Aquatic SERENITY STUDIO 35 User manual

SPECIFICATIONS:
The manufacturer accepts a 1/4” variance. There are variations on each tub and specifications are subject to change as we improve upon our product
as required. The dimensions needed for site preparation and structure building should be measured from the tub; Aquatic Industries, Inc. assumes no
responsibility for preparatory work.
www.aquaticwhirlpools.com 800.555.5324
June 2008
SErENITy STudIO 35
GENERAL SPECIFICATIONS:
Tub Size 59 3/4” x 36” x 24”
152 cm x 91 cm x 61 cm
Bathing Well 38” long
21” wide
21” interior depth
Maximum Water Depth 17 1/2”
Shipping Weight 158 lbs. / 72 kg
Tub Weight Filled 779 lbs. / 353 kg
Tub Only Weight 88 lbs. / 40 kg
Weight with Equipment 98 lbs. / 44 kg
Gallons to Overow 82 gal. / 310 L
ELECTRICAL SPECIFICATIONS:
Blower/Heater 1 HP; 10.5 AMP; 120V
Requirement 15 AMP; 120V, separate circuit
required protected w/ Class A GFCI
STANDARD EQUIPMENT: OPTIONAL EQUIPMENT:
SErENITy STudIO MODEL # AI35AIR6036/AI35AIR6036TO (Tub Only)
Deck
Width
4”
36”
Deck Width
3 3/4”
38”
21”
36”
22”
24”
59 3/4”
20 1/2”
Air Bath System:
- 70 Air Jets
- 1 HP Variable Speed Air Blower with 20-Minute Timer
- 600 Watt Air Heating System
- Electronic Control Package with Wave and Pulse Features
- Automatic Purge and Dry Cycle with Water Sensors
Aquatic Quality Features:
- Chromatherapy
- Slip Resistant Floor
- Air Channels Lined with Antimicrobial Coating
- Pre-leveled ABS Support Base
- Durable, Easy to Clean, Lucite® Cast Acrylic Surface
- Available in 8 Standard No-Charge Colors
UL & IAPMO Listed, Factory Tested
Limited Lifetime Warranty
• Comfort Pillow - Oval or Rectangle
• Bolt-On Grab Bars
- White, Biscuit, Chrome, Polished Brass, Gold,
Polished Nickel, Satin Nickel or Oil Rubbed Bronze
• Lift & Turn Waste and Overow
- Chrome, Polished Brass, Gold, Polished Nickel,
Satin Nickel or Oil Rubbed Bronze
• Cable Drive Waste and Overow
- Chrome, Polished Brass, Gold, Polished Nickel,
Satin Nickel, Oil Rubbed Bronze or
Color Matched (Bone, White and Biscuit Only)
• Waterproof Remote Control with infrared sensor
and 25’ cord
• Remote Blower Wiring Kit
• Integral Tiling Flange (Customer must specify which
side(s) should receive ange)
• Color Matched Acrylic Skirt
• Premium Colors
All acrylic colors featured by Aquatic match the
industry’s leading xture manufacturers.
Each Serenity Air Bath model is equipped with a 600 watt air heating system to raise the temperature of the air going into the bath. This air temperature will
be less than the bathing temperature of the water, but will help to reduce a rapid decrease in water temperature. In addition, the air coming from the air jets
will feel cool against the skin, just as a breeze on a warm day cools your body. This system does not heat the water.
Fax-On-Demand
Document # 1148
Back Angle
26°
Rough-In Plumbing
Measurements
2 3/4”
10 3/4”
