SPECIFICATIONS:
The manufacturer accepts a 1/4” variance. There are variations on each tub and specifications are subject to change as we improve upon our product as required. The dimensions needed for site preparation
and structure building should be measured from the tub; Aquatic Industries, Inc. assumes no responsibility for preparatory work. www.aquaticwhirlpools.com 800.555.5324
August 2008
Rough-In Plumbing
Measurements
Aquatic Quality Features:
- 1.5 kW Inline Maintenance Heater
- Run-Dry Pump with 20-Minute Timer
- 2 Circulation Portal Covers
- Bath-Side On/Off Electronic Button
- “Quiet Pad” Anti-Vibration Pump Mount for Quiet Operation
- Slip Resistant Floor
- 4 Arm Rests
- Extra Deep and Long Bathing Well
- Pre-leveled ABS Support Base
- Color Matched Grab Bar
- Heat-bent Rigid PVC Piping for Optimum Sanitary Conditions
- Durable, Easy to Clean, Lucite® Cast Acrylic Surface
- Available in 8 Standard No-Charge Colors
UL & IAPMO Listed, Factory Tested
Limited Lifetime Warranty
STANDARD EQUIPMENT:
• Chromatherapy LED Lighting*
• Comfort Pillow - Oval or Rectangle
• Grab Bar
- White, Biscuit, Chrome, Polished Brass, Gold,
Polished Nickel, Satin Nickel or Oil Rubbed Bronze
• Lift & Turn Waste and Overow
- Chrome, Polished Brass, Gold, Polished Nickel,
Satin Nickel or Oil Rubbed Bronze
• Cable Drive Waste and Overow
- Chrome, Polished Brass, Gold, Polished Nickel,
Satin Nickel, Oil Rubbed Bronze or Color Matched
(Bone, White and Biscuit Only)
• Optional Pump Location
• Premium Colors
All acrylic colors featured by Aquatic match the industry’s
leading xture manufacturers.
*This whirlpool will need to be hard wired to the breaker box.
Three outlets will be supplied on the whirlpool.
OPTIONAL EQUIPMENT:
GENERAL SPECIFICATIONS:
Tub Size 70 1/4” x 35 3/4” x 24 3/4”
178 cm x 91 cm x 63 cm
Bathing Well 45 3/4” long
19” wide
22 3/4” interior depth
Shipping Weight 146 lbs. / 66 kg
Tub Weight Filled 828 lbs. / 376 kg
Gallons to Overow 80 gal. / 303 L
ELECTRICAL SPECIFICATIONS:
Pump 1/15 HP; 1.3 AMP; 110V
Heater 1.5 kW; 12.5 AMP; 110V
Requirements 20 AMP; 110V, separate circuit
required protected w/ Class A GFCI
This unit is not recommended for shower installations.
hOTSOAk 69
hOTSOAk SErIES Model # AI16AIR7036HS
35 1/8”
35 3/4”
70 1/4”
65”
21 1/4”
Two Person Bath
35 3/4”
32”
23 1/2”
24 3/4”
Fax-On-Demand
Document #1244
5 3/8”
12”
