Apache Buffalo Sound MP3-321 User manual

BuffaloSound
MP3Player
Model:MP3-321/331/341
Digital MP3Player
User'sGuide
PDFcreated withpdfFactoryProtrialversion www.pdffactory.com

1
TableofContents
1.Player Overview
2.Accessories
3.Quick StartGuide---Menu mode
4.Functionandoperation
4.1PowerOn/Off &MP3/WMAplayback
4.2VoiceRecording operation
4.3FMRadio
4.4SettingsEQ(Equalizer)
4.5Repeat mode &A-Brepeat section
4.6ToDeleteFiles
4.7Setting mode
4.7-1The LCD Contrast setting
4.7-2The Backlight setting
4.7-3IdleTimesetting
4.7-4SettingVoice RecordingParameter
4.7-5ID3 DisplayLanguage support setting
4.8MemoryInformation display
4.9USB Connect tocomputer
4.10 Hot Keydescription-KeyLock &PowerLock
5.Install Driver
5.1Windows98 / 98SE Installation
IMPORTANTNOTICES
Disclaimer
Technical Specifications
PDFcreated withpdfFactoryProtrialversion www.pdffactory.com

2
1. PlayerOverview
A. Key Function:
B. Display &IconList:
REC/A-B
MODE
Volume
-
Volume +
EQ
Repeatmode
Battery
Status
Play Mode
(MP3/WMA/VOICE)
Play/Stop/
Pause
Play/Record Time
Selection
Songname
A
-
B
FF
Rew
Play Key
(PowerOn/Off
Play/Pause)
Volume
PDFcreated withpdfFactoryProtrialversion www.pdffactory.com

3
2.Accessories
AAABattery (Alkaline)Earphone
DriverDiscUSB Cable
Manual
PDFcreated withpdfFactoryProtrialversion www.pdffactory.com

4
3. Quick StartGuide
Menumode:
Menu
MusicPlaymode MusicMP3/WMAformat(Standard)
VoicePlaymode VoicechooseWAVEformat.
FMRadio
VoiceRecording
EQmode
NORM
ROCK
JAZZ
CLASS
POP
Exit
Repeatmode No repeat, allmusicplayoncethen stop
Repeat 1, repeat singlemusic.
Repeat all,repeat all musicinsequence.
Random, playallmusiconcerandomly
Randomrepeat,repeat allmusicrandomly
Exit
Deletemode DeleteMusicfile/
Delete1 format
DeleteVoicefile/
Delete1 format
Exit
Setting mode Contrast (0-9)
Back Light(10/20/30/60/ON/OFF)
IDELTime(OFF/3/5/30)
Voicequalitysetting(8K,11.025K, 16K, 22.05K, 32K)
Language(English/T-Chinese/S-Chinese/ German/
French/ Spanish/ Italian/ Japanese/ Korean)
Exit
Information mode
Exit
PDFcreated withpdfFactoryProtrialversion www.pdffactory.com

5
4. Function&Operation
4.1MP3/WMAPlayback
(1)Press 3secondson PlayKeytoturnonthe player.LCD displaysasbelow:
---à--à--à--à
(2)Poweroff: Press playbottomfor3seconds
321OFF
(3)If therearealreadyMP3orWMAfilesinthe FlashMemory,the LCD will showthe musicfilename.
Tobeginthe playbackof MP3orWMAfile,press againPlayKey.
(4)Volume: Press volumebutton toadjustvoicevolume
4.2Voice RecordingOperation
(1)Press 3secondson PlayKeytoturnon theplayer
(2)Press RECtostart recording
(3)Press againRECtostop record.
(4)Press PlayKeytoplaythe previousrecorded WAVfiles
4.3FMRadio
Press Modeand choosethe FMfunction and press againtoenterthe FM.Thepanelwill displayas
below
(1) Tosave theFMchannel (Totalsave20 channels): PressRECfor1second toselectthe channel. Use
and tochoosethe channelfromCH 1~20. If youwant tosavepress PlayKeyagaintosave
the channel.If not press the Modetocancelthe selection.
(2) Selectthepresetchannel: press the RECtoselectthechannel.
(3) FMrecording: Press RECfor2secondswill enterthe recording function. When finishrecording.The
filewillsaveasFM/Fxxx.WAVformat.
OnlyFM(Fxxx.WAV) recording formatcan playinMusicmode.
PDFcreated withpdfFactoryProtrialversion www.pdffactory.com

6
4.4SettingEQ (Equalizer)
(1)Press Modeand chooseEQmode.Press Modeagaintoenterthesub-menu.
(2)Selectthe following settings:
àààà
Press Modeagainforconfirmation,then the icon willshowon the display.
4.5Repeatmode&A-Brepeatsection
(1)Press Modeand chooseRepeat mode.Press Modeagaintoenterthe
sub-menu.
(2)Selectthe following settings:
l àààà
Press Modeagainforconfirmation,then the icon willshowon the display.
(3)During playback press RECtoenterthe repeat readmode.
The startpointAwillbe marked.Then press RECbottom
againthe ”A-B”icon willshowon the display-à
4.6To DeleteFiles
(1)Press Modeand chooseDeletemode. Press Modeagaintoenterthe sub-menu.
(2)Selectthe following settings:
à/ à/
Press Modeagainforconfirmation,then the icon willshowon the display.
4.7SettingMode
(1)Press Modeand chooseSetting mode.Press Modeagaintoenterthesub-menu.
4.7-1Contrast: set the degree oflightness (0~9).
4.7-2The Backlight sixchoices: 10/20/30/60secondsorON/OFF.
4.7-3IdleTime:3/5/30minutesorOFF.
4.7-4VoiceRecordbit-rate: , , , ,
4.7-5Multi-Language Displaysupport:
(English/T-Chinese/S-Chinese/ German/French/ Spanish/ Italian/Japanese/ Korean)
(2)Selectthe following settings:
àààààà
Press Modeagainforconfirmation,then the icon willshowon the display.
4.8Memory Informationdisplay
(1)Press Modeand chooseInformation mode.Press Modeagaintoenter
the setting.
(2)Icon display:
Press Modeagain, and the displaywillshowas-à
PDFcreated withpdfFactoryProtrialversion www.pdffactory.com

7
4.9USBConnecttoComputer
(1)Usethe USB cabletoconn
ecttoPC’sUSB port.The displaywillshowas
--à
(2)During USBoperations(including connection withPC,filecopy/ delete,
FlashMemoryformat),The displayshowas--à
4.10 HotKey description
(1)KeyLock:
Press both “volume+ “and “volume- “tolockall keys.
(2)PowerLock:
Press andholdboth “volume+ “and “Play “bottom. You can
not turnon the powerwhen the powerfunction islocked.
You havetopress and holdbothbottomsagaintounlock
the power.
PDFcreated withpdfFactoryProtrialversion www.pdffactory.com

8
5. Howtoinstall driver
Declare:
Suggest toPlaywithMultiPlayer. Pleaseupgrade abovetoWindows2000 SP4
version.
5.1Windows98/98SEInstallation：
(1)Plug MultiPlayerintoUSBport. Systemwilldetect one newhardwareand searchforproperdriverto
install.
(2)Choosethe first recommend toinstall.
MultiPlayerUSB Device
PDFcreated withpdfFactoryProtrialversion www.pdffactory.com

9
(3)Choosesetting up from “Specifyalocation”and selectthe CD ROM. Press “Next”tocontinue.
(4)Toexecuteinstallation bypress “Next”.
(5)Press “Finish”tocompleteinstallation.
MultiPlayerUSB Device
PDFcreated withpdfFactoryProtrialversion www.pdffactory.com

10
ImportantNotice
(i)Beforeunplug MultiPlayerfromtheUSB port in WindowsME/2000/XP, makesureyou go tothe
right hand bottomof the screen tostop the USB device. Otherwise, it mayresultinlosing datathat
you havesaved on MultiPlayer.
(ii)It maycausedevicedamage if you putbatteryincorrect.
Disclaimer
Allthe information inthisdocumentissubjecttochange withoutpriornotice.The manufacturerdoesnotmake
anyrepresentationsoranywarranties(impliedorotherwise)regarding theaccuracyand completeness ofthis
documentand shallinno eventbeliableforanyloss ofprofitoranyothercommercial damage,including butnot
limited tospecial,incidental,consequential,orotherdamages.
No partofthisdocumentmaybe reproduced ortransmitted inanyformbyanymeanswithoutthe express
written permission ofthe manufacturer.
Allbrand namesand productnamesused inthisdocumentaretrademarksorregistered trademarksoftheir
respectiveholders.
Technical Specifications
Memorysize 128MB/ 256MB/ 512MB
Battery AAA (AlkalineRecommended)
LCD Display 30(L)x13(H)mm
Size 70 x42 x15 mm
Earphone Power 10mW+10mW
Supporting Frequency 20Hz –20KHz
MP3SupportingBit Rate 32K~320Kbps
WMASupporting Bit Rate 20K~192Kbps
MusicFormat MP3,WMA
RecordFormat ADPCM(WAV)
USB Type 2.0version
ID3Language (English/T-Chinese/S-Chinese/ German/French/
Spanish/ Italian/ Japanese/ Korean)
