AOpen AK89 MAX User manual

1
A
AK K8 89 9 M Ma ax x / / A AK K8 89 9- -L L / / A AK K8 89 9- -N N O On nl li in ne e M Ma an nu ua al l
AK89 MAX / AK89-L / AK89-N
DOC. NO.: AK89MAX-OL-E0401C

2
A
AK K8 89 9 M Ma ax x / / A AK K8 89 9- -L L / / A AK K8 89 9- -N N O On nl li in ne e M Ma an nu ua al l
W
Wh ha at t’ ’s s i in n t th hi is s m ma an nu ua al l
TU AK89 MAX / AK89-L / AK89-NUT ............................................................................................................1
TU What’s in this manualUT ......................................................................................................................................................2
TU You Must NoticeU T ..............................................................................................................................................................9
TU Before You StartUT ...........................................................................................................................................................10
TU OverviewU T ....................................................................................................................................................................... 11
TU AK89 Max / AK89-L / AK89-N Comparison TableU T ..........................................................................................................12
TU Feature HighlightU T ..........................................................................................................................................................13
TU Quick Installation ProcedureUT .........................................................................................................................................17
TU Motherboard MapU T .........................................................................................................................................................18
TU Block DiagramU T ..............................................................................................................................................................19
TU Hardware InstallationUT ...............................................................................................................20
TU About “Manufacturer Upgrade Optional” and “User Upgrade Optional”…UT .....................................................................21
TU CPU InstallationUT ............................................................................................................................................................22
TU EzColorU T .........................................................................................................................................................................24
TU AOpen Overheat Protection (O.H.P.) TechnologyUT .........................................................................................................26
TU CPU Over-current ProtectionUT ........................................................................................................................................27
TU Enlarged Aluminum HeatsinkUT ........................................................................................................................................28
TU Full-range Adjustable CPU Core VoltageU T ......................................................................................................................29

3
A
AK K8 89 9 M Ma ax x / / A AK K8 89 9- -L L / / A AK K8 89 9- -N N O On nl li in ne e M Ma an nu ua al l
TU Setting CPU FrequencyU T ................................................................................................................................................30
TU Supported CPU FrequencyU T ...........................................................................................................................................31
TU AOpen “Watch Dog ABS”UT ..............................................................................................................................................32
TU CPU and Housing Fan Connector (with H/W Monitoring)UT ..............................................................................................33
TU DIMM SocketsU T ..............................................................................................................................................................34
TU ATX Power ConnectorUT ...................................................................................................................................................37
TU AC Power Auto RecoveryUT .............................................................................................................................................37
TU IDE and Floppy ConnectorUT ............................................................................................................................................38
TU ATA/133 SupportedU T .......................................................................................................................................................40
TU Serial ATA Supported (For AK89 Max Only, With RAID Function)UT .................................................................................41
TU Connecting Serial ATA DiskUT ..........................................................................................................................................42
TU Front Panel ConnectorU T ..................................................................................................................................................44
TU IrDA ConnectorU T .............................................................................................................................................................45
TU AGP (Accelerated Graphic Port) 8X Expansion SlotU T .....................................................................................................46
TU Self-Powered PCI Slot (for AK89 Max only)UT ..................................................................................................................47
TU 10/100/1000 Mbps LAN onboardU T ..................................................................................................................................48
TU Support Six USB 2.0 connectorsU T ...................................................................................................................................49
TU Onboard IEEE 1394 Controller (for AK89 Max only)UT .....................................................................................................50
TU DieHard BIOS II (for AK89 Max only)U T ............................................................................................................................51

4
A
AK K8 89 9 M Ma ax x / / A AK K8 89 9- -L L / / A AK K8 89 9- -N N O On nl li in ne e M Ma an nu ua al l
TU Color Coded Back PanelU T ...............................................................................................................................................52
TU Super 5.1 Channel Audio EffectUT ....................................................................................................................................53
TU Front Audio ConnectorU T ..................................................................................................................................................54
TU S/PDIF (Sony/Philips Digital Interface) ConnectorU T ........................................................................................................55
TU Case Open ConnectorU T ..................................................................................................................................................56
TU CD Audio ConnectorU T .....................................................................................................................................................57
TU AUX-IN ConnectorU T ........................................................................................................................................................58
TU Game Port Bracket SupportedU T ......................................................................................................................................59
TU JP15/JP16 Dr. Voice II Language Select Jumpers (for AK89 Max only)U T ........................................................................60
TU JP2 Dr. Voice Output Select Jumper (for AK89 Max only)UT .............................................................................................61
TU JP14 Clear CMOS Data JumperUT ...................................................................................................................................62
TU JP28 KB/Mouse Wake-up JumperU T ................................................................................................................................63
TU STBY LEDU T ....................................................................................................................................................................64
TU AGP Protection Technology and AGP LEDU T ...................................................................................................................65
TU Battery-less and Long Life DesignUT ................................................................................................................................66
TU Resetable FuseUT .............................................................................................................................................................67
TU 3300 μ F Low ESR CapacitorUT ........................................................................................................................................68
TU RAID IntroductionU T .....................................................................................................................70
TU What’s RAID?U T ...............................................................................................................................................................70

5
A
AK K8 89 9 M Ma ax x / / A AK K8 89 9- -L L / / A AK K8 89 9- -N N O On nl li in ne e M Ma an nu ua al l
TU What are the RAID levels?U T ............................................................................................................................................71
TU HDD Capacity of RAID LevelsUT ......................................................................................................................................74
TU Serial ATA RAID for Silicon ImageUT ................................................................................................................................75
TU PHOENIX-AWARD BIOSU T .............................................................................................................76
TU How To Use Phoenix-Award™ BIOS Setup ProgramU T ....................................................................................................77
TU How To Enter BIOS SetupU T .............................................................................................................................................78
TU BIOS Upgrade under Windows environmentUT .................................................................................................................79
TU WinBIOS Utility (for AK89 Max only)U T .............................................................................................................................81
TU Open JukeBox Player (for AK89 Max only)U T ...................................................................................................................83
TU Vivid BIOS technologyU T ..................................................................................................................................................87
TU Driver and UtilityU T .......................................................................................................................88
TU Auto-run Menu from Bonus CDU T .....................................................................................................................................88
TU Installing NVIDIA Windows nForce DriversUT ...................................................................................................................89
TU Installing LAN Driver (for AK89 Max and AK89-L)UT .........................................................................................................90
TU Installing LAN Driver (for AK89-N)U T ..............................................................................................................................101
TU Installing Silicon Image SiI3114 SATARaid Driver (for AK89 Max only)UT .......................................................................104
TU Installing Silicon Image SiI3114 SATARaid Utility (for AK89 Max only)U T ....................................................................... 112
TU AOConfig UtilityUT .......................................................................................................................................................... 113
TU The noise is gone!! ---- SilentTekUT ................................................................................................................................115

6
A
AK K8 89 9 M Ma ax x / / A AK K8 89 9- -L L / / A AK K8 89 9- -N N O On nl li in ne e M Ma an nu ua al l
TU EzClockU T ...................................................................................................................................................................... 118
TU GlossaryU T ..................................................................................................................................122
TU AC97 CODECUT .............................................................................................................................................................122
TU ACPI (Advanced Configuration & Power Interface)U T .....................................................................................................122
TU ACR (Advanced Communication Riser)U T ......................................................................................................................122
TU AGP (Accelerated Graphic Port)UT .................................................................................................................................123
TU AMR (Audio/Modem Riser)U T .........................................................................................................................................123
TU ATA (AT Attachment)UT ...................................................................................................................................................123
TU BIOS (Basic Input/Output System)UT ..............................................................................................................................124
TU BluetoothU T ....................................................................................................................................................................124
TU CNR (Communication and Networking Riser)U T .............................................................................................................125
TU DDR (Double Data Rate) RAMUT ....................................................................................................................................125
TU ECC (Error Checking and Correction)U T .........................................................................................................................126
TU EEPROM (Electronic Erasable Programmable ROM)UT .................................................................................................126
TU EPROM (Erasable Programmable ROM)U T ....................................................................................................................126
TU EV6 BusU T ......................................................................................................................................................................126
TU FCC DoC (Declaration of Conformity)U T .........................................................................................................................127
TU FC-PGA (Flip Chip-Pin Grid Array)UT .............................................................................................................................127
TU FC-PGA2 (Flip Chip-Pin Grid Array)UT ...........................................................................................................................127

7
A
AK K8 89 9 M Ma ax x / / A AK K8 89 9- -L L / / A AK K8 89 9- -N N O On nl li in ne e M Ma an nu ua al l
TU Flash ROMUT .................................................................................................................................................................127
TU Hyper ThreadingU T .........................................................................................................................................................127
TU IEEE 1394U T ..................................................................................................................................................................128
TU Parity BitU T .....................................................................................................................................................................128
TU PCI (Peripheral Component Interface) BusU T .................................................................................................................129
TU PDF FormatU T ................................................................................................................................................................129
TU PnP (Plug and Play)UT ....................................................................................................................................................129
TU POST (Power-On Self Test)UT ........................................................................................................................................129
TU PSB (Processor System Bus) ClockU T ...........................................................................................................................130
TU RDRAM (Rambus Dynamic Random Access Memory)UT ...............................................................................................130
TU RIMM (Rambus Inline Memory Module)U T ......................................................................................................................130
TU SDRAM (Synchronous DRAM)U T ....................................................................................................................................130
TU SATA (Serial ATA)UT .......................................................................................................................................................131
TU SMBus (System Management Bus)UT ............................................................................................................................131
TU SPD (Serial Presence Detect)U T ....................................................................................................................................131
TU USB 2.0 (Universal Serial Bus)UT ...................................................................................................................................131
TU VCM (Virtual Channel Memory)UT ..................................................................................................................................132
TU Wireless LAN – 802.11bU T .............................................................................................................................................132
TU ZIP fileU T ........................................................................................................................................................................132

8
A
AK K8 89 9 M Ma ax x / / A AK K8 89 9- -L L / / A AK K8 89 9- -N N O On nl li in ne e M Ma an nu ua al l
TU TroubleshootingUT ......................................................................................................................133
TU Technical SupportU T ...................................................................................................................137
TU Product RegistrationUT ...............................................................................................................140
TU How to Contact UsUT ..................................................................................................................141

9
A
AK K8 89 9 M Ma ax x / / A AK K8 89 9- -L L / / A AK K8 89 9- -N N O On nl li in ne e M Ma an nu ua al l
Y
Yo ou u M Mu us st t N No ot ti ic ce e
Adobe, the Adobe logo, Acrobat is trademarks of Adobe Systems Incorporated.
AMD, the AMD logo, Athlon and Duron are trademarks of Advanced Micro Devices, Inc.
Intel, the Intel logo, Intel Celeron, Pentium II, Pentium III, Pentium 4 are trademarks of Intel Corporation.
Microsoft, Windows, and Windows logo are either registered trademarks or trademarks of Microsoft Corporation in the United
States and/or other countries.
All product and brand names used on this manual are used for identification purposes only and may be the registered
trademarks of their respective owners.
All of the specifications and information contained in this manual are subject to change without notice. AOpen reserves the right
to revise this publication and to make reasonable changes. AOpen assumes no responsibility for any errors or inaccuracies that
may appear in this manual, including the products and software described in it.
This documentation is protected by copyright law. All rights are reserved.
No part of this document may be used or reproduced in any form or by any means, or stored in a database or retrieval
system without prior written permission from AOpen Corporation.
CopyrightP
©
P1996-2003, AOpen Inc. All Rights Reserved.

10
A
AK K8 89 9 M Ma ax x / / A AK K8 89 9- -L L / / A AK K8 89 9- -N N O On nl li in ne e M Ma an nu ua al l
B
Be ef fo or re e Y Yo ou u S St ta ar rt t
This Online Manual will introduce to the user how this product is installed. All useful information will be described in later
chapters. Please keep this manual carefully for future upgrades or system configuration changes. This Online Manual is saved
in HTUPDF formatUT H , we recommend using Adobe Acrobat Reader 5.0 for online viewing, it is included in Bonus CD disc or you can
get free download from H T U Adobe web siteU T H .
Although this Online Manual is optimized for screen viewing, it is still capable for hardcopy printing, you can print it by A4 paper
size and set 2 pages per A4 sheet on your printer. To do so, choose File > Page Setup and follow the instruction of your printer
driver.
Thanks for the help of saving our earth.

11
A
AK K8 89 9 M Ma ax x / / A AK K8 89 9- -L L / / A AK K8 89 9- -N N O On nl li in ne e M Ma an nu ua al l
O
Ov ve er rv vi ie ew w
Thank you for choosing AOpen AK89 MAX / AK89-L / AK89-N. The AK89 MAX / AK89-L / AK89-N is AMDP
®
PSocket 754
motherboard (M/B) based on the ATX form factor featuring the NVIDIA nForce3 chipset. As high performance chipset built in the
M/B, the AK89 MAX / AK89-L / AK89-N comes with AMDP
®
PSocket 754 Athlon 64 processor and 600MHz Hyper Transport bus. In
the AGP performance, it has one AGP slot and supports AGP 8X/4X mode and pipelined spilt-transaction long burst transfer up
to 2.1GB/sec. With memory controller built in the Athlon 64 processor, HTUDDR400(PC3200)UTH, HT U DDR333(PC2700)U T H and
HT U DDR266(PC2100)U T H DDR RAM can be applied to the AK89 MAX / AK89-L / AK89-N and DDR400 maximum memory size can be
up to 2GB and DDR333/266 up to 3GB. The on-board
IDE controller supports Ultra DMA 66/100/133 mode
and the transfer rate up to 133MB/s. AK89 MAX also
has four Serial ATA connectors and they aim to
provide you an even faster transfer rate of 150
Mbytes/second. The SATA connectors support RAID 0
and RAID 1. On the strength of RealTek RTL8110S
controller on board, AK89 Max / AK89-L provides
10/100/1000Mbps Ethernet for office and home use
(AK89-N provides 10/100Mbps Ethernet). Beside,
AK89 MAX / AK89-L / AK89-N has a S/PDIF
connector and an HTUAC97UT H U CODECURealTek ALC655
chipset onboard for providing high performance and
magic surround stereo sound to let people enjoy
working with it. More than that, this motherboard
supports HTUUSB 2.0UTH function with a fancy speed of up to
480Mbps. Now, enjoy all features from AOpen AK89 MAX / AK89-L / AK89-N.

12
A
AK K8 89 9 M Ma ax x / / A AK K8 89 9- -L L / / A AK K8 89 9- -N N O On nl li in ne e M Ma an nu ua al l
A
AK K8 89 9 M Ma ax x / / A AK K8 89 9- -L L / / A AK K8 89 9- -N N C Co om mp pa ar ri is so on n T Ta ab bl le e
Following we list the different functions in those four models. “V” represents those functions that the model equips with and “X”
represents functions that model doesn’t have. Please always refer to this page to see the functions of your model.
AK89 Max AK89-L AK89-N
SATA Connector VXX
IEEE 1394 Connector VX X
10/100Mbps LAN V V V
Gigabits LAN VVX
Dr. Voice II V XX
Die Hard BIOS II V X X
WinBIOS Utility V X X
Self-Powered PCI Slot V X X

13
A
AK K8 89 9 M Ma ax x / / A AK K8 89 9- -L L / / A AK K8 89 9- -N N O On nl li in ne e M Ma an nu ua al l
F
Fe ea at tu ur re e H Hi ig gh hl li ig gh ht t
CPU
Supports AMDP
®
PSocket 754 Athlon 64 CPU with 800 MHz Hyper Transport Bus.
Chipset
The NVIDIAP
®
PnForce3 processor is a single-chip, highly integrated, high-performance, low-cost PC2001-compliant peripheral
controller with AGP 8X and an AMD Athlon 64 CPU interface. The nForce3 implements a fast dedicated Hyper Transport link,
running at up to 3600MB/s, to communicate with the AMD Athlon 64 CPU. Its architecture accommodates AGP 8X, up to six PCI
slots, three ATA-133, up to six USB2.0, Fast Ethernet, LPC, and AC’97 audio/modem peripherals.
Ultra DMA 66/100/133 Bus Master IDE
Comes with an on-board PCI Bus Master IDE controller with two connectors that supports four IDE devices in two channels,
supports Ultra DMA 66/100/133, PIO Modes 3 and 4 and Bus Master IDE DMA Mode 4, and supports Enhanced IDE devices.
LAN Port
For AK89 Max and AK89-L, on the strength of RealTek RTL8110S controller on board, which is a highly integrated Platform LAN
Connect device, it provides 10/100/1000 Mbps Ethernet for office and home use. For AK89-N, with Realtek RTL8100C network
controller on boards, it provides 10/100 Mbps Ethernet for office and home use.

14
A
AK K8 89 9 M Ma ax x / / A AK K8 89 9- -L L / / A AK K8 89 9- -N N O On nl li in ne e M Ma an nu ua al l
Serial ATA (for AK89 Max only)
On the strength of Silicon Image SATA controller, This motherboard provides 4 SATA connectors, aiming to provide you an even
faster transfer rate of 150 Mbytes/second. The SATA connectors support RAID 0, RIAD 1 and RAID 0+1.
Expansion Slots
Including five 32-bit/33MHz PCI and one AGP 8X slots. The HTUPCIUT H local bus throughput can be up to 132MB/s. The HTUAccelerated
Graphics Port (AGP)UT H specification provides a new level of video display sophistication and speed. The AGP video cards support
data transfer rate up to 2.1GB/s. As AK89 MAX / AK89-L / AK89-N includes one AGP expansion slot for a bus mastering AGP
graphic card, For AD and SBA signaling, AK89 MAX / AK89-L / AK89-N can support 133MHz 4X/8X mode. AK89 MAX / AK89-L /
AK89-N supports five master PCI slots for arbitration and decoding functions.
Memory
With memory controller built in the AMD Athlon 64 processors, which is a brand new design in AMD Athlon 64 CPUs. AK89
MAX / AK89-L / AK89-N can support HT U Double-Data-Rate (DDR) RAMUT H . The DDR RAM interface allows zero wait state bursting
between the RAM and the data buffers at 400/333/266/200 MHz. The six banks of DDR RAM can be composed of an arbitrary
mixture of 64, 128, 256, 512,1024MB x N DDR RAM and support DDR400 maximum up to 2GB and DDR333/266 up to 3GB.
On-board AC97 Sound
AK89 MAX / AK89-L / AK89-N uses the HTUAC97 CODECUT H RealTek ALC655 chip, which supports high quality of 5.1 Channel audio
effects. This on-board audio includes a complete audio recording and playback system.

15
A
AK K8 89 9 M Ma ax x / / A AK K8 89 9- -L L / / A AK K8 89 9- -N N O On nl li in ne e M Ma an nu ua al l
Six USB 2.0 Connectors
Provides three HTUUSBUTH ports for USB interface devices, such as mouse, keyboard, modem, scanner, etc. Please note that USB 2.0,
with fancy speed up to 480Mbps, is 40 times faster than the traditional ones. Except for the speed increase, USB 2.0 supports
old USB 1.0/1.1 software and peripherals, offering impressive and even better compatibility to customers.
1MHz Stepping CPU Frequency Adjustment
Provides “1MHz Stepping CPU Frequency Adjustment” function in the BIOS. This magic function allows you adjust CPU HTUFSBUTH
frequency from 100~250MHz by 1MHz stepping, and lets your system can get maximum performance.
Watch Dog ABS
Includes AOpen “Watch Dog ABS” function that can auto-reset system in 4.8 seconds when you fail the system overclocking.
Power Management/Plug and Play
AK89 MAX / AK89-L / AK89-N supports the power management function that confirms to the power-saving standards of the
U.S. Environmental Protection Agency (EPA) Energy Star program. It also offers HT U Plug-and-PlayUTH, which helps saving users from
configuration problems, thus making the system much more user-friendly.
Hardware Monitoring Management
Supports CPU or system fans status, temperature and voltage monitoring and alert, through the on-board hardware monitor
module and AOpen Hardware Monitoring Utility.

16
A
AK K8 89 9 M Ma ax x / / A AK K8 89 9- -L L / / A AK K8 89 9- -N N O On nl li in ne e M Ma an nu ua al l
Enhanced ACPI
Fully implement the HTUACPIUT H standard for WindowsP
®
P95/98/ME/NT/2000/XP series compatibility, and supports Soft-Off, STR
(Suspend to RAM, S3), STD (Suspend to Disk, S4), WOM (Wake On Modem), WOL (Wake On LAN) features.
Super Multi-I/O
AK89 MAX / AK89-L / AK89-N provides two high-speed UART compatible serial ports and one parallel port with EPP and ECP
capabilities. UART2 can also be directed from COM2 to the Infrared Module for the wireless connections.

17
A
AK K8 89 9 M Ma ax x / / A AK K8 89 9- -L L / / A AK K8 89 9- -N N O On nl li in ne e M Ma an nu ua al l
Q
Qu ui ic ck k I In ns st ta al ll la at ti io on n P Pr ro oc ce ed du ur re e
This page gives you a quick procedure on how to install your system. Follow each step accordingly.
1. Installing HTUCPUUTH and HTUFanUTH
2. HT U Installing System Memory (DIMMUT H )
3. HT U Connecting Front Panel CableUT H
4. HT U Connecting IDE and Floppy CableUT H
5. HT U Connecting ATX Power CableU T H
6. HT U Connecting Back Panel CableUTH
7. HT U Power-on and Load BIOS Setup DefaultUTH
8. HT U Setting CPU FrequencyUTH
9. Reboot
10. HT U Installing Operating System (such as Windows XP)UTH
11. HT U Installing Driver and UtilityUTH

18
A
AK K8 89 9 M Ma ax x / / A AK K8 89 9- -L L / / A AK K8 89 9- -N N O On nl li in ne e M Ma an nu ua al l
Motherboard Map
Colored Back Panel
ATX Power Connector
SYSFAN1 Connector
AGP 8x Slot
754-pin CPU Socket with
Voltage and Frequency
Auto-Detection that supports
AMDP
TM
PAthlonP
TM
P64
NVIDIA nForce3 chipset
CPUFAN Connector
184-pin DIMMx3 supports
DDR400 max. up to 2GB and
DDR333/DDR266 max up to
3GB
CD-IN Connector
AC97 CODEC
AUX-IN Connector
Serial ATA connector x4
(for AK89 Max only)
32-bit PCI Expansion Slot x5
STBY LED
IrDA Connector
SYS
FAN
2
C
onnec
t
or
Front Audio Connector
Front Panel Connector
JP14 Clear CMOS Jum
p
er
Case Open Connector
S/PDIF Connector
USB 2.0 Connector
JP28 Keyboard/Mouse
Wakeup Jumper
3300μF Low ESR Capacitors
4-pin 12V ATX Power Connector
Game Port Connector
IDE Connector x 2
FDD Connector
Realtek RTL8110S LAN Chip
(for AK89 Max and AK89-L)
Realtek RTL8100C LAN Chip
(for AK89-N)
The PCI Slot with independent
power supply (for AK89 Max
onl
y)
IEEE 1394 Connector x2
(for AK89 Max only)
JP15 & JP16 Dr. Voice II
Language Selection Jumper
(
for AK89 Max onl
y)
Phoenix Award Flash ROM
BIOS (BIOS1)
Phoenix Award Flash ROM
BIOS (BIOS2, for AK89 Max
only)
JP25 BIOS2 Protection Jumper
(for AK89 Max only)
JP24 BIOS Select Jumper
(for AK89 Max only)
JP2 Dr. Voice II Speaker/buzzer
Output Jumper (for AK89 Max
only)

19
A
AK K8 89 9 M Ma ax x / / A AK K8 89 9- -L L / / A AK K8 89 9- -N N O On nl li in ne e M Ma an nu ua al l
NVIDIA nForce3
Socket 754
AMD Athlon 64
CPU
Hyper
Transport
Link
DDR SDRAM Socket x3
AGP 8X Slot
Serial Port x2
2nd USB Port
1st USB Port
USB2.0 Connector x6
32-bit PCI Slot x5
Parallel Port
IDE Driver x4
ATA
66/100/133
DDR400 RAM Up to 2GB and
DDR333/266 RAM to 3GB
Primary
Channel
Secondary
Channel
Audio CODEC AC’97 Link
PCI Bus
AGP Bus
Floppy Disk Drive x2
RealTek RTL8110S (for
AK89 Max and AK89-L)
Realtek RTL8100C
(for AK89-N)
LAN connect
Component
3rd USB Port
IEEE 1394 portx2
4Mb Flash EEPROM
Self-Powered PCI Slot
(for AK89 Max)
Second ROM
for AK89 Max
only
Silicon Image
SATA
Controller (for
AK89 Max
only)
Serial ATA
Driver x4
(for AK89
Max only)
for AK89 Max
only
Agere FW323
(for AK89 Max
only)
Winbond
Super IO
B
Bl lo oc ck k D Di ia ag gr ra am m

20
A
AK K8 89 9 M Ma ax x / / A AK K8 89 9- -L L / / A AK K8 89 9- -N N O On nl li in ne e M Ma an nu ua al l
H
Ha ar rd dw wa ar re e I In ns st ta al ll la at ti io on n
This chapter describes jumpers, connectors and hardware devices of this motherboard.
Note: Electrostatic discharge (ESD) can damage your processor, disk drives, expansion boards,
and other components. Always observe the following precautions before you install a system
component.
1. Do not remove a component from its protective packaging until you are ready to install it.
2. Wear a wrist ground strap and attach it to a metal part of the system unit before handling a
component. If a wrist strap is not available, maintain contact with the system unit throughout
any procedures requiring ESD protection.
