Aquacal Pool Pilot Cubby Digital User manual

1
Models: 75080 and 75081
Cubby Digital
INSTALLER: THIS DOCUMENT IS PURCHASER’SPROPERTY AND IS TO REMAIN WITH THE EQUIPMENT OWNER
PN:LTP0027REV-2
2/14/08-B
Owner’s
Manual
Salt Chlorine Generator
IMPORTANT !
Swimming Pool & Spa Purification System
Read This Manual Before
Installing or Operating
Installation and Operation
Thismanualcoverstheinstallationandoper-
ation of Cubby Digital Chlorine Generators
equipped with the following Cell & Manifold
assemblies(soldseparately),PartNumbers:
94105& 75082.
Pool Pilot®
ForusewithSC-36Cell,ONLY!

2

3
OWNER TABLE OF CONTENTS
WELCOME TO THE TEAM ................................................................................................. 5
FACTORY CONTACT INFORMATION ................................................................................ 6
SAFETYINFORMATION ..................................................................................................... 7
Safety Signals .........................................................................................................................7
SafetyInformation MainTable..................................................................................................7
OWNER QUICK START & RUN ......................................................................................... 9
How Your Chlorine Generator Works ......................................................................................9
Control Overview.....................................................................................................................9
UPandDOWNArrows..................................................................................................9
TheBoost Button .......................................................................................................... 10
Menu and Select Button.............................................................................................10
Check System Light andAudibleAlarm .....................................................................10
Normal Display ......................................................................................................................10
Water Balance & Chemistry Recommendations ..................................................................11
Winterizing ........................................................................................................................... 11
IMPORTANT FEATURES.................................................................................................. 12
Patented Temperature Compensation...................................................................................12
TwoAvailable Options for Water ManifoldsAssemblies ........................................................12
GettheMostfromYourPurchase........................................................................................... 12
INSTALLER TABLE OF CONTENTS ............................................................................... 14
REFERENCESECTION ................................................................................................................ 33
SaltAdditionChart .................................................................................................................... 33
Basic Water Chemistry .........................................................................................................34
UsingtheSaturation Index (SI) ..............................................................................................35
MAINTENANCE................................................................................................................. 36
Fuse Location and Ratings....................................................................................................36
Tri-Sensor Assembly .............................................................................................................36
Removing\Inspecting\Cleaning the Tri-Sensor ......................................................................37
Testing Flow Switch, Cleaning Screen & Bypass Valve ......................................................... 38
ServicingtheSuperCell............................................................................................................ 39
Removal of the SuperCell..........................................................................................39
Visual Inspection of the SuperCell .............................................................................39
ManualCleaning of the SuperCell..............................................................................40
Installation of a SuperCell ..........................................................................................41
Winterizing ............................................................................................................................41
Spring Start-Up ......................................................................................................................41
TROUBLESHOOTING ...................................................................................................... 42

4
SECTION SYMBOLS
Troubleshooting
Maintenance
Reference Tables
Installation Programming & Setup
Installation
Specifications
Owner - Operator Quick Start
Contact the Factory

5
Team
Dear Owner:
Congratulations on your wise decision to make an AquaCal AutoPilot chlorinator a part of your home. Just add salt, and let your Cubby
produce the chlorine to sanitize your pool or spa. And, a wonderful thing
happens to the salt after it is turned into chlorine and does the work of
sanitizing the water—it turns back into salt and the process begins all over
again. Plus, the salt, being at a much lower level than even contact lens
solutions, means no “salty” taste to the water.
No more odors from harsh chlorine products, and never again carry chlo-
rine jugs or buckets in your car or worry
about storage. And, no longer expe-
rience the discomfort and inconve-
nience of harsh chemical reactions like
red eyes, green hair, itchy skin, or faded
swim wear.
Your pool and spa will retain a con-
stant level of chlorine, purifying the water while making it soft and silky to
the touch.
Welcome
to the
“You can rest assured know-
ing your new chlorinator is of
the highest quality and effi-
ciency, and is designed and
built to provide years of
trouble-free operation.”

6
Pool Pilot
What We Need to Know If You need To Contact Us...
Ifyou should need tocallAquaCalAutoPilotfor questions, service, or parts,pleasehavethefollowinginformation
ready:
CONTACT INFORMATION
If you have questions, please refer to our web site at www.autopilot.com for the latest manual revisions,
additional information, and helpful service advice.
You can also call us toll-free at: [phone]. We are here to serve you from 8:00A.M. to 5:00 P.M.
Eastern time, Monday through Friday. If calling after hours, our voice mail system will handle your call.
Please be sure to leave your name, a complete address, and your telephone number.
You may also reach us by email at:[e-mail].
Or, if you prefer, you may FAX us at: [phone]. Be certain to provide your full address and a daytime
telephone number.
Cubby Digital
®
Manufactured by
AquaCal AutoPilot, Inc.
2737 24th Street North
St. Petersburg, Florida 33713
U.S.A.
INSTALLER - Please record the following information prior to installation:
Control Unit
Date of Installation:
Control Unit
SuperCellSuperCell Model
(Pool Volume in Liters:)
Tri-Sensor
Pool Volume in Gallons:
Installer:
Serial Number:
Serial Number:
Serial Number:Model Type:
Type: SC-36 (only permitted type)
To Contact the Factory...

7
Used and maintained properly, your chlorine generator will provide year-upon-year of safe and economical
service. However, as with any mechanical or electrical device, to get the most from your equipment— while
insuring personal safety for you and others—certain operational and maintenance factors must be observed.
Likewise, excepting a few minor owner-capable maintenance items (explained later in this manual), repair
and service of your chlorinator must be performed only by experienced service personnel. Should you, the
owner, suspect your chlorine generator is not performing properly, by referring to the section in this manual
entitled: "Troubleshooting," you will be able to determine if a call for service is required. Your installer can
be one source of service, orAquaCalAutoPilot Customer Support personnel stand ready to assist you at:
[phone]. For questions concerning installation, operation, service and upkeep, please contact your
installerorAquaCalAutoPilot Customer Support. Warrantiesmaybe voided ifthe chlorinator has been installed,
operated, maintained, or repaired improperly.
In addition to voiding the manufacturer’s warranty... unapproved installation methods, modifications, poor
or incorrect maintenance, service by unqualified personnel, or improper use of the chlorinator may result
in personal injury and/or property damage. For personal safety, and to avoid damage to equipment, follow
all safety instructions displayed on the equipment and within this manual.
SAFETY INFORMATION
Throughout this manual the following two safety signals are placed where particular attention is required.
Please note "WARNING" relates to personal safety, while "CAUTION" signals promote avoiding damage
to equipment.
Safety Signals
Safety Information Main Table
A“warning” signal appears in this manual where special attention is required for personal safety.
(Specific instructions will appear in this box.)
Failure to heed the following may result in permanent injury
or death.
WARNING !
A “caution” signal appears in this manual where special care is required to avoid equipment damage.
(Specific instructions will appear in this box.)
Failure to heed the following may result in equipment
damage.
CAUTION !
Failure to heed the following may result in permanent injury
or death.
WARNING !
RISK OF ELECTRICAL SHOCK -Abonding lug has been provided on the outside of the Control
Unit. This lug permits the connection of a No. 8AWG (8.4mm2) solid copper-bonding conductor
(No. 6 AWG in Canada). Make this connection between the Control Unit and all other electrical
equipment and exposed metal within 5-feet (1.5m) of the Control Unit.All field-installed metal com-
ponents (such as rails, ladders, drains, etc.) within 10-feet of the pool, spa, or hot tub, must be
bonded to the equipment grounding bus using copper conductors not smaller than No. 8-AWG
(8.4mm2) (No. 6 AWG in Canada).
CHLORINATOR CONTAINS NO OWNER-REPAIRABLE COMPONENTS - Repairs must not be at-
tempted by untrained and/or unqualified individuals. If service is deemed necessary, contact install-
ing dealer orAquaCalAutoPilot Customer Support at: [phone].
Failure to heed the following may result in permanent injury
or death.
WARNING !

8
SAFETY INFORMATION
(CONTINUED)
RISK OF ELECTRICAL SHOCK - Control units configured to 115-VAC must be installed at least
10-feet (3 m) from the pool or spa wall. Control units configured to 230-VAC must be installed at
least 5-feet (1.5m) from the pool or spa wall.
Failure to heed the following may result in permanent injury
or death.
WARNING !
RISK OF ELECTRICAL SHOCK -Adisconnect device, incorporated into the fixed wiring, must be in-
cluded in the supply circuit (such as a time clock, relay, or circuit breaker).
Failure to heed the following may result in permanent injury
or death.
WARNING !
RISK OF CHILD DROWNING OR INJURY - Children must be closely supervised at all times around
pool or spa equipment.
Failure to heed the following may result in permanent injury
or death.
WARNING !
WATER CHEMISTRY SAFETY - Improper water chemistry can present a serious health hazard.The
proper residual chlorine level and water chemistry must be maintained. The addition of certain pool
maintenance chemicals can reduce the effectiveness of chlorine. Maintain Pool / Spa water per stan-
dards detailed later in this manual.
Failure to heed the following may result in permanent injury
or death.
WARNING !
TheAquaCalAutoPilot chlorinator is equipped with an electronic flow switch that automatically turns
the unit off in the event of a “low water flow” situation. Do not tamper in any way with this safety fea-
ture.
Failure to heed the following may result in equipment
damage.
CAUTION !
RISK OF ELECTRICAL SHOCK - Disconnect allAC power when installing or servicing this system.
Failure to heed the following may result in permanent injury
or death.
WARNING !
To permit proper air circulation, the Control Unit must be mounted at least 1-foot (300 mm) off ground
level.
Failure to heed the following may result in equipment
damage.
CAUTION !
A Note Concerning Terminology:
Throughout this manual, the portion of the system which mounts to the wall (and powers the cell) may be
referred to as the: Cubby Digital, Pool Pilot, power center, control center, or unit. In addition, when “pool”
is referred to in the absence of the word “spa,” it should be assumed “spa” is inferred (should a spa be present
in the installation).
TheAquaCalAutoPilot Chlorinator must be installed and operated as specified. Failure to do so will
void the equipment warranty.
Failure to heed the following may result in equipment
damage.
CAUTION !

9
The Pool Pilot Cubby Digital is a salt chlorination system designed for pool or spa water purification.Although
the Pool Pilot is easy to use, it is important to read through the entire manual before attempting to operate
the system. How Your Chlorine Generator Works
The system requires a low concentration of dissolved salt (sodium chloride) in the water. The salt concentration
level is normally maintained below the taste threshold. The Cubby Digital automatically converts the salt
into chlorine, which your pool/spa requires to remain sanitized and algae free. The chlorine reverts back
to salt after treating the water. Since the salt is constantly recycled, there is minimal loss during a swimming
season. However, salt can be lost due to filter backwashing, rain water overflow, leaks, or bather splashing/
carry out... but not through evaporation.
The Cubby Digital is designed to handle the purification needs of residential
swimmingpoolsand spas. The amountof chlorine required for propersanitization
will vary based on the pool size and various factors such as water tempera-
ture, bather load, exposure to direct sunlight, and special water features.
Thewatercirculation pump must be operatingfor your Cubby to producechlorine,
so run time is one of several key components to maintaining the proper sanitizer
levels. Most installations require a minimum of eight (8) hours-per-day
pump run time to properly filter and sanitize the water.
Control Overview
Followingisabriefexplanationofowner/operatorcontroloptions.ForfullfeaturesoftheOwnerOptions
Menu,please see page-26. The MENU button is pressedto obtain access to the Owner Options Menu.
Please Note: Thissectionassumestheinstallerhasalreadyprogrammedthesystemforspecificsiteparameters,
has established proper water balance, and has pretreated water to 1 - 3 ppm chlorine.
AttentionOwner: shouldcentigradevs.fahrenheit,choiceof language,orother owneroptionsrequire modification,
please refer to the programming information located on page-27. See: Menu Button and Owner Options.
Use the UP and DOWN arrows to control the purifier output level,
thenpresstheSELECTbuttontosavethevaluechosen.Withaproperly
prepared pool, the recommended starting output level is 50%.
Upon initial start-up, check sanitizer level every few days and make
small output level adjustments as necessary to maintain 1-3 ppm
freechlorinelevels.Keepinmind,yourCubbydoesnot directlymeasure
orregulate the sanitizer levels in yourpool.Rather,theowner/operator
willneedtoperiodically test the water todeterminethe current chlorine
level, and adjust the output setting as needed.
After the purifier output level is “tuned in,” the unit will automatically
make fine output adjustments as the water temperature fluctuates. This temperature compensation feature
willadjustoutputdependingon water temperature. See page-12 formoreinformationconcerningthe temperature
compensation feature.
Please Note: The optimum output setting will vary based upon pool size, location, exposure to sunlight,
number of users, vegetation around the pool, water balance practices, and pump run time. Your installer
shouldhavealready taken these factors into considerationwhenperforming installation programming. Therefore,
your adjustments, at this point, should be relatively minor.
Up and Down Arrows:
OWNER QUICK START & RUN

10
Purifier Output level ........................:
Water Temperature .........................:
Cell Status .....................................:
Check System Light ........................:
Check System Light ........................:
Normal Display:
TheCHECKSYSTEMlightwillflashtowarntheunitmayneedattention.
A warning message will also be displayed. If enabled, an audible
alarm* may also be heard when the system light is flashing. Unless
deemed a normal condition, per below, see troubleshooting section
beginning on page-42.
Check System Light and Audible Alarm:
Flashesredwhenpump is off / water flowisinsufficient. (Normal
if the water pump is off)
Flashes when salt is low
Flasheswhenwater temperature exceeds 125°F,or dropsbelow
10°F
The Boost Button:
The BOOST button increases output to 100%. Use this feature when
a heavier that normal bather load is anticipated.
Press BOOST once........................ = 24-Hour Boost
Press and hold BOOST for 8 seconds = 72-Hour Boost
Press BOOST a second time............= Deactivate Boost
Menu and Select Button:
Allowsaccess to the “Test,”“Setup,” “Owner Option,” “Maintenance,”
and “Installer” menus. The SELECT button allows the operator to
choose program menu options. The owner / operator should not
normally need to access these features on a regular basis. Consult
“Programming” section, or contact factory customer support for
additional information.
OWNER QUICK START & RUN
(CONTINUED)
* NOTE: WHEN ENABLED, AN AUDIBLE ALARM WILL SOUND DUE TO ANY OF THE ABOVE THREE (3) CONDITIONS. IFWATER FLOW
CEASES (OR FALLS BELOW MINIMUM ACCEPTABLE LEVELS), THE ALARM WILL AUTOMATICALLY SILENCE AFTER 10-MINUTES. TO
ENABLE OR DISABLE AUDIBLE ALARM, SEE “AUDIBLE ALARM” PROGRAMMING INSTRUCTIONS LOCATED ON PAGE-30.
In 1% increments, from 0% to 100%
In Fahrenheit or Celsius
ON or OFF
OFF when operating normally
Normally blinking when water pump is off and supply power to
the controller remains on.

11
Proper water balance is critical to the operation of your Cubby Sanitizer.
Conditions such as high pH levels, low cyanuric acid (stabilizer ) levels, or other factors causing unbalanced
water, will mask thesanitizer production of your Cubby. Please note the following recommendedwater chemistry
parameters:
See “Basic Water Chemistry,” on page-34, and “Using the Saturation Index, on page-35, for further information
concerning pool/spa water chemistry maintenance requirements.
PH........................................:
Calcium Hardness....................:
TotalAlkalinity.........................:
Salt.......................................:
CyanuricAcid (stabilizer )..........:
Chlorine.................................:
Should you have additional water balance or chemistry questions, please refer the Troubleshooting section
inthebackof this manual. For additional assistance,pleasecontactfactory Customer Support per the information
provided on page-6 of this manual.
Water Balance & Chemistry Recommendations
Winterizing
Freeze Protection & Extended Shut Down:
Important !!!
Information Critical to the Survival
of Your Pool Pilot Follows...
In areas where freezing conditions are a rare occurrence, allow the filtration
system to run continuously throughout the freeze period. Typically, during light
freeze conditions, circulating (moving) water will not freeze.
In areas where freezing conditions are prevalent and sustained, the Pool
Pilot MUST be winterized; please refer to winterizing instructions on page-41.
Special measures are required in the event of freezing conditions.Your Pool Pilot may be damaged
if measures are not taken in advance of freezing conditions. Equipment damage due to freezing con-
ditions is NOT covered under the equipment warranty.
Failure to heed the following may result in equipment
damage.
CAUTION !
OWNER QUICK START & RUN
(CONTINUED)
7.2 – 7.8
200 – 400 ppm
80 – 100 ppm
2500 – 3500 ppm (ideal 3000 ppm)
60 – 80 ppm
1 – 3 ppm

12
IMPORTANT FEATURES
Patentedtemperaturecompensationforchlorineoutputcontrol...
Programmablemicroprocessor control...
Multi-languagedigitaldisplay (English, Spanish,& French)...
Digitallycontrolled powerto theSuperCell...
Tri-sensor circuitry to monitor water flow, water temperature, and salt level. Calculates and
providesrecommended salt addition amountsrequiredto maintain the recommended3000
ppm(3.0g/l))salt concentrationlevel.
Patented Temperature Compensation
TheTri-Sensor temperaturesensorworksinconjunctionwiththepurifier%featuretoautomatically
adjust chlorineoutputbaseduponchangesinwatertemperature.Theautomaticcompensation
feature operates between 55°F and 125°F (13°C - 52°C).
Aswater temperature falls below65°F(18°C), the controller willactivate a high purifier percent
lockout,and maynot allow purifieradjustments upto100%. Thisfeature preventsthecontroller
from over-driving the cell under colder temperatures, thus preventing premature cell wear.
At 55°F (13°C) or colder water temperatures, the controller will adjust to a fixed 1% output,
thus preventing over-chlorination and premature cell failure.
As the water temperature rises above set point, the controller will adjust at 5% per °F up to
100%, thus preventing under-chlorination during warmer water temperatures.
WaterManifoldsAssemblies-TwoAvailableOptions
The Cubby Digital may be operated with either the Inline-Cell ManifoldAssembly (#75082),
or the PatentedAutomatic-Flow Bypass ManifoldAssembly (#94105). Use with SC-36 cell,
ONLY!
Please see Installer section: “Basic System Overview,” for details and diagrams on both
assemblies.
To become fully-familiar with all the features, the safe operation, and the
care of your new chlorinator, please read through the entire remainder of
this manual.
Get the Most from Your Purchase!

13
Cubby Digital
Pool Pilot
&7
®
INSTALLER-SPECIFIC
INFORMATION
FOLLOWS
Thismanual coverstheinstallation and operationof Cubby Digital
ChlorineGenerators equipped withthefollowing Cell &Manifold as-
semblies (sold separately): Part Numbers 94105 & 75082.
Models: 75080 and 75081
Salt Chlorine Generator
Swimming Pool & Spa Purification System
Foruse with SC-36 Cell, ONLY!
INSTALLER: THIS DOCUMENT IS PURCHASER’SPROPERTY AND IS TO REMAIN WITH THE EQUIPMENT OWNER

14
INSTALLER TABLE OF CONTENTS
FACTORY CONTACT INFORMATION ................................................................................ 6
SAFETYINFORMATION ..................................................................................................... 7
Safety Signals .........................................................................................................................7
SafetyInformationMainTable..................................................................................................7
SPECIFICATIONS ............................................................................................................. 16
Input Electrical Power ...........................................................................................................16
Chlorine Output .....................................................................................................................16
Manifold Flow Requirements.................................................................................................16
AgencyApprovals..................................................................................................................16
INSTALLATION ................................................................................................................. 17
BeforeInstalling.....................................................................................................................17
What is included....................................................................................................................17
What is not included..............................................................................................................17
TwoAvailable Options for Water ManifoldsAssemblies........................................................18
TheInline-Cell ManifoldAssembly (#75082)..............................................................18
TheAutomatic-Flow Bypass ManifoldAssembly (#94105)........................................18
Basic System Overview........................................................................................................19
Inline-Cell ManifoldAssembly (#75082)....................................................................19
Automatic-Flow Bypass ManifoldAssembly (#94105) ..............................................19
InstallationSteps ...................................................................................................................20
Plumbing Requirements........................................................................................................20
Plumbing the ManifoldAssembly...........................................................................................20
For flow rates within the normal range ..........................................................20
For flow rates greater than 100 gpm (379 L/m).............................................20
MountingtheControl Unit ......................................................................................................21
Electrical Requirements........................................................................................................21
Electrical Connections ..........................................................................................................22
Groundingand Bonding.........................................................................................................22
High Voltage Wiring ...............................................................................................................22
Connecting75081 Cubby Digital to an External Timeror Controller.......................................22
Low Voltage Wiring................................................................................................................23
Connecting the SuperCell Cable ...............................................................................23
ConnectingtheTri-SensorCable............................................................................... 23
PREPARINGTHEPOOLWATER..................................................................................................24
Steps to Prepare Water.........................................................................................................24
Calculating Pool Volume........................................................................................................24
AddingSalt ............................................................................................................................25
Type of SalttoAdd .................................................................................................................. 25
DetermineAmount ofSaltRequired .......................................................................................25
Salt level to maintain......................................................................................25
Adding Salt to Pool Water......................................................................................................25
How to add the salt ........................................................................................25

15
INSTALLER TABLE OF CONTENTS
(CONTINUED)
MENUOVERVIEW .......................................................................................................................... 26
ACCESSTO PROGRAMMING .....................................................................................................26
ControlPanel......................................................................................................................... 26
Operationof Buttons ................................................................................................................. 26
Menus...................................................................................................................................... 26
PROGRAMMING..............................................................................................................................27
MenuButton ............................................................................................................................ 27
SelectButton..........................................................................................................................27
ViewSetup ..............................................................................................................................27
ProgrammingatInstallation....................................................................................................28
Review of Installer, Owner, & Maintenance Menu Programming ...........................................28
PoolVolume...............................................................................................................28
Calibrating Salt ..........................................................................................................28
Select Language........................................................................................................28
CalibratingTemperature ............................................................................................29
Select Units ...............................................................................................................29
Temperature Display (F or C)....................................................................................29
Set Reverse Time......................................................................................................29
Force Reverse ..........................................................................................................30
AudibleAlarm.............................................................................................................30
Basic Operational Programming...........................................................................................30
Adjusting the Purifier Output %..................................................................................30
Boost or Super Boost................................................................................................30
Control Options .....................................................................................................................31
PurifierMode .............................................................................................................31
Test Pool Pilot............................................................................................................32
REFERENCESECTION .................................................................................................................33
SaltAddition Chart ..................................................................................................................33
Basic Water Chemistry .........................................................................................................34
Usingthe Saturation Index (SI) ..............................................................................................35
MAINTENANCE................................................................................................................................36
FuseLocation and Ratings ................................................................................................... 36
Tri-Sensor Assembly.............................................................................................................36
Removing\Inspecting\Cleaning theTri-Sensor......................................................................37
TestingFlow Switch, Cleaning Screen &BypassValve .........................................................38
Servicingthe SuperCell ............................................................................................................ 39
Removalofthe SuperCell .......................................................................................... 39
Visual Inspection of the SuperCell .............................................................................39
ManualCleaningoftheSuperCell................................................................................40
Installation of a Super Cell .........................................................................................41
Winterizing ............................................................................................................................41
Spring Start-Up ......................................................................................................................41
TROUBLESHOOTING....................................................................................................................42

16
SPECIFICATIONS
Date of Installation
Control Unit Model (Type should be # 75080 or # 75081)
Control Unit Serial Number
SC-36 SuperCell Serial Number
Tri-Sensor Serial Number
Installer... please record the following information on page-6 of this manual:
Chlorine Output:
For questions concerning installation or operation of this equipment:
Visit www.autopilot.com for latest manual revisions and helpful troubleshooting tips.
Contact factory Customer Support by dialing: [phone] or [phone]... or by
email [e-mail] ... or by FAX at: [phone].
Run the “View Setup” (page-27) and record the information displayed; have the following
information available prior to contactingAquaCal AutoPilot Customer Support:
Current Measured Salt Level
Software (SW) Versions
-or-
Agency Approvals:
ETLTested to conform to the following UL specifications:
Manifold Flow Requirements:
SuperCell Type-36 (ONLY): Maximum Chlorine Output of SC-36 cell is 0.8 lbs /day (0.36 kg /day)
UL1081......................:
CAN/CSA-E60335-1....:
Standard for Safety for Swimming Pool Pumps, Filters, and Chlorinators
Safety of Household and Similar ElectricalAppliances
Input Power:
Model 75080...................:
Model 75081...................:
110-120 VAC, 2.0Amp
220-240 VAC, 1.0Amp
Minimum Flow Rate.........:
Maximum Flow Rate........:
Maximum Op. Pressure....:
20-gallons per minute (gpm) (76 liters/minute (L/m))
100-gallons per minute (gpm) (379 liters/minute (L/m))
85-psi

17
Determine origination point for control center power feed:
Directly from a circuit breaker...
From an external timer, or
From an electronic controller
INSTALLATION
Before Installing:
Determine everything needed for installation is on hand.
Determine where the Manifold Assembly will be plumbed.
Identify a suitable mounting location for the Control Unit within proper cord length to the manifold.
Plan runs for SuperCell and Tri-Sensor Cables.
Plan wire runs and wiring connections for source power.
Cubby Digital is to be wired to the same location as the circulation
pump; the Cubby Digital is activated when the circulation pump
is energized.
What is included:
Although the manifold assembly may be sold separately, both a manifold and a Cubby Digital Control Center
are required for a complete installation. The standard cell & manifold assembly is available with the SC-36
residential cell. Before attempting the installation, verify the following items have been included with the
Control Center:
What is NOT included with Control Center:
Power service electrical wire.
½" liquid tight (nonmetallic flex) conduit.
A Note Concerning Terminology:
Circuit breaker is used to power the Cubby Digital and circulation
pump.
Determine whether the input voltage for the Cubby Digital will be 115-VAC (as with Model 75180),
or 230-VAC (as with Model 75081).
Screws and
Anchors
SuperCell
Cable
Quantity Item Description
1 Power Cord with 110 VOLT plug
1 SuperCell Cable
4 Plastic Anchors
4 Mounting Screws
Quantity Item Description
2 6' Power Leads
1 SuperCell Cable
4 Plastic Anchors
4 Mounting Screws
75080 CUBBY DIGITAL CONTROLLER
75081 CUBBY DIGITAL CONTROLLER
Manifold Options Follow on Next Page...
Throughout this manual, the portion of the system which mounts to the wall (and powers the cell) may be
referred to as the: Cubby Digital, Pool Pilot, power center, control center, or unit. In addition, when “pool”
is referred to in the absence of the word “spa,” it should be assumed “spa” is inferred (should a spa be present
in the installation).

18
Two Available Water Manifolds Assemblies:
INSTALLATION (CONTINUED)
Inline-Cell Manifold Assembly (#75082)
SEE
INSTALLATION
DIAGRAM
,
NEXT
PAGE
The manifold is connected into the plumbing after all
other equipment. Water from the pool/spa is moved
thoughthemanifoldby the circulation pump. Theman-
ifold'skeycomponentsaretheTri-SensorandSuperCell.
TheTri-Sensor providesdata(fromelectronicsensors)
to the Control Unit for monitoring water flow, water
temperature,and salt concentration level. The Control
Unit uses this data to determine if conditions are safe
for the SuperCell to operate; the signal read from the
temperaturesensor allows the automatic temperature
compensation feature to function.
TheSC-36 SuperCell receives powerfrom the Control
Unit and converts the salt contained in the water to
chlorine.
The manifold is connected into the plumbing after all
other equipment. Water from the pool/spa is moved
thoughthemanifoldbythe circulation pump. The man-
ifold's four key components are the: Strainer Screen,
Tri-Sensor, SuperCell, and Bypass Flow Valve.
The Strainer Screen prevents debris in the water from
entering the Tri-Sensor or SuperCell, and requires
periodic inspection and cleaning.
TheTri-Sensorprovidesdata(fromelectronicsensors)
to the Control Unit for monitoring water flow, water
temperature,and salt concentrationlevel. The Control
Unit uses this data to determine if conditions are safe
for the SuperCell to operate; the signal read from the
temperaturesensor allows the automatic temperature
compensation feature to function.
TheSC-36 SuperCell receives power from the Control
Unit and converts the salt contained in the water to
chlorine.
The Bypass Valve allows the water flow rate to be slowed and optimized through the SuperCell, while
permitting the pump to continue to circulate water to-and-from the pool/spa at full flow rates. The slowed
waterflow through theSuperCell results ina more efficient"Super-Chlorination” effect, resultingin improved
overall sanitization.
Automatic-Flow Bypass Manifold Assembly (#94105)
SEE
INSTALLATION
DIAGRAM
,
NEXT
PAGE
Tri-Sensor
SuperCell
Strainer Screen
Bypass Flow Valve
(INSIDE)

19
Basic System Overview:
The Cubby Digital unit is a salt chlorination system for pool or spa purification, and is designed to operate
in the following configurations:
INSTALLATION (CONTINUED)
Shown with Automatic-Flow Bypass Manifold Assembly (#94105):
Circuit
Breaker Timer
Pump
Filter Cell
Tri-Sensor
Water
Flow
Water
Flow
○○○
○○○○
NOTE:
BROKEN LINES REPRESENT ELECTRICAL
SUPPLY POWER SOURCE OPTIONS.
○○○○○○○
BREAKER
TIMER
WARNING!
MANIFOLD VERTICAL ONLY
Shown with Inline-Cell Manifold Assembly (#75082)
Water
Flow
Water
Flow
Pump
Filter Tri-Sensor Cell
Timer
Circuit
Breaker
○○○○○
○○○○
NOTE:
BROKEN LINES REPRESENT ELECTRICAL
SUPPLY POWER SOURCE OPTIONS.
○○○○○○○
BREAKER
TIMER

20
Installation Steps:
Details on each step of the installation process are presented on the following pages:
1. Plumbing the ManifoldAssembly (see below)
2. Mounting the Control Unit (page-21)
3. Electrical Requirements & Connections (pages 21-22-23)
a. Grounding and bonding
b. Line (high) voltage wiring (Pool Pilot Digital to an external timer or controller)
c. Low voltage wiring
• SuperCell cable
• Tri-sensor cable
4. Preparing the Water (pages-24 & 25)
5. Programming and Setup for Site Parameters. (pages 26-32)
Note: Insure flow rates for two-speed pump can provide sufficient flow at low speed.
Plumbing the Manifold Assembly:
STEP-1: Select the location for installing the manifold:
It is recommended the manifold be installed prior to installation of the Control Unit. The Control Unit
must be installed close enough to the ManifoldAssembly to allow the Tri-Sensor and SuperCell cables
sufficient slack to enable component service and maintenance. The cables are 12’ long.
If using the Bypass Manifold/Cell (# 94105), the assembly must be installed in a vertical orientation as
illustratedin the diagram on previous page. This orientation prevents hazardous gas buildup in the system,
should the flow switch should fail to detect insufficient flow. WARNING! Place manifold vertical ONLY.
Thedirectionof the water flowthrough the manifold mustbe as indicated forthe system to operate properly.
For a Pool/Spa combination, the manifold must be located as the last component in the POOLRETURN
LINE (to avoid over-sanitization of the spa).
Flow Rates Within Normal Range:
The manifold can be directly plumbed into the system (as shown in the diagrams on the prior page).
If the flow rate for the system is less than 20-gpm (76 L/m), a larger pump must be installed (or steps
taken to improve flow rate).
Plumbing Requirements:
The ManifoldAssembly is 2" Schedule 40 PVC, and is typically plumbed into the pool return line; and, if
applicable, after the heater and spa return diverter valve.
INSTALLATION (CONTINUED)
Flow Rates Exceeding 100-gpm (379 L/m)
TOPOOL
RETURN
FROM
PUMP &
FILTER
# 75082
5-LB SPRING BYPASS CHECK
VALVE MUST BE PLUMBED IN
PARALLEL WITH THE MANIFOLD.
FROM
PUMP &
FILTER
TOPOOL
RETURN
# 94105
WARNING!
MANIFOLD VERTICAL ONLY
