Arada Deck Open Chimeneas User manual

PLEASE RETAIN THIS GUIDE FOR FUTURE REFERENCE
BK 768 Rev 01 ISSUE DATE : 24/06/2022
Chimeneas
(Deck Open, Deck Closed & Teepee)
User Guide
22

Page 2 BK768
Chimenea User Guide
Congratulations on the purchase of your new Chimenea!
More than 30 years of experience has been put into the development of your heater to
ensure ultimate performance and years of trouble free use and enjoyment.
Every detail of your appliance has been carefully designed and engineered which is why we
are so confident in the reliability of our products.
Should you have any questions about your heater which are not covered by this user guide,
please contact your retailer in your area or visit our website : www.aradastoves.com, which
offers a further information on how to care for and get the best from your appliance.
Please ensure that you read these instructions in full and understand them before operating
your heater.
Arada has a policy of continuous product development and therefore we reserve the right to
amend specifications without prior notice.
Due to printing cycles, items or options may be described before they are generally
available or after they have ceased in production.
Please check with your retailer or dealer if you are unsure about any aspect of your
appliance, its installation or the correct use.
IMPORTANT NOTE :
The following items are packed together with your chimenea for shipping
purposes :
 4x Vermiculite Liner Panels (Open & Closed Chimeneas)
 2x Vermiculite Liner Panels (Teepee Chimenea)
Installation of the above items should be carried out by a suitably competent
person (s).

BK768 Page 3
Chimenea User Guide
Contents
1. Identifying your Chimenea ......................................................... 3
2. Warnings …. . ........................................................................... 4
3. Preparation for use …………………………………………………..5
4. Lighting your Chimenea..……………………………………………6
5. Care of your heater …………………………………………………..7
6. Warranty ………………………………………………………………..7
7. Recycling………………………………………………………………..8
1. Identifying Your Chimenea
Closed Deck Chimenea Open Deck Chimenea Teepee Chimenea

Page 4 BK768
Chimenea User Guide
2. Warnings—
Any manufacturer’s instructions must not be taken as overriding statutory requirements.
The appliance is solely designed only to be used OUTDOORS and should never be
installed or used inside a building or property.
Do Not use this heater under a covered area, such as an tent or marquee or gazebo.
Do Not use aerosol sprays or other flammable materials near the appliance when in
use.
Do Not use the appliance as an incinerator.
For WOOD LOGS ONLY. We recommended seasoned dry wood logs with a mois-
ture content of less than 20% for heating purposes, however, man-made or compressed
logs can be used.
Pure petroleum coke or Bituminous house coal or MSF (manufactured solid fuels) must
NOT be burned in this appliance.
The use of these fuels will invalidate the appliance guarantee.
Use only recommended fuels, STRICTLY NO unsuitable and non recommended fuels or
materials or liquid fuels allowed.
A suitable non flammable level surface would be an ideal location for the heater, however,
the appliance can be used upon wooden decking or grass, but caution should be
exercised when re-fuelling the appliance due to the risk of hot falling ash when refuelling.
Caution must be exercised during operation of the appliance as both internal and
external surfaces will be hot to touch, use suitable stove gauntlets.
Caution should be used in the presence of children, elderly people and pets should
be kept away from the appliance or use a suitable fireguard conforming to BS 8423:2002
could be used.
Always observe the distances to combustible materials.
Ensure no soft furnishings or garden foliage, such as overhanging branches, leaves and
bushes are susceptible to heat radiating from the appliance.
Ignoring the warnings could lead to damage/injury to persons and/or property.
Arada Ltd will not be responsible for any consequential or incidental loss or injury however
caused.
IMPORTANT INFORMATION

BK768 Page 5
Chimenea User Guide
3. Preparation For Use —
 Locate a suitable placement for the chimenea, taking in mind the location of
combustible materials and level ground requirements. Moving of the chimenea is
best done using a sack truck, with an additional person steading and guiding the
front.
 Remove the outer cling wrap packaging, internal foam packing and internal plastic
bag. See section on recycling of waste materials.
 Inside of each corner, there are temporary screws holding the appliance to the base
packaging pallet, these will need to be removed and the chimenea carefully moved
onto the ground. Again the wooden pallet can be recycled (See Fig. 1.)
 Place on to a suitable level location, ensure the appliance is stable and secure.
 Ensure the ash pan / grate is fitted (See Fig. 2.)
 In the case of the Open & Closed Chimeneas position the 4x vermiculite liners into
the firebox, note the 2x longer panels (350mm) and 2x shorter panels (325mm) are
placed on alternating sides (See Fig. 3.)
 For the Teepee Chimenea, the 2x vermiculite liners are positioned at the rear face of
the firebox (See Fig.4).
Remove
Packing
Screws
Fig. 1
Fig. 2
Fig. 3 Fig. 4

Page 6 BK768
Chimenea User Guide
4. Lighting Your Chimenea —
 Using the ‘Top Down Lighting Technique’, begin to place 2x large logs (approx.
100mm in diameter) in the front to back position, within the base of the chimenea.
(See Fig. 5)
 Next, place smaller logs 180 degrees to the larger logs. Infill these with suitable
firelighters.
 On top of the smaller logs, build a grid of kindling and place a further fire lighter on
the very top. (See Fig. 6)
 Light the top fire lighter, the structure will start to burn downwards causing the lower
combustion products to ignite.
 Leave for approximately 5-10mins, to establish an ash bed.
 Reload on to a hot glowing ember bed with fresh logs.
Fig. 5
Fig. 6
DO NOT use and flammable liquids for lighting or re-lighting this heater.
During the first lighting an odour may be present, this is normal and will disappear once the paint
has cured.
KEEP, Children, elderly and pets away from the appliance during use.
1x Firelighter
Kindling
Small Log
2x Firelighter
Large Log

BK768 Page 7
Chimenea User Guide
5. Care Of Your Chimenea —
After use, allow your heater to completely cool. Caution should be exercised, as
although the flame may be extinguished, there may be red hot embers or the
casing of the appliance may still be HOT.
 Before moving or cleaning the appliance ensure it is cool to touch.
 Do not allow the ash to build up above the base of the opening, remove the ash if it
becomes too high. Dispose of the ash appropriately.
 Cleaning the exterior finish, use a soft brush and a damp lint free cloth.
 Your Chimenea is designed to be kept undercover and dry when not in use.
 For long term storage over the winter months, we recommend apply a coating of light
oil (linseed) over the exterior and cover with a waterproof tarpaulin.
 After long term storage, inspect the heater for wear and tear or damage. Should
external areas need re-painting, only use Arada high temperature aerosol paint, as
differing paints may react with the surface finish.
 Replacement parts can be obtained from www.aradastovesandspares.com or your
local retailer.
PLEASE NOTE : Discolouring of the exterior finish and surface oxidation is
normal, through usage, and adds to the patina of the appliance.
6. Warranty —
Your Garden Heater comes with a ONE year warranty, covering against defect in
materials and workmanship.
For the purposes of this warranty, a material or manufacturing defect includes the splitting
or cracking of the main body (defined as the steel outer casing and items fixed immovably
to the casing).
All other items are classed as consumable components and are therefore subject to
damage through wear and tear or incorrect use or application, such as over-firing or the
use of non specified or incorrect fuels.

Page 8 BK768
Chimenea User Guide
Date of issue: 24/06/2022 BK768
Arada Ltd
The Fireworks, Weycroft Avenue, Axminster, Devon,EX13 5HU United Kingdom
www.aradastoves.com www.aradastovesandspares.com Tel: [phone]
7. Recycling
7.1 Packaging recycling
The majority of the packaging components can be recycled, by the material components:
WOOD (Pallet) - Household quantities of wood can be taken to your local Household
Waste Recycling Centre.
CARDBOARD (Outer packaging) - Most local councils will collect cardboard as part of
their kerbside collection; Otherwise, cardboard can be recycled at your local Household
Waste Recycling Centre.
PLASTIC (Internal Bubble Packing / Bags / Outer Strapping) - Some district councils
collect plastic packaging in their kerbside collections; Alternatively, most supermarkets
have plastic bag collections. The outer strapping should be taken to your local Household
Waste Recycling Centre.
7.2 End of life product recycling
Again like the packaging the majority of the appliance components can be recycled, by
the material components:
CAST IRON & STEEL - All metal components can be recycled at your local Household
Waste Recycling Centre.
.
FIREBOX LINERS & GASKETS/SEALS - These components are currently not recyclable
and should be disposed off at your Household Waste Recycling Centre.
Your local Household Waste Recycling Centre can be located—
https://www.recyclenow.com/local-recycling?
