APDM Opal V2R User manual

1
Motion Studio
V2R
Version 2
April, 2019

2
WELCOME
to Motion Studio
Motion Studio provides an easy way to collect data with your Opal System.
Features include advanced conguration, recording, data management, calibration,
and real-time visualization.
