Arbrux Two Light Fixture Kit User manual

Two Light Fixture Kit
5- Step Quick Install Guide

Thank you for choosing Arbrux!
Our products represent great quality at a great price!
We have worked hard to become the benchmark for our industry since 1979.
We are excited to show you how easy our products are to install...
Here we go...

Step 1: Tighten Light Connector
•Hand tighten
lighting underwater
connector from
lights to shore
power cable.

Step 2: Assemble
•Assemble U shaped
bracket on fixture
to L shaped bracket
as shown.
U bracket to L bracket must be
adjusted to ensure fixture is
completely submerged when
installed in water.

Step 3: Install
•Install L shaped
bracket from
previous step on
float.
Shown on 40 inch float, 32 inch
float can accommodate four
fixtures maximum.

Step 4: Run Power Cables
1. Install fountain or aerator as per instructions and
moor float.
2. Run power cables to shore.
2
1

Step 5A: Connect- ½ HP Single Phase
1. For ½ HP Single Phase
models connect shore
end of light kit cable to
external lighting
controller shown.
2. Plug controller into GFCI
protected receptacle.
3. Adjust controller to
desired setting.
.
1
2

Step 5B: Connect- For Larger Single Phase
For larger single phase
models, have your
electrician connect to
applicable terminals in
control panel and adjust
timer

You’re Done... Time to Enjoy the View!

Don’t Forget to Show us your Lights in Action...
Email your Images to
[email protected]
and your night images
could be featured on our
site!
