Apricus OG-300 User manual

OG-300 External Brazed Plate Heat Exchanger
Solar Hot Water Systems
Schematics and Parts Lists
(Revision 1.0 - May 2011)
IMPORTANT INFORMATION
Diagrams are conceptual only and not to scale.!Final system design must adhere to all relevant codes,
regulations and guidelines and may require the approval and stamp of a licensed engineer. It is the
responsibility of the installer/contractor to ensure that the system design meets all relevant standards,
regulations and guidelines and is safe and operating correctly. Any installer/contractor must be legally
certified to install solar water heating systems and have attended an accredited Apricus training
session before completing the installation of any Apricus products.
The installation of Apricus products must be in accordance with guidelines outlined in the latest version
of the Apricus installation manual.!For the latest version of the manual contact your local Apricus
agent or email offi[email protected].

Table of Contents
......................................................................................................................................Naming Convention Overview!1
...............................................................................................................................................................Symbol Guide!2
.........................................................................................System Schematic: APSS_CLOSED_BPHE_AP30_FTD-E!3
.........................................................................................System Schematic: APSS_CLOSED_BPHE_AP60_FTD-E!3
...................................................................................System Schematic: APSS_CLOSED_BPHE_AP30_DT-FTD-E!5
...................................................................................System Schematic: APSS_CLOSED_BPHE_AP60_DT-FTD-E!5
.........................................................................System Schematic: APSS_CLOSED_BPHE_AP30_DT-FTD_STD-E!7
.........................................................................System Schematic: APSS_CLOSED_BPHE_AP60_DT-FTD_STD-E!7
.........................................................................System Schematic: APSS_CLOSED_BPHE_AP30_DT-FTD_STD-G!9
.........................................................................System Schematic: APSS_CLOSED_BPHE_AP60_DT-FTD_STD-G!9
...............................................................................System Schematic: APSS_CLOSED_BPHE_AP30_FTD_TBGT!11
...............................................................................System Schematic: APSS_CLOSED_BPHE_AP60_FTD_TBGT!11
.........................................................................System Schematic: APSS_CLOSED_BPHE_AP30_DT-FTD_TBGT!13
.........................................................................System Schematic: APSS_CLOSED_BPHE_AP60_DT-FTD_TBGT!13
...............................................................................System Schematic: APSS_CLOSED_BPHE_AP30_FTD_PBGT!15
...............................................................................System Schematic: APSS_CLOSED_BPHE_AP60_FTD_PBGT!15
.........................................................................System Schematic: APSS_CLOSED_BPHE_AP30_DT-FTD_PBGT!17
.........................................................................System Schematic: APSS_CLOSED_BPHE_AP60_DT-FTD_PBGT!17

Naming Convention Overview
Apricus uses the following format coding to describe the systems in this document:
NAME_TYPE_EXHE_TUBE_1STTANK_2NDTANK_EXTBOOST
The following information describes the different options.
NAME: This describes the type of system
!
!APSS - Apricus solar system
TYPE: This describes the type of system being installed
!DIRECT !! - Direct flow solar thermal system
!CLOSED !- Closed loop solar thermal system
EXHE1: This describes the type of external heat exchanger
!BPHE! ! - Dual wall brazed plate heat exchanger with leak detection
TUBE: This describes the number of tubes installed
!AP-30! ! - One AP-30 collector with 30 tubes total
!AP-60! ! - Two AP-30 collectors with 60 tubes total
1stTANK: This describes the type of tank the solar thermal system is connected to
!FTD! ! - Direct flow tank (no heat exchanger)
!FTB! ! - Internal coil tank
!FTW! ! - Dual internal coil tank
!DT-XXX!! - Tank has a dip tube solar connection
!XXX-E! ! - Tank has an electric element
2ndTANK1: This describes the second tank in series in the solar thermal system
!STD-E! ! - Standard electric water heater
!STD-G! ! - Standard gas water heater
EXTBOOST1: This describes the type of external auxiliary heating
!PBGT! ! - Tankless water heater
!TBGT! ! - Top boosted by pumped tankless water heater
!TBGB! ! - Top boosted by indirect boiler
Example:
APSS_CLOSED_BPHE_AP30-DT-FTD-PBGT:
!Apricus closed loop solar thermal system with external heat exchanger, one AP-30 with a dip tube connection to a standard tank
feeding a tankless water heater.
Notes:
1. Depending on the type of system this position may not be filled.
Copyright © 2010 - Apricus Inc. Doc: A7-05.4.10-PB-1.0 Page 1 of 43

Symbol Guide
System Symbols used in Diagrams
Air Vent
Drain Valve
Drain Valve (on tank)
Flow Meter
Check Valve
Ball Valve
Circulation Pump
Anti-scald Valve
3 Way Solenoid Valve
Expansion Tank
T = 180$C / 360$F
P
=10 bar / 150 psi
Quick-connect Fitting
Temperature & Pressure Relief Valve
Pressure Relief Valve
Copyright © 2010 - Apricus Inc. Doc: A7-05.4.10-PB-1.0 Page 2 of 43

System Schematic: APSS_CLOSED_BPHE_AP30_FTD-E
System Schematic: APSS_CLOSED_BPHE_AP60_FTD-E
T = 180$C / 360$F P
=10bar / 150 psi
T1
n/o n/o
T3
T2
GRUNDFOS
!"#$%&
'
() () *+*+*,-
('+* +*+*,-+ (.+* +*+*,-+ /)+* +*+*+0+ /1+* +*+*+0
('++++++++++++(.
GRUNDFOS
Isolation Valves: n/o Drain valves: n/c
Cold In Hot Out
n/o
Copyright © 2009 Apricus Solar Co., Ltd
Notes
Suggested Controller Settings (refer also to controller manual)
n/c = valve normally closed n/o = valve normally open
IMPORTANT
System schematics are provided as a guide only. Apricus does not guarantee schematic accuracy, that they meet your customers requirements or adhere to local code. Any systems designed and installed must adhere to local codes and regulations, and may need to be approved by a licensed engineer, and che cked by a plu mbin g ins pect or pr ior t o commissioning. Please contact your local authorities for more information.
Revision: 1.5 Creation Date: 29th July 09 Drawing By: MH 1. Auto Air vent can be removed after initial bleeding. 2. May be required by local regulations. Always required if check valve installed on cold supply line. 3. Element should be set to operate based on thermostatic settings of the controller.
Note 1
Note 2
Note 3
Apricus AP-30 Solar Collector
5
Description
3 4 Solar Ready Storage Tank
High Amp Relay for Electrical Element Apricus Brazed Plate Heat Exchanger Kit (Double Wall with P2) Apricus Closed Loop Pump Station with P1
1 2
No.
Control System Setting: 1 Function Settings Protection Functions - Max Temp = no - Cooling = no - Overheat protection = no - Freeze protection = yes (-40oF) Flow Meter = enter flow rate (gal/min) Pump P1 = PhAC SC Setting Menu Maxtemp tank1 = 176oF dtMax tank1 = 20oF dtMin tank1 = 5oF Min rev pump = 50% Mintemp Collector = 85oF Extra Functions Thermostat Function - Start = 125oF - Hysteresis = 30oF
4
5
2
3
1
Copyright © 2010 - Apricus Inc. Doc: A7-05.4.10.2-PB-1.0 Page 3 of 43

OG300 Parts List
System
APSS_CLOSED_BPHE_AP30_FTD-E
APSS_CLOSED_BPHE_AP60_FTD-E
Collector
Apricus AP-30
2x Apricus AP-30
Pump
P1: Grundfos UPS 15-58FC
P2: Grundfos UPS 15-29SF
P1: Grundfos UPS 15-58FC
P2: Grundfos UPS 15-29SF
Controller
Watts Radiant Solar Control
Watts Radiant Solar Control
Tank
A.O.Smith ProMax SUN-80
Bradford White Solar Saver MS80R6SS
Rheem Solaraide 81VR80-1
A.O.Smith ProMax SUN-120
Bradford White Solar Saver MS120R6SS
Rheem Solaraide 81VR120-1
Expansion Tank
Watts Radiant ETX 30
Watts Radiant ETX 30
Expansion Tank
Watts PLT-12 (Potable Water)
Watts PLT-12 (Potable Water)
Heat Exchanger
Hrale B3-14DW-12-3.0 (Dual Wall)
Hrale B3-14DW-12-3.0 (Dual Wall)
Heat Transfer
Fluid
Whitlam Solar Hi-Temp
Dowfrost HD
Clariant SOL HT
Whitlam Solar Hi-Temp
Dowfrost HD
Clariant SOL HT
Piping
Copper or Stainless Steel
Copper or Stainless Steel
Check Valve
NSF/CSA Approved 3/4” Valve
NSF/CSA Approved 3/4” Valve
Mixing Valve
NSF/CSA Approved 3/4” Anti-Scald Valve
NSF/CSA Approved 3/4” Anti- Scald Valve
Pressure Relief
Valve
Watts 3/4” Pressure Relief Valve, 75psi
Watts 3/4” Pressure Relief Valve, 75psi
Insulation
Outdoor: UV protected 7/8x1” Closed Cell
EPDM Insulation >R-3.6
Indoor: 7/8x1” Closed Cell EPDM Insulation
>R3.6
Outdoor: UV protected 7/8x1” Closed Cell
EPDM Insulation >R-3.6
Indoor: 7/8x1” Closed Cell EPDM Insulation
>R3.6
Air Vent
Watts Regulator HAV Air Vent
Watts Regulator Air Vent
Isolation Valve
Watts 600/800 WOG
Watts 600/800 WOG
Drain Valve
Watts Radiant Drain Valve
Watts Radiant Drain Valve
Flow Control
Valve
Watts Radiant Flow Guard
Watts Radiant Flow Guard
Instrumentation
Watts Radiant DPTG-3 Temperature &
Pressure Gauge
Watt Radiant DPTG-3 Temperature &
Pressure Gauge
Copyright © 2010 - Apricus Inc. Doc: A7-05.4.10.2-PB-1.0 Page 4 of 43

System Schematic: APSS_CLOSED_BPHE_AP30_DT-FTD-E
System Schematic: APSS_CLOSED_BPHE_AP60_DT-FTD-E
T = 180$C / 360$F P
=10bar / 150 psi
T1
n/o n/o
T3
T2
GRUNDFOS
!"#$%&
'
() () *+*+*,-
('+* +*+*,-+ (.+* +*+*,-+ /)+* +*+*+0+ /1+* +*+*+0
('++++++++++++(.
GRUNDFOS
Isolation Valves: n/o Drain valves: n/c
Cold In Hot Out
n/o
Copyright © 2009 Apricus Solar Co., Ltd
Notes
Suggested Controller Settings (refer also to controller manual)
System Code:
n/c = valve normally closed n/o = valve normally open
IMPORTANT
System schematics are provided as a guide only. Apricus does not guarantee schematic accuracy, that they meet your customers requirements or adhere to local code. Any systems designed and installed must adhere to local codes and regulations, and may need to be approved by a licensed engineer, and chec ked b y a plum bing i nspe cto r p rio r to commissioning. Please contact your local authorities for more information.
Revision: 1.5 Creation Date: 29th July 09 Drawing By: MH 1. Auto Air vent can be removed after initial bleeding. 2. May be required by local regulations. Always required if check valve installed on cold supply line. 3. Element should be set to operate based on thermostatic settings of the controller.
Note 1
Note 2
Note 3
Apricus AP-30 Solar Collector
5
Description
3 4 Solar Ready Storage Tank
High Amp Relay for Electrical Element Apricus Brazed Plate Heat Exchanger Kit (Double Wall with P2) Apricus Closed Loop Pump Station with P1
1 2
No.
Control System Setting: 1 Function Settings Protection Functions - Max Temp = no - Cooling = no - Overheat protection = no - Freeze protection = yes (-40oF) Flow Meter = enter flow rate (gal/min) Pump P1 = PhAC SC Setting Menu Maxtemp tank1 = 176oF dtMax tank1 = 20oF dtMin tank1 = 5oF Min rev pump = 50% Mintemp Collector = 85oF Extra Functions Thermostat Function - Start = 125oF - Hysteresis = 30oF
4
5
2
3
1
Copyright © 2010 - Apricus Inc. Doc: A7-05.4.10.2-PB-1.0 Page 5 of 43

OG300 Parts List
System
APSS_CLOSED_BPHE_AP30_DT-FTD-E
APSS_CLOSED_BPHE_AP60_DT-FTD-E
Collector
Apricus AP-30
2x Apricus AP-30
Pump
P1: Grundfos UPS 15-58FC
P2: Grundfos UPS 15-29SF
P1: Grundfos UPS 15-58FC
P2: Grundfos UPS 15-29SF
Controller
Watts Radiant Solar Control
Watts Radiant Solar Control
Tank
American #SE62-80H-045S
A.O.Smith ProMax SUN-80
Bradford White Solar Saver MS80R6SS
Rheem Solaraide 81VR80TC-1
American #SE62-119R-045S
A.O.Smith ProMax SUN-120
Bradford White Solar Saver MS120R6SS
Rheem Solaraide 81VR120TC-1
Expansion Tank
Watts Radiant ETX 30
Watts Radiant ETX 30
Expansion Tank
Watts PLT-12 (Potable Water)
Watts PLT-12 (Potable Water)
Heat Exchanger
Hrale B3-14DW-12-3.0 (Dual Wall)
Hrale B3-14DW-12-3.0 (Dual Wall)
Heat Transfer
Fluid
Whitlam Solar Hi-Temp
Dowfrost HD
Clariant SOL HT
Whitlam Solar Hi-Temp
Dowfrost HD
Clariant SOL HT
Piping
Copper or Stainless Steel
Copper or Stainless Steel
Check Valve
NSF/CSA Approved 3/4” Valve
NSF/CSA Approved 3/4” Valve
Mixing Valve
NSF/CSA Approved 3/4” Anti-Scald Valve
NSF/CSA Approved 3/4” Anti- Scald Valve
Pressure Relief
Valve
Watts 3/4” Pressure Relief Valve, 75psi
Watts 3/4” Pressure Relief Valve, 75psi
Insulation
Outdoor: UV protected 7/8x1” Closed Cell
EPDM Insulation >R-3.6
Indoor: 7/8x1” Closed Cell EPDM Insulation
>R3.6
Outdoor: UV protected 7/8x1” Closed Cell
EPDM Insulation >R-3.6
Indoor: 7/8x1” Closed Cell EPDM Insulation
>R3.6
Air Vent
Watts Regulator HAV Air Vent
Watts Regulator Air Vent
Isolation Valve
Watts 600/800 WOG
Watts 600/800 WOG
Drain Valve
Watts Radiant Drain Valve
Watts Radiant Drain Valve
Flow Control
Valve
Watts Radiant Flow Guard
Watts Radiant Flow Guard
Instrumentation
Watts Radiant DPTG-3 Temperature &
Pressure Gauge
Watt Radiant DPTG-3 Temperature &
Pressure Gauge
Copyright © 2010 - Apricus Inc. Doc: A7-05.4.10.2-PB-1.0 Page 6 of 43

System Schematic: APSS_CLOSED_BPHE_AP30_DT-FTD_STD-E
System Schematic: APSS_CLOSED_BPHE_AP60_DT-FTD_STD-E
T = 180$C / 360$F P
=10bar / 150 psi
T1
n/o
T3
T2
n/o
n/o
Cold In Hot Out
n/c
n/o
n/o
GRUNDFOS
!"#$%&
'
() () *+*+*,-
('+* +*+*,-+ (.+* +*+*,-+ /)+* +*+*+0+ /1+* +*+*+0
('++++++++++++(.
GRUNDFOS
Isolation Valves: n/o Drain valves: n/c
Copyright © 2009 Apricus Solar Co., Ltd
Notes
Suggested Controller Settings (refer also to controller manual)
System Code:
n/c = valve normally closed n/o = valve normally open
IMPORTANT
System schematics are provided as a guide only. Apricus does not guarantee schematic accuracy, that they meet your customers requirements or adhere to local code. Any systems designed and installed must adhere to local codes and regulations, and may need to be approved by a licensed engineer, and che cke d by a pl umbing in spe cto r pri or to commissioning. Please contact your local authorities for more information.
Revision: 1.3 Creation Date: 29th July 09 Drawing By: MH
APSS_CLOSED_BPHE_AP_DT-FTD_STD-E
1. Auto Air vent can be removed after initial bleeding. 2. May be required by local regulations. Always required if check valve installed on cold supply line. 3. Use cold dip tube and cut to about 3/4 original length.
Note 1
Note 2
Apricus AP-30 Solar Collector
5
Description
3 4 Storage Tank
Existing Electric Water Heater (standard boosting) Apricus Brazed Plate Heat Exchanger Kit (SW or DW) Apricus Closed Loop Pump Station
1 2
No.
Control System Setting: 1 Function Settings Protection Functions - Max Temp = no - Cooling = no - Overheat protection = no - Freeze protection = yes (-40oF) Flow Meter = enter flow rate (gal/min) Pump P1 = PhAC SC Setting Menu Maxtemp tank1 = 176oF dtMax tank1 = 20oF dtMin tank1 = 5oF Min rev pump = 50% Mintemp Collector = 85oF
45
2
3
1
Note 3
Tank Inlet
Apricus Closed Loop Pump Station with P1 Apricus Brazed Plate Heat Exchanger Kit (Double Wall with P2)
Copyright © 2010 - Apricus Inc. Doc: A7-05.4.10.2-PB-1.0 Page 7 of 43

OG300 Parts List
System
APSS_CLOSED_BPHE_AP30_DT-FTD_STD-E
APSS_CLOSED_BPHE_AP60_DT-FTD_STD-E
Collector
Apricus AP-30
2x Apricus AP-30
Pump
P1: Grundfos UPS 15-58FC
P2: Grundfos UPS 15-29SF
P1: Grundfos UPS 15-58FC
P2: Grundfos UPS 15-29SF
Controller
Watts Radiant Solar Control
Watts Radiant Solar Control
Tank
American #SE62-80H-045S
A.O.Smith ProMax SUN-80
Bradford White Solar Saver MS80R6SS
Rheem Solaraide 81VR80TC-1
American #SE62-119R-045S
A.O.Smith ProMax SUN-120
Bradford White Solar Saver MS120R6SS
Rheem Solaraide 81VR120TC-1
Expansion Tank
Watts Radiant ETX 30
Watts Radiant ETX 30
Expansion Tank
Watts PLT-12 (Potable Water)
Watts PLT-12 (Potable Water)
Heat Exchanger
Hrale B3-14DW-12-3.0 (Dual Wall)
Hrale B3-14DW-12-3.0 (Dual Wall)
Heat Transfer
Fluid
Whitlam Solar Hi-Temp
Dowfrost HD
Clariant SOL HT*
Whitlam Solar Hi-Temp
Dowfrost HD
Clariant SOL HT*
Piping
Copper or Stainless Steel
Copper or Stainless Steel
Check Valve
NSF/CSA Approved 3/4” Valve
NSF/CSA Approved 3/4” Valve
Mixing Valve
NSF/CSA Approved 3/4” Anti-Scald Valve
NSF/CSA Approved 3/4” Anti- Scald Valve
Pressure Relief
Valve
Watts 3/4” Pressure Relief Valve, 75psi
Watts 3/4” Pressure Relief Valve, 75psi
Insulation
Outdoor: UV protected 7/8x1” Closed Cell EPDM
Insulation >R-3.6
Indoor: 7/8x1” Closed Cell EPDM Insulation >R3.6
Outdoor: UV protected 7/8x1” Closed Cell EPDM
Insulation >R-3.6
Indoor: 7/8x1” Closed Cell EPDM Insulation >R3.6
Air Vent
Watts Regulator HAV Air Vent
Watts Regulator Air Vent
Isolation Valve
Watts 600/800 WOG
Watts 600/800 WOG
Drain Valve
Watts Radiant Drain Valve
Watts Radiant Drain Valve
Flow Control
Valve
Watts Radiant Flow Guard
Watts Radiant Flow Guard
Instrumentation
Watts Radiant DPTG-3 Temperature & Pressure
Gauge
Watt Radiant DPTG-3 Temperature & Pressure Gauge
Copyright © 2010 - Apricus Inc. Doc: A7-05.4.10.2-PB-1.0 Page 8 of 43

System Schematic: APSS_CLOSED_BPHE_AP30_DT-FTD_STD-G
System Schematic: APSS_CLOSED_BPHE_AP60_DT-FTD_STD-G
T = 180$C / 360$F P
=10bar / 150 psi
T1
n/o
T3
T2
n/o
n/o
Cold In Hot Out
n/c
n/o
n/o
GRUNDFOS
!"#$%&
'
() () *+*+*,-
('+* +*+*,-+ (.+* +*+*,-+ /)+* +*+*+0+ /1+* +*+*+0
('++++++++++++(.
GRUNDFOS
Isolation Valves: n/o Drain valves: n/c
Copyright © 2009 Apricus Solar Co., Ltd
Notes
Suggested Controller Settings (refer also to controller manual)
System Code:
n/c = valve normally closed n/o = valve normally open
IMPORTANT
System schematics are provided as a guide only. Apricus does not guarantee schematic accuracy, that they meet your customers requirements or adhere to local code. Any systems designed and installed must adhere to local codes and regulations, and may need to be approved by a licensed engineer, and che cked b y a plu mbin g ins pec t or pr ior t o commissioning. Please contact your local authorities for more information.
Revision: 1.3 Creation Date: 29th July 09 Drawing By: MH
APSS_CLOSED_BPHE_AP_DT-FTD_STD-G
1. Auto Air vent can be removed after initial bleeding. 2. May be required by local regulations. Always required if check valve installed on cold supply line. 3. Use cold dip tube and cut to about 3/4 original length.
Note 1
Note 2
Apricus AP-30 Solar Collector
5
Description
3 4 Storage Tank
Existing GasWater Heater (standard boosting) Apricus Brazed Plate Heat Exchanger Kit (SW or DW) Apricus Closed Loop Pump Station
1 2
No.
Control System Setting: 1 Function Settings Protection Functions - Max Temp = no - Cooling = no - Overheat protection = no - Freeze protection = yes (-40oF) Flow Meter = enter flow rate (gal/min) Pump P1 = PhAC SC Setting Menu Maxtemp tank1 = 176oF dtMax tank1 = 20oF dtMin tank1 = 5oF Min rev pump = 50% Mintemp Collector = 85oF
45
2
3
1
Note 3
Tank Inlet
Apricus Closed Loop Pump Station with P1 Apricus Brazed Plate Heat Exchanger Kit (Double Wall with P2)
Copyright © 2010 - Apricus Inc. Doc: A7-05.4.10.2-PB-1.0 Page 9 of 43

OG300 Parts List
System
APSS_CLOSED_BPHE_AP30_DT-FTD_STD-G
APSS_CLOSED_BPHE_AP60_DT-FTD_STD-G
Collector
Apricus AP-30
2x Apricus AP-30
Pump
P1: Grundfos UPS 15-58FC
P2: Grundfos UPS 15-29SF
P1: Grundfos UPS 15-58FC
P2: Grundfos UPS 15-29SF
Controller
Watts Radiant Solar Control
Watts Radiant Solar Control
Tank
American #SE62-80H-045S
A.O.Smith ProMax SUN-80
Bradford White Solar Saver MS80R6SS
Rheem Solaraide 81VR80TC-1
American #SE62-119R-045S
A.O.Smith ProMax SUN-120
Bradford White Solar Saver MS120R6SS
Rheem Solaraide 81VR120TC-1
Expansion Tank
Watts Radiant ETX 30
Watts Radiant ETX 30
Expansion Tank
Watts PLT-12 (Potable Water)
Watts PLT-12 (Potable Water)
Heat Exchanger
Hrale B3-14DW-12-3.0 (Dual Wall)
Hrale B3-14DW-12-3.0 (Dual Wall)
Heat Transfer
Fluid
Whitlam Solar Hi-Temp
Dowfrost HD
Clariant SOL HT*
Whitlam Solar Hi-Temp
Dowfrost HD
Clariant SOL HT*
Piping
Copper or Stainless Steel
Copper or Stainless Steel
Check Valve
NSF/CSA Approved 3/4” Valve
NSF/CSA Approved 3/4” Valve
Mixing Valve
NSF/CSA Approved 3/4” Anti-Scald Valve
NSF/CSA Approved 3/4” Anti- Scald Valve
Pressure Relief
Valve
Watts 3/4” Pressure Relief Valve, 75psi
Watts 3/4” Pressure Relief Valve, 75psi
Insulation
Outdoor: UV protected 7/8x1” Closed Cell EPDM
Insulation >R-3.6
Indoor: 7/8x1” Closed Cell EPDM Insulation >R3.6
Outdoor: UV protected 7/8x1” Closed Cell EPDM
Insulation >R-3.6
Indoor: 7/8x1” Closed Cell EPDM Insulation >R3.6
Air Vent
Watts Regulator HAV Air Vent
Watts Regulator Air Vent
Isolation Valve
Watts 600/800 WOG
Watts 600/800 WOG
Drain Valve
Watts Radiant Drain Valve
Watts Radiant Drain Valve
Flow Control
Valve
Watts Radiant Flow Guard
Watts Radiant Flow Guard
Instrumentation
Watts Radiant DPTG-3 Temperature & Pressure
Gauge
Watt Radiant DPTG-3 Temperature & Pressure Gauge
Copyright © 2010 - Apricus Inc. Doc: A7-05.4.10.2-PB-1.0 Page 10 of 43

System Schematic: APSS_CLOSED_BPHE_AP30_FTD_TBGT
System Schematic: APSS_CLOSED_BPHE_AP60_FTD_TBGT
T = 180$C / 360$F P
=10bar / 150 psi
T1
n/o n/o
T3
T2
GRUNDFOS
Gas
Tankless
Water
Heater
℃50.5
Gas Supply
n/o
n/o
Cold In Hot Out
n/o
!"#$%&
'
() () *+*+*,-
('+* +*+*,-+ (.+* +*+*,-+ /)+* +*+*+0+ /1+* +*+*+0
('++++++++++++(.
GRUNDFOS
Isolation Valves: n/o Drain valves: n/c
Copyright © 2009 Apricus Solar Co., Ltd
Notes
Suggested Controller Settings (refer also to controller manual)
System Code:
n/c = valve normally closed n/o = valve normally open
IMPORTANT
System schematics are provided as a guide only. Apricus does not guarantee schematic accuracy, that they meet your customers requirements or adhere to local code. Any systems designed and installed must adhere to local codes and regulations, and may need to be approved by a licensed engineer, and che cked b y a plu mbin g ins pec t or pr ior t o commissioning. Please contact your local authorities for more information.
Revision: 1.3 Creation Date: 29th July 09 Drawing By: MH
APSS_CLOSED_BPHE_AP_FTD_TBGT
1. Auto Air vent can be removed after initial bleeding. 2. May be required by local regulations. Always required if check valve installed on cold supply line. 3. Tankless water heater should be set to 140oF to ensure water is hot enough to kill Legionella bacteria.
Note 1
Note 2
Gas Tankless Water Heater (solar ready)6 Apricus AP-30 Solar Collector
5
Description
3 4 Solar Ready Storage Tank
Single Speed Potable Water Circulation Pump Apricus Brazed Plate Heat Exchanger Kit (SW or DW) Apricus Closed Loop Pump Station
1 2
No.
1
2
3
4
5
Control System Setting: 1 Function Settings Protection Functions - Max Temp = no - Cooling = no - Overheat protection = no - Freeze protection = yes (-40oF) Flow Meter = enter flow rate (gal/min) Pump P1 = PhAC SC Setting Menu Maxtemp tank1 = 176oF dtMax tank1 = 20oF dtMin tank1 = 5oF Min rev pump = 50% Mintemp Collector = 85oF Extra Functions Thermostat Function - Start = 125oF - Hysteresis = 30oF
6
Note 3
Tank Inlet
P3
Apricus Closed Loop Pump Station with P1 Apricus Brazed Plate Heat Exchanger Kit (Double Wall with P2)
Copyright © 2010 - Apricus Inc. Doc: A7-05.4.10.2-PB-1.0 Page 11 of 43

OG300 Parts List
System
APSS_CLOSED_BPHE_AP30_FTD_TBGT
APSS_CLOSED_BPHE_AP60_FTD_TBGT
Collector
Apricus AP-30
2x Apricus AP-30
Pump
P1: Grundfos UPS 15-58FC
P2: Grundfos UPS 15-29SF
P3: Grundfos UP 15-100F
P1: Grundfos UPS 15-58FC
P2: Grundfos UPS 15-29SF
P3: Grundfos UP 15-100F
Controller
Watts Radiant Solar Control
Watts Radiant Solar Control
Tank
A.O.Smith ProMax SUN-80
Bradford White Solar Saver MS80R6SS
Rheem Solaraide 81VR80-1
A.O.Smith ProMax SUN-120
Bradford White Solar Saver MS120R6SS
Rheem Solaraide 81VR120-1
Tankless Heater
Quietside ODW-99A
Takagi T-Kjr.
Takagi T-H1
Takagi T-K3-SP
Expansion Tank
Watts Radiant ETX 30
Watts Radiant ETX 30
Expansion Tank
Watts PLT-12 (Potable Water)
Watts PLT-12 (Potable Water)
Heat Exchanger
Hrale B3-14DW-12-3.0 (Dual Wall)
Hrale B3-14DW-12-3.0 (Dual Wall)
Heat Transfer
Fluid
Whitlam Solar Hi-Temp
Dowfrost HD
Clariant SOL HT
Whitlam Solar Hi-Temp
Dowfrost HD
Clariant SOL HT
Piping
Copper or Stainless Steel
Copper or Stainless Steel
Check Valve
NSF/CSA Approved 3/4” Valve
NSF/CSA Approved 3/4” Valve
Mixing Valve
NSF/CSA Approved 3/4” Anti-Scald Valve
NSF/CSA Approved 3/4” Anti- Scald Valve
Pressure Relief
Valve
Watts 3/4” Pressure Relief Valve, 75psi
Watts 3/4” Pressure Relief Valve, 75psi
Insulation
Outdoor: UV protected 7/8x1” Closed Cell
EPDM Insulation >R-3.6
Indoor: 7/8x1” Closed Cell EPDM Insulation
>R3.6
Outdoor: UV protected 7/8x1” Closed Cell
EPDM Insulation >R-3.6
Indoor: 7/8x1” Closed Cell EPDM Insulation
>R3.6
Air Vent
Watts Regulator HAV Air Vent
Watts Regulator Air Vent
Isolation Valve
Watts 600/800 WOG
Watts 600/800 WOG
Drain Valve
Watts Radiant Drain Valve
Watts Radiant Drain Valve
Flow Control
Valve
Watts Radiant Flow Guard
Watts Radiant Flow Guard
Instrumentation
Watts Radiant DPTG-3 Temperature &
Pressure Gauge
Watt Radiant DPTG-3 Temperature &
Pressure Gauge
Copyright © 2010 - Apricus Inc. Doc: A7-05.4.10.2-PB-1.0 Page 12 of 43

System Schematic: APSS_CLOSED_BPHE_AP30_DT-FTD_TBGT
System Schematic: APSS_CLOSED_BPHE_AP60_DT-FTD_TBGT
T = 180$C / 360$F P
=10bar / 150 psi
T1
n/o
T3
T2
n/o
Gas
Tankless
Water
Heater
℃50.5
Gas Supply
n/o
n/o
GRUNDFOS
Cold In Hot Out
n/o
!"#$%&
'
() () *+*+*,-
('+* +*+*,-+ (.+* +*+*,-+ /)+* +*+*+0+ /1+* +*+*+0
('++++++++++++(.
GRUNDFOS
Isolation Valves: n/o Drain valves: n/c
Copyright © 2009 Apricus Solar Co., Ltd
Notes
Suggested Controller Settings (refer also to controller manual)
System Code:
n/c = valve normally closed n/o = valve normally open
IMPORTANT
System schematics are provided as a guide only. Apricus does not guarantee schematic accuracy, that they meet your customers requirements or adhere to local code. Any systems designed and installed must adhere to local codes and regulations, and may need to be approved by a licensed engineer, and che c ked b y a plum bin g i nsp ecto r pri o r to commissioning. Please contact your local authorities for more information.
Revision: 1.3 Creation Date: 29th July 09 Drawing By: MH
APSS_CLOSED_BPHE_AP_DT-FTD_TBGT
1. Auto Air vent can be removed after initial bleeding. 2. May be required by local regulations. Always required if check valve installed on cold supply line. 3. Use cold dip tube and cut to about 3/4 original length. 4. Tankless water heater should be set to 140oF to ensure water is hot enough to kill Legionella bacteria.
Note 1
Note 3
Gas Tankless Water Heater (solar ready)6 Apricus AP-30 Solar Collector
5
Description
3 4 Storage Tank
Single Speed Potable Water Circulation Pump Apricus Brazed Plate Heat Exchanger Kit (SW or DW) Apricus Closed Loop Pump Station
1 2
No.
1
2
3
4
5
Control System Setting: 1 Function Settings Protection Functions - Max Temp = no - Cooling = no - Overheat protection = no - Freeze protection = yes (-40oF) Flow Meter = enter flow rate (gal/min) Pump P1 = PhAC SC Setting Menu Maxtemp tank1 = 176oF dtMax tank1 = 20oF dtMin tank1 = 5oF Min rev pump = 50% Mintemp Collector = 85oF Extra Functions Thermostat Function - Start = 125oF - Hysteresis = 30oF
6
Note 2
Note 4
Tank Inlet
P3
Apricus Closed Loop Pump Station with P1 Apricus Brazed Plate Heat Exchanger Kit (Double Wall with P2)
Copyright © 2010 - Apricus Inc. Doc: A7-05.4.10.2-PB-1.0 Page 13 of 43

OG300 Parts List
System
APSS_CLOSED_BPHE_AP30_DT-FTD_TBGT
APSS_CLOSED_BPHE_AP60_DT-FTD_TBGT
Collector
Apricus AP-30
2x Apricus AP-30
Pump
P1: Grundfos UPS 15-58FC
P2: Grundfos UPS 15-29SF
P3: Grundfos UP 15-100F
P1: Grundfos UPS 15-58FC
P2: Grundfos UPS 15-29SF
P3: Grundfos UP 15-100F
Controller
Watts Radiant Solar Control
Watts Radiant Solar Control
Tank
American #SE62-80H-045S
A.O.Smith ProMax SUN-80
Bradford White Solar Saver MS80R6SS
Rheem Solaraide 81VR80TC-1
American #SE62-119R-045S
A.O.Smith ProMax SUN-120
Bradford White Solar Saver MS120R6SS
Rheem Solaraide 81VR120TC-1
Tankless Heater
Quietside ODW-99A
Takagi T-Kjr.
Takagi T-H1
Takagi T-K3-SP
Expansion Tank
Watts Radiant ETX 30
Watts Radiant ETX 30
Heat Exchanger
Hrale B3-14DW-12-3.0 (Dual Wall)
Hrale B3-14DW-12-3.0 (Dual Wall)
Heat Transfer
Fluid
Whitlam Solar Hi-Temp
Dowfrost HD
Clariant SOL HT*
Whitlam Solar Hi-Temp
Dowfrost HD
Clariant SOL HT*
Piping
Copper or Stainless Steel
Copper or Stainless Steel
Check Valve
NSF/CSA Approved 3/4” Valve
NSF/CSA Approved 3/4” Valve
Mixing Valve
NSF/CSA Approved 3/4” Anti-Scald Valve
NSF/CSA Approved 3/4” Anti- Scald Valve
Pressure Relief
Valve
Watts 3/4” Pressure Relief Valve, 75psi
Watts 3/4” Pressure Relief Valve, 75psi
Insulation
Outdoor: UV protected 7/8x1” Closed Cell EPDM
Insulation >R-3.6
Indoor: 7/8x1” Closed Cell EPDM Insulation
>R3.6
Outdoor: UV protected 7/8x1” Closed Cell EPDM
Insulation >R-3.6
Indoor: 7/8x1” Closed Cell EPDM Insulation
>R3.6
Air Vent
Watts Regulator HAV Air Vent
Watts Regulator Air Vent
Isolation Valve
Watts 600/800 WOG
Watts 600/800 WOG
Drain Valve
Watts Radiant Drain Valve
Watts Radiant Drain Valve
Flow Control
Valve
Watts Radiant Flow Guard
Watts Radiant Flow Guard
Instrumentation
Watts Radiant DPTG-3 Temperature & Pressure
Gauge
Watt Radiant DPTG-3 Temperature & Pressure
Gauge
Copyright © 2010 - Apricus Inc. Doc: A7-05.4.10.2-PB-1.0 Page 14 of 43

System Schematic: APSS_CLOSED_BPHE_AP30_FTD_PBGT
System Schematic: APSS_CLOSED_BPHE_AP60_FTD_PBGT
T = 180$C / 360$F P
=10bar / 150 psi
T1
n/o n/o
T3
T2
GRUNDFOS
!"#$%&
'
() () *+*+*,-
('+* +*+*,-+ (.+* +*+*,-+ /)+* +*+*+0+ /1+* +*+*+0
('++++++++++++(.
GRUNDFOS
Isolation Valves: n/o Drain valves: n/c
Gas
Tankless
Water
Heater
℃50.5
n/c
Hot Out
Gas Supply
n/o n/o
Cold In
Copyright © 2009 Apricus Solar Co., Ltd
Notes
Suggested Controller Settings (refer also to controller manual)
System Code:
n/c = valve normally closed n/o = valve normally open
IMPORTANT
System schematics are provided as a guide only. Apricus does not guarantee schematic accuracy, that they meet your customers requirements or adhere to local code. Any systems designed and installed must adhere to local codes and regulations, and may need to be approved by a licensed engineer, and che c ked b y a plum bin g i nsp ecto r pri o r to commissioning. Please contact your local authorities for more information.
Revision: 1.3 Creation Date: 29th July 09 Drawing By: MH
APSS_CLOSED_BPHE_AP_FTD_PBGT
1. Auto Air vent can be removed after initial bleeding. 2. May be required by local regulations. Always required if check valve installed on cold supply line. 3. Tankless water heater should be set to 140oF, and must be able to accept hot water up to 160oF. 4. Must be Anti-scold, not just mixing valve and must be NSF certified.
Note 1
Note 2
Apricus AP-30 Solar Collector
5
Description
3 4 Solar Ready Storage Tank
Gas Tankless Water Heater (solar ready) Apricus Brazed Plate Heat Exchanger Kit (Double Wall with P2) Apricus Closed Loop Pump Station with P1
1 2
No.
Control System Setting: 1 Function Settings Protection Functions - Max Temp = no - Cooling = no - Overheat protection = no - Freeze protection = yes (-40oF) Flow Meter = enter flow rate (gal/min) Pump P1 = PhAC SC Setting Menu Maxtemp tank1 = 176oF dtMax tank1 = 20oF dtMin tank1 = 5oF Min rev pump = 50% Mintemp Collector = 85oF
2
1
3
4
5
Note 3 Note 4
Copyright © 2010 - Apricus Inc. Doc: A7-05.4.10.2-PB-1.0 Page 15 of 43

OG300 Parts List
System
APSS_CLOSED_BPHE_AP30_FTD_PBGT
APSS_CLOSED_BPHE_AP30_FTD_PBGT
Collector
Apricus AP-30
2x Apricus AP-30
Pump
P1: Grundfos UPS 15-58FC
P2: Grundfos UPS 15-29SF
P1: Grundfos UPS 15-58FC
P2: Grundfos UPS 15-29SF
Controller
Watts Radiant Solar Control
Watts Radiant Solar Control
Tank
A.O.Smith ProMax SUN-80
Bradford White Solar Saver MS80R6SS
Rheem Solaraide 81VR80-1
A.O.Smith ProMax SUN-120
Bradford White Solar Saver MS120R6SS
Rheem Solaraide 81VR120-1
Tankless Heater
Quietside ODW-99A
Takagi T-Kjr.
Takagi T-H1
Takagi T-K3-SP
Expansion Tank
Watts Radiant ETX 30
Watts Radiant ETX 30
Expansion Tank
Watts PLT-12 (Potable Water)
Watts PLT-12 (Potable Water)
Heat Exchanger
Hrale B3-14DW-12-3.0 (Dual Wall)
Hrale B3-14DW-12-3.0 (Dual Wall)
Heat Transfer
Fluid
Whitlam Solar Hi-Temp
Dowfrost HD
Clariant SOL HT*
Whitlam Solar Hi-Temp
Dowfrost HD
Clariant SOL HT*
Piping
Copper or Stainless Steel
Copper or Stainless Steel
Check Valve
NSF/CSA Approved 3/4” Valve
NSF/CSA Approved 3/4” Valve
Mixing Valve
NSF/CSA Approved 3/4” Anti-Scald Valve
NSF/CSA Approved 3/4” Anti- Scald Valve
Pressure Relief
Valve
Watts 3/4” Pressure Relief Valve, 75psi
Watts 3/4” Pressure Relief Valve, 75psi
Insulation
Outdoor: UV protected 7/8x1” Closed Cell
EPDM Insulation >R-3.6
Indoor: 7/8x1” Closed Cell EPDM Insulation
>R3.6
Outdoor: UV protected 7/8x1” Closed Cell
EPDM Insulation >R-3.6
Indoor: 7/8x1” Closed Cell EPDM Insulation
>R3.6
Air Vent
Watts Regulator HAV Air Vent
Watts Regulator Air Vent
Isolation Valve
Watts 600/800 WOG
Watts 600/800 WOG
Drain Valve
Watts Radiant Drain Valve
Watts Radiant Drain Valve
Flow Control
Valve
Watts Radiant Flow Guard
Watts Radiant Flow Guard
Instrumentation
Watts Radiant DPTG-3 Temperature &
Pressure Gauge
Watt Radiant DPTG-3 Temperature &
Pressure Gauge
Copyright © 2010 - Apricus Inc. Doc: A7-05.4.10.2-PB-1.0 Page 16 of 43

System Schematic: APSS_CLOSED_BPHE_AP30_DT-FTD_PBGT
System Schematic: APSS_CLOSED_BPHE_AP60_DT-FTD_PBGT
T = 180$C / 360$F P
=10bar / 150 psi
T1
Gas
Tankless
Water
Heater
℃50.5
n/c
Hot Out
Gas Supply
n/o
n/o
Cold In
Note 2
n/o
T3
T2
n/o
GRUNDFOS
!"#$%&
'
() () *+*+*,-
('+* +*+*,-+ (.+* +*+*,-+ /)+* +*+*+0+ /1+* +*+*+0
('++++++++++++(.
GRUNDFOS
Isolation Valves: n/o Drain valves: n/c
Copyright © 2009 Apricus Solar Co., Ltd
Notes
Suggested Controller Settings (refer also to controller manual)
System Code:
n/c = valve normally closed n/o = valve normally open
IMPORTANT
System schematics are provided as a guide only. Apricus does not guarantee schematic accuracy, that they meet your customers requirements or adhere to local code. Any systems designed and installed must adhere to local codes and regulations, and may need to be approved by a licensed engineer, and che cked b y a plu mbi ng in spec tor p rio r to commissioning. Please contact your local authorities for more information.
Revision: 1.3 Creation Date: 29th July 09 Drawing By: MH
APSS_CLOSED_BPHE_AP_DT-FTD_PBGT
1. Auto Air vent can be removed after initial bleeding. 2. May be required by local regulations. Always required if check valve installed on cold supply line. 3. Tankless water heater should be set to 140oF, and must be able to accept hot water up to 160oF. 4. Must be Anti-scold, not just mixing valve and must be NSF certified.
Note 1
Apricus AP-30 Solar Collector
5
Description
3 4 Storage Tank
Gas Tankless Water Heater (solar ready) Apricus Brazed Plate Heat Exchanger Kit (Double Wall with P2) Apricus Closed Loop Pump Station with P1
1 2
No.
Control System Setting: 1 Function Settings Protection Functions - Max Temp = no - Cooling = no - Overheat protection = no - Freeze protection = yes (-40oF) Flow Meter = enter flow rate (gal/min) Pump P1 = PhAC SC Setting Menu Maxtemp tank1 = 176oF dtMax tank1 = 20oF dtMin tank1 = 5oF Min rev pump = 50% Mintemp Collector = 85oF
2
1
3
4
5
Note 3 Note 4
Copyright © 2010 - Apricus Inc. Doc: A7-05.4.10.2-PB-1.0 Page 17 of 43

OG300 Parts List
System
APSS_CLOSED_BPHE_AP30_DT-FTD_PBGT
APSS_CLOSED_BPHE_AP60_DT-FTD_PBGT
Collector
Apricus AP-30
2x Apricus AP-30
Pump
P1: Grundfos UPS 15-58FC
P2: Grundfos UPS 15-29SF
P1: Grundfos UPS 15-58FC
P2: Grundfos UPS 15-29SF
Controller
Watts Radiant Solar Control
Watts Radiant Solar Control
Tank
American #SE62-80H-045S
A.O.Smith ProMax SUN-80
Bradford White Solar Saver MS80R6SS
Rheem Solaraide 81VR80TC-1
American #SE62-119R-045S
A.O.Smith ProMax SUN-120
Bradford White Solar Saver MS120R6SS
Rheem Solaraide 81VR120TC-1
Tankless Heater
Quietside ODW-99A
Takagi T-Kjr.
Takagi T-H1
Takagi T-K3-SP
Expansion Tank
Watts Radiant ETX 30
Watts Radiant ETX 30
Expansion Tank
Watts PLT-12 (Potable Water)
Watts PLT-12 (Potable Water)
Heat Exchanger
Hrale B3-14DW-12-3.0 (Dual Wall)
Hrale B3-14DW-12-3.0 (Dual Wall)
Heat Transfer
Fluid
Whitlam Solar Hi-Temp
Dowfrost HD
Clariant SOL HT*
Whitlam Solar Hi-Temp
Dowfrost HD
Clariant SOL HT*
Piping
Copper or Stainless Steel
Copper or Stainless Steel
Check Valve
NSF/CSA Approved 3/4” Valve
NSF/CSA Approved 3/4” Valve
Mixing Valve
NSF/CSA Approved 3/4” Anti-Scald Valve
NSF/CSA Approved 3/4” Anti- Scald Valve
Pressure Relief
Valve
Watts 3/4” Pressure Relief Valve, 75psi
Watts 3/4” Pressure Relief Valve, 75psi
Insulation
Outdoor: UV protected 7/8x1” Closed Cell EPDM
Insulation >R-3.6
Indoor: 7/8x1” Closed Cell EPDM Insulation
>R3.6
Outdoor: UV protected 7/8x1” Closed Cell EPDM
Insulation >R-3.6
Indoor: 7/8x1” Closed Cell EPDM Insulation >R3.6
Air Vent
Watts Regulator HAV Air Vent
Watts Regulator Air Vent
Isolation Valve
Watts 600/800 WOG
Watts 600/800 WOG
Drain Valve
Watts Radiant Drain Valve
Watts Radiant Drain Valve
Flow Control
Valve
Watts Radiant Flow Guard
Watts Radiant Flow Guard
Instrumentation
Watts Radiant DPTG-3 Temperature & Pressure
Gauge
Watt Radiant DPTG-3 Temperature & Pressure
Gauge
Copyright © 2010 - Apricus Inc. Doc: A7-05.4.10.2-PB-1.0 Page 18 of 43
