OVERVIEW
This document describes the PreView® Side Defender™ radar system
manufactured by PRECO® Electronics, located in Boise, Idaho, USA. There are
two different systems described in this manual, the right (passenger) side system,
model SDR8503 and the left side system, model SDL8503. This document covers
the components that comprise the Side Defender™ radar systems – the Side
Defender™ radar sensor, the PreView® in-cab display and the sensor/display
interconnect cable. This document may be amended, corrected, and enhanced
in keeping with the sensor development progress.
Product Description
The PreView® Side Defender™ radar is a small, rugged radar sensor designed
by Preco® Electronics for side blind zone object detection in heavy duty over-
the-road applications. When combined with an in-cab display, it alerts drivers
to objects in the side blind zones of heavy trucks, busses, waste trucks, utility
trucks, re/ambulance and other heavy and medium-duty on-road vehicles. If
provided vehicle speed over a J1939 CAN-bus interface, the Side Defender™
has intelligent modes of operation that help minimize false alerts due to xed
objects such as guardrails, while still providing reliable side object detection.
Figure 1. PreView® Side Defender™ Radar Sensor
