Raymarine hsb2 PLUS Reference guide

Quick Reference Card: hsb2PLUS Series CRT Radar Displays
86060_1
RANGE
Controls range scale.
Range scale and range rings are shown in the Status Bar.
- Press top of key to increase the range scale.
- Press bottom of key to decrease the range scale.
- Press and hold to change the scale faster.
ALARMS
Used to control guard zones.
- Press soft key to place guard zone if one not already placed.
Adjust size/shape using trackball, press ENTER to finish.
- Press to display soft keys if guard zone already placed.
Use soft key to toggle zone ON or OFF.
Adjust size/shape using trackball, press ENTER to finish.
MULTI
Controls display contrast and brilliance, key lighting, rain clutter
around the vessel (RAIN), distant rain clutter (FTC), guard zone
alarm sensitivity and tuning the receiver.
- Press to display slider, options and soft keys.
- use trackball to highlight option in list.
Press soft key (if appropriate) to toggle highlighted
option between ON/OFF or between AUTO/MAN.
Turn knob to adjust slider setting of highlighted option.
Press ENTER to finish.
CONT
BRILL
LIGHTS
RAIN
FTC
ALARM
TUNE
Press soft key to toggle between Auto/Man.
Turn knob to adjust slider, and press ENTER to finish.
GAIN and SEA
Controls for background noise (speckle) and sea clutter.
- Press for soft keys display.
- In MANual mode, turn knob to adjust setting.
DISPLAY
RANGE
MARKS
VRM/EBL
ALARMS
GAIN
SEA
MULTI
MOB
ENTER CLEAR MENU POWER
Soft Key Labels:
Change when you press a key.
Default soft key labels are shown.
SEA
TARGETS SCREEN
HDG MODE
Trackball
Controls cursor position on screen, the sliders and setup options.
CLEAR
Cancels operation in progress and returns to previous display.
Deletes an object/function under cursor control.
POWER
Press and hold until unit beeps to turn on display.
Press to toggle between Standby and Transmit.
Press for 3 seconds to turn off display.
Soft keys
Press to select option, or highlight option or slider.
Labels change when you press soft/dedicated key.
Elipses (...) after the text indicate that pressing soft key
leads to a further display of soft key options.
ENTER
Confirms selection and (if appropriate) clears current
soft key labels. It either performs the selected task,
accepts changes, or leads to display of more options.
When cursor text is displayed, cursor takes control of
the object.
When arrow-head cursor symbol is displayed, drops
the object under cursor control.
D4111-3
DISPLAY
Controls display mode and windows.
- Press for display mode and soft keys display.
- Press again to toggle through display modes, then ENTER.
- Press and hold for 2 seconds for full page radar display.
Press WINDOWS soft key to toggle window on/off, or return to
full screen.
Zoom: Press ZOOM key to display Zoom Window options.
Move Zoom box using trackball, press ENTER to finish.
SELECT
WINDOW
WINDOWS
OFF ON ZOOM...
VRM/EBL
Used to measure range and bearing to/between targets.
- Press to place VRM/EBL if one not already placed.
Adjust position using trackball, and press ENTER to finish.
- Press to display soft keys if VRM/EBL already placed.
Use soft key to toggle VRM/EBL on or off.
Press FLOAT to access float options for existing VRM/EBL.
Press VRM/EBL DATABOX to toggle data box display off/on.
FLOAT¬
VRM/EBL2
OFF ON
VRM/EBL1
OFF ON
VRM/EBL
DATABOX
OFF ON
MENU
Provides access to setup options.
- Press to display soft keys.
Press soft key to display required setup menu, then use trackball to
select option and soft key to change setting.
Press ENTER to close menu, and CLEAR to finish.
- Press ENTER to finish.
MARKS / MOB
Controls placing marks, and Man Overboard function.
- Press for soft keys display, then press soft key to place mark.
- Press and hold for 2 seconds to activate or cancel MOB.
GAIN
AUTO MAN
TUNE
AUTO MAN
AUTO SEA
HARBOUR OFFSHORE MAN
PLACE MRK
AT CURSOR
PLACE MRK
AT VESSEL
SYSTEM
SET UP¬
RADAR
SET UP¬
MARPA
SET UP¬
GUARD 1
OFF ON
GUARD 2
OFF ON
MARPA

D5729_1
Press the required soft key to change the heading or motion mode,
and press ENTER.
Press the soft key to toggle INTerference REJection or Target
EXPANSION on/off.
Press the WAKES soft key until the required option (short, medium or long
wakes, or OFF) is highlighted. Press ENTER to accept.
Press CLEAR WAKES to clear existing wakes from the display.
Press the appropriate soft key to toggle on/off Cursor Readout Databox,
Range Rings, Data Boxes or Waypoint display, and press ENTER to accept.
CURSOR
HDG MODE TARGETS SCREEN
BRG
RNG n
045°
0.28
R
Landmass
Surface
vessel
Default soft key labels
These can be turned off; press any soft key to re-display them.
Different labels are displayed when you press a key.
Channel buoy
Range rings
The number and
spacing depend on
the current range, or
you can turn them off
Status Bar
Ship's Heading
Marker (SHM)
You can hide this
temporarily
Ship's position
You can move this
off-centre if required
Cursor position,
controlled by the
trackpad
Targets:
Bearing scale,
each tick indicating
10˚ of azimuth
Cursor position box
Shows the current
cursor position as
either Range/Bearing
or Lat/Long. You can
move this box to your
preferred position
on the screen, or
turn it off.
Default Display
COURSE UPNORTH UP HEAD UP
INT REJ
OFF ON
EXPANSION
OFF ON
WAKES
OFF S M L
CLEAR
WAKES
CRSR BOX
OFF ON
RNGE RNGS
OFF ON
DATABOXES
OFF ON
WAYPOINT
OFF ON
3nm 126°T
AUTO
IR
RINGS
1/2 H-UP TTRUE REL
Status Bar
Selected range,
in nautical miles
Range ring interval
Not displayed if
range rings are off
Range rings
(displayed if
rings are on)
Current heading
if data available, or
Course Over Ground.
Displayed in degrees
Magnetic or True
Heading mode
Normally Head Up (H-UP);
Course Up (C-UP) or
North Up (N-UP) can be
selected if heading data
available
Mode Indicators
displayed when function on:
Target
Expansion
Wakes
Interference
Rejection
Auto mode
Gain, Sea,
Tune
FTC
(Remote rain)
Rain
Clutter
Guard Zone
Alarms
3nm 126°T AUTO WKS
FTC
EX
RC
GZ
IR
RINGS
1/2 H-UP GST
RM RV3
Motion Mode
Relative Motion
True Motion
Target Vectors
True Vector or
Relative Vector
and vector length
TM RV3
Context Sensitive Cursor Control
Text Label
BOX
CTR
EBL
FLT
GRD
MARPA
MOB
MRK
SHM
VRM
VRM/EBL
WPT
ZMB
Feature
Data box (any type)
Radar centre
Electronic Bearing Line
Floating VRM/EBL
Guard zone corner or side
MARPA Target
Man Overboard Marker
Mark
Ship's Heading Marker
Variable Range Marker
VRM and EBL
Chart Waypoint
Zoom box
Move (for example, an EBL)
1.
2.
3.
4.
Delete (for example, an EBL)
1.
2.
When the cursor is positioned over
special features on the display,
a text label appears to identify the
feature.
Depending on the feature,
you can then move, re-size or
delete it.
MARPA
SCREEN
TARGETS
HDG MODE
CANCEL
TARGET
ACQUIRE
TARGET
MARPA
LIST
Press the appropriate soft key to acquire or cancel selected target.
Press the appropriate soft key to view the target data box or database list.
MARPA
MARPA BOX
OFF ON
