16W 5%
ESD_DVI
RX1+ 5
RX2- 5

17
B0+
PA5*
P35*
Audio_EN
C424
10N 50V
SOG_DE T3
VCC3.3
PB3
R447 NC /100R 1/ 16W 5%
AVCC
VCC 1.8
SPI_SO
U402
Pm25LD020C-SCE
1
2
3
4
8
7
6
5
CE#
SO
WP#
GND
VDD
HOLD#
SCK
SI
RX2+
PB9
RESETB
Q402
LMBT3906LT1G
C411
MLVS0402M04
1 2
DVDD
OSC_VDD
G0-
RX2-
RXC+4
PWMC*
R406 0R 05 1/16 W
LPD_IN1*
PB4
C415
10N 50V
CN401
NC/8PIN
2
4
6
8
1
3
5
7
DDCSDA13
R440
NC /0R05 1/16W
VCC3.3
LVB0M
PA3*
R403 NC /2K2 1/16W 5%
R457
NC /0R05 1/10W
DDCSCL24
ADC2
R417
560OHM +-5% 1/ 10W
DVDD
TP2
P_SCL
PA3*
R486 NC
VGA_CABLE_DET3
G0+
LED_1
DVI_CABLE_DET4
LVBCKP
+5V
RX0+
POWER
PB4
C404
4.7UF 10V
C0805
R410
0R05 1/16W
C410
MLVS0402M04
1 2
RXC-4
PA1*
LED_A
FB405
300OHM
SPI_SI
R484
NC /4K7 1/ 16W 5%
C416
4.7UF 10V
C0805
PA5*
CABLE_DET
CVDD
LVB2P
DDCSDA2
LVB1P
TP4
TP-R-0.75
C426
22pF 50V
R483
NC /4K7 1/ 16W 5%
KEY2
C402
10N 50V
R0-
MSD A
VCC3.3
R452
NC
RX1+4
U403
NC/ M24C16
1
2
3
45
6
7
8A0
A1
A2
GNDSDA
SCL
WP
VCC
ADC1
ADC_VAA
LVB1M
P34*
LED_G
PB3
R424 1K 1/ 16W 5%
C437
NC
PB[2.. 9]6
P/SD A
CN410
NC/CONN
1
2
3
4
5
6
R437
NC/ 22K 1/16W 5%
CN405
NC/7PIN
1
2
3
4
5
6
7
VCC3.3
EE_WP
R434 100R 1/16W 5%
B0-3
LVB2M
R412
NC /0R05 1/16W
INTB(PWM)
R419
10K+-5%1/16W
LVB0P
PB5
R414
NC /0R05 1/16W
OSC_VD D
TOUCH_POWER
WP
DDCSCL1
R429
10K 1/16W 5%
R0+3
TXD*
MSC L
PC1*
RESETB
R416
220K 1/16W 5%
PB5
LED_A
C429
220N16V
CN402
CONN
1
2
3
4
5
6
PA4*
5V_DET_IN T
R402 NC /2K2 1/16W 5%
EDID_WP 3,4
PWMB*
C418
10N 50V
VCC3.3
RXC-
RX2+4
ADC3
+5V
VCC3.3
P/SDA
LVBCKM
SPI_CE
R408
470R 1/16W 1%
R401
3.9K1/16W
R431 100R 1/16W 5%
DDCSDA24
AVCC
PC5
LVB2M
TP1
P_SDS
ADC1
PA0*
LVBCKP
DDCSCL13
D401 NC /RLZ5.6B
C430
NC /220N 10V
C42010N 50V
D404
NC/RLZ5.6B
RX0+4
B0-
SPI_SO
CN403
NC/6PIN
1
2
3
4
5
6
+5V 3,4,7
PC4
SPI_CK
KEY 2
C428
22pF 50V
C417
10N 50V
R432
1MOHM 1/16W +/-5%
PC0*
R439
100R 1/16W 5%
RXD*
AHS03
PA0*
EE_WP
LED_G
X401
12MHz
1 2
RX1-4
5V_DET
PB2
R423
NC /7K5 1/ 16W 5%
AHS0
MSC L
INTB(PWM)
R444
10K 1/16W 5%
SOG_DET
PB6
EDI D_W P
FB406
NC /300OHM
1 2
C427
100NF 25V
MSD A
R442
NC /4K7 1/16W 5%
PA7*
WP
LVB1P
CN404
NC/CONN
1
2
3
4
5
6
7
VCC1.8 7
ADC3
AVCC
5V_DET
R451
NC
C453
NC
DVI_HPD 4
VGA_CABLE_DET
R455
NC /4K7 1/ 16W 5%
B
C
35Thursday , J une 30, 2011
715G4870-M0C-000-0040-2SCALER
715G4870-M0C-000-0040-1-110321
OE M MOD E L S ize
Rev
Date Sheet of
TPV MOD EL
PCB NAME
称爹
T P V ( Top Vict ory E lectronics Co . , Ltd. )
Key Componen t
絬 隔 瓜 絪 腹
VCC3.3
R0+
PB6
RX0-4
VCC3.3
DDCSCL2
DDCSDA1
POWER
Audio_DET
SPI_CK
R487 1K 1/ 16W 5%
C414
1uF 10V
C0402
C413
4.7UF 10V
C0805
+5V
C409100N 16V
B0+3
P/SCL
PB2
R436
NC /22K 1/ 16W 5%
Audio_DET 7
R405
3.9K1/16W
C405
10N 50V
C425 10 N 50V
AVS03
PC6
VCC 3.3
CN411
NC/CONN
1
2
3
4
5
C422
10N 50V
PB8
FB402
300OHM
C421
4.7UF 10V
C0805
ADC2
+5V
on_BACKLIGHT 7
C412
MLVS0402M04
1 2
R425
10K 1/16W 5%
PB7
KEY 1
LVB0P
U401
NT68620FG/B
30
62
1
2
11
3
4
5
6
24
7
8
10
14
15
16
17
18
19
20
21
13 12
44
43
83
98
97
25
26
37
92
28
27
31
32
22 38
90
45
46
47
48
49
50
51
74
75
72
71
70
69
68
67
66
65
64
63
9
61
60
59
58
57
56
55
54
53
52
34
84
33
93
94
100
99
96
76
23 39
78
77
85
86
88
87
89
91
40
80
81
41
35
36
73
29
82
79
42
95
RSTB
DGND
RX2+
RX2-
TVCC
RX1+
RX1-
RX0+
RX0-
DGND
RXC+
RXC-
REXT
AGND
BIN1+
BIN1-
SOG1I
GIN 1+
GIN 1-
RIN1+
RIN1-
ADC_1V8 ADC_3V3
P31*/ TXD*
P30*/ RXD*
PB2/ADC2/INTE0
PB7*/D VI_SDA* /TXD*
PB6*/D VI_SCL* /R XD*
HSYNCI1
VSYNCI1
DGND
OSC_VD D
PB5*/VGA_SDA*/TXD*
PB4*/VGA_SCL*/RXD*
P35*
P34*
DVDD DVDD
PC6/ IN TE2
NC
NC
NC
NC
NC
NC
NC
NC
NC
T0M
T0P
T1M
T1P
T2M
T2P
TCLK1M
TCLK1P
T3M
T3P
TGND
T4M
T4P
T5M
T5P
T6M
T6P
TCLK2M
TCLK2P
T7M
T7P
PA1*/PWMD*/DBC*
PA2*/PWMD*/DBC*
PA0*/PW MC*
OSCO
OSCI
PC5
PC4
PC1*/ LPD_OUT*
PC0*/PWMA*/DBC*
DVDD
CVDD_1V8
PE1*/LPD_I N1* /I NT_VSO*
DGND
PA3*
SPI_CLK
SPI_SI
SPI_SO
SPI_CE
PC7
PA4*/I NTE3*/I NT_HSO*
PA7*
PA6*/PW MC*
PA5*/PW MB*
PB0/ADC0
PB1/ADC1
DVDD
PE0*/PW MA*/LPD_I N0*
PB3/ADC3/INTE1
PE3*/PW MB*
PE2*/PW MA*/DBC *
OSC_GN D
+5V
LED_2
R485 NC
PC6
KEY1
R409
0R05 1/ 16W
VCC3. 3 7
Adj_BACKLIGHT 7
PA4*
RX1+
MSC L
LED_1
FB407
300OHM
P34*
C408100N 16V
RX0-
LVB2P
R441
NC /4K7 1/16W 5%
Panel_ON 7
SPI_CE
LVBCKM
C401
4.7UF 10V
C0805
R456
NC /4K7 1/ 16W 5%
FB408
300OHM
R404
3.9K1/16W
LVB1M
Panel_lightbar7
SPI_SI
DVI_HPD
R415
100K 1/16W 5%
PE2*
ADC_VAA
Audio_EN 7
PB7
FB401
300OHM
R422
4.7K 1/ 16W
RX2-4
VCC3.3
ADC_VAA33
RX1-
PB8
R438
NC/ 10K 1/16W 5%
C403
10N 50V
R418
470OHM1/10W
P35*
AVS0
R445 NC /100R 1/ 16W 5%
Q401
LMBT3906LT1G
PE0*
R488 1K 1/ 16W 5%
C423
4.7UF 10V
C0805
G0-3
ADC0
PB[2..9]
PB9
R453
0R05 1/16W
FB404
300OHM
R454
22K 1/16W 5%
LVB0M
R407 0R 05 1/16 W
TP3
TP-R-0.75
D402 NC /RLZ5.6B
PC4
VCC3.3
P/SCL
DVI_C ABLE_DET
C419
10N 50V
G0+3
DVDD
PS_EN 7
MSD A
R427
2K2 1/16W 5%
PC4
RXC+
CABLE_DET
D403 NC /RLZ5.6B
R411
2K2 1/16W 5%
ADC_VAA33
R0-3
LPD_IN1*
CVDD
LED_2
R443
NC /22K 1/ 16W 5%
R413
2K2 1/16W 5%
R446
NC /0R05 1/16W

18
LVB0P
BKLT-EN7
Panel_lightbar5
BKLT-VBRI
LVB1P
RXO1-
R775
4K7 1/16W 5%
14V51
R773
100K 1/16W 5%
PB3 BKLT-VBRI7
BKLT-EN
C434
10N 50V
LVB2M
R772
10K 1/16W 5%
14V5
LVB2P
RXO0-
14V5 7
R776nc/3.3K 1/4W
RXO1+
LVB2P
LVB1M
PB[2. .9]
R448220 OHM 1/ 4W R449220 OHM 1/ 4W
R774
47K +-1% 1/16W
C772
0.1uF 50V
+
C774
100uF 25V
CN409
CONN
Connect or
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41 42
PB6
PB2
C773
10N 50V
LVB1P
LVBCKM
PB9
VLCD 7
RXOC-
C771
220N16V
R461
0R05 1/16W
RXO0+
RXO2+
LVB1M
LVBCKM
PB4
LVB0M
14V5
LVB2M
LVBCKP
R771
22K 1/16W 5%
R462
0R05 1/16W
RXO2-
PB5
B
B
45Monday , J une 13, 2011
715G4870-M0C-000-0040-2LVDS PAN EL I/O
715G4870-M0C-000-0040-1-110321
OEM MOD EL Size
Rev
Date Sheet of
TPV MODEL
PCB N AME
称爹
T P V ( Top Victory Electronics Co . , Ltd. )
Key Component
絬 隔 瓜 絪 腹
PB7
LVBCKP
FB409
120 OHM
1 2
Q771
LMBT3904LT1G
14V51
LVB0P
PB8
LVB0M
R777
NC/0 OHM +-5% 1/8W
+
C433
100uF16V
Q772
AO3401A
RXOC+
VLCD
PB[2. .9]5

19
C708
NC
VCC3.3
Audio_EN1
R712 NC/100R 1/16W 5%
R721
4K7 1/16W 5%
Q706
LMBT3904LT1G
R707
4.7 OH M +-5% 2WS
U703
LSP2159BE18AD
3
1
2
4
VIN
GND
VOUT
TH
R710
NC /100K 1/ 16W 5%
Audio_EN 5
+5V
R718
NC
VLCD 6
U701 NC/AP2114H-3. 3TRG1
3 2
1 4
VI VO
GND 4
+5V
R715
100K 1/16W 5%
R719
22K 1/16W 5%
R708
NC /10K 1/16W 5%
ON/OFF
VLCD
R722
NC/10K 1/16W 5%
VCC1.8 5
C713
10N 50V
CN701
CONN
1
2
3
4
5
6
7
8
9
R711 NC/0R05 1/16W
VCC3.3
VCC3.3
R720
NC/0R05 1/16W
Audio_DET2
C704
10N 50V
C715
220N16V
Adj_BACKLI GHT 5
R799
10K 1/16W 5%
Panel_ON5
+
C716
NC/10uF 50V
C706
10N 50V
Q705
AO3401A
R724
NC
C712
10N 50V
BKLT-EN6
C703
10N 50V
TO-252
R798
NC/100R 1/16W 5%
R723
NC/4K7 1/16W 5%
+5V
Audio_DET1
R717
NC
+5V
R701
22K 1/16W 5%
R725
NC /10K 1/16W 5%
PS_EN 5
Q703
NC/2N3904S-RTK/PS
+
C710
100uF16V
R704
10K 1/16W 5%
Q707
NC /2N3904S-RTK/PS
C701
10N 50V
R703 100R 1/16W 5%
VCC3.3
14V5 6
VCC3.3
Q704
NC /AO4449 -7A/-30V
1 2 3 4
8 7 6 5
S S S G
D D D D
+5V
+
C702
100uF16V
FB701
0 OHM +-5% 1/8W
U702
3 2
1
VIN VOU T
ADJ(GND)
BKLT-VBRI6
C709
NC/100NF 25V
U704
3 2
1
VIN VOUT
GND
+5V3,4,5
R727
0 OH M +-5% 1/ 8W
R716
NC /10K 1/16W 5%
R714
10K 1/16W 5%
R706
NC/10K 1/16W 5%
on_BACKLIGH T 5
C707
10N 50V
Q702
NC/2N3904S-RTK/PS
R702
22K 1/16W 5%
+
C705
100uF16V
C718
220N16V
R726
NC/0 OHM +-5% 1/8W
VCC1.8
DIM
C717
NC/100NF 25V
R709
NC/22K 1/16W 5%
Audio_DET 5
VCC3.3 5
R713 NC
A
B
55Friday , May 13, 2011
715G4870-M0C-000-0040-1POWER
715G4870-M0C-000-0040-1-110321
<Variant Name>
OEM MOD EL Size
Rev
Date Sheet of
TPV MODEL
PCB N AME
称爹
T P V ( Top Victory Electronics Co . , Ltd. )
Key Component
絬 隔 瓜 絪 腹
14V5
+5V
C714
NC /100NF 25V
VCC3.3
Q701
LMBT3904LT1G

20
6.2 Power Board
715G3189P02LED001S
R903
11K 1/8W 1%
GND3
GND
1
2
C901
82pF
+
C918
10uF/50V
D904 31DQ06F C3
!
IC901
TOP255EN
1
2
3
4 5 7
V
X
C
F SD
+
C912
1000uF 25V
Q901
KTD1028
+
C913
680uF 10V
R906 30 OHM 1/4W
R920
3.3 OHM 1/4W
R907 30 OH M 1/4W
DIM_INPUT
+5V1
!
+5V
HS1
HEAT SINK(IC901)
1
2
R912
10K 1/10W 5%
IC902
PC123X2YFZ OF
12 43
R926
2.2 OHM 1/4W
1
Custom
Monday, N ov ember 08, 2010
715G3189-PO1-LED ODM MODEL 02.POWER
G3189-PO2-LED-X-19-101108
OEM MODEL Size
Rev
Date Sheet of
TPV M OD EL
PCB NAME
称爹
T P V ( Top Victory Electronics Co . , Ltd. )
Key Component
絬 隔 瓜 絪 腹
+
C914
470UF M 16V
8.
R900
620K +-1% 1/4W
C910
2N2 500V
R915
9.31KOHM +-1% 1/10W
!
17.4V
R927
0R05 4A 1/4W
R919
100K OMH 2W +-5%
T901
POWER X'FMR
1
2
3
4
5
6
7
8
9
10
L902
ON/OFF_OUTPUT
R923
10K 1/8W 1%
VOL
MU TE
D908
NC
1 2
R910
100 OHM 1/4W
D906 31DQ06F C3
CN902
WAFER 2.5MM
1
2
3
4
5
6
7
8
9
CN903
CONN
1
2
3
4
5
6
7
8
9
10
R901
620K +-1% 1/4W
FB902
BEAD
1 2
!
-+
BD901
KBP208G
2
1
3
4
R921
3.3 OHM 1/4W
R922
3.3 OHM 1/4W
F901
11.3K 4/13
ZD901
MTZJ T-72 18B
1 2
R904 30 OHM 1/4W
C919
2N2 500V
+5V
C904
0.47UF
C911
2N2 500V
+14. 5V
R924
6R8 +-5% 1/8W
R925
82K +-1% 1/8W
R917
1K 1/10W 1%
D905 31DQ10F C
!
D901
FR103
93G 6038T52T
R902
620K +-1% 1/4W
F902 FUSE
R908 30 OH M 1/4W
L903
C903
330pF/250V
+14. 5V
DIM_OUTPUT
C905
100nF 50V
R905 30 OHM 1/4W
!
!
D902
FR107
GND 2
GND
1
2
GND1
GND
1
2
R914
NC
R911
NC
ZD902
MTZJ T-72 16B
1 2
ON/OFF_INPUT
+
C907
NC/47uF M 450V
C902
330pF/250V
R918
250OHM2W
C915
100N 50V
+
C908
47uF/50V
L901
30mH
1
4
2
3
C920
2N2 500V
CN901
SOCKET
12
3
R916
470 OHM 1/10W
C917
100N 50V
C900
1000PF/250VAC
R913
10K 1/10W 1%
D903 31DQ10F C
R909 30 OH M 1/4W
C906
1500PF2KV
+
C907A
100uF 450V
NR901
NTCR
C916
10N 16V
F601
0R05 4A 1/4W
IC903
KIA431A-AT/P
