Aquatic 1
Serenity Owner's Manual & Installation Guide
OWNER’S MANUAL &
INSTALLATION GUIDE
Serenity Air Baths
INSTALLER: This booklet must be given to the product owner.
Read all instructions before proceeding. All specifications
are ± 3⁄8’’ and are subject to change without notice.
Dimensions listed in inches.
Model #
Purchase Date
Serial #
Distributor

2 Aquatic
Serenity Owner's Manual & Installation Guide
TABLE OF CONTENTS
PRODUCT WARRANTY REGISTRATION INFORMATION 3
INSTRUCTIONS PERTAINING TO A RISK OF FIRE, ELECTRIC SHOCK,
OR INJURY TO PERSONS 4 – 5
SERENITY AIR BATH USER INFORMATION 6
FCC INFORMATION 6
AQUATIC LIMITED WARRANTY 7
INSTALLATION INSTRUCTIONS
Pre-Installation Procedures 8
Structural Preparation 9 – 11
Factory Installed Tile Flange 12
Plumbing 12
Electrical Installation 13
Electrical Connections 14 – 17
Variable Speed Air Blower Remote Mounting (Non-Freestanding) 18
Installation of Freestanding Models 19 – 22
Variable Speed Air Blower Remote Mounting (Freestanding) 23 – 24
Remote Control (Non-Freestanding) 25 – 26
Remote Control (Freestanding) 27
Final System Test & Clean-Up 28
OPERATION
Bathside Control Systems (Non-Freestanding) 29
Bathside Control Systems (Freestanding) 30
To Replace LED Light 31
TUB CARE
Maintenance 32
Flushing/Sanitizing 32
Surface Scratch Removal 32
Repair 32
Water and Air Temperature 32
WATER QUALITY ISSUES
Chemical and Water Quality 33 – 34
TROUBLESHOOTING GUIDE 35
REPLACEMENT PARTS LIST 35
REPLACEMENT PARTS MAP 36

Aquatic 3
Serenity Owner's Manual & Installation Guide
Thank you for choosing an Aquatic bath. You have chosen one of the finest bath products in the industry! Aquatic supports
your purchase with strong commitments to quality and customer satisfaction.
Please read and follow all of the instructions contained in this Owner’s Manual before installing, operating or maintaining your
air bath. In addition, you should continually refer to these instructions during the life of your air bath. Failure to comply with
these instructions may invalidate your warranty. If you have any questions concerning installation, operation, maintenance
or any other aspect of your Air Bath, please contact:
AQUATIC CUSTOMER SERVICE CENTER: [phone]
(The Troubleshooting Guide on page 35 may be helpful in answering some of your questions.)
NOTE: The installation and service of your Air Bath
should be performed ONLY by a qualified electrician and plumber.
AQUATIC
Product Warranty Registration Information
IMPORTANT!
To activate Product Warranty please register with Aquatic.
Your product warranty must be registered and confirmed with Aquatic through
the Serial Number on your unit. To register, please contact Aquatic.
(800) 945--2726 • www.aquaticbath.com/register
This product MUST BE WATER-TESTED and inspected prior to installation
or warranty will be voided. See page 8 for instructions.
PLEASE CHECK ENTIRE UNIT FOR ANY DAMAGE.
If it appears damaged, contact your Aquatic Distributor immediately.
Aquatic warranty does not cover damage that occurs in transit.
IMPORTANT!
SERIAL NUMBER LOCATION
The tub model and serial numbers are located
above the blower area on the backside of the drop-in
models. Your installer should have a service access panel
in this location. The numbers are located on the bottom
of the tub on freestanding models. Look for a label
which resembles the one on the right.
Customer Service: 800.945.2726 • aquaticbath.com

4 Aquatic
Serenity Owner's Manual & Installation Guide
INSTRUCTIONS PERTAINING TO A RISK OF FIRE,
ELECTRIC SHOCK, OR INJURY TO PERSONS
WARNING: When using this unit, basic precautions should always be followed. Failure to follow these instructions could
result in personal injury, electric shock, or fire.
READ AND FOLLOW ALL INSTRUCTIONS:
• WARNING: Risk of lethal electric shock. To reduce risk of electric shock, connect only to circuits protected by a
Ground-Fault Circuit-Interrupter (GFCI) or Residual Current Device (RCD).
• DANGER: To reduce the risk of injury, do not permit children to use this unit unless they are closely supervised at
all times.
• Use this unit only for its intended use as described in this manual. Do not use additional attachments and/or
equipment not recommended by the manufacturer.
• Never drop or insert any object into any opening.
• The unit must be connected only to a supply circuit that is protected
by a Ground-Fault Circuit-Interrupter (GFCI). Such a GFCI should be
provided by the installer and should be tested on a routine basis. To
test the GFCI, push the test button. The GFCI should interrupt power.
Push the reset button. Power should be restored. If the GFCI fails to
operate in this manner, there is a ground current flowing, indicating the
possibility of an electric shock. Do not use this unit. Disconnect the unit
and have the problem corrected by a qualified service representative
before using.
• To reduce the risk of injury, enter and exit the bath slowly.
• This product is intended for indoor use only. Installing this unit outdoors
could cause personal injury and will void your warranty.
SAVE THESE INSTRUCTIONS.
Your safety and the safety of
others are very important.
We have provided many important
safety messages in this manual and
on your appliance. Always read
and obey all safety messages.
This is the safety alert
symbol. This symbol
alerts you to potential
hazards that can kill or
hurt you and others.
All safety messages will follow the
safety alert symbol and either the
word “DANGER” or “WARNING.”
These words mean:
DANGER
You can be killed or seriously
injured if you don’t immediately
follow instructions.
WARNING
All safety messages will tell you
what the potential hazard is, tell you
how to reduce the chance of injury,
and tell you what can happen if the
instructions are not followed.
CALIFORNIA PROP. 65
WARNING: This product
can expose you to chemicals
including styrene and sty-
rene compounds, which are known
to the State of California to cause
cancer and birth defects or other
reproductive harm. For more informa-
tion go to www.p65warnings.ca.gov

Aquatic 5
Serenity Owner's Manual & Installation Guide
INSTRUCTIONS PERTAINING TO A RISK OF FIRE,
ELECTRIC SHOCK, OR INJURY TO PERSONS
Before taking your first air bath, be sure you have performed the “Flushing/ Sanitizing.” [See TUB CARE on page 32.]
Be sure that you are familiar with all the controls and switches and that the unit is operating properly. [See BATHSIDE
CONTROL SYSTEMS on pages 29 - 30.]
1. The water in a bath tub should never exceed 40º C (104º F). Water temperature between 38º C (100º F) and 40º C
(104º F) are considered safe for a healthy adult. Bathing time should be limited to approximately 30 minutes, followed
by a shower to cool down. Longer exposure may result in hyperthermia. The symptoms of this condition are nausea,
dizziness and fainting, which can be fatal. Lower water temperatures are recommended for extended use (exceeding
10-15 minutes) and for young children.
2. If you will not be operating the air bath system during your bath, you may fill the bathtub to any comfortable level.
However, if you will operate the system, you must fill the bathtub with water to a minimum of 4" above air channel.
This will assure proper operation of the system.
3. A few important bathing “DONT’S”-
DO NOT operate the air bath system if:
• The bathtub isn’t filled to required levels above air channels.
• You’re pregnant (until you’ve consulted your doctor).
• You’re taking medications or drugs that may make you drowsy.
• You’re drinking any form of alcohol.
• You’ve just had a meal. Wait for 30 minutes after eating.
• There is a child in the bathtub who may be left unattended at any time. Never allow small children to remain
unattended in any bathtub.
• There are any small objects in the bathtub. The air bath action can move small objects at high speeds, causing
pain and possible injury.
• You’re smoking. The heat of burning tobacco can damage the bathtub surface. Keep tobacco products and
ashtrays away from the bathtub.
• You have problems with your immunity system (until you have consulted your doctor).
• Never operate electrical appliances (television, hair dryer, radio, telephone, etc.) inside or within five feet (5') of
the bath.
• You are using additional attachments and/or equipment not recommended by the manufacturer.
• You have a medical history of heart disease, low or high blood pressure,
circulatory system problems, or diabetes, consult with a physician before using an airbath.
• You are under the influence of drugs, anticoagulants, stimulants, antihistamines, vasoconstrictors, vasodilators,
hypnotics, narcotics, or tranquilizers.
