APURO CT938-A User manual

Model:
CT938-A / CY423-A
Milkshake maker
Instruction manual
CT938-A_CY423-A_A5_v1_20200302.indb 1 2020/3/2 11:36

2
AU Telephone Helpline: 1300225960
Safety Tips
• Position on a flat, stable surface.
• A service agent/qualified technician should carry out
installation and any repairs if required. Do not remove any
components on this product.
• Consult Local and National Standards to comply with the
following:
- Health and Safety at Work Legislation
- Fire Precautions
- Wiring Regulations
- Building Regulations
• DO NOT use jet/pressure washers to clean the appliance.
• DO NOT immerse the appliance in water.
• This appliance is only suitable for mixing beverages. Do not
use this appliance for anything other than its intended use.
• Always switch off and disconnect the power supply to the
appliance when not in use.
• Not suitable for outdoor use.
• Keep all packaging away from children. Dispose of the
packaging in accordance to the regulations of local authorities.
• If the power cord is damaged, it must be replaced by an
Apuro agent or a recommended qualified technician in order
to avoid a hazard.
• This appliance is not intended for use by persons (including
children) with reduced physical, sensory or mental capabilities,
or lack of experience and knowledge, unless they have been
given supervision or instruction concerning the use of the
appliance by a person responsible for their safety.
• Children should be supervised to ensure that they do not play
with the appliance.
• Do not let cord hang over edge of table or counter, or touch
hot surfaces.
CT938-A_CY423-A_A5_v1_20200302.indb 2 2020/3/2 11:36

3
AU
Telephone Helpline: 1300225960
• Keep hands and utensils out of the mixing cup while motor is
running to prevent severe personal injury and / or damage to
the appliance.
• Never try to remove agitators while cup is sitting on the
microswitch plate.
• Do not operate with loose or damaged agitators.
• Do not place cup on to microswitch plate with On/Off switch in
the On position (Ior II position).
• Please note milk may double in volume after mixing so fill the
cup accordingly.
• When using the Tritan jug please use the Tritan agitators
supplied. (Note: The Tritan jug and agitators are sold
separately.)
• Do not leave appliance unattended while in use.
• Apuro recommends that this appliance should be periodically
tested (at least annually) by a Competent Person. Testing
should include, but not be limited to: Visual Inspection,
Polarity Test, Earth Continuity, Insulation Continuity and
Functional Testing.
Introduction
Please take a few moments to carefully read through this manual. Correct maintenance and operation of
this machine will provide the best possible performance from your Apuro product.
Product Description
CT938-A - Apuro Single Milkshake Mixer
CY423-A - Apuro Double Milkshake Mixer
Pack Contents
The following is included:
• Apuro Milkshake Mixer
• Mixing cup
• Instruction manual
Apuro prides itself on quality and service, ensuring that at the time of packaging the contents are
supplied fully functional and free of damage.
Should you find any damage as a result of transit, please contact your Apuro dealer immediately.
CT938-A_CY423-A_A5_v1_20200302.indb 3 2020/3/2 11:36

4
AU Telephone Helpline: 1300225960
Operation
Model: CY423-A
Motor
Mixing cup
Replaceable agitators
Suction feet
On/Off switch
Microswitch plate
Safety Microswitch
On/Off switch:
Up position for Low speed (I); Down position for high speed (II); Middle position for turning off (0).
Mixing
Before use, ensure to
• Clean all removable parts thoroughly.
• Turn off On/Off switch (0 position).
1. Plug in appliance.
2. Place ingredients into mixing cup. .
3. Locate cup on to the microswitch plate.
4. Turn on appliance by setting the On/Off switch to desired speed setting.
CT938-A_CY423-A_A5_v1_20200302.indb 4 2020/3/2 11:36

5
AU
Telephone Helpline: 1300225960
Note:
• Do not run the appliance excessively for more than 3 minutes at a time to
avoid overheating activation. In case of overheating, the appliance will stop
work automatically. Let it cool down sufficiently before restart.
• With the safety microswitch, the appliance will turn off automatically once
the mixing cup is released from the microswitch plate.
• Before removing cup, ensure to turn off appliance using On/Off switch and
let the motor come to a complete stop.
Cleaning, Care & Maintenance
• Always disconnect from power supply before cleaning.
• Always allow to cool before cleaning.
• Let the motor come to a complete stop before removing the cup.
• The cup is NOT dishwasher proof!
• Use warm, soapy water and a damp cloth to clean the cup.
• The agitators can be removed for thorough cleaning. Or, with the agitators in place, you can run the
appliance with clean water in the cup for seconds.
• Dry thoroughly after cleaning.
• The Apuro dealer or qualified technician should carry out repairs if required.
Warning: Do not allow any water to spill into the body of the appliance when
cleaning.
Troubleshooting
Fault Probable Cause Solution
The unit is not
working
The unit is not switched on Check the unit is plugged in correctly and
switched on
Plug and lead are damaged Call Apuro agent or qualified Technician
Fuse in the plug has blown Replace the plug fuse
Power supply Check power supply
Internal wiring fault Call Apuro agent or qualified technician
Cup not located properly Relocate cup
Technical Specifications
Model Voltage Power Current Cup
Capacity
Dimensions
h x w x d mm Weight
CT938-A 220-240V~
50/60Hz
80W 0.34A 750ml 510 x 170 x 170 3.45kg
CY423-A 220-240V~
50/60Hz
80W+80W 0.34A 2 x 750ml 510 x 360 x 170 7.0kg
CT938-A_CY423-A_A5_v1_20200302.indb 5 2020/3/2 11:36

6
AU Telephone Helpline: 1300225960
Electrical Wiring
The plug is to be connected to a suitable mains socket.
This appliance is wired as follows:
• Live wire (coloured brown) to terminal marked L
• Neutral wire (coloured blue) to terminal marked N
• Earth wire (coloured green/yellow) to terminal marked E
This appliance must be earthed.
If in doubt consult a qualified electrician.
Electrical isolation points must be kept clear of any obstructions. In the event of any emergency
disconnection being required they must be readily accessible.
Compliance
The product must not be disposed of as household waste. To help prevent possible harm to human
health and/or the environment, the product must be disposed of in an approved and environmentally safe
recycling process. For further information on how to dispose of this product correctly, contact the product
supplier, or the local authority responsible for waste disposal in your area.
Apuro parts have undergone strict product testing in order to comply with regulatory
standards and specifications set by international, independent, and federal authorities.
Apuro products have been approved to carry the following symbol:
All rights reserved. No part of these instructions may be produced or transmitted in any form or by any means, electronic,
mechanical, photocopying, recording or otherwise, without the prior written permission of Apuro.
Every effort is made to ensure all details are correct at the time of going to press, however, Apuro reserve the right to
change specifications without notice.
CT938-A_CY423-A_A5_v1_20200302.indb 6 2020/3/2 11:36

DECLARATION OF CONFORMITY
Equipment Type
Single Milkshake Maker
Double Milkshake Maker
Model
CT938-A
CY423-A
Legislation
Electrical Safety
Electromagnetic Compatibility
Standards
IEC 60335-1: 2010 +A1:2013
IEC 60335-2-64: 2000 +A1:2002
EN 55014-1: 2006 +A1:2009 +A2:2011
EN 55014-2:2015
EN 61000-3-2:2014
EN 61000-3-3:2013
Producer Name
Apuro
Producer Address
15 Badgally Road,
Campbelltown,
NSW 2560
I, the undersigned, hereby declare that the equipment specified above conforms to the above Legislation and Standard(s).
Date
27th February 2020
Signature
Full Name
Ashley Hooper
Position
Global Quality Manager
Date
27th February 2020
Signature
Full Name
Josie Holt
Position
Commercial Manager/ Responsible Supplier
