AQUAVENTRONICS Beat The Bucket User manual

WWW.AQUAVENTRONICS.COM
© 2011 AQUAVENTRONICS
AQUAVENTRONICS
Manitoba, Canada
[phone]
B
B
E
E
A
A
T
T
T
T
H
H
E
E
B
B
U
U
C
C
K
K
E
E
T
T
O
OW WN NE ER RS S M MA AN NU UA AL L

BUMP N' BLAST
OWNERS MANUAL
WWW.AQUAVENTRONICS.COM
© 2011
AQUAVENTRONICS
Table Of Contents
1. ASSEMBLY..........................................................................................................1
1.1 BATTERY PACK .................................................................................................................2
1.3 POWER SUPPLY & CHARGER ........................................................................................2
2. OPERATION......................................................................................................3
2.1 Water Settings.................................................................................................................4
3. MAINTENANCE...............................................................................................5
3.1 Winter Storage ................................................................................................................5
3.2 Replacing the Control Module.......................................................................................5
4. SAFETY .............................................................................................................. 6
5. PRODUCT LIABILITY DISCLAIMER.........................................................7
MANUAL VE
RS
ION 1.0
RELEASED
15 APRIL
2010

WWW.AQUAVENTRONICS.COM
© 2011
AQUAVENTRONICS
BUMP N' BLAST
OWNERS MANUAL
P
AGE
1
OF
11
1. ASSEMBLY
The proper assembly of your Beat The Bucket game is critical to ensure a safe and
fun environment for any participants. Extra care should be taken when assembling
your Beat The Bucket game, and this manual should be read in its entirety prior to
performing any work. The improper assembly could result in unsafe operating
conditions, permanent damage to your game, and/or damage to the surrounding
environment.
If your game has been shipped with the Bucket Assembly and Fill Tube removed,
please follow these instructions to secure these components to your game.
STEP 1: Install the Bucket Assembly to the game using the 1/4" stainless steel
bolts, washers, and locknuts supplied. A single washer should go to the
bottom side of the aluminum frame before the nut. The "Beat The
Bucket" logo should be facing the front of the game.
STEP 2: Plug in the Bucket Assembly magnet with the 2 wire connector. If you
will not be taking the bucket off regularly, it may be a good idea to wrap
the connector with some electrical tape or "heat shrink" to ensure it
remains together at all times.
STEP 3: Connect the Fill Tube to the game using the 1/4" stainless steel
hardware. The fill tube should overhang the back of the game. Check to
ensure the tube can swivel 180 degrees from the raised position, to the
lowered position. Connect the water tube to the solenoid valve by simply
pushing the tubing into the connector firmly.
STEP 4: Inspect the game for any visible signs of damage from transport, paying
close attention for any worn, frayed, or exposed wires. Should there be
any issues, contact Aquaventronics immediately.

WWW.AQUAVENTRONICS.COM
© 2011
AQUAVENTRONICS
BUMP N' BLAST
OWNERS MANUAL
P
AGE
2
OF
11
1.1 BATTERY PACK
Each Beat The Bucket game is supplied with a 12 Volt Battery Pack. Under no
conditions should the game be operated without the supplied battery pack or under
any other power source. Failure to do so may cause damage to the electronic
control module and will void all warranty.
Please use the push button indicator on the battery pack to ensure the battery is
fully charged at all times. When the charger is connected, the yellow "Charging"
light should be on continuously.
1.3 POWER SUPPLY & CHARGER
A 12 Volt, Low Voltage Power Supply & Charger have been supplied as part of your
Beat The Bucket game. The positive (12V+) wire on the power supply is RED, the
negative or common (12V ) is Brown. The 2 wire power supply connector should
have the RED wire as the Female plug, and the Brown wire as the Male plug. This
connector should only be plugged into the opposite connector, marked "Charger" on
the battery pack. Although the wire does have a protective shielding, the wire
should never be attached to the Battery Pack such that there is potential for
anything to cause wear or damage to the wire.
The Power Supply is not weather resistant, and must be mounted out of the
elements. Approved, weather proof enclosures are recommended if being used
outdoors.
The Power Supply should be connected to a 110 Volt Ground Fault outlet if being
used to continuously supply power to the pack while connected to the game. Please
check your local electrical codes to ensure you meet the minimum requirements.

WWW.AQUAVENTRONICS.COM
© 2011
AQUAVENTRONICS
BUMP N' BLAST
OWNERS MANUAL
P
AGE
3
OF
11
2. OPERATION
To operate your Beat The Bucket game:
STEP 1: Find a flat surface where there is sufficient drainage.
STEP 2: Remove Pins from all 4 legs and lower into position.
STEP 3: One side at a time; raise the game slightly in the air while inserting the
pins in the lowered position.
STEP 4: Raise the bucket fill tube into position. Remove the pin or bolt and
replace once rotated into position.
STEP 5: Raise the upped framework by lifting in the center as high as possible if a
single person, then using one hand to pull the framework up, insert the
pins on one side and then do the same on the opposite side. (Easiest
method is with 2 people, lifting at the same time)
Step 6: Move the blocker arm to the center position
STEP 7: Connect the water supply to the garden hose connection
Step 8: Plug in the game battery pack
* Once the power is disconnected, the bucket will dump!! Watch Out!!
STEP 3
STE
P
5

WWW.AQUAVENTRONICS.COM
© 2011
AQUAVENTRONICS
BUMP N' BLAST
OWNERS MANUAL
P
AGE
4
OF
11
2.1 Water Sett ngs
Every Beat The Bucket game has been supplied with a preprogrammed water fill
time. In most cases, the bucket should be filled to within 2 3 inches of the top.
The amount of water dumped from the bucket is adjustable, however the game
does require approximately half of the bucket to be full in order to dump. The
easiest method of adjusting the amount of water is by simply partially closing a
valve or tap connected to the water source, or using the supplied water valve on
the game.
For alternative play, such as 2 hits to dump the bucket, test with different valve
settings until you get it right.
2.2 Game Play
Beat The Bucket is meant to be played with 2 people. A single player is to stand
behind the framework, while a second player throws water logged foam balls (or
juggle balls) at the targets. The player behind the framework can block the balls
from hitting the targets by operating the blocking lever. The player throwing the
balls should be 10 15 feet away, depending on the age and skill of the participants.
Should a target be hit, the bucket will automatically dump the water, reset to the
upright position, and refill with the predetermined amount of water. Once the
water stops filling, a target may be triggered.
DO NOT USE ANY HARD BALLS ON THE GAME!!

WWW.AQUAVENTRONICS.COM
© 2011
AQUAVENTRONICS
BUMP N' BLAST
OWNERS MANUAL
P
AGE
5
OF
11
3. MAINTENANCE
Preventative maintenance of your Bump N’ Blast module will allow for continued and
safe operation. All components should be visually inspected daily for any signs of
wear, fatigue, damage, or vandalism. Any wires not protected with conduit or other
protective measures should also be inspected to ensure there are no areas of wear
or exposed wires.
he Beat The Bucket game utilizes a commercial grade solenoid valve. Depending on
the quality of your water source, fine particles or mineral buildup can restrict the
flow of the valves. Should the unit not be performing as desired, the valve may
have some dirt or buildup and should be cleaned.
3.1 W nter Storage
Should there be any risk of temperatures below freezing (32ºF or 0ºC) you must
ensure there is no water in your Beat The Bucket game. The use of antifreeze is
highly recommended. The easiest method to remove all water from the solenoid
valve is to connect an air source to your water line, and trigger a target with the
game power on. This should allow the air to force any water remaining in the valve
out. The Electronic Control Module can be left connected to the blast unit. If you
have any questions regarding the winterization of your Beat The Bucket game,
please contact Aquaventronics.
3.2 Replac ng the Control Module
In the event that there is a problem with your Electronic Control Module, simply
disconnect the pigtail connectors from the enclosure and send the unit in for
repair. Never attempt to repair an electronic module yourself, this will void any
and all warranty.

WWW.AQUAVENTRONICS.COM
© 2011
AQUAVENTRONICS
BUMP N' BLAST
OWNERS MANUAL
P
AGE
6
OF
11
4. SAFETY
Every Beat The Bucket unit should be properly maintained and inspected as
outlined in this manual to reduce any potential for personal injury or damage to
property and/or equipment. The instructions contained in this manual include a
number of key considerations when selecting an appropriate location for the Beat
The Bucket game.
Under no circumstances should any debris, material, or object be placed within or
around the bucket. Preventative steps should be taken to ensure no game
participant is allowed to retrieve balls from under the blocking arm at anytime
during the game play. All spectators and participants should be alert and aware of
any foam ball or juggling ball being thrown in the vicinity of the game at all times,
and prior to the powering of the unit, the game and battery back should be
inspected to verify there are no loose or damaged electrical wires.
DO NOT USE ANY HARD BALLS ON THE GAME!!

WWW.AQUAVENTRONICS.COM
© 2011
AQUAVENTRONICS
BUMP N' BLAST
OWNERS MANUAL
P
AGE
7
OF
11
5. PRODUCT LIABILITY DISCLAIMER
TERMS OF USE, WARRANTY & LIABILITY WAIVER
Aquaventronics offers its products with the terms, conditions and notices as
follows:
Terms of use
This product is offered to you conditioned upon your acceptance without
modification of the terms, conditions, and notices contained.
Exclus ve Obl gat on
This product may not be used for unlawful purposes and that use is expressly
prohibited under the terms and conditions of use.
Use l m tat on
You may not modify, copy, distribute, transmit, display, perform, reproduce,
publish, license, create derivative works from, transfer, or sell, any information,
software, products, or services obtained, from Aquaventronics website or its
products.
90 Day Warranty
This product is warranted against any manufactured defect for a period of 90 days
from the date of purchase. Damage caused by the improper storage, improper use,
abuse, neglect, or incompetence will not be covered by this warranty. The
purchaser is responsible for all shipping costs associated with returning the
damaged components to Aquaventronics for processing, and the subsequent return
of any new or replacement components. All warranty claims may be subject to an
inspection by Aquaventronics, and claim approval is at Aquaventronics' discretion.
L m tat on Of L ab l ty
In no event shall Aquaventronics be liable for any direct, indirect, punitive,
incidental, special consequential damages whatsoever arising out of or connected
with the use or misuse of it’s products.
=

WWW.AQUAVENTRONICS.COM
© 2011
AQUAVENTRONICS
BUMP N' BLAST
OWNERS MANUAL
P
AGE
8
OF
11
Other Statements
Aquaventronics employees or representatives, ORAL OR OTHER WRITTEN
STATEMENTS, DO NOT CONSTITUTE WARRANTIES, shall not be relied upon
by buyer, and is not part of the contract for sale or this limited warranty.
Ent re Obl gat on
The TERMS OF USE, WARRANTY AND DISCLAIMER document states the entire
obligation of Aquaventronics with respect to the products. If any part of this
disclaimer is determined to be void, invalid, unenforceable or illegal, including, but
not limited to the warranty disclaimers and liability disclaimers and liability
limitations set forth above, then the invalid or unenforceable provision will be
deemed superseded by a valid, enforceable provision that most closely matches the
intent of the original provision and the remainder of the agreement shall remain in
full force and effect.
General
This disclaimer statement is governed by the laws of the Province Of Manitoba,
Canada. You hereby consent to the exclusive jurisdiction and venue of the Courts
of competent jurisdiction, Canada, in all disputes arising out of or relating to the
use of this product. Use of this product is unauthorized in any jurisdiction that
does not give effect to all provisions of these terms and conditions, including
without limitation this paragraph.
Mod f cat on of Terms and Cond t ons
Aquaventronics reserves the right to change the terms, conditions, and notices
under which their products are offered.
