Aquatec ERP 500 User manual

PERMEATEPUMPINSTALLATION INSTRUCTIONS
This is the side of the pump that the brine ( waste water)
connections are made.
After your flow restrictor on the waste line on the way to the drain
you install this side of the pump. Run a tube from the flow
restriction on your unit to the brine in port on the pump. Then run a
tube from the brine out port of the pump to the drain.
Remember the out port must be up when compared to the in port.
With the out port in the up position no air can remain trapped in the
pump.
The ports are marked check the pump label.
This is the permeate ( pure water ) side of the pump. This side is
installed between the membrane and the final filter or the storage
tank.
Permeate ( pure water ) from the membrane is connected to the
permeate in port. The permeate out port connects to one side of the
final filter or to the storage tank. Most systems have a tee on the inlet
of the final filter connect to that tee.
When you combine the white clip with the black clip you can mount
the pump directly onto the membrane housing.
You may use fittings to make the connection or you can simply push
tubing into the ports.
These are push-in fittings and
you just firmly push the tube into
place.
If you want to remove the tube,
First push in on the tube, hold
down on the fitting collar with
your thumb nail and pull lightly
on the tube. If you have properly
held the collar down then the tube
will slip out pretty easily.
