Aprilaire S86W MUPR Setup guide

READ AND SAVE THESE INSTRUCTIONS
Thermostats
SAFETY & INSTALLATION
INSTRUCTIONS
Model S86W MUPR
Wi-Fi Thermostat with IAQ
70
72
HEATING

TABLE OF CONTENTS
INSTALLATION. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Installation Location Recommendations . . .3
Outdoor Temperature Sensor (included) . . .4
Remote Temperature Sensor (optional). . . 6
Wireless Sensors . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Thermostat Mounting . . . . . . . . . . . . . . . . . . . . . . 9
Power and Reset Options . . . . . . . . . . . . . . . . . 10
Wiring Terminal . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
WIRING DIAGRAMS. . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Single & Multi Stage Heat/Cool,
One Transformer. . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Single & Multi Stage Heat/Cool,
(Ex: Boiler) Two Transformer . . . . . . . . . . . . . . . 13
Single & Multi Stage Heat Pump,
One Transformer. . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Radiant & Heat/Cool, One Transformer. . . .15
Radiant & Heat Pump, One Transformer . . .16
Indoor Air Quality Equipment
Wiring Diagrams. . . . . . . . . . . . . . . . . . . . . . . . . . . .17
SETUP AND TESTING . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Installer Setup Wizard and
Installer Setting . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
HVAC Installer System Settings Table. . . . . 19
TABLE 1 – HVAC Installer System Settings . . .19
Indoor Air Quality System
Settings Tables. . . . . . . . . . . . . . . . . . . . . . . . . . . . .26
TABLE 2 – Humidier System Settings. . . . .26
TABLE 3 – Dehumidier System Settings. .30
TABLE 4 – Air Cleaning System Settings. . . 32
TABLE 5 – Fresh Air Ventilation System
Settings. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .33
System Test Menu . . . . . . . . . . . . . . . . . . . . . . . . .38
Wi-Fi Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .38
QUICK REFERENCE TO CONTROLS
AND DISPLAY. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .39
TROUBLESHOOTING . . . . . . . . . . . . . . . . . . . . . . . . . . .42
Error Codes. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .44
THERMOSTAT FEATURES . . . . . . . . . . . . . . . . . . . . . . .45
SPECIFICATIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .46
INSTALLATION
INSTALLATION LOCATION RECOMMENDATIONS
Thermostat should be mounted:
• On an interior wall, in a frequently occupied space.
• Approximately 5 feet above oor.
• At least 18” from outside wall.
• Thermostat can be mounted to a vertical junction box.
Do not mount thermostat:
• Behind doors, in corners or other dead air spaces.
• In direct sunlight, near lighting xtures, or other appliances that give off heat.
• On an outside or unconditioned area wall.
• In the ow of a supply register, in stairwells, or near outside doors.
• On a wall with concealed pipes or ductwork.
32

OUTDOOR TEMPERATURE SENSOR (INCLUDED)
Outdoor temperature can be measured by attaching the included 8052 sensor to the T1 and T2
terminals. The outdoor sensor must be enabled in the installer setup menu.
Heat pump models can use the outdoor temperature to effectively utilize the heat pump:
• When the outdoor temperature is lower than the Low Balance Point, the heat pump will be
locked out and only auxiliary heating will be used to provide heating.
• When the outdoor temperature is higher than the High Balance Point, the auxiliary heating will
be locked out and only the heat pump will be used to provide heating.
Indoor Air Quality functions can use the outdoor temperature sensor to:
• Control humidication set point based on outdoor temperature to prevent condensation.
• Lock out ventilation based on high and/or low outdoor temperatures.
• Display outdoor temperature on thermostat.
Outdoor temperature sensor should be mounted:
• On side of building out of direct sunlight (north side recommended).
• Above snow line.
• At least 3 feet away from exhaust vents and condensing lines.
• Using less than 300 feet of wire.
• Do not route wires along 120 VAC lines.
G
Y
W
RC
RH
W2
C
O/B
L
T2
Y2
T1
I2
I1
90-2561
FIGURE 1 – OUTDOOR TEMPERATURE SENSOR WIRING
54

REMOTE TEMPERATURE SENSOR (OPTIONAL)
A remote temperature sensor can be used for control if the thermostat is to be mounted in a
concealed location or a remote sensor can be averaged with the thermostat sensor to control
a large space. An 8051 ush mount or 8053 surface mount remote temperature sensor can be
attached to the T1 and T2 terminals and mounted in a recommended area. The remote sensor
must be enabled in the installer set-up menu, and once enabled will override or be averaged
with the thermostat’s internal temperature sensor, based on the setting.
Remote temperature sensor should be mounted:
• On an interior wall, in a frequently occupied space.
• Approximately 5 feet above oor.
• At least 18” from outside wall.
• Using less than 300 feet of wire.
Do not mount remote sensor:
• Behind doors, in corners or other dead air spaces.
• In direct sunlight, near lighting xtures, or other appliances that give off heat.
• On an outside or unconditioned area wall.
• In the ow of a supply register, in stairwells, or near outside doors.
• On a wall with concealed pipes or ductwork.
• Near 120 VAC lines.
G
Y
W
RC
RH
W2
C
O/B
L
T2
Y2
T1
I2
I1
90-2562
FIGURE 2 – REMOTE TEMPERATURE SENSOR WIRING
76

WIRELESS SENSORS
This thermostat is compatible with the following AprilAire wireless sensors:
• Model Z10IDT Indoor Temperature and Humidity Sensor
Up to eight of these sensors can be connected to the thermostat. Connected sensors will
automatically be averaged, or individual sensors can be selected for scheduled events.
• Model Z10ODT Outdoor Temperature and Humidity Sensor
One sensor can be connected to the thermostat.
The wireless sensor settings can be found under the thermostats’ installer settings. See the
sensors instruction manual for mounting and connecting details.
THERMOSTAT MOUNTING
1. Remove the rear mounting plate
from the thermostat.
2. Pull wires through the opening on
the back of the rear mounting plate.
3. Position and level the mounting
plate of the thermostat on wall
and mark the hole locations with a
pencil.
4. Insert and tighten supplied self-
drilling anchors (drywall only).
5. Place mounting plate over anchors,
insert and tighten screws.
6. Seal wire entry holes to prevent
drafts affecting temperature
readings.
90-2563
FIGURE 3 – THERMOSTAT MOUNTING
98

POWER AND RESET OPTIONS
The thermostat is powered from 24VAC. In the case of power loss, the thermostat will maintain
the clock for 2 hours. The thermostat has a memory backup that saves the thermostat settings
in case of power interruption. The thermostat can be set back to factory defaults from the
installer settings menu. See Installer System Settings section for details.
The factory reset does not clear thermostat account information from the AprilAire Wi-Fi
Thermostat App. To clear this information, remove the thermostat from the app or use the
unregister option from the thermostat’s Wi-Fi settings.
WIRING TERMINAL
WIRE SPECIFICATIONS:
• 18-24 gauge thermostat wire
INSTALLATION NOTES:
• Ensure power at the HVAC equipment is off.
• Loosen screw terminals, insert stripped wire and re-tighten.
• Push the excess wire back into the opening and plug the wall opening to prevent drafts.
RH 24VAC supply heating*
RC 24VAC supply cooling*
WFirst stage heat (conventional) /
First stage auxiliary (heat pump)
YFirst stage cooling (conventional) /
First stage compressor (heat pump)
GFan
CCommon
O/B Reversing valve
LSystem fault indicator (optional)
(heat pump only)
W2 Second stage heat (conventional) /
Second stage auxiliary (heat pump)
Y2
Second stage cooling (conventional) /
Second stage compressor
(heat pump)
T1 & T2 Outdoor/remote temperature sensor
I1 & I2 Indoor Air Quality control output
*Jumper between RC & RH is used in single
transformer systems (see wiring diagrams).
90-2564
FIGURE 4 – WIRING TERMINALS
1110

G
Y
W
RC
RH
W2
C
O/B
L
T2
Y2
T1
I2
I1
Y2
AIR
CONDITIONER
C
FURNACE
ODT/REMOTE
TEMP SENSOR
Y
G
Y2
Y
W
R
C
W2
JUMPER
WIRING DIAGRAMS
FIGURE 5 – SINGLE & MULTI
STAGE HEAT/COOL, ONE
TRANSFORMER
NOTE: Dashed lines
represent wiring for multi
stage systems only.
90-2565
G
Y
W
RC
RH
W2
C
O/B
L
T2
Y2
T1
I2
I1
Y2
AIR
CONDITIONER
C
HEAT SOURCE
(EX: BOILER)
ODT/REMOTE
TEMP SENSOR
Y
W
R
AIR
HANDLER
C
G
Y
R
Y2
(REMOVE JUMPER)
90-2566
FIGURE 6 –
SINGLE & MULTI STAGE
HEAT/COOL, (EX: BOILER)
TWO TRANSFORMER
NOTE: Dashed lines
represent wiring for multi
stage systems only.
1312

FIGURE 7 – SINGLE
& MULTI STAGE
HEAT PUMP, ONE
TRANSFORMER
NOTE: Dashed lines
represent wiring for
multi stage systems
only.
G
Y
W
RC
RH
W2
C
O/B
L
T2
Y2
T1
I2
I1
Y2
OUTDOOR
UNIT
C
AIR
HANDLER
ODT/REMOTE
TEMP SENSOR
Y
G
Y2
Y
W
R
C
W2
JUMPER
W
R
O/B
L
90-2567
FIGURE 8 – RADIANT
& HEAT/COOL, ONE
TRANSFORMER
24V
COM NO(1)
COM(3)
E/W2
RRADIANT
FLOOR
W
CAIR
CONDITIONER
Y
FURNACE
G
C
R
W
Y
AA
8024
JUMPER
ODT/REMOTE
TEMP SENSOR
G
Y
W
RC
RH
W2
C
O/B
L
T2
Y2
T1
I2
I1
90-2677
1514

FIGURE 9 –
RADIANT &
HEAT PUMP, ONE
TRANSFORMER
24V
COM NC(2)
COM(3)
E/W2
G
AIR
HANDLER
C
JUMPER
NO(4)
COM(6)
AA
8024
Y
R
O/B
W
Y
RRADIANT
FLOOR
W
ODT/REMOTE
TEMP SENSOR Y
OUTDOOR
UNIT
W
O/B
R
C
L
G
Y
W
RC
RH
W2
C
O/B
L
T2
Y2
T1
I2
I1
90-2678
FIGURE 10 - INDOOR AIR QUALITY EQUIPMENT WIRING DIAGRAMS
DUCT MOUNTED EVAPORATIVE HUMIDIFIERS
(APRILAIRE SERIES 400, 500, 600, 700)
I2
I1
SOLENOID
TRANSFORMER
HUMIDIFIER
DRY CONTACT INPUT
STANDALONE OR RESIDENTIAL STEAM HUMIDIFIER
(APRILAIRE SERIES 300, 800)
I2
I1
HUMIDIFIER
DEHUMIDIFIER
(APRILAIRE SERIES 1800, e-SERIES)
DRY CONTACT INPUT
I2
I1
DEHUMIDIFIER
VENTILATION
(APRILAIRE SERIES 8100)
VENTILATION
TRANSFORMER*
DAMPER
I2
I1
90-2569
90-2571
90-2570
90-2680
NOTE:The I1/I2 output is a dry contact closure. The HUMIDIFIER wiring diagram assumes the
control is powering a solenoid valve. The DEHUMIDIFIER wiring diagram is for a normally open
dry contact input. The VENTILATION wiring diagram assumes the control is for a normally closed
damper. Refer to the individual humidier, dehumidier or ventilation installation instructions for
product specic wiring details.
*If required by ventilation accessory.
1716

HVAC INSTALLER SYSTEM SETTINGS TABLE
The following table contains the system settings and their details. Default settings are shown in
bold. The availability of some settings is dependent upon the value of other settings.
TABLE 1 – HVAC INSTALLER SYSTEM SETTINGS
System setting Description Factory default setting (bold) and setting range
Equipment Type
NOTE:Equipment Type related
settings will return to defaults if this is
changed.
Heat/Cool
Heat Pump
O/B Energized For? Selects O or B reversing valve
operation. (Heat Pump mode only.)
Cooling
Heating
Control Setup Used to lockout heating or cooling
outputs. (Heat/Cool mode only).
Heat & Cool
Heat Only
Cool Only
Heat Pump
Auxiliary Type
Selects auxiliary type. (Heat Pump
mode only.)
Gas/Oil Heat
Electric Heat
Fan Control in
Heating
Selects thermostat or equipment to
control the fan in heating. (Heat/Cool
mode only.)
Gas/Oil Heat
Electric Heat
SETUP AND TESTING
INSTALLER SETUP WIZARD AND
INSTALLER SETTING
The rst time the thermostat is powered
up (or after a factory reset) it will enter the
Installer Setup Wizard. All Installer Settings
can be set through this process. The
Installer Settings are also accessible in the
Installer Menu.
HOW TO ENTER THE INSTALLER MENU:
1. Press Select to enter the Main Menu.
2. Use or to navigate to Settings,
press SELECT.
3. Press and hold and for 3 seconds
to unlock the Installer option.
4. Use or to navigate to Installer,
press SELECT. Refer to the chart at right for
options.
INSTALLER
MENU OPTIONS DESCRIPTION
HVAC Settings
Essential HVAC
equipment (equipment
type, stages, etc.)
HVAC Advanced
Advanced HVAC control
(effsets, deadbands,
staging, protection, etc.)
IAQ Settings
Humidier, Dehumidier,
Air Cleaner, and
Ventilation conguration
Wireless Sensor
Connect/disconnect
wireless indoor and
outdoor sensors
Test
Installer test for
congured equipment
relay outputs
Reset Reset all settings to
factory default
1918

TABLE 1 – HVAC INSTALLER SYSTEM SETTINGS
System setting Description Factory default setting (bold) and setting range
Number of
Compressor
Stages
Select number of compressor stages.
(Heat Pump mode only.)
One
Two
Number of Auxiliary
Heat Stages
Select number of auxiliary heat
stages. (Heat Pump mode only.)
One
Two
Number of Stages
of Heat
Select number of heat stages. (Heat/
Cool mode only.)
One
Two
Number of Stages
of Cool
Select number of cool stages. (Heat/
Cool mode only.)
One
Two
Programmable Non Programmable hides all
scheduling features.
Programmable
Non Programmable
Wired Temperature
Sensor Installed?
Selects how the external temperature
sensor terminals (T1 & T2) are being
used. Choose Outdoor for a wired
outdoor sensor or Remote/Remote
Average for a wired indoor sensor.
Outdoor
Remote
(Onboard sensor disabled)
Remote Average
(Average with onboard sensor)
No
(No external sensor connected)
TABLE 1 – HVAC INSTALLER SYSTEM SETTINGS
System setting Description Factory default setting (bold) and setting range
Outdoor
Temperature Data
Provided From?
Select where the outdoor temperature
data comes from. (This option is not
available if you are using the wired
outdoor temperature sensor.)
Web
Automation
(for home automation cong only)
None
Wireless
(Wireless outdoor sensor)
Advanced HVAC
Settings?
Select No to skip the rest of the
thermostat settings.
No
Yes
Connection Type
Selects if the thermostat connects
with an automation system or an
AprilAire account.
AprilAire Cloud
Automation System
Progressive
Recovery
Enables or disables progressive
recovery.
Disabled
Enabled
Display Heat Blast? Select if the Heat Blast option is
displayed.
No
Yes
Heat Blast Offset Amount of heating when Heat Blast is
initiated.
3°F (1.5°C)
4°F (2°C)
5°F (2.5°C)
2120

TABLE 1 – HVAC INSTALLER SYSTEM SETTINGS
System setting Description Factory default setting (bold) and setting range
Extended Fan –
Heat
Extends fan operation 90 seconds
after heat call ends. NOTE: Only
available with electric heat.
Disabled
Enabled
Extended Fan –
Cool
Extends fan operation 90 seconds
after cool call ends.
Disabled
Enabled
Auto Changeover Enable or disable Auto Changeover
mode.
Disabled
Enabled
DeadBand Auto Changeover mode deadband. 3°F (1.5°C)
2 to 9°F (1 to 4.5°C)
Auto Changeover
Time
Minimum time between heating and
cooling calls.
4 Minutes
1 to 5 Minutes
Temp Sensor Offset Field adjustment of controlling
temperature sensors.
0°F (0°C)
-4 to 4°F (-2 to +2°C)
RH Sensor Offset Internal RH sensor. Increases or
decreases displayed RH%.
0
-5 to 5
Equipment
Minimum On Time
Minimum on time for heating and
cooling.
2 Minutes
1 to 5 Minutes
TABLE 1 – HVAC INSTALLER SYSTEM SETTINGS
System setting Description Factory default setting (bold) and setting range
Heating Minimum
Off Time Minimum off time for heating. 2 Minutes 1 to 5 Minutes
Compressor
Minimum Off Time
Minimum off time for compressor
protection.
5 Minutes
1 to 5 Minutes
Outdoor
Temperature High
Balance Point
Enable or disable high balance point.
(Available if an ODT is installed.)
Enabled
Disabled
High Balance Point
Temperature
If outside temperature is above the
high balance point the aux heat
operation is not allowed. (Available if
high balance point is enabled.)
65°F (14.5°C)
0 to 80°F (-18 to 22°C)
Outdoor
Temperature Low
Balance Point
Enable or disable low balance point.
(Available if an ODT is installed.)
Enabled
Disabled
Low Balance Point
Temperature
If outside temperature is below the
low balance point the compressor
operation is not allowed. (Available if
low balance point is enabled.)
20°F (-8°C)
0 to 60°F (-18 to 12°C)
2322

TABLE 1 – HVAC INSTALLER SYSTEM SETTINGS
System setting Description Factory default setting (bold) and setting range
Stage Rate
Accumulation of difference from
setpoint over time in staging
determination.
Enabled
Disabled
Stage Rate Factor
1 = more rapid staging of equipment
(comfort),
5 = slower staging of equipment
(economy).
2
1 to 5
First Stage
Differential First stage differential. 1°F (0.5°C) 1 to 9°F (0.5 to 4.5°C)
Second Stage
Differential Second stage differential. 1°F (0.5°C) 1 to 9°F (0.5 to 4.5°C)
Third Stage
Differential Third stage differential. 1°F (0.5°C) 1 to 9°F (0.5 to 4.5°C)
Fourth Stage
Differential Fourth stage differential. 1°F (0.5°C) 1 to 9°F (0.5 to 4.5°C)
Service HVAC
Reminder
Enable or disable the HVAC Service
reminder message.
Disabled
Enabled
TABLE 1 – HVAC INSTALLER SYSTEM SETTINGS
System setting Description Factory default setting (bold) and setting range
Recurrence Select number of months between
HVAC Service reminder messages.
12 Months
1 to 12 Months
Max Heat Setting Select the maximum heating set point
temperature allowed.
90°F (32°C)
40 to 90°F (4.5 to 32°C)
Min Heat Setting Select the minimum heating set point
temperature allowed.
40°F (4.5°C)
40* to 90°F (4.5 to 32°C)
Max Cool Setting Select the maximum cooling set point
temperature allowed.
99°F (37°C)
50 to 99°F (10 to 37°C)
Min Cool Setting Select the minimum cooling set point
temperature allowed.
50° (10°C)
50 to 99°F (10 to 37°C)
2524

INDOOR AIR QUALITY SYSTEM SETTINGS TABLES
The following tables contain the Indoor Air Quality system settings and their details. Default
settings are shown in bold. The availability of some settings is dependent upon the value of
other settings. The use of outdoor temperature data enables additional Indoor Air quality
functionality. While the outdoor temperature sensor option was presented in the HVAC installer
settings, it is also available in the Indoor Air Quality settings.
Please refer to the Owner’s Manual for further information about thermostat features.
TABLE 2 – HUMIDIFIER SYSTEM SETTINGS
System setting Description Factory default setting (bold) and setting range
NOTE: A humidier can only be installed if ventilation is not installed and dehumidier control
is not set to Whole Home.
Humidier
Installed?
Selects whether a humidier is installed.
Yes/On HVAC is used for applications
where the humidier is installed on the
HVAC duct. Yes/Standalone is used for
applications where the humidier is
independent from the HVAC system. (If
set to No, no other humidier settings will
be available.)
No
Yes/On HVAC
Yes/Standalone
TABLE 2 – HUMIDIFIER SYSTEM SETTINGS
System setting Description Factory default setting (bold) and setting range
Wired
Temperature
Sensor
Installed?
Selects how the external temperature
sensor terminals (T1 & T2) are being used.
Choose Outdoor for a wired outdoor
sensor or Remote/Remote Average for a
wired indoor sensor.
Outdoor
Remote
(Onboard sensor disabled)
Remote Average
(Average with onboard sensor)
No
(No external sensor connected)
Outdoor
Temperature
Data Provided
From?
Select where the outdoor temperature
data comes from. (This option is not
available it you are using the wired
outdoor temperature sensor)
Web
Automation
(for home automation cong only)
None
Wireless
(Wireless outdoor sensor)
Humidier Mode
Selects auto or manual mode. Auto mode
controls humidity based on the humidity
setting and outdoor temperature. Manual
mode controls humidity based on the
%RH setpoint. (Auto mode is only available
if an outdoor sensor option is enabled.)
Auto
Manual
2726

TABLE 2 – HUMIDIFIER SYSTEM SETTINGS
System setting Description Factory default setting (bold) and setting range
Allowed
Humidier
Operation
Selects when humidication is allowed
to occur relative to heating and fan
operation. NOTE: Without Fan is only
available when Humidier Installed
is set to Yes/Standalone. It allows
humidication to occur without
activating an HVAC fan and should only
be used when the humidier is mounted
independently of any HVAC system.
Heat Only
Heat or Fan
Forces Fan
Without Fan
CAUTION
When Humidier Operation is set to Without Fan the thermostat will turn on
humidication without energizing the HVAC fan. Do not select this option when the
humidier is installed on the HVAC duct. Without airow moisture can accumulate in the
duct resulting in signicant damage.
TABLE 2 – HUMIDIFIER SYSTEM SETTINGS
System setting Description Factory default setting (bold) and setting range
Humidier
Reminder
Selects when the “Change Water Panel”
message is displayed.
Off
150h Valve
300h Valve
600h Valve
1 per season
2 per season
Single or First
Reminder
Appears
Determines the month the rst (or only)
“Change
Water Panel” message is displayed.
October
November
December
January
February
March
April
May
June
July
August
September
Second
Reminder
Appears
Determines the month the second
“Change Water
Panel” message is displayed. (Only
available when 2 reminders per season
is selected.)
October
November
December
January
February
March
April
May
June
July
August
September
2928

TABLE 3 – DEHUMIDIFIER SYSTEM SETTINGS
System setting Description Factory default setting (bold) and setting range
NOTE: Dehumidier control can only be set to Whole Home if ventilation and humidication
are not enabled.
Dehumidier Type
Installed?
Selects if a dehumidier is installed. (If set to
None, no other dehumidier settings will be
available.) AC w/ IAQ selects overcooling,
I1 and I2 terminals energize during
overcooling. AC w/o IAQ selects overcooling,
I1 and I2 terminals are not used.
None
Whole Home
AC w/ IAQ
AC w/o IAQ
Disable
Dehumidication
During Cooling?
Selects if dehumidication is disabled
during a cooling call.
Yes
No
Dehumidier Forces
Fan?
Selects if dehumidication can turn on the
HVAC system fan.
Yes
No
Dehumidier
Overcool Limit
Selects the amount of overcooling that can
occur for dehumidication. (Only available
if dehumidier type is set to Overcool.)
1°F (0.5°C)
2°F (1°C)
3°F (1.5°C)
TABLE 3 – DEHUMIDIFIER SYSTEM SETTINGS
System setting Description Factory default setting (bold) and setting range
Dehumidier
Reminder
Enable or disable the Dehumidier Service
reminder message.
Disabled
Enabled
Recurrence Select number of months between
Dehumidier Service reminder messages.
12 Months
1 to 12 Months
Dehumidify in
Vacation Hold?
Selects if dehumidication with the air
conditioner is done in vacation mode.
No
Yes
Vacation Hold Low
Temperature Limit
Sets the lowest temperature the air
conditioner will cool to, to meet RH setpoint
in Vacation Mode. (Only available if
dehumidier type is set to Overcool.)
75°F (24°C)
70 to 85°F (21 to 29.5°C)
Humidity Deadband
Select the minimum difference between
the humidier and dehumidier setpoints.
(Only available if both Humidier and
Dehumidier are enabled.)
10%
10 to 20%
3130

TABLE 4 – AIR CLEANING SYSTEM SETTINGS
System setting Description Factory default setting (bold) and setting range
Air Cleaner Installed?
Selects if an air cleaner is installed.
(If set to No, no other air cleaner settings
will be available.)
No
Yes
Air Cleaner Reminder Enable or disable the Change Air Filter
message.
Disabled
Enabled
Recurrence Select number of months between
Change Air Filter messages.
12 Months
1 to 12 Months
TABLE 5 – FRESH AIR VENTILATION SYSTEM SETTINGS
System setting Description Factory default setting (bold) and setting range
NOTE: Ventilation can only be installed if humidication is not enabled and dehumidier
control is not set to Whole Home.
Fresh Air Vent
Installed?
Selects if ventilation is installed. (If set to
No, no other ventilation settings will be
available.)
No
Yes
Fresh Air Setup
Type
Selects if ventilation is congured through
the Code setup or Comfort. Comfort
setup has more lockout options. Code
setting ensures time missed due to
lockouts is made up.
Comfort
Code
Number of
Bedrooms
Selects the number of bedrooms to be
used for the Calculated Minutes per Hour.
3 Bedrooms
1 to 10 Bedrooms
Square Footage Selects the size of the home to be used
for the Calculated Minutes per Hour.
2500 SQ FT
500 to 7500 SQ FT
Measured CFM Selects the ventilation CFM to be used for
the Calculated Minutes per Hour.
110 CFM
30 to 250 CFM
3332

TABLE 5 – FRESH AIR VENTILATION SYSTEM SETTINGS
System setting Description Factory default setting (bold) and setting range
Calculated
Minutes Per
Hour
Displays the Fresh Air Time calculated. None
Range 6 to 60 Minutes
Override Manual adjustment of Calculated Minutes
per Hour.
(Calculated Minutes per Hour)
Range 6 to 60 Minutes
Wired
Temperature
Sensor
Installed?
Selects how the external temperature
sensor terminals (T1 & T2) are being used.
Choose Outdoor for a wired outdoor
sensor or Remote/Remote Average for a
wired indoor sensor.
Outdoor
Remote
(Onboard sensor disabled)
Remote Average
(Average with onboard sensor)
No
(No external sensor connected)
Outdoor
Temperature
Data Provided
From?
Select where the outdoor temperature
data comes from. ( This option is not
available it you are using the wired
outdoor temperature sensor)
Web
Automation
(for home automation cong only)
None
Wireless
(Wireless outdoor sensor)
TABLE 5 – FRESH AIR VENTILATION SYSTEM SETTINGS
System setting Description Factory default setting (bold) and setting range
High Vent RH
Limit
Selects if ventilation is disabled when the
indoor RH exceeds the indoor RH limit.
(Only available if Fresh Air Setup is set to
Comfort.)
Disabled
Enabled
High Vent RH
Limit
Sets the ventilation indoor RH lockout
limit. (Only available if High Vent RH Limit
is set to Enabled.)
55%
45% to 70%
Low Vent RH
Limit
Selects if ventilation is disabled when the
indoor RH exceeds the indoor RH limit.
(Only available if Fresh Air Setup is set to
Comfort.)
Disabled
Enabled
Low Vent RH
Limit
Sets the ventilation indoor RH lockout
limit. (Only available if Low Vent RH Limit is
set to Enabled.)
20%
10% to 30%
High Vent
Temperature
Limit
Enables high ventilation temperature
lockout limit. (Only available if an outdoor
sensor option is enabled.)
Disabled
Enabled
3534

TABLE 5 – FRESH AIR VENTILATION SYSTEM SETTINGS
System setting Description Factory default setting (bold) and setting range
High Vent
Temperature
Limit
Sets high ventilation temperature
lockout limit. (Only available if High Vent
Temperature Limit is set to Enabled.)
100°F (38°C)
85°F to 105°F (29°C to 41°C)
Low Vent
Temperature
Limit
Enables low ventilation temperature
lockout limit. (Only available if an outdoor
sensor option is enabled.)
Disabled
Enabled
Low Vent
Temperature
Limit
Sets low ventilation temperature
lockout limit. (Only available if Low Vent
Temperature Limit is set to Enabled.)
10°F (-12°C)
-10°F to 40°F (-24°C to 6°C)
HVAC Fan with
Vent?
Selects if ventilation forces the fan on.
(Yes with high and low limits is only
available if an outdoor sensor option is
enabled.)
Yes
Yes with high and low limits
No
High Mixing
Temperature
Enables high mixing temperature. (Only
available is HVAC Fan with Vent is set to
Yes with high and low limits.)
Disabled
Enabled
High Mixing
Temperature
Sets the high mixing temperature. (Only
available if High Mixing Temperature is set
to Enabled.)
80°F or (26°C)
60°F to 105°F (14°C to 41°C)
TABLE 5 – FRESH AIR VENTILATION SYSTEM SETTINGS
System setting Description Factory default setting (bold) and setting range
Low Mixing
Temperature
Enables low mixing temperature. (Only
available is HVAC Fan with Vent is set to
Yes with high and low limits.)
Disabled
Enabled
Low Mixing
Temperature
Sets the Low mixing temperature. (Only
available if Low Mixing Temperature is set
to Enabled.)
40°F (6°C)
0°F to 50°F (-18°C to 12°C)
Fresh Air
Reminder
Enable or disable the Service Fresh Air
message.
Disabled
Enabled
Recurrence Select number of months between
Service Fresh Air messages.
12 Months
1 to 12 Months
3736

SYSTEM TEST MENU
The system test menu is used to test a system after installation. The Installer Test can be accessed
from the Installer Menu. All equipment outputs that are congured in the installer settings can be
turned on and off for testing equipment. Minimum on and off times are not enforced while in this
mode. The instructions below show how to enter the test mode and turn outputs on and off.
ENTER THE SYSTEM TEST MENU
1. Press Select to enter the Main
Menu.
2. Use or to navigate to
Settings, press Select.
3. Press and hold and
for 3 seconds to unlock the
Installer option.
4. Use or to select
Installer Settings, press Select.
5. Use or to select System
Test, press Select.
SYSTEM TEST STEPS
1. Heating equipment
test.
2. Cooling equipment
test.
3. Fan equipment test.
4. Humidication
equipment test.
5. Dehumidication
equipment test.
6. Ventilation
equipment test.
HP: Heat Stage
1, Gas
Next
W
WI-FI SETUP
For detailed instructions for connecting the thermostat to a Wi-Fi network and registering it to an
AprilAire account, refer to the Wi-Fi Quick Start Guide included in the box.
QUICK REFERENCE TO CONTROLS & DISPLAY
HOME SCREEN
70
72
HEATING
AWAY
UP ARROW
BACK
EQUIPMENT
STATUS
SELECT (OPENS
MENU FROM
HOME SCREEN)
ROOM
TEMPERATURE
DOWN ARROW
ROOM
TEMPERATURE
SETTING
EVENT
STATUS
3938
