Owner’s Manual & Installation Guide
for the Windsor Bay(8830)
GAS-FIRED DIRECT VENT HEATER
READ THIS OWNER’S
MANUAL
Operate and maintain this gas heater
according to this instruction manual.
Read This Manual In Its Entirety.
WARNING: If the information in these
instructions is not followed exactly, a fire or
explosion may result causing property damage,
personal injury or loss of life.
Do not store or use gasoline or other flammable
vapors and liquids in the vicinity of this or any
other appliance.
WHAT TO DO IF YOU SMELL GAS:
•Do not try to light any appliance.
•Do not touch electrical switches; do not use
the phone in your building.
•Immediately call your gas supplier from a
Neighbor’s phone. Follow your gas suppliers
instructions.
•If you cannot reach your gas supplier, call the
fire department.
A qualified installer, service agency or gas supplier
must perform installation and service.
AVERTISSEMENT: Assurez-vous de bien suivre
les instructions donné dans cette notice pour
réduire au minimum le risque d’incendie ou pour
éviter tout dommage matéeriel, toute blessure ou la
mort.
Ne pas entresposer ni utiliser d’essence ni d’autre
vaperurs ou liquides inflammables dans le
voisinage
de cet apprareil ou de tout autre appareil.
QUE FAIRE SI VOUS SENTEZ UNE
ODEUR
DE GAZ:
•Ne pas tenter d’allumer d’appareil.
•Ne touchez à aucun interrupteur. Ne pas vous
servir des téléphones se trouvant dans le
batiment où vous vous trouvez.
•Appelez immédiatement votre fournisseur de
gaz depuis un voisin. Suivez les instructions
du fournisseur.
•Si vous ne pouvez rejoindre le fournisseur de
gaz, appelez le service dos incendies.
L’installation et service doit être exécuté par un
qualifié installer, agence de service ou le
fournisseur de gaz.
6400-40435
Model #8830
05-22-03

HearthStone Quality Home Heating Products Inc Windsor Bay Model #8830
2
HearthStone
Quality Home Heating Products
317 Stafford Avenue,
Morrisville, Vermont 05661
E-Mail: [email protected]

HearthStone Quality Home Heating Products Inc Windsor Bay Model #8830
3
INFORMATION SHEET
Record, on this page, all relevant information concerning the purchase, installation, and maintenance
of your WINDSOR BAY Gas-Fired Direct Vent heater. This information will facilitate servicing,
purchase of replacement parts, and warranty claims (if necessary). Keep your original receipt in a safe
place as proof of purchase.
Serial Number:
Fuel type (check one) Natural Gas Liquid Propane
Sold by:
Phone: Date of Purchase:
Installed by:
Phone: Date of Installation:
Gas Supplier:
Phone:
Read this Owner’s Manual before installing or operating the WINDSOR BAY heater. Retain this manual for
future reference.
SERVICE RECORD
Date Who Performed Work Work Performed Notes:
WHAT WHEN WHAT WHEN
Firebox Cleaning............. annually Door Gasket.................... Replacement as needed
Glass Cleaning................ as needed

HearthStone Quality Home Heating Products Inc Windsor Bay Model #8830
4
Introduction
Congratulations on your purchase of a
Windsor Bay Gas-Fired Direct Vent heater.
The Windsor Bay incorporates the latest in
energy and gas technology, which will
provide you with clean, efficient heat for
years to come. The combination of natural
stone and cast iron gives the Windsor Bay
years of attractive looks and allows for
durable performance that can be maintained
with minimal care.
The Windsor Bay will provide you with
years of practical and convenient service.
However, as with any gas appliance, the unit
must be properly and safely installed and
maintained by qualified service personnel to
ensure safe and trouble-free operation.
Your Windsor Bay is equipped with a
standard pilot which:
1. generates a milli-volt signal that
powers the wall-mounted thermostat
and;
2. lights the main burner when the
thermostat calls for heat.
This unit is equipped with an
On/Off/T’STAT switch and a variable
output control. The variable output control is
located on the gas control valve. It allows
you to vary the heat output, along with the
flame height to suit personal taste. Heat
output can be reduced {set to “LOW”}
during the Fall and Spring, when the need
for heat is reduced and increased {set to
“HIGH” during Winter months, when the
need for heat is the greatest.
A wall-mounted thermostat is provided by
HearthStone. Regardless of how you set the
variable output control, when the optional
thermostat has been installed and the
On/Off/T’STAT switch is set to “T’STAT”,
the wall-mounted thermostat will control the
on/off cycling of the unit. At any time, you
can override the thermostat with the
On/Off/T’STAT switch by setting it to
“ON” or “OFF”.
The Unit is equipped with a two speed
blower fan, which turns on and off
independently of the burner flames. When
the HIGH/OFF/LO switch, which allows
you to turn the fan on or off and control the
speed of the fan to suit your needs, is set to
“High” or “Lo”, the fan will automatically
turn on when the stove is hot and cycle off
when the unit is no longer hot.
Also available are two different optional
remote controls. Both of the remote controls
are capable of turning the unit on and off.
One of the optional remotes also allows you
to control the temperature of the stove from
anywhere in the vicinity of the unit. If “ON”
& “OFF” are the only controls required, Kit
# 90-56912 can be used. If you would like to
control the temperature via the remote
control, use Kit # 90-56914.
READ THIS OWNER’S MANUAL
Operate and maintain this gas heater
according to the instructions in this manual.
Read this manual in its entirety. This
manual has two sections, the first section is
for the OPERATOR, and the second section is
for the QUALIFIED SERVICE PERSONNEL only.
HEATER MUST BE INSTALLED
AND MAINTAINED BY QUALIFIED
SERVICE PERSONNEL
Verify the gas connections and venting
systems with requirements of local, regional
or national installation codes. Qualified
service personnel must inspect the gas heater
before use and at least annually.

HearthStone Quality Home Heating Products Inc Windsor Bay Model #8830
5
TABLE OF CONTENTS
READ THIS OWNER’S MANUAL........1
INTRODUCTION...........................................4
OWNER’S INFORMATION............................5
SAFETY INFORMATION...............................5
SPECIFICATIONS:.................................8
ROUTINE MAINTENANCE AND CARE.......11
INSTALLER’S INFORMATION ....................11
UNPACK AND INSPECT FOR DAMAGE ..... 12
VENTING COMPONENTS &
CONFIGURATION ......................................14
ELECTRICAL CONNECTIONS ....................17
GAS SUPPLY & CONNECTIONS.................20
ASSEMBLING THE UNIT............................22
LOG PLACEMENT .....................................26
LIGHTING THE UNIT FOR THE FIRST TIME
...................................................................28
INITIAL ADJUSTMENTS.............................29
MAINTENANCE AND CARE........................31
PARTS LISTS .............................................33
LIMITED WARRANTIES ....................39
Owner’s Information
Safety Information
Your Windsor Bay is a very attractive and
extremely efficient, utilizing today’s best
technologies. By following a few simple
safety precautions and by performing minimal
maintenance, the unit will remain appealing
while providing years of quality performance.
The installation must conform to local codes
or, in the absences of local codes, the current
National Fuel Gas Code, ANSI Z223.1 (NFPA
54) or CAN/CGA B149 Installation Code.
(Installer l’appareil selon les codes ou
réglements locaux, ou, en l’absence de tells
réglements, selon les Codes d’installation
CAN/CGA B149.)
Do not use this appliance if any part has been
under water. Immediately call a qualified
service technician to inspect the heater and to
replace any part of the control system and gas
control that has been under water. (Ne pas se
servir de cet appareil s’il a été plongé dans
l’eau, complétement ou en partie. Appeler un
technicien qualifié pour inspector l’appareil et
remplacer toute partie du systéme de contrôle
et toute commande qui ont été plunges dans
l’lau.)
During the first few hours of operation the
appliance may produce a slight smoke and/or
odor. This is normal during the first several
burns. During the initial burn, open a
window(s) to assist in the removal of the
smoke/odor. If the logs appear to smoke, turn
the heater off and call a qualified service
technician.
The appliance and its individual shutoff valve
must be disconnected from the gas supply
piping system during any pressure testing of
that system at test pressures in excess of ½
psig. (3.5k Pa). The appliance must be isolated
from the gas supply piping system by closing
its individual manual shutoff valve during any
pressure testing of the gas supply piping
system at test pressures equal to or less than ½
psig (3.5k Pa).
FIRE HAZARD
Do not store or use gasoline or other
flammable vapors or liquids in the vicinity
of this appliance. The Windsor Bay should
be located out of traffic and away from
furniture, draperies, clothing, and flammable
material.

HearthStone Quality Home Heating Products Inc Windsor Bay Model #8830
6
SHOCK HAZARD
This appliance is equipped with a three-
prong (grounding) plug for protection
against shock hazard and should be plugged
directly into a properly grounded three-
prong receptacle. Do not cut or remove the
grounding prong from the plug.
MUST BE VENTED TO THE
OUTSIDE
Never vent the gas heater to other rooms or
buildings.
¦WARNING:
This gas appliance must not be
connected to a chimney flue serving a
separate solid-fuel burning appliance.
SERVICE CAUTION
If you believe your Windsor Bay is not, in
any way, performing properly, immediately
discontinue operation until the unit has been
inspected and approved by qualified service
personnel. Prior to servicing the unit, turn
the valve control knob clockwise to “OFF”.
The unit should be cool prior to servicing
and cleaning. Any safety screen, guard, or
component removed during servicing should
be replaced prior to operation. Use of any
components not supplied by HearthStone on
the stove voids all warranties. Do not
substitute components.
HOT SURFACES
Certain exposed surfaces of the Windsor Bay
will reach high temperatures during normal
operation. Clearances to combustibles must
be maintained, as specified in the “Clearances
To Combustibles” section of this manual.
Due to high temperatures the appliance
should be located out of traffic and away
from furniture, draperies, clothing and
flammable materials. Children and adults
should be alerted to the hazards of high
surface temperatures and should stay away
to avoid burns to skin or clothing ignition.
Young children should be carefully
supervised when in the same room as the
appliance. Clothing or other flammable
material should not be placed on or near
the appliance. (Surveille les enfants. Garder
les vêtements, les meubles, l’essence ou autres
liquides à vapeur inflammables lin de
l’appareil.) Clean the area around, under, and
behind the unit on a regular basis to prevent
the accumulation of dust and lint.
NEVER BURN PAPER, WOOD, OR
OTHER MATERIALS
This gas heater is designed to burn either
natural gas (NG) or liquid propane (LP).
Never burn any fuel that was not intended
for use.
DO NOT LIGHT PILOT OR MAIN
BURNERS BY HAND
The standing pilot light equipped with this
gas heater is lit by using a piezoelectric
spark generator, as described in the How To
Turn The Unit On & Off section of this
manual. Never attempt lighting the pilot or
main burners by hand (with a match or
lighter). After repeated attempts, if the pilot
light fails to light, discontinue operation,
turn off the gas control valve, and
immediately contact qualified service
personnel for assistance.
¦WARNING:DO NOT OPERATE THE
APPLIANCE WITH THE FRONT GLASS
REMOVED, CRACKED OR BROKEN.
REPLACEMENT OF GLASS SHOULD
BE DONE BY A LICENSED OR
QUALIFIED SERVICE PERSON. ONLY
OPEN FRONT FOR ROUTINE SERVICE.
DO NOT SLAM OR STRIKE GLASS.

HearthStone Quality Home Heating Products Inc Windsor Bay Model #8830
7
CERAMIC FIBER LOG SAFETY
INFORMATION
If the decorative ceramic log material
supplied with the Windsor Bay is damaged
or missing, it must be replaced with the
same, approved replacement parts supplied
by the manufacturer. These components
affect the combustion quality and safety of
the heater. Do not replace fiber ceramic logs
with unapproved ceramic logs or any other
material.
Always wear gloves and safety goggles
while handling the log set and ember
strip.
Certified for use by:
Board of State Examiners of Plumbers and Gasfitters
100 Cambridge Street, Room 1511
Boston, Massachusetts
02202
Caution
A reverse flue condition may occur if the
venting is not attached correctly, or if the
unit is lit before the glass front is
properly secured. This condition may
damage the unit.

HearthStone Quality Home Heating Products Inc Windsor Bay Model #8830
8
SPECIFICATIONS:
LISTED: DIRECT VENT
GAS HEATER
Listed: DV Gas Heater
Model: Windsor Bay
Direct Vent Insert Room
Heater
Testing Agency: Intertek
Testing Services NA Inc.
(ITS)
Tested to: ANSI Z21.88-
1998, CSA 2.33-M98, LARGE SURROUND SMALL SURROUND
Figure 1: Windsor Bay Dimensions
VIEW
VIEW
FRONT
TOP
*Allow 4" extra
for venting
connection
Fireplace Dimensions
Fireplace Dimensions: Minimum Maximum
Width: 28” 42”
Height: 20” 31”
Depth: 10” >15”
NG LP
Input rating (Btu/hr) 0-2000ft 32,000 32,000
Maximum output (Btu/hr) 0-2000ft 24,000 24,500
Minimum input rating(Btu/hr) 20,000 26,000
Orifice size DMS 0-2000ft 46 56
Man. pressure-HI setting (in.w.c./kPa) 3.5/0.87 10.0/2.48
Man. pressure-LO setting (in.w.c./kPa) 1.6/0.42 6.4/1.59
Inlet pressure-HI (in.w.c./kPa.) 10.5/2.6 14.0/3.47
Inlet pressure-Lo (in.w.c./kPa) 5.0/1.24 11.0/2.88

HearthStone Quality Home Heating Products Inc Windsor Bay Model #8830
9
LIGHTING INSTRUCTIONS
NOTE: The gas control knobs and the piezo
ignitor are located in the lower right side
door.
1. STOP! Read the What To Do If You
Smell Gas! Warning (on the cover of
this manual).
2. Set the on/off/T’STAT switch or
thermostat
to the “OFF” position.
3. Push in and turn gas control knob
clockwise to “OFF”. (If not previously
lit, the knob should be in this position.)
4. Wait (5) five minutes to clear out any
gas. If you then smell gas, STOP! Smell
all around the appliance area for gas.
Be sure to smell next to the floor because
some gases are heavier than air and will
settle on the floor. If you smell gas
immediately follow the What To Do If
You Smell Gas! warning on the cover of
this Manual. If you do not smell gas,
proceed to the next step.
5. Turn gas control knob counter-clockwise
to “PILOT”.
6. Push in control knob all the way and
hold in. Immediately light the pilot with
the piezo lighter (push in and “click” the
red piezoelectric spark ignitor button
several times until lit). Continue to hold
the control knob in for about 20 seconds
after the pilot is lit. Release the knob and
it will pop back out. Pilot should remain
lit. If the pilot goes out, repeat the
operation.
•If knob does not pop out when released,
stop, shut off the gas supply to the heater
and immediately call a qualified service
technician or gas supplier.
•If the pilot will not stay lit after several
tries, turn the gas control knob “OFF”
and call a qualified service technician or
gas supplier.
7. After the pilot lights, turn gas control
knob counter-clockwise to “ON”.
8. If the ON/OFF/T’STAT switch is set to
“ON”, the stove should now be lit. If the
thermostat (or remote) has been
installed, set the ON/OFF/T’STAT
switch to “T’STAT” and turn the
thermostat (or remote) to “ON”. Then
set the desired temperature.
9. Shut the gas control valve access door.

HearthStone Quality Home Heating Products Inc Windsor Bay Model #8830
10
NOTE: When pressing/clicking the red
piezoelectric spark ignition button to light
the pilot, watch through the glass (front) of
the unit. Click the red ignitor button until a
flame is visible at the pilot. Once the pilot is
lit, continue to press on the gas control knob
for another 20 seconds, then release.
Ascertain that the pilot is still lit by looking
through the front glass. If lit, then turn the
gas control knob fully counter-clockwise to
the “ON” position. If the pilot fails to light,
or if it went out due to a premature release
of the gas control knob while pressed in the
“PILOT” position, wait 60 seconds for the
Interlock to release. Then repeat the lighting
process as described in this section of the
manual.
Once the pilot has been lit, the gas control
knob has been turned to the “ON” position,
and the ON/OFF/T’STAT switch has been
turned to “ON”, the main burners should
light immediately. If you would like to use
the thermostat and it has been installed,
switch the ON/OFF/T’STAT switch to
T’STAT. Turn the thermostat to "ON" and
set it to a higher position so that it "calls" for
heat in order to turn light the main burners
(i.e. turns the unit on). Note that the
thermostat controls the on/off cycling of the
main burners, but the pilot remains lit
regardless of the thermostat setting. The
only way to turn the pilot off is to turn the
gas control knob fully clockwise to the
“OFF” position.
TO TURN OFF GAS TO APPLIANCE
1. Set the thermostat to the “OFF”
position or turn the
ON/OFF/T’STAT switch to the
“OFF” position.
2. If shutting the unit off for the non-
heating season, turn the gas control
knob fully clockwise to the “OFF”
position. Do not force the knob to
turn.
DAILY OPERATION
The Windsor Bay gas-fired heater is easily
operated by the homeowner once installed
and adjusted by a qualified service
technician. The unit can be controlled
automatically or manually. The unit is
controlled manually by setting the
ON/OFF/T’STAT switch (upper switch) in
the “ON” position, the thermostat will not
operate, and the main burner will stay on
constantly. In the “OFF” position, only the
pilot remains lit but the main burners and
thermostat will not operate. The unit is
controlled automatically via the wall-
mounted thermostat by setting the switch to
“T’STAT”. By setting the thermostat to the
desired room temperature, the unit will cycle
on and off as requested by the room
thermostat, supplied with your stove. By
adjusting the variable output control, located
on the gas control valve, the rate of heat
output can be varied to meet the heating
requirements of the season. Choosing a low
flame setting will result in longer burn
cycles at a reduced output, while choosing a
high flame setting will result in a shorter,
hotter burn cycle.
Through trial and error you can select the
optimum flame size for your setting and
application. During the summer, non-heating
season, switch the wall thermostat and
rocker switches to “OFF”, and turn off the
pilot. This will improve the overall
efficiency of the unit as the heat from the
pilot is not wanted in the summer. When
putting the unit back into service follow the
Lighting The Unit portion in the How To
Turn The Unit On & Off section of this
manual.

HearthStone Quality Home Heating Products Inc Windsor Bay Model #8830
11
When the unit is first lit, especially when
cool, it is normal to experience some
condensation on the inside of the glass
window. This condensation will burn off
within the first few minutes of operation. If
continuous condensation or water drips are
noted from any part of the unit, immediately
discontinue operation of the unit and contact
a qualified service technician.
Routine Maintenance and
Care
The Windsor Bay requires minimal routine
maintenance and care. The unit should
always be cool and off when being cleaned.
CLEANING
¦WARNING: Do not clean the unit
when hot. The unit should receive
regular cleaning on, under, and around
the stove to prevent the buildup of dust
and lint. The exterior surfaces of the unit
can be cleaned using soap, water, and a
soft cloth. Do not use abrasive or
chemical cleaners and take care not to
scratch the stones, glass or enamel finish
(if so equipped) when cleaning the unit.
The use of chemical wax based cleaners
or polishes are not recommended due to
the potential for discoloration or the
enamel when the residue of the cleaners
or polishes is exposed to heat.
FIREBOX, PILOT, & BURNER
TUBES
The firebox, pilot & burner tubes should
receive periodic cleaning to prevent the
accumulation of dust, lint and debris.
Regularly check to insure the area around
the Windsor Bay is kept free and clear from
combustible materials, gasoline, and other
flammable vapors and liquids. Check that
the flow of ventilation air is not obstructed.
Once a year the unit and its venting
system should be inspected by qualified
service personnel to ensure that it is clean,
free of obstruction, safe, and in good
working order. If service or maintenance
is required, qualified service personnel
should perform it.
Installer’s Information
CODES
Adhere to all local codes or, in their
absence, the latest edition of THE
NATIONAL FUEL GAS CODE ANSI
Z223.1 (NFPA 54) or CAN/CGA B149
Installation Code that can be obtained from:
AMERICAN NATIONAL STANDARDS
INSTITUTE, INC.
1430 BROADWAY
NEW YORK, NY 10018
OR
NATIONAL FIRE PROTECTION
ASSOCIATION, INC.
BATTERY MARCH PARK
QUINCY, MA 02269
The appliance when installed, must be
electrically connected and grounded in
accordance with local codes or, in the
absence of local codes, with the current
NFPA 70-National Electrical Code or CSA
C22.1-Canadian Electric Code.
A manufactured home (mobile) OEM
installation must conform with the
Manufactured Home Construction and
Safety Standard, Title 24 CFR, Part 3280
(U.S.) or Standard for Manufactured Home
Installation, ANSI/NCBCS A225.1 or
Standard for Gas Equipped Recreational
Vehicles and mobile Housing, CSA
Z240.4.CAN/SCA Z240 MH (Canada).
(Installer l’appareil selon les codes ou
règlements locaux, ou, en l’absence de tels

HearthStone Quality Home Heating Products Inc Windsor Bay Model #8830
12
règlements, selon les Codes d’installation
CAN/CGA-B149.)
ITEMS REQUIRED FOR
INSTALLATION
* External regulator (for propane/L.P.G.
only)
* Piping which complies with local codes
* Pipe sealant approved for use with
propane/L.P.G. (resistant to sulfur
compounds)
* Manual shutoff valve
* Sediment trap
* Tee joint
* Pipe wrench
* Phillips head screwdriver
* Other parts as required by local code
*Safety Glasses
*Gloves
PACKING LIST
1-Windsor Bay Gas-Fired Heater
1-Surround Set (3 pcs.) (optional)
1-Hardware Set
1-Accessory Box
1-Thermostat with 40’ wire
1-Owners Manual
1-Warranty Validation Form
1-Top Center Stone
1-Top Center Grill
2-Embers
1-Andiron
1-Ember Screen
6-Decorative Ceramic Fiber Logs
1-Flex Gas Tube
1-Restrictor Disc
UNPACKING AND INSPECTION
UNPACK AND INSPECT FOR DAMAGE
The Windsor Bay is packaged by the
manufacturer to withstand shipment without
damage. However, damage can occur during
transit so take care to inspect for damage
when unpacking and installing the unit. If
any damage or missing parts are detected,
immediately contact your dealer.
Do not install or put into service a
damaged or incomplete heater.
Within the accessory box is the top center
stone, top center grill, thermostat, and
thermostat wire. The location and
installation instructions for these parts will
follow the inspection for damage.
Unbolt and lift off the pallet and partially
insert it into the fireplace, (with regards to
the Clearances To Combustibles section of
this manual).
Inspect the stove for visible and/or
concealed damage. The unit should appear
to be square and true. The stones should be
whole and without cracks, chips, or
breakage. The sheet metal parts should be
smooth and free of bends and/or dents. If the
heater is enameled, the enameled cast iron
should be free of chips and/or cracks.
If visible or concealed damage is found or
suspected, contact your local dealer for
instructions. Refer to Figure 7 on page 23
for the next step. To open the firebox,
remove the front grill, and the 4 screws
holding on the front façade. Inspect the log
for damage. It is important to wear safety
goggles and gloves when handling the log
set. If a damaged log is encountered, contact
your local dealer for a replacement log. Put
the log set aside. It will be installed later.
Sediment Trap
3"MIN.
Cap
Nipple
ToEquipment
Inlet TeeFitting
GasSupply
Inlet

HearthStone Quality Home Heating Products Inc Windsor Bay Model #8830
13
HEARTH REQUIREMENT/FLOOR
PROTECTION
The Windsor Bay may be placed on a non-
combustible surface or wood floor. For
placement of the Windsor Bay on carpeting,
vinyl tile or other combustible materials, the
appliance shall be installed on a metal or
wood panel extending the full width and
depth of the appliance. Installations must
meet local codes.
Note: Some wood floor varnishes, stains, or
polyurethanes may be affected by heat.
CLEARANCES TO COMBUSTIBLES
8" - TO ALL SIDE WALLS
10" - WITH 1.5" MANTLE
NO HEARTHPAD REQUIRED
16" - WITH 7.5" MANTLE
Figure 2: Clearances to Combustibles

HearthStone Quality Home Heating Products Inc Windsor Bay Model #8830
14
CLEARANCE TO COMBUSTIBLES
Due to high surface temperatures, the unit
should be located out of traffic and away
from furniture and draperies. Clothing and
other flammable material should not be
placed on or near the heater. When
positioning the unit always maintain
adequate clearances around air openings into
the combustion chamber and allow for
adequate ventilation. Minimum clearances
to combustibles must be maintained as
shown in Figure 2.
NOTE: These clearances represent
minimum distances in all cases, which,
through testing in an independent
laboratory to ANSI and CSA standards,
will prevent fire or spontaneous
combustion. We do not control the
combustible materials exposed to heat by
this product; therefore, an assessment
must be made by the installer to prevent
consequential damage of walls and
flooring.
Venting Components &
Configuration
The Windsor Bay cannot be vented jointly
with any other solid fuel or gas appliance.
The Windsor Bay must be vented directly to
the outside of the building using a proper
termination as listed below. The venting
configuration is shown in figure 3. If the
vent-air system is disassembled for any
reason, reinstall per the instructions
provided in the Assembling The Unit section
of this manual.
CONFIGURATIONS FOR FIREPLACE
INSTALLATIONS
1.Chimney Liner System*
1. Two Sections 3” Co-Linear Flex
Liners (10ft Min./30ft Max.). Dura-
Vent #2280
2. Chimney Liner Termination Kit
(Includes Co-Linear to Co-Axial
Termination and Flashing) Dura-
Vent #923GK.
3. High Wind Termination Cap Dura-
Vent #930.
4. High Temperature Silicone.
5. Four 3-1/2” Hose Clamps.
* Available through your local HearthStone
dealer.
Figure 3: Venting Configuration

HearthStone Quality Home Heating Products Inc Windsor Bay Model #8830
15
2.Using the existing chimney as an air inlet
The chimney flue must be carefully sealed from the room environment. Fabricate a plate of non-
combustible material and carefully fit it to the damper area with high temperature sealant.
This stove is certified for use with a coaxial venting system. ANSI Z21.88 standards state
that the maximum leakage rate for the venting system is 32 SCFM @ .06” w.c. This leakage
must be accounted for if you use the chimney for intake air.
Non-combustible damper seal:
1) Must support inlet flex pipe
2) Musr seal chimney opening around inlet and exhaust flex pipe
Inlet:
Must extend through the damper seal
3" Co-Linear Flex
Extensions(exhaust must be within 10'-30')
Chimney Liner
Termination Kit (Exhaust to center connector)
Exhaust
NOTE: All joints must be sealed. Leakage around the damper seal must be avoided.
WARNING: This installation may not work in a negative pressure environment, or if a
seal cannot be attained. If sooting, ghosting of flame occurs, please check and repair
leakage of chimney system.
The following installation procedure is not covered under the ANSI Z21.88 test method and
product certification. Use of an existing chimney as an air intake must be specifically approved by
your gas supplier and the local code Authority Having Jurisdiction

HearthStone Quality Home Heating Products Inc Windsor Bay Model #8830
16
Restrictor Disc
Your Windsor Bay has been supplied with a restrictor disc. This disc will provide excellent
restriction for vertical runs exceeding 20 feet. If your vertical rise is less than 20 feet, do not use
the restrictor.
EXHAUST
INTAKE
Figure 4: Restrictor Disc
Cet appareil peut être installé dans un
maison préfabriquée (mobile) déjà installée
à demeure si les règlements locaux le
permettent.
Cet appareil doit être utilisé uniquement
avec les types de gas indiqués sur la plaque
signalétique. Ne pas l’utiliser avec d’autres
gas sauf si un kitde conversion certifié est
installé
Conditionally approved for purchased
mobile home installation. This appliance
may be installed in an aftermarket
permanently located, manufactured
(mobile) home, where permitted by local
codes.
This appliance is only for use with the type
of gas indicated on the rating plate. This
appliance is not convertible for use with
other gases, unless a certified kit is used,
available through your local HearthStone
dealer.

HearthStone Quality Home Heating Products Inc Windsor Bay Model #8830
17
Electrical Connections
NOTE: OPEN VALVE DOOR ON THE RIGHT SIDE FOR ELECTRICAL AND GAS
CONNECTIONS.
THERMOSTAT
The ON/OFF/T’STAT switch or wall
mounted thermostat controls the Windsor
Bay. We recommend installation of the
thermostat for more comfortable
performance, however you may still
override the thermostat by setting the switch
to “ON”. The thermostat controls the unit by
“calling for heat.” The thermostat turns the
unit on when the room is cold, and turns the
unit off once the room is warmed
sufficiently. The thermostat is controlled by
a 750 millivolt DC two-wire circuit.
REMOTE CONTROL
There are two different optional remote
controls. Both of the remote controls are
capable of turning the unit on and off. One
of the optional remotes also allows you to
control the temperature of the stove, (in the
same way the thermostat controls the
heater), from anywhere in the vicinity of the
unit. If “ON” & “OFF” are the only controls
required, Kit #90-56912 can be used. If you
would like to control the temperature via the
remote control, use Kit #90-56914.
Installation instructions are provided with
the kits.
THERMOSTAT PLACEMENT
The thermostat should be placed in the same
room or living space as the unit. Typically
5’ (1.5m) off the floor and away from any
influences that may cause the temperature in
the vicinity of the thermostat to be
unrepresentative of the room temperature in
general. Such influences might include
strong lighting, a heater vent from the
central heating system, or a nearby drafty
window.
Placement of the thermostat on an inside
wall rather than an outside wall is
preferable. Do not place the thermostat
directly behind or too close to the unit,
otherwise heat from the unit will
immediately satisfy the thermostat and turn
the unit off.
THERMOSTAT WIRING
The thermostat wire from the unit to the
thermostat can be surface mounted, routed
under the floor, or through walls, etc. The
thermostat should be connected to the unit
using a maximum of 40’ (12m) of insulated
thermostat wire provided, but must not
exceed 40’ (12m) in length. Be sure to leave
a small coil of wire behind the unit so that it
can be moved out of position for servicing
and cleaning.
ELECTRICAL GROUNDING
INSTRUCTIONS
This appliance is equipped with a three-
prong (grounding) plug for your protection
against shock hazard and should be plugged
directly into a properly grounded three-
prong receptacle. Do not cut or remove the
grounding prong from this plug.
WIRING INSTRUCTIONS
The proper location of wire connections is
shown following and in Figure 4. When
making these connections, position the
thermostat wire so it extends out the side
surround panel towards the thermostat. (At
the thermostat, the wires should be

HearthStone Quality Home Heating Products Inc Windsor Bay Model #8830
18
connected to the two connection screws on
the back of the thermostat per the
instructions received with the thermostat).
Take care not to over-tighten the connection
screws and not to damage the internal parts
of the thermostat. Now attach the wires in
their proper location on the fireplace, shown
in Figure 5.
LOCATION OF WIRE CONNECTIONS:
Wire Location Label
Thermostat (2 wires) 1-Top Post on Valve TH
1Bottom Post on Switch T’STAT
Thermopile (2 wires) 1-Bottom Post TP/TH
1-Middle Post TP
The proper location of wire connections is shown in Figure 5.
NOTICE: A qualified technician must connect the heater to the gas supply and leak test the
unit before it is approved for use. Consult all local codes.
¦WARNING: The unit must be installed and connected in accordance with local codes, or in
the absence of local codes, with the most current edition of the National Fuel Gas Code
ANSI Z223.1.

HearthStone Quality Home Heating Products Inc Windsor Bay Model #8830
19
31 2 21 3
W
B
G
Y
R
Bk
V
G
G
B
R
W
Bk
Y
Bk
V
V
Bk
W
W
Wiring Diagram - Windsor Bay Fireplace Insert
Y
NOTE: Numbers on switch
are shown on opposite side.
Wiring Color KEY:
Figure 5: Wiring Diagram

HearthStone Quality Home Heating Products Inc Windsor Bay Model #8830
20
Figure 6
Gas Supply &
Connections
¦NOTICE: A qualified technician must
connect the heater to the gas supply
and leak test the unit before it is
approved for use. Consult all codes.
¦WARNING: The unit must be installed
and connected in accordance with local
codes, or in the absence of local codes,
with the most current edition of the
National Fuel Gas Code ANSI Z223.1
(NFPA 54) or CAN/CGA B149
Installation Code.
We recommend using new black iron or
steel pipe only. Internally tinned copper
tubing can be used in some areas when
permitted by local codes. Only use pipe of
½” or greater diameter to allow full gas
volume to heater, without undue loss of
pressure. Excessive pressure loss will occur
if the pipe is too small.
The gas supply line must include a manual
shut-off valve and union so the unit can be
disconnected for servicing. Also a sediment
trap and a 1/8” N.P.T. plugged tapping must
be installed upstream of the heater. The
sediment trap is installed to prevent moisture
and contaminants from passing through the
pipe to the heater controls and burners.
Failure to install a sediment trap could
prevent the heater from operating reliably.
The 1/8” N.P.T. plugged tapping is installed
for the test gauge connection (immediately
upstream of the gas supply connection).
Damage to the valve caused by lack of a
sediment trap will not be covered by the
warranty.
We have supplied a 24” flexible stainless
steel gas line for installation convenience
and to avoid undue mechanical load on the
valve. We recommend using the flexible
line, but also refer to local code. The gas
supply line connection is made to the
flexible line in the lower rear right portion of
the Windsor Bay. Apply a thread sealant to
both male ends on the flexible gas line.
