Aquatic SYMPHONY SERIES User manual

Note: Read all instructions before proceeding with installation.
All specifications are ± 1/4’’ and are subject to change without notice.
OWNER’S MANUAL &
INSTALLATION GUIDE
SYMPHONY SERIES

PRODUCT REGISTRATION INFORMATION 4
CONGRATULATIONS! 5
SAFETY INSTRUCTIONS 6
INSTALLATION INSTRUCTIONS
Pre-Installation Procedures 7
Electrical Installation 8
Structural Preparation 9
Framing Diagrams 10
Integrally Skirted Whirlpools 11
Flat Panel Skirt Installation 12-14
System Test and Clean-Up 15
OPERATION
Whirlpool Operations 16-18
MAINTENANCE AND CARE
Initial Cleaning 19
Whirlpool System Cleaning 19
Surface Cleaning 19
Jet Cleaning 19
Surface Scratch Removal 20
Repair Information 20
Water Quality Issues 20-21
TROUBLESHOOTING GUIDE
Symptoms/Possible Problems/Solutions 23
Serial Number - How to Locate 23
PARTS ORDER FORM/PARTS MAP/PARTS LIST
Parts Order Form 24
Parts Order Map 25
Parts Order List 26
AQUATIC LIMITED WARRANTY 27
TABLE OF CONTENTS

Aquatic Industries, Inc.
4
Your product warranty is registered and confirmed with Aquatic through the Serial Number on
your unit. You do not need to contact Aquatic to confirm registration. Please fill out the information
below and reference when contacting the distributor to expedite warranty claims.
OWNER INFORMATION:
Model Name
Serial Number
(See Table of Contents for Location)
Purchase Date
Distributor
P.O. Box 889 • Leander, TX 78646-0889
Phone [phone] • Fax [phone]
AQUATIC INDUSTRIES, INC.
Product Registration Information

Aquatic Industries, Inc. 5
NOTE:
The installation and service of your whirlpool should be
performed ONLY by a qualified electrician, technician or plumber.
You have chosen one of the finest bath products in the world! Aquatic Industries supports your purchase
with strong commitments to quality and customer satisfaction.
Please read and follow all of the instructions contained in this Owner’s Manual before installing, operating or
maintaining your whirlpool. In addition, you should continually refer to these instructions during the life of your
whirlpool. Failure to comply with these instructions may invalidate your warranty. If you have any questions
concerning installation, operation, maintenance or any other aspect of your whirlpool, please contact:
AQUATIC INDUSTRIES CUSTOMER SERVICE CENTER: 800-928-3707
(The Troubleshooting Guide on page 23 may be helpful in answering some of your questions.)
CONGRATULATIONS!
IMPORTANT!
This product MUST BE WATER-TESTED and inspected prior to installation
or warranty will be voided. See page 7 for instructions.
PLEASE CHECK ENTIRE UNIT FOR ANY DAMAGE.
If it appears damaged, contact your Aquatic Distributor immediately.
Aquatic Industries, Inc. warranty does not cover damage that occurs in transit.

Aquatic Industries, Inc.
6
IMPORTANT SAFETY INSTRUCTIONS
WARNING: WHEN USING THIS UNIT, THESE BASIC PRECAUTIONS SHOULD BE FOLLOWED.
This manual contains information and instructions for proper operation and maintenance of your whirlpool. Failure to
follow these instructions could result in personal injury, electrical shock or fire.
READ AND FOLLOW ALL INSTRUCTIONS
DANGER! TO REDUCE THE RISK OF INJURY:
1. Do not permit children to use this unit unless they are closely supervised by an adult at all times.
Supervision is also required when whirlpool bath is used by an elderly or handicapped individual.
2. Use this unit only for its intended use as described in this manual. Do not use attachments not
recommended by the manufacturer.
3. Do not operate this unit without guard over the suction fitting.
4. The water in a whirlpool should never exceed 40°C (104°F). Water temperatures between 38°C (100°F)
and 40°C (104°F) are considered safe for a healthy adult. Use time should be limited to approximately
30 minutes, followed by a shower to cool down. Longer exposures may result in hyperthermia. The
symptoms of this condition are nausea, dizziness and fainting, which can be fatal. Lower water
temperatures are recommended for extended use (exceeding 10-15 minutes) and for young children.
5. Since excessive water temperatures have a high potential for causing fetal damage during the early
months of pregnancy, pregnant or possibly pregnant women should limit whirlpool water temperatures
to 38°C (100°F).
6. The use of drugs or alcoholic beverages before or during whirlpool use may lead to unconsciousness with
the possibility of drowning. Never use the whirlpool while under the influence of alcohol, anticoagulants,
stimulants, antihistamines, vasoconstrictors, vasodilators, hypnotics, narcotics or tranquilizers.
7. Persons with a medical history of heart disease, low or high blood pressure, circulatory system problems,
or diabetes should consult a physician before using a whirlpool.
8. Persons using medication should consult a physician before using a whirlpool since medication may
induce drowsiness while other medication may affect heart rate, blood pressure and circulation.
DANGER: To reduce the risk of injury, enter and exit the bath slowly.
WARNING: Never operate electrically connected devices in or near the bath. Never drop or insert any object into any
opening within the whirlpool.
This unit must be connected to a supply circuit that is protected by a Ground Fault Circuit Interrupter (GFCI). Such
a device should be installed by a licensed electrician and should be tested on a regular basis (at least monthly). To
test the GFCI push the TEST button. The GFCI should interrupt the power. Push the RESET button and the power
should be restored. If the GFCI fails to operate in this manner there is the possibility of an electric shock. DO NOT
USE. Disconnect the unit and have the problem corrected by a qualified service technician. To avoid the possibility
of personal injury and discoloration of the acrylic surface, the inlet water temperature should not exceed 60°C (140°F).
The bath should be drained after each use. Each bather should start their bath with fresh water.
CAUTION: DO NOT USE HARSH ABRASIVES OR SOLVENTS FOR CLEANING THIS UNIT.
INSTALLER/OWNER BEARS ALL RESPONSIBILITY TO COMPLY WITH ALL
STATE AND LOCAL CODES WHEN INSTALLING THIS PRODUCT.
SAVE THESE INSTRUCTIONS

Aquatic Industries, Inc. 7
1. This whirlpool is factory-assembled, complete with motor, pump, controls and plumbing. DO NOT lift or support
unit using plumbing lines or any part of circulation system. DO NOT relocate or otherwise modify any part of the
factory-installed circulation system, as this may affect the performance or safe operation of the whirlpool and will
void all warranties.
2. Inspect whirlpool unit and circulation system carefully before installing. Water test the unit before installation. If any
damages or defects are observed, DO NOT INSTALL. Notify your dealer immediately.
TO TEST: PLACE THE TUB IN AN AREA WHERE IT MAY BE DRAINED AFTER TESTING.
3. Fill the tub with hot water (approximately 1000 F) to the overflow and allow to stand for a few minutes.
4. Plug in pump cord and run pump for 10 minutes.
5. Inspect the tub completely. Any defect must be reported to Aquatic Industries, Inc. prior to installation in order to
have it covered by warranty.
6. Check to ensure that your installation will conform to all applicable codes and secure necessary permits. All electri-
cal and plumbing connections should be made by qualified electricians and plumbers.
7. This unit has been factory-tested prior to shipment for leakage and proper operation of the system. However,
in transit and handling, the half-unions on the suction and discharge ends of the pump may become loose. Make
sure these are hand-tight.
Aquatic will not be liable for any defects or damages, including incidental or consequential damages that could
have been discovered or prevented by following these procedures for storage, handling and inspection.
PRE-PLANNING ACCESS, PLUMBING AND ELECTRICAL INSTALLATION:
INSTALLATION
INSTRUCTIONS / GUIDELINES
READ ALL INSTRUCTIONS CAREFULLY BEFORE INSTALLATION
1. Sufficient clearance must be provided for access to service connections: motor, pump and electrical hook-ups.
(Minimum unobstructed access 16” x 16”)
A. Alcove Installation (with optional skirt): Access is provided by removing the skirt. To permit removal of skirt, allow
at least 6” clearance at both ends of tub: vanity, toilet, etc., must not obstruct skirt removal.
B. Island or Pier Installations: Provide access panel at motor end (see diagrams on page 9)
C. Sunken Installations: Provide access panel in floor or in ceiling below.
2. Drain/waste pipe stub must be located in wall or floor to match location of drain, waste and overflow
kit tee fitting. Provide a 6” x 12” box-out in sub-floor or slab (see diagrams on page 9).
3. When fittings (spout, handles, valves, etc.) are to be mounted on the unit, be certain that the hot and cold water copper
supply lines are located where there is ample room for mounting before setting the unit in place.
4. WARNING: When using electrical products, basic precautions should always be followed, including the
following:
A. DANGER: Risk of Electrical Shock. Connect only to a separate circuit protected by a Ground Fault Circuit
Interrupter (GFCI).
B. Connection. Electrical hook-up must be performed by a licensed electrician in accordance with local,
state and national electrical codes.
C. Access Panel Required. For built-in custom units, provide an access panel for servicing electrical
components (see Electrical Installation on page 8).
PRE-INSTALLATION PROCEDURES:

Aquatic Industries, Inc.
8
When using electrical products, basic precautions should always be observed, including the following:
1. READ AND FOLLOW ALL INSTRUCTIONS.
2. Circuit: A separate circuit (not to supply any other electrical devices) is required as follows: For units
equipped with a pump motor only, a 110/120 VAC 15 Amp circuit is required. Wire coding is black [hot], white
[neutral] and green (or bare copper for ground).
3. GFCI: A Ground Fault Circuit Interrupter must be installed in the circuits which bring power to the
whirlpool; do not omit. To test the GFCI, push the test button. The GFCI should interrupt power. Push the reset
button. Power should be restored. If the GFCI fails to operate in this manner, there is a ground current flowing,
indicating the possibility of an electric shock. Do not use this unit. Disconnect the unit and have the problem
corrected by a licensed electrician before using.
4. Grounding: Motors have a three prong electrical plug requiring a black [hot], white [neutral] and
green wired circuit.
5. Bonding: A pressure wire connector is provided on the exterior of the motor within this unit to permit connection
of a No. 8 AWG solid copper bonding conductor between all electrical equipment, as needed to comply with local
requirements.
6. Wall Switch: A remote wall switch is required by many state codes. It must not be within 5 ft. (1.5 m) reach of a
bather while standing in the tub and it must be mounted at a height to be out of the reach of small children. The
remote switch should not be further than 10 ft. (3.0 m) away.
7. Integral On/Off Switch: For a Symphony whirlpool supplied with a motor that has an integral on/off switch -- Make
certain the air tube that is connected to the motor is also connected to the on/off button nipple under the deck in
order for the system to function.
All local, state and national electrical codes must be observed by a licensed electrician in connecting power to the
Aquatic whirlpool.
INSTALLATION INSTRUCTIONS
ELECTRICAL INSTALLATION:

Aquatic Industries, Inc. 9
Framing and supports will vary according to the model and type of installation selected.
1. Plumbing Connections: (spout, handles, valves, etc.) should be made after unit is installed. When mounting
fittings on unit, drill holes from finished surface, using appropriate-sized hole saw with fine-tooth or abrasive grit
cutting edge.
2. When plumbing connections have been made, proceed with electrical hook-up (see Electrical Installation on page 8).
TYPES OF INSTALLATIONS:
*Installation dimensions should be taken directly from the bathtub. Do not support the weight of the tub by its rim.
Alcove: Requires a skirt. Models shown with skirts have optional removable skirts. Other models not shown require
a field built skirt, have an integral skirt, or no skirt is available.
1. a) Alcove Framing: Leveled 1” x 3” ledgers indicated height “LH” dimension (see Alcove Diagrams on
page 9). Use a 3’ level. Nail ledgers to studs.
Island -- All Models: Above floor; no wall contact.
Peninsula -- All Models: Above floor; one end at plumbing wall.
Sunken (Partial or Full) -- All Models: Flush mount or self-rimming.
b) Island, Peninsula, Sunken Framing: Construct framework as shown in Island Diagrams on page 10, with
inside (cutout) dimensions “IW” and “ID” and height dimension “DH”. (Full height framework required, even in
sunken installations.) Check framework for proper dimensions, squareness and plumb. Use a 3’ (minimum)
level.
2. a) Before moving unit into alcove or framework see and follow enclosed Electrical Installation instructions on
page 8. (Electrical and air tube hook-ups will be difficult to perform if unit is installed first.)
b) Models with leveling feet: The following procedure is recommended for pre-leveled bottoms: Lift unit by the
rim, place in alcove or framework. If necessary, shim feet until unit is completely resting on leveled ledges or
framework. Secure the unit by fastening the bottom feet to the subfloor with any construction adhesive caulk.
The use of cement mortar is suggested as a foundation bed between the floor and the bottom of the unit to
suppress noise and give the rock solid feel for the user.
3. See and follow Sealing & Finishing diagrams (below) and System Test and Clean-Up on page 15.
STRUCTURAL PREPARATION:
(Not to support tub’s lip)
INSTALLATION INSTRUCTIONS

Aquatic Industries, Inc.
10
INSTALLATION INSTRUCTIONS
Rectangular
Models
↔
Corner
Models
↔
Oval
Models
↔
DECK CUTOUT: A paper template will be enclosed with all
oval models. For the deck cutout, scribe on the deck two
center lines (a major and minor axis). Next, match the center
lines and trace the ellipse. Repeat this step three more
times. Once the tracing is complete, cut out the ellipse. The
dimensions should be exactly 2” smaller than the unit.
A - 6” x 12” (150 x 305)
Box-outs
B - Leveled Supports
1” x 3” (25 x 75) Ledgers
C - 12” x 18” (305 x 460)
Minimum Access
ALCOVES ISLANDS
A
Measurements should be taken directly from the tub.

Aquatic Industries, Inc. 11
REMOVABLE SKIRT PANEL FOR INTEGRALLY SKIRTED MODELS:
These models are offered with removable access panels. They provide a flush-to-wall installation (sheet rock overlaps
skirt while still providing access). The skirt features a decorative removable panel enabling easy access to motor, pump
and electrical hookups. IMPORTANT: Before installation of the panel, fill the unit, test the whirlpool system for proper
operation and check for leaks, then drain.
INSTALLATION INSTRUCTIONS
INTEGRALLY SKIRTED WHIRLPOOLS:
Remove the shipping blocks of wood that are nailed along the back of the long 1 x 4 of the “H” frame.
1. To avoid obstructions during installation, make sure water lines, spout pipes and valve plumbing do not project into
alcove.
2. Ledger Strip: Fasten a 1” x 3” (25mm x 75mm) ledger strip along rear for alcove and along both sides in corner
installations at Dimension LH. (see diagram 6A)
3. Mix a 3 gallon bucket of cement mortar and water to a paste. Place three or four mounds of cement away from
drain hole in a line or square, approximately twice as high as the cavity under the tub bottom.
4. Place tub into alcove with front skirt firmly on floor and depress cement mounds. Make certain that back ledge of
tub rests firmly on ledger strip. (see diagram 6A)
5. Using 1 1/2” (40mm) galvanized roof nails or washer head screws: (a) spot-fasten the two bottom corners and the
two top corners of the vertical side nailing flanges. (b) Fasten at each stud through the top sides flanges and back flange,
working from both ends toward back center. (c) Complete fastening vertical side flanges.
6. When other than scratch coat is used, furring strips as thick as nailing flanges are recommended for installation on
studs above the installed Aquatic tub to assure drywall will be flush.
7. See and follow the Sealing & Finishing Diagram (diagram 6B) and System Test and Clean-Up on page 15.
6A 6B
Clips
(backside of panel)
Dry Wall
Right Side Edge
Panel
Left Side Edge
Integrally Skirted Acrylic Whirlpool
Framing

Aquatic Industries, Inc.
12
PARTS INCLUDED FOR INSTALLATION:
4 - Spring clips
8 - #6, ½” self tap screws for spring clips
3 - #8, 1¾” stainless steel screws
(use 2 for 5’ skirts, 3 for 6’ skirts)
3 - Chrome decorative caps
3 - Brass decorative caps
3 - Decorative cap holders
9 - Decorative caps in assorted colors with attached cap holders
1 - Instruction sheet
If any of the above parts are missing from your package, contact Aquatic Technical Department at [phone].
TOOLS REQUIRED FOR INSTALLATION: (NOT INCLUDED)
Phillips Head Screwdriver
Belt Sander
Fine-Tooth Saw
Wood Blocks
Pencil
Safety Glasses
Square/Level
Gloves
FLAT PANEL SKIRT INSTALLATION INSTRUCTIONS
PLEASE READ INSTRUCTIONS BEFORE PROCEEDING WITH INSTALLATION
NOTE: The skirt panel may require re-sizing to fit the specific installation. Carefully take your measurements so
that the skirt will fit the skirt opening. If re-sizing is required, it is suggested that the skirt is measured and marked
to the required dimensions. Cut to within 1/8” of finished dimensions using a fine tooth saw. Use a belt sander to
remove the remaining material to the finished size. The skirt could be damaged if improper procedures and/or tools
are used. It is important to follow all the steps in this installation procedure. If additional guidance is required, you may
contact the Aquatic Technical Department at [phone].
FLAT PANEL SKIRT INSTALLATION INSTRUCTIONS
1. Remove the wood strip (on some models) from the structural support. DO NOT REMOVE the structural support.
(SEE DETAIL VIEW A ON PAGE 13).
2. Locate the raised lip support channel beneath the lip of the bath tub as shown in FIGURE 1 ON PAGE 14. NOTE:
Some models do not have the lip support channel running the full length of the tub. These tubs will need to have
blocks of wood glued (construction cement) to the underside of the tub so that the spring clips can be attached.
3. Place the spring clips at even intervals along the support channel, use all four clips. Position the front of the clip
to line up with outside of the bath lip, (SEE FIGURE 4 ON PAGE 14) making sure they line up properly. Mark the
hole openings for the screws with a pencil. Place a #6, 1/2” screw at the marked position and secure the clips
to the channel. Use 2 #6 screws for each clip as shown in FIGURE 1. Make sure the screws go into the support
channel or into the wood blocks.
4. Slide upper side of skirt (SEE FIGURE 4) under the lip of the tub. Align the offset edge of the skirt so it is parallel
with the bottom of the bath lip (SEE FINAL ASSEMBLY DIAGRAM ON PAGE 14). The panel should slip into place
between the lip rim and the four spring clips (SEE FIGURE 4). While holding skirt at the bottom, move it inward
toward the tub (SEE FIGURE 2). The vertical edge of the skirt should be aligned perpendicular to the floor (SEE
FINAL ASSEMBLY DIAGRAM).
SEE FIGURE 2 AND FINAL ASSEMBLY. To secure the bottom of the skirt, wood blocks (2 for 5’ skirts or 3 for 6’ skirts),
will need to be anchored to the floor. Use a level (that is held against the outside face of the tub lip and touching the
floor) at each pre-drilled hole location to mark where the face of the skirt panel will be aligned. Subtract the thickness
of the skirt and the structural support to position the wood blocks. Anchor the blocks to the floor, then screw the 1¾”
#8 screws, through the decorative caps and the pre-drilled holes, into the wood blocks.

Aquatic Industries, Inc. 13
DETAIL VIEW A
DETAIL VIEW B

Aquatic Industries, Inc.
14
FIGURE 3 FIGURE 2
FIGURE 1 FINAL ASSEMBLY
* Base and plumbing may vary by model.

Aquatic Industries, Inc. 15
INSTALLATION INSTRUCTIONS
1. Remove all construction residue and foreign materials. Wipe unit clean with a damp rag, otherwise staining may
occur.
2. Plaster may be removed by scraping with the edge of a piece of wood or rigid plastic. Do not use metal scraper.
For spots left by plaster or grout: rub lightly with a liquid detergent (Spic and Span or similar) on damp cloth or
sponge.
3. Do not use abrasive cleaners, scouring powders, steel wool, wire brushes or anything else that may harm or dull
the surface.
4. Paint, tar, or stubborn stains may be removed with rubbing alcohol. To avoid discoloration, cleaners containing
petroleum distillates must not remain on surfaces. NEVER use lacquer thinner or chlorinated solvents.
5. Dulled areas can be restored to a high gloss with white or a non-abrasive automotive rubbing compound, followed
by application of carnauba wax or white or cream automotive paste wax and buffing.
6. Remove minor scratches with 600 grit wet/dry sandpaper, followed by use of automotive rubbing compound and
paste wax, as above.
7. Major gouges require professional repair. Contact supplier to arrange factory-authorized repair services.
CLEAN-UP:
SYSTEM TEST:
1. Fill clean tub with water to a point no less than 2” above the highest jet, dirt left in tub may cause staining.
2. To test the Ground Fault Circuit Interrupter (GFCI), push the test button. The GFCI should interrupt power. Push
the reset button. Power should be restored. If the GFCI fails to operate in this manner, there is a ground current
flowing, indicating the possibility of an electric shock. Do not use this unit. Disconnect the unit and have the problem
corrected by a licensed electrician before using.
3. Push on/off button on the whirlpool unit.
4. Allow system to run a full 10-minutes.
5. Through access door or removable skirt, check for leaks in whirlpool plumbing system. Make sure half-unions at
both ends of pump are hand-tight. If leakage is occurring at any other points, notify distributor.
6. If any electrical malfunctions occur, consult electrician. Malfunctions of the pump/motor, whirlpool controls or
the circulating system should be reported to the distributor who supplied the whirlpool tub.

Aquatic Industries, Inc.
16
JET OPERATIONS:
The Symphony Series uses spinning back jets and directional jets to provide an invigorating hydrotherapy experience.
AQUATIC DIRECTIONAL JET:
• To adjust pressure (SEE DIAGRAM 10A) :
1. Grasp the outer ring of the jet.
2. Turn the outer ring counter clockwise to increase flow, clockwise
to decrease.
• To aim jet action (SEE DIAGRAM 10B) :
1. Simply push the jet nozzle to desired position.
• To remove jet (SEE DIAGRAM 10C) :
1. Grasp the outer ring of the jet.
2. Turn the jet counter-clockwise, until the jet clicks, then pull.
• To replace jet (SEE DIAGRAM 10C) :
1. Insert the jet into jet housing, pushing gently.
2. Turn the jet clockwise, past point of resistance, until the jet locks into
place.
SYMPHONY WHIRLPOOL JETS
10B
10C
All Symphony Series jets are removable, and can simply be put into the dishwasher for easy cleaning. (Note: use top
rack and remove before drying cycle.)
10A
OPERATION OF SYMPHONY
WHIRLPOOLS
• To remove jet (SEE DIAGRAM 10D) :
1. Grasp the outer ring of the jet.
2. Turn the jet counter-clockwise, then pull.
• To replace jet (SEE DIAGRAM 10D AND 10E) :
1. Insert the jet into jet housing.
2. Align notches with detents, push in gently.
3. Turn the jet clockwise, past point of resistance, until the jet locks into place.
AQUATIC SPINNING BACK JET:
10D
10E

Aquatic Industries, Inc. 17
OPERATION OF SYMPHONY
WHIRLPOOLS
Your whirlpool bathtub features a built-in circulating system that mixes the bath water with air and pumps the mixture
back into the bathtub creating the hydromassage action. Because it is a bathtub, it must be drained after each use.
The circulating system mixes air and water and must never be operated unless the bathtub is filled as described in the
section entitled “Before Your First Use.”
BEFORE YOUR FIRST USE:
• Make sure the bathtub is clean: If there are any residue or foreign materials left from
construction, clean the bathtub thoroughly. Use only the methods and materials described
in a later section entitled “Initial Cleaning” on page 19.
• Fill bathtub above jets: For your first “test run” use cold water. Fill the bathtub until the
water is at least 2” above the highest jet. Never operate the whirlpool unless water is at
least this high.
TO OPERATE YOUR WHIRLPOOL:
• ON/OFF BUTTON (see Diagram 11A): Models, so equipped, will have a button mounted
on the bathtub and may not have a wall mounted timer. Pushing the button forces a column
of air to a control which turns the pump motor on or off.
• GROUND FAULT CIRCUIT INTERRUPTER (GFCI): Test the GFCI as described in the prior
section “Electrical Installation” on page 8. This extra safety device is mounted either at the
remote power switch or in your home’s electrical panel. Push the test button. The GFCI
should interrupt the power. Push the reset button. Power should be restored. If the GFCI
fails to operate in this manner, there is a ground current flowing, indicating the possibility
of an electric shock. Do not use this product until the problem is corrected by a licensed
electrician.
• DIRECTIONAL JET NOZZLES (see Diagram 11B): The nozzle on each jet rotates freely
360°. You can adjust its position to concentrate the whirlpool action against a specific part
of the body or to adjust the overall whirlpool action in the bathtub.
WHIRLPOOL OPERATIONS:
Before the initial use of your whirlpool bath, be sure you have performed the “test run” described above, that you are
familiar with all the controls and switches and that the unit is operating properly. (See “Electrical Installation” on page 8.)
Be sure to keep all electrical appliances at least five feet away from the whirlpool bathtub.
1. Fill the bathtub with warm water. Water temperature must not exceed 104°F (40°C). Baths that are too hot can
be dangerous to your health. Also, water that’s too hot may cause discoloration and/or deform your whirlpool and
its circulating system.
2. If you will not be operating the whirlpool system during your bath, you may fill the bathtub to any comfortable level.
However, if you will operate the system, you must fill the bathtub as described in the prior section entitled “Before
Your First Use”. This will assure proper operation of the system and keep the jets from squirting water outside the
bathtub.
11A
11B

Aquatic Industries, Inc.
18
3. Do not operate the whirlpool system if:
• The bathtub is not filled to required levels above jets.
• You are pregnant (until you have consulted your doctor).
• You are taking medications or drugs that may make you drowsy.
• You are drinking any form of alcohol.
• You are using soap or bubble bath. This may cause over-foaming, collect in and eventually clog the system. It
is okay to use these after the whirlpool system has been turned off. Make sure to drain and rinse the bathtub
afterwards.
• You have just had a meal. Wait at least 30 minutes after dining.
• There is a child in the bathtub who may be unattended at any time. Never allow small children to remain
unattended in any bathtub.
• There are any small objects in the bathtub. The jet action can move small objects at high speeds, causing pain
and possible injury.
• The safety suction cover is not in place. The suction cover is the large fitting with a pattern of holes on its face,
mounted on the bathtub’s side wall.
• Your hair is loose and longer than shoulder length. If it is, secure it close to the head with pins or wear a shower
cap. Keep hair away from the suction cover.
• You are smoking. The heat of burning tobacco can damage the bathtub surface. Keep tobacco products and
ashtrays away from the bathtub.
4. Enter the bathtub. Sit back, stretch out, relax. Push the on/off button. You’ll feel water being pumped gently out
of the jets. Turn the jet nozzles to direct the air/water mixture against aching or tired limbs and muscles or adjust the
nozzles to create maximum whirlpool action in the whole bathtub. Adjust the volume of water by rotating the face
plate of directional jets, counterclockwise for more water, clockwise for less water.
OPERATION OF SYMPHONY
WHIRLPOOLS
WHIRLPOOL OPERATIONS (continued):

Aquatic Industries, Inc. 19
MAINTENANCE AND CARE
Before tub is used, the whirlpool system should be cleaned and disinfected. Remove all debris and clean tub before
putting whirlpool into service. DO NOT USE ABRASIVE CLEANERS ON THE ACRYLIC FINISH. Use a non-abrasive
detergent and rinse well after cleaning.
• Fill the tub with HOT water to a level 2” above the highest jet.
• Add 2 teaspoons of low-sudsing automatic dishwashing detergent and no more than 4 ounces of household
bleach to the water.
• Operate whirlpool for 10 minutes. Drain.
• Refill with cold water and operate whirlpool for 5 minutes. Drain.
To remove accumulations of bath residue from the whirlpool system, we recommend that you purge it at least twice a
month, or more depending on usage. To do this, follow this simple procedure. Fill the bath with hot water (not exceeding
140oF). Add to the hot water, 4 (6) tablespoons of low foaming detergent such as liquid Cascade or Calgonite and 24
(48) oz. of liquid household bleach, such as Clorox [use lesser amounts shown for 5-foot bathtubs, greater amounts
in parentheses for larger bathtubs]. Run the bath for 5 to 10 minutes. Drain the bath completely and refill with cold
water only. Run the whirlpool for 5 to 10 minutes, then drain the bath completely. Depending on the usage and/or the
content of the local water supply, more frequent purging may be necessary.
NOTE: DO NOT USE OIL OR OIL BASED BATH ADDITIVES.
If you want to use any kind of bath additive, use only a small amount of low-foaming powder or crystal substance; the
whirlpool action intensifies the foaming properties of soaps.
The use of certain bubble baths and bath additives may increase the level of accumulations of bath residue in the
whirlpool system. If excess accumulations persist, you should discontinue use of these products.
If you have followed the monthly purging instructions and still have an excess accumulation of bath residue and desire an
alternative cleaning mechanism, we recommend SUPER SYSTEMS CLEAN PLUS manufactured by Stearns Packaging
Corporation to rectify this condition. This may be obtained by calling Aquatic Industries, Inc. at [phone]. It is
recommended that you follow the instructions provided by the manufacturer with the product. Repeated use may be
necessary. SUPER SYSTEMS CLEAN PLUS does not replace the necessity to purge your whirlpool system at least
twice a month with a low foaming detergent and bleach.
Use common household, non-abrasive cleaners for most cleaning jobs. Rinse well and dry with a clean cloth. Never
use abrasive cleaners. Do not allow your Lucite® acrylic surface to come into contact with products such as acetone
(nail polish remover), nail polish, dry cleaning solution, lacquer thinners, gasoline, pine oil, etc. Remove dust with a soft,
dry cloth. Clean grease, oil, paint, and ink stains with isopropyl (rubbing) alcohol.
All Symphony jets are easily removable, and can simply be put into the dishwasher for easy cleaning.
(NOTE: Use top rack and remove before drying cycle.)
S
INITIAL CLEANING:
WHIRLPOOL SYSTEM CLEANING:
SURFACE CLEANING:
JET CLEANING:

Aquatic Industries, Inc.
20
MAINTENANCE AND CARE
Owners of fill and drain whirlpool bathtubs need to know basic information concerning water quality: how it affects
performance and enjoyment of the operation of their tubs, and steps that can be taken by the owner to correct related
problems. Important issues are the microbiological and chemical quality of the water.
MICROBIOLOGICAL QUALITY:
Microbes are present in water supplied by individual wells or water systems and even in the air around us. These
microbes are usually in amounts below what is noticeable. Microbes from the water or air or from a bather’s body may
settle on wetted surfaces such as a whirlpool bathtub’s surface or piping systems where they can grow in numbers
where we can notice them. With regards to whirlpool bathtubs, brown/black fungi/mold or pigmented (colored) bacteria
can be noted.
Fungi/Mold- Fungi and mold are always present. The levels are usually such that we do not notice them. When
moisture and temperature are sufficient, the organisms will grow to levels that we may smell and/or see. The best
example of such growth is the very common black growth on the bottom of shower curtains. The best solution to keep
these surfaces free from growth is frequent cleaning.
Pigmented Bacteria- Water utilities from all over the United States have experienced calls from consumers inquiring
and complaining about pinkish substance on bathroom fixtures that is very persistent, appearing in the shower, sink and
along the water line of toilet bowls. With whirlpool bathtubs, the formation of this colored substance may be particularly
pronounced in white tubs. The residue is less likely a problem associated with water quality than with naturally occurring
airborne bacteria. The bacteria may produce a pinkish film, and sometimes a dark gray film, on surfaces that are
regularly moist, including toilet bowls, shower heads, sink drains, and tiles. The problem is more common in humid
areas of the country. In any particular case, the determination of the exact species of bacteria causing the problem
would require lengthy and costly laboratory testing; however, most experts believe the bacteria responsible is Serratia
marcescens. These bacteria thrive on moisture, dust and phosphates, and are widely distributed in soil, food and also
in animals. The American Water Works Association suggests that short of buying pink fixtures, the best solution to
keep these surfaces free from the bacterial film is continual cleaning. The AWWA recommends a chlorine containing
the compound as the best cleaner and avoiding abrasives to avoid scratching fixtures, which will make them more
susceptible to bacteria.
SURFACE SCRATCH REMOVAL:
Minor scratches may be removed by polishing your tub with a non-abrasive car polish, followed by buffing. Deeper
scratches can be removed by:
• Sanding with wet 400 grit sandpaper.
• Sanding with wet 600 grit sandpaper.
• Sanding with wet micro-grit sandpaper.
• Buff out using car polish.
The installation and service of your whirlpool bath should be performed only by a qualified service technician.
Remember when contacting your dealer always have your serial number, proof of purchase and model number
available. This will ensure a quick response on warranty items.
The model and serial numbers are located above the pump on the backside of the whirlpool.
NOTE: ALL WARRANTY REPAIRS MUST BE AUTHORIZED BY AQUATIC BEFORE WORK IS STARTED. FOR SERVICE,
ALWAYS CONTACT YOUR DEALER.
CAUTION: Care should be taken to prevent inappropriate chemicals coming in contact with the Lucite® acrylic surface.
Please read and observe all instructions and/or warnings on containers containing substances you contemplate applying
to your whirlpool. Any failure to comply may void your warranty.
REPAIR:
WATER QUALITY ISSUES:
