INSTALLATION
AND
OPERATING
INSTRUCTIONS
P/N 8835500 2-09
1
Heavy Duty Open Burner Ranges
MODELS: HHP-212, HHP-424, HHP-636, HHP-848
HHPS-212, HHPS-424, HHPS-636, HHPS-848
Please complete this information and retain this manual for the life of the equipment. For
Warranty Service and/or Parts, this information is required.
Model Number Serial Number Date Purchased
IMPORTANT FOR FUTURE REFERENCE
FOR YOUR SAFETY: Do not store or use gasoline or other flammable vapors or liquids
in the vicinity of this or any other appliance.
WARNING: Improper installation, adjustment, alteration, service or maintenance can
cause property damage, injury or death. Read the installation, operating and
maintenance instructions thoroughly before installing, or servicing this equipment.
WARNING: Instructions must be posted in a prominent location. All safety precautions
must be taken in the event the user smells gas. Safety information can be obtained from
your local gas supplier.
LISTED
GAS-FIRED
US
CUL
ANSI/NSF4
UL
EPH
APW Wyott Foodservice Equipment Company
E-mail: [email protected]
www.apwwyott.com
Dallas Plant
729 Third Ave. Dallas, TX 75226
Local: 1-[phone]
Toll Free: 1-[phone]
Parts/Service Fax: [phone]
Cheyenne Plant
1938 Wyott Drive, Cheyenne, WY 82007
Local: 1-[phone]
Toll Free: 1-[phone]
Parts/Service Fax: [phone]

TABLE OF CONTENTS:
2
LOCATION OF DATA PLATE
The data plate for the gas open burner range is located on the right side panel.
IMMEDIATELY INSPECT FOR SHIPPING DAMAGE
All containers should be examined for damage before and during unloading. The freight carrier has
assumed responsibility for its safe transit and delivery. If equipment is received damaged, either apparent or
concealed, a claim must be made with the delivering carrier.
A) Apparent damage or loss must be noted on the freight bill at the time of delivery. It must then be signed by
the carrier representative (Driver). If this is not done, the carrier may refuse the claim. The carrier can supply
the necessary forms.
B) Concealed damage or loss if not apparent until after equipment is uncrated, a request for inspection
must be made to the carrier within 15 days. The carrier should arrange an inspection. Be certain to hold all
contents and packaging material.
Installation and start-up should be performed by a qualified installer who thoroughly read, understands and
follows these instruction.
If you have questions concerning the installation, operation, maintenance or service of this product, write
Technical Service Department APW Wyott Foodservice Equipment Company, 1938 Wyott Drive,
Cheyenne, WY 82007.
Before installing and operating this equipment be sure everyone involved in its operation is fully trained and
is aware of all precautions. Accidents and problems can result by a failure to follow fundamental rules and
precautions.
Shut off gas flow through the appliance before cleaning or servicing unit.
The following words and symbols, found in this manual, alert you to hazards to the operator, service
personnel or the equipment. The words are defined as follows.
1. SAFETY PRECAUTIONS
SECTION ITEM PAGE
1 Safety Precautions.......................................................................................................2
2 General Installation Instructions ..................................................................................4
3 Specifications...............................................................................................................4
4 Lighting Instructions.....................................................................................................7
5 Maintenance ................................................................................................................8
6 Conversion...................................................................................................................9
7 Replacement Parts Lists & Exploded View.................................................................11
8 Warranty .....................................................................................................................16

3
DANGER: This symbol warns of imminent hazard which will result in serious injury or
death.
WARNING: This symbol refers to a potential hazard or unsafe practice, which could result
in serious injury or death.
CAUTION: This symbol refers to a potential hazard or unsafe practice, which may result in
minor or moderate injury or product or property damage.
NOTICE: This product is intended for commercial use only. Not for household use.
CAUTION: These models are designed, built, and sold for commercial use. If these
models are positioned so the general public can use the equipment make sure that
cautions, warnings, and operating instructions are clearly posted near each unit so that
anyone using the equipment will use it correctly and not injure themselves or harm the
equipment.
WARNING: Improper installation, adjustment, alteration, service or maintenance can
cause property damage, injury or death. Read installation, operating and maintenance
instructions thoroughly before installing or servicing this equipment.
NOTICE: This symbol refers to information that needs special attention or must be fully
understood even though not dangerous.
WARNING: For your safety do not store or use gasoline or other flammable vapors or
liquids in the vicinity of this or any other appliance. Keep the area free and clear of
combustibles. (SeeANZI Z83.14B, 1991)
NOTICE: Local codes regarding installation vary greatly from one area to another. The
National Fire Protection Association, Inc., states in its NFPA96 latest edition that local
codes are “Authority Having Jurisdiction”when it comes to requirement for installation of
equipment. Therefore, installation should comply with all local codes.
NOTICE: Instructions to be followed if anyone smells gas should be posted in a prominent
place. These may be obtained from the gas supplier.
WARNING: Do not turn on gas valves without lighting pilot. A build up of gas and possible
explosion could occur.
GENERAL INFORMATION
THIS MANUAL SHOULD BE RETAINED FOR FUTURE REFERENCE
!!
WARNING: A factory authorized agent should handle all maintenance and repair. Before
doing any maintenance or repair, contact APW Wyott.

2. GENERAL INSTALLATION INSTRUCTIONS:
Ensure gas supply and gas type, as shown on unit data plate agree. (Data plate is located on the right side
panel of unit).
Unit installation must conform with the National Fuel Gas Code, ANSI Z223.1/NFPA 54, the National Gas
Installation Code, CSA B149.1, or the Propane Installation Code, CSA B149.2 as applicable and in
accordance with local codes.
Screw legs into the permanently fastened nuts on the four corners of the unit and tighten by hand. Level the
unit by turning the adjustment screw at the bottom of each leg. Do not slide unit with legs mounted, lift if
necessary to move unit.
Pipe gas supply to unit.
Pipe threading compound must be resistant to the action of liquefied petroleum gases.
These units are suitable for installation on non-combustible surfaces.
Unit must have adequate clearances for servicing. (Sides = 0”, Rear = 0”, Floor = 4”)
4
3. SPECIFICATIONS AND DIMENSIONS
GAS PRESSURE
The appliance and it’s individual shutoff valve (to be supplied by user) must be disconnected from the gas
supply piping system during any pressure testing of that system at test pressures in excess of ½ psi
(3.45 kPa).
The appliance must be isolated from the gas supply piping system by closing it’s individual manual shut-off
valve during any pressure testing of the gas supply piping system at test pressures equal to or less than
½ psi (3.45 kPa).
NOTE: Gas shutoff valve is supplied on CE models.
Congratulations on your purchase of APW Wyott commercial cooking equipment. APW Wyott takes pride
in the design and quality of our products. When used as intended and with proper care and maintenance,
you will experience years of reliable operation from this equipment. To ensure best results, it is important
that you read and follow the instructions in this manual carefully.
The countertop hot plate, models HHP-212, HHP-424, HHP-636, HHP-848, HHPS-212, HHPS-424,
HHPS-636 & HHPS-848 provides countertop heating and cooking capabilities. These units incorporate 2,
4, 6 or 8 burners at 30,000 BTU/Hr each for fast, even cooking and heating.
Warning: DO NOT use an open flame to check for leaks. Check all gas piping for leaks with
a soap and water solution before operating unit.
MODEL WIDTH
IN. (MM)
DEPTH
IN. (MM)
HEIGHT
IN. (MM)
# OF
BURNERS
BTU/Kw PER
BURNER
NATURAL GAS
TOTAL
BTU/kW HOUR
NATURAL GAS
HHP-212 12" (305) 31.09" (789.7) 13.8" (351) 2 30,000 (8.79) 25,000 (8.32) 60,000 (17.6) 50,000 (14.64) 5 (12.4) 10 (24.9)
HHP-424 24”(610) 31.09" (789.7) 13.8" (351) 4 120,000 (35.2) 100,000 (29.29)
HHP-636 36”(914) 31.09" (789.7) 13.8" (351) 6 180,000 (52.7) 150,000 (43.93)
HHP-848 48”(1219) 31.09" (789.7) 13.8" (351) 8 240,000 (70.3) 200,000 (58.57)
HHPS-212 12" (305) 31.09" (789.7) 16.8" (427) 2 60,000 (17.6) 50,000 (14.64)
HHPS-424 24”(610) 31.09" (789.7) 16.8" (427) 4 120,000 (35.2) 100,000 (29.29)
HHPS-636 36”(914) 31.09" (789.7) 16.8" (427) 6 180,000 (52.7) 150,000 (43.93)
HHPS-848 48”(1219) 31.09" (789.7) 16.8" (427) 8 240,000 (70.3) 200,000 (58.57)
30,000 (8.79) 25,000 (8.32) 5 (12.4) 10 (24.9)
30,000 (8.79) 25,000 (8.32) 5 (12.4) 10 (24.9)
30,000 (8.79) 25,000 (8.32) 5 (12.4) 10 (24.9)
30,000 (8.79) 25,000 (8.32) 5 (12.4) 10 (24.9)
30,000 (8.79) 25,000 (8.32) 5 (12.4) 10 (24.9)
30,000 (8.79) 25,000 (8.32) 5 (12.4) 10 (24.9)
30,000 (8.79) 25,000 (8.32) 5 (12.4) 10 (24.9)
BTU/Kw PER
BURNER
PROPANE
TOTAL
BTU/kW HOUR
PROPANE
W.C. IN.
('MBAR')
NATURAL
GAS
W.C. IN.
('MBAR')
PROPANE

5
SPECIFICATIONS - HEAVY DUTY OPEN BURNER RANGE: HHP-212
21827000
SPECIFICATIONS - HEAVY DUTY OPEN BURNER RANGE: HHP-424
21827100

6
SPECIFICATIONS - HEAVY DUTY OPEN BURNER RANGE: HHP-636
21827200
SPECIFICATIONS - HEAVY DUTY OPEN BURNER RANGE: HHP-848
21827300

7
4. LIGHTING INSTRUCTIONS
HHP and HHPS Gas Open Burner Ranges are furnished with either a pilot safety valve or a standing pilot
(not available in the European Community). Please follow the instructions for your unit.
Operation of the gas valve pilot:
1. Turn knob on the main gas valve to the pilot position
2. Depress knob to start gas flow to the pilot valve
3. Light pilot valve
a. Using a match or taper
4. Hold in knob for 15 to 30 seconds to heat up the thermocouple
5. Release knob and turn to the desired gas flow position
a. If pilot goes out repeat steps 1-4, some thermocouples will take longer to heat up
( NotAvailable in the European Community )
The pilot lights on the broilers have been set at the factory. A screwdriver may be required for the first lighting
to adjust the flame for your elevation.
1. Turn off the manual shut off valve and wait 5 minutes to clear the gas.
2. Turn all knobs to the "OFF" position.
3. The valve can be accessed through an opening in the front panel or remove the cooking grates and
light the pilot from above.
4. Turn the manual shut off valve on.
5. Hold an ignition source (match) to both openings on the pilot tube. When the flames are established,
remove the ignition source.
6. Turn the burner knobs to “ ”. If the burner does not ignite, promptly open the pilot valve more. If the
pilot flame appears larger than necessary, turn it down and reset burner ignition. The pilot flame should
be as small as possible but large enough to guarantee reliable ignition of the burners when the knobs
are turned to .
If the pilot light should go out for any reason:
Promptly shut off all gas at the manual shut off valve.
Turn off all knobs and pilot valves; wait 5 minutes to clear gas.
Relight following steps 4 through 6 under
Since the burner is lit from constantly burning pilot, turn knobs to "HI" to put the unit in operation; then adjust
to any desired position between "LO" and "HI".
To light burner, turn knob to "max." then back off to the desired flame level. The range of adjustment is
virtually infinite between high and off. (At the small flame, there is a pre-set low).
When the broiler is first heated, it will smoke until oil used in manufacturing, preservation and dust from
storage and shipping are burned off. An hour at "max." on all burners is usually sufficient.
Turn knobs off and let cool
For first cooking, set the grates at maximum tilt position and preheat before broiling. You will have to
experiment with knob settings and grate position for each particular item.
Keep the grease/water pan with sufficient water to cover the entire bottom.
Clean regularly. Grates may be removed for washing in the sink. Brush out carbonized particles.
Thoroughly wash the grease/water pan.
Never attempt to move a grill section while cooking. An unexpected flare could cause severe injury. Turn off
the unit, let it cool and use potholders and/or gloves to reposition or remove. The space between the legs at
the bottom admits combustion air. DO NOT BLOCK THIS SPACE.
Pilot Operation Flame Failure Gas Valve:
Standing Pilot Lighting Instructions:
Standing Pilot Lighting Instructions.
LIGHTING THE MAIN BURNER:
CAUTION
HI
“HI”
RELIGHTING PILOT
l
l
l
l
l
l
l
l
l

Main burner air supply:
European Community:
If adjustment becomes necessary in the field, it should be done by a factory authorized and trained
technician who should seal the screw after the adjustment to safeguard against un-authorized
tampering by the end user.
For efficient burner operation, a proper balance of gas volume and primary air supply must be maintained
which will result in complete combustion. Insufficient air supply results in a yellow streaming flame. Primary
air supply is controlled by an air shutter on the front of the burner.
Loosen the screws on the front of the burner, and adjust the air shutter to just eliminate the yellow tips of the
burner flame. Lock the air shutter in place by tightening the screws.
All burners are lit from constantly burning pilots. Turning the valve to the desired flame height is all that is
required to put the unit in service.
Do not permit fans to blow directly at the unit. Wherever possible, avoid open windows next to the units'
sides or back.Avoid wall type fans which create air cross-currents within a room.
It is also necessary that sufficient air should be allowed to enter the room to compensate for the amount of air
removed by any ventilating system. Otherwise, a subnormal atmospheric pressure will occur, affecting
operation and causing undesirable working conditions.
A properly designed and installed hood will act as the heart of the ventilating system for the room or area in
which the unit is installed, and will leave the unit independent of changing draft conditions.
All valves must be checked and lubricated periodically. This must be done by an authorized service
representative in your area.
5. MAINTENANCE
CAUTION: Use only non-abrasive cleaners. Abrasive cleaners could scratch the finish of
your unit, marring it’s appearance and making it susceptible to dirt accumulation. Do Not
use steel wool, other abrasive cleaners or cleaners/sanitizers containing chlorine, iodine,
ammonia or bromine chemicals as these will deteriorate the stainless steel and glass
material and shorten the life of the unit.
Daily:
Weekly:
1. Thoroughly clean back, sides, top and front of unit.
2. Clean grates daily.
1. Clean unit thoroughly. Clean stainless steel or chromed surfaces with a damp cloth and polish with a
soft, dry cloth. A detergent may be used for cleaning. To remove discolorations, use a non-abrasive
cleaner.
2. To clean the drip pan: Remove the drip pan by grabbing the handle and pulling it out of the opening
in the front panel. To replace the pan, reverse this procedure.
3. Burner air shutter openings must be kept clean.
4. Main burner ports must be kept clean. To clean burners, boil them in a strong solution of lye water
for 15 to 20 minutes. Then either brush with a wire brush or clean gas ports with a sharp-pointed
metal instrument to insure open ports.
CAUTION: Clean the regulator at least once a month. Make sure the vent opening is open
and not blocked in any way. Failure to do so will cause variations in pressure. Your unit will
not function as well and it could shorten the life of the product.
8

l
l
l
l
l
l
l
l
Connect the regulator to the unit, connect gas and check for leaks. Do not use an open
flame to check for leaks.
Check the system pressure. With the front panel removed remove the plug
from the manifold.
Place a fitting in the plug opening and connect a manometer.
For Natural gas the pressure in the manifold should be 5”water column or 12.4
millibar. For LP the pressure in the manifold should be 10”water Column or 24.9
millibar.
To adjust the pressure remove the brass cap and turn the white plastic part inside
the stem of the regulator. See picture regulator 8.
Take a wide straight screw driver and place it in the two notches shown in picture regulator 7 turn
clockwise to increase pressure and counter-clockwise to reduce pressure. See picture regulator 8.
Once the pressure has been adjusted replace the brass cap.
Note the blue cap on the regulator, this is the vent there are openings below the top rim. block
these openings your regulator will fail to operate correctly. On at least a monthly basis blow off any dust
or grease which may accumulate around this cap. The openings must remain open for the regulator to
function. Clean more often in a very greasy atmosphere.
WARNING:
NEVER
9
NAT
LP
6. CONVERSION
l
l
l
Instructions are for conversion from Natural Gas to Propane (L.P.) on all models HHP and HHPS.
The conversion should be done before connecting the unit to the gas supply.
Units are shipped from the factory equipped for use on natural gas. Orifices necessary for LP (propane)
are provided in a bag tied to the valve on the front panel.
1. Remove the knobs and front panel.
2. Remove the orifice fittings from the valve. Change the orifices to the size recommended for
propane (L.P.).
3. Replace the orifice fittings into the valve.
lTo change the regulator:
1. Remove brass
cap
2. Locate the plastic
part attached to the
brass cap
3. This is the natural
gas position
4. Snap the plastic
part off of the brass
cap
5. Flip the plastic part
over & snap the
plastic part onto the
brass cap in the
opposite direction
6. Note you can read
LP on the plastic
part it is now in the
LP position
7. Replace the brass
cap back into the
body of the
regulator
8. To adjust pressure:
Remove brass cap &
turn white plastic
part inside the stem
of regulator

10
NOTES:
