This Online Manual will introduce to the user how this product is installed. All useful information will be described in later
chapters. Please keep this manual carefully for future upgrades or system configuration changes. This Online Manual is saved
in PDF format, we recommend using Adobe Acrobat Reader 4.0 for online viewing, it is included in Bonus CD disc or you can
get free download from Adobe web site.
Although this Online Manual is optimized for screen viewing, it is still capable for hardcopy printing, you can print it by A4 paper
size and set 2 pages per A4 sheet on your printer. To do so, choose File > Page Setup and follow the instruction of your printer
driver.
Thanks for the help of saving our earth.

11
A
AK K7 77 7 P Pr ro o( (A A) )- -1 13 33 3 / / A AK K7 77 7 P Pl lu us s( (A A) )- -1 13 33 3 O On nl li in ne e M Ma an nu ua al l
O
Ov ve er rv vi ie ew w
Thank you for choosing AOpen AK77 Pro(A)-133 / AK77 Plus(A)-133. The AK77 Pro(A)-133 / AK77 Plus(A)-133 is AMD®Socket
462 motherboard (M/B) based on the ATX form factor featuring the VIA Apollo KT266A chipset. As high performance chipset
built in the M/B, the AK77 Pro(A)-133 / AK77 Plus(A)-133 AMD®Socket 462 series Athlon™ & Duron™ processor and 266MHz
EV6 system bus. In the AGP performance, it has one AGP slot and supports AGP 1X/2X/4X mode and pipelined spilt-transaction
long burst transfer up to 1056MB/sec. With high bandwidth 266MB/s 8-bit V-Link Host Controller, PC1600 and PC2100 DDR
SDRAM can be applied to the AK77 Pro(A)-133 / AK77 Plus(A)-133 and the maximum memory size can be up to 3GB. The
on-board IDE controller supports Ultra DMA
66/100/133 mode and the transfer rate up to
133MB/s. AK77 Plus(A)-133 with a Promise®
FastTrak™ 100 Lite IDE RAID controller that
provides high performance and fault tolerance.
Further flexibility can be achieved by taking
advantage of the Communication and Network
Riser (CNR) card option that allows audio and
modem configuration on a single baseboard design.
Besides, the AK77 Pro(A)-133 / AK77 Plus(A)-133
has an AD 1885 AC97 CODEC chipset onboard for
provides high performance and magic surround
stereo sound to let people enjoy working with it.
Now, enjoy all features from AOpen AK77
Pro(A)-133 / AK77 Plus(A)-133.

12
A
AK K7 77 7 P Pr ro o( (A A) )- -1 13 33 3 / / A AK K7 77 7 P Pl lu us s( (A A) )- -1 13 33 3 O On nl li in ne e M Ma an nu ua al l
F
Fe ea at tu ur re e H Hi ig gh hl li ig gh ht t
CPU
Supports AMD® Socket 462 series CPU with both 200MHz and 266MHz EV6 Bus designed for Socket 462 technology.
Athlon: 600MHz~1.4GHz
Duron: 600MHz~1.2GHz
AthlonXP: 1500+(1.3GHz)~1900+(1.6GHz)
Chipset
The VIA Apollo KT266A consists of the VT8366A V-Link DDR Host system controller and the VT8233A highly integrated V-Link
Client PCI/LPC controller. The Host system controller provides superior performance between the CPU, SDRAM, AGP bus, and
V-Link interface with pipelined, burst, and concurrent operation. The VT8233A V-Link Client controller is a highly integrated
PCI/LPC controller. Its internal bus structure is based on 66MHz PCI bus that provides 2x bandwidth compare to previous
generation PCI/ISA bridge chips. The VT8233A integrated Client V-Link controller with 266MB/s bandwidth between Host/Client
V-Link interface, provides a V-Link-PCI and V-Link-LPC controller. Of five PCI slots provided, AK77 Pro(A)-133 supports all five
master PCI slots with arbitration and decoding for all integrated functions and LPC bus; while AK77 Plus(A)-133 supports four
master PCI slots for arbitration and decoding functions also and one slave PCI slot.

13
A
AK K7 77 7 P Pr ro o( (A A) )- -1 13 33 3 / / A AK K7 77 7 P Pl lu us s( (A A) )- -1 13 33 3 O On nl li in ne e M Ma an nu ua al l
Ultra DMA 66/100/133 Bus Mater IDE
Comes with an on-board PCI Bus Master IDE controller with two connectors that supports four IDE devices in two channels,
supports Ultra DMA 66/100/133, PIO Modes 3 and 4 and Bus Master IDE DMA Mode 4, and supports Enhanced IDE devices.
Expansion Slots
Including five 32-bit/33MHz PCI, one CNR and one AGP 4X slots. The PCI local bus throughput can be up to 132MB/s. The
Communication & Nectworking Riser (CNR) slot provided from AK77 Pro(A)-133 / AK77 Plus(A)-133 can support CNR interface
for a Modem/Audio card. The Accelerated Graphics Port (AGP) specification provides a new level of video display sophistication
and speed. The AGP video cards support data transfer rate up to 1056MB/s. As AK77 Pro(A)-133 / AK77 Plus(A)-133 includes
one AGP expansion slot for a bus mastering AGP graphic card, For AD and SBA signaling, AK77 Pro(A)-133 / AK77 Plus(A)-133
can support 133MHz 2X/4X mode.
Memory
With VIA Apollo KT266A chipset, the AK77 Pro(A)-133 / AK77 Plus(A)-133 can support Double-Data-Rate (DDR) SDRAM. The
DDR SDRAM interface allows zero wait state bursting between the SDRAM and the data buffers at 66/100/133MHz. The six
banks of DDR SDRAM can be composed of an arbitrary mixture of 1M/2M4M/8M/16M/32M/64MxN DDR SDRAM and maximum
up to 3GB. The AK77 Pro(A)-133 / AK77 Plus(A)-133 allows DDR SDRAM to run at either synchronous or pseudo-synchronous
mode with the host CPU bus frequency (66/100/133MHz).

14
A
AK K7 77 7 P Pr ro o( (A A) )- -1 13 33 3 / / A AK K7 77 7 P Pl lu us s( (A A) )- -1 13 33 3 O On nl li in ne e M Ma an nu ua al l
On-board ATA/100 IDE RAID (AK77 Plus(A)-133 Only)
1. Supports data striping (RAID 0) and mirroring (RAID 1). Provides dramatic increase in drive performance and/or fault
tolerant options. Offers performance customization and data rebuilds from the BIOS menu. Mirroring supports automatic
background rebuilds. Fault tolerance can be restored automatically without rebooting.
2. Supports up to four IDE drives which capacities are more than 8.4GB on the two IDE RAID connectors while still supporting
four IDE devices on the motherboard. The burst data transfer rates can up to 100MB/s from ATA/100 drives to boast overall
system performance.
3. Supports IDE Bus Master operation allows multi-tasking during disk drives transfer which increase CPU efficiency, then the
CPU is free to process task during IDE data transfer through PCI bus interface to/from system memory.
On-board AC97 Sound
AK77 Pro(A)-133 / AK77 Plus(A)-133 uses the AD 1885 AC97 CODEC chip. This on-board audio includes a complete audio
recording and playback system.
Four USB Connectors
Provides two ports, four USB connectors for USB interface devices, such as mouse, keyboard, modem, scanner, etc. The
onboard USB Host controller is fully compliant with USB UHCI 1.1 specification that can fully compatible with low power mode
and wake-up specification.

15
A
AK K7 77 7 P Pr ro o( (A A) )- -1 13 33 3 / / A AK K7 77 7 P Pl lu us s( (A A) )- -1 13 33 3 O On nl li in ne e M Ma an nu ua al l
1MHz Stepping Frequency Adjustment
Provides “1MHz Stepping Frequency Adjustment” function in the BIOS. This magic function allows you adjust CPU FSB
frequency from 100~248 by 1MHz stepping, and lets your system can get maximum performance.
Watch Dog Timer
Includes AOpen “Watch Dog Timer” function that can auto-reset system in 4.8 seconds when you fail to system overclocking.
Die-Hard BIOS with external controller (Upgrade Optional)
The Die-Hard BIOS technology is a very effective hardware protection method that doesn’t involve any software or BIOS coding.
Hence, it is 100% virus free.
Dr. LED (Upgrade Optional)
The Dr. LED has 8 LEDs on AK77 Pro(A)-133 / AK77 Plus(A)-133, which can easily show what kind of problem you may
encounter.
Power Management/Plug and Play
The AK77 Pro(A)-133 / AK77 Plus(A)-133 supports the power management function that confirms to the power-saving standards
of the U.S. Environmental Protection Agency (EPA) Energy Star program. It also offers Plug-and-Play, which helps saving users
from configuration problems, thus making the system much more user-friendly.

16
A
AK K7 77 7 P Pr ro o( (A A) )- -1 13 33 3 / / A AK K7 77 7 P Pl lu us s( (A A) )- -1 13 33 3 O On nl li in ne e M Ma an nu ua al l
Hardware Monitoring Management
Supports CPU or system fans status, temperature and voltage monitoring and alert, through the on-board hardware monitor
module and Aopen Hardware Monitoring Utility.
Enhanced ACPI
Fully implement the ACPI standard for Windows®95/98/ME/NT/2000 series compatibility, and supports Soft-Off, STR (Suspend
to RAM, S3), STD (Suspend to Disk, S4), WOM (Wake On Modem), WOL (Wake On LAN) features.
Super Multi-I/O
The AK77 Pro(A)-133 / AK77 Plus(A)-133 provides two high-speed UART compatible serial ports and one parallel port with EPP
and ECP capabilities. UART2 can also be directed from COM2 to the Infrared Module for the wireless connections.

17
A
AK K7 77 7 P Pr ro o( (A A) )- -1 13 33 3 / / A AK K7 77 7 P Pl lu us s( (A A) )- -1 13 33 3 O On nl li in ne e M Ma an nu ua al l
Q
Qu ui ic ck k I In ns st ta al ll la at ti io on n P Pr ro oc ce ed du ur re e
This page gives you a quick procedure on how to install your system. Follow each step accordingly.
1. Installing CPU and Fan
2. Installing System Memory (DIMM)
3. Connecting Front Panel Cable
4. Connecting IDE and Floppy Cable
5. Connecting ATX Power Cable
6. Connecting Back Panel Cable
7. Power-on and Load BIOS Setup Default
8. Setting CPU Frequency
9. Reboot
10. Installing Operating System (such as Windows 98)
11. Installing Driver and Utility

18
A
AK K7 77 7 P Pr ro o( (A A) )- -1 13 33 3 / / A AK K7 77 7 P Pl lu us s( (A A) )- -1 13 33 3 O On nl li in ne e M Ma an nu ua al l
Motherboard Map
PC99 Colored Back Panel
Resettable Fuse
JP28 Keyboard/Mouse
Wake-u
p
Select Jum
p
er
A
TX Power Connector
FAN3 Connector
A
GP 4x Expansion Slot
462-pin CPU Socket with
Voltage and Frequency
A
uto-Detection that supports
A
MD®Athlon®/ Duron®/ and
A
thlonXP
VIA® Apollo KT266A
Chipset with FANsink and
VT8233A SB
(
ATA100/133 su
pp
orted
)
CPU Fan Connector with
H/W Monitoring
184-pin DDR SDRAM Slot x3
support maximum up to 3GB
JP21 FSB Select Jumper
A
TA/100 IDE RAID
Connector x2 (AK77
Plus(A)-133 Only)
IDE Connector x 2
(ATA100/133 supported)
FDD Connector
CD-IN Connector
Die Hard BIOS with 100% Virus
Protection (UpgradeOptional)
JP30 Die Hard BIOS
Select Jumper
Onboard AC97 CODEC
Green: AUX-IN Connecto
r
Red: Modem-CN Connecto
r
CNR Expansion Slot
32-bit PCI Ex
p
ansion Slot x5
2nd USB Port Connector
Dr. LED Connector
(Upgrade Optional)
WOM (Wake ON Modem)
Connecto
r
WOL (Wake ON LAN)
Connecto
r
IrDA Connecto
r
FAN3 Connector
with H/W Monitoring
Front Audio Connector
Front Panel Connector
JP14 CMOS Data Clear Jumper
PROMISE®FastTrak 100™
Lite IDE RAID Controller
(
AK77 Plus
(
A
)
-133 Onl
y)
System & RAM Power
Indicate LED
Chassis Intrusion Sensor
Connecto
r
(PCI 5 supports slave mode
PCI card only)

19
A
AK K7 77 7 P Pr ro o( (A A) )- -1 13 33 3 / / A AK K7 77 7 P Pl lu us s( (A A) )- -1 13 33 3 O On nl li in ne e M Ma an nu ua al l
VT8366V
DDR V-Link
Host North 552
BGA
Socket 462
AMD
Athlon/Duron
CPU
66/100/133MHz
System Bus
DDR SDRAM Socket x3
AGP 4X Slot
VT8233V
V-Link Client
South 376
BGA
Serial Port x2
2nd USB Port
1st USB Port
USB connector x4
32-bit PCI Slot x5
Parallel Port
IDE Drive x4
ATA
66/100/133
PC1600/PC2100 DDR
SDRAM Up to 3GB
Primary
Channel
Secondary
Channel
2MBit Flash EEPROM
Audio CODEC
Modem CODEC
AC’97 Link
IDE Drive x4
Primary
Channel
Secondary
Channel
Promise
FastTrak
100 IDE
RAID
Controller
Supports ATA100 IDE RAID
0 and RAID 1 Solution
(AK77 Plus Only)
PCI Bus
CNR Slot
AGP Bus
Floppy Disk Drive x2
B
Bl lo oc ck k D Di ia ag gr ra am m

20
A
AK K7 77 7 P Pr ro o( (A A) )- -1 13 33 3 / / A AK K7 77 7 P Pl lu us s( (A A) )- -1 13 33 3 O On nl li in ne e M Ma an nu ua al l
H
Ha ar rd dw wa ar re e I In ns st ta al ll la at ti io on n
This chapter describes jumpers, connectors and hardware devices of this motherboard.
Note: Electrostatic discharge (ESD) can damage your processor, disk drives, expansion boards,
and other components. Always observe the following precautions before you install a system
component.
1. Do not remove a component from its protective packaging until you are ready to install it.
2. Wear a wrist ground strap and attach it to a metal part of the system unit before handling a
component. If a wrist strap is not available, maintain contact with the system unit throughout
any procedures requiring ESD protection.
