arcelik 6555 X User manual

Document Number :
Bulaşık Makinesi
Kullanma Kılavuzu
6555 X
6555 B
Dishwasher
User’s Manual
EN
1728767140_AC_ARCELIK_B5_6555 X_6555 B_EN/ 20-02-19.(14:46)

Explanation of symbols
Throughout this User Manual the following symbols are used:
CImportant information or
useful hints about usage.
AWarning for hazardous
situations with regard to life
and property.
BWarning for electric shock.
Packaging materials of the
product are manufactured
from recyclable materials
in accordance with our
National Environment
Regulations.
Do not dispose of the packaging materials together with the domestic or other
wastes. Take them to the packaging material collection points designated by
the local authorities.
Please read this user manual first!
Dear Customer,
We hope that you get the best results from your product which has been
manufactured with high quality and state-of-the-art technology. Therefore,
please read this entire user manual and all other accompanying documents
carefully before using the product and keep it as a reference for future use.
If you handover the product to someone else, give the user manual as well.
Follow all warnings and information in the user manual.
Remember that this user manual is also applicable for several other models.
Differences between models will be identified in the manual.

Document Number :
1728767140_AC_ARCELIK_B5_6555 X_6555 B_EN/ 20-02-19.(14:46)
Document Number :
6555 X
6555 B
Dishwasher
User’s Manual
EN

Explanation of symbols
Throughout this User Manual the following symbols are used:
CImportant information or
useful hints about usage.
AWarning for hazardous
situations with regard to life
and property.
BWarning for electric shock.
Packaging materials of the
product are manufactured
from recyclable materials
in accordance with our
National Environment
Regulations.
Do not dispose of the packaging materials together with the domestic or other
wastes. Take them to the packaging material collection points designated by
the local authorities.
Please read this user manual first!
Dear Customer,
We hope that you get the best results from your product which has been
manufactured with high quality and state-of-the-art technology. Therefore,
please read this entire user manual and all other accompanying documents
carefully before using the product and keep it as a reference for future use.
If you handover the product to someone else, give the user manual as well.
Follow all warnings and information in the user manual.
Remember that this user manual is also applicable for several other models.
Differences between models will be identified in the manual.

CONTENTS
1 
 
General safety ....................................4
Intended use .......................................5
Children’s safety .................................5
Disposing of packaging material.........5
Transportation of the product .............6
Compliance with WEEE Directive and
Disposing of the Wa󰀬e Product .........6
Compliance with RoHS Directive........6
Package information ...........................6
2  
Overview.............................................7
Technical specifications ......................8
3  
Appropriate in󰀬allation location ..........9
Connecting water supply ..................10
Connection to the drain ....................10
Adju󰀬ing the feet ..............................11
Electrical connection......................... 11
Initial use .......................................... 11
 
Tips for energy saving ......................12
Water softening sy󰀬em ....................12
Adju󰀬ing the water softening sy󰀬em12
Adding salt ........................................12
Detergent ..........................................13
Tablet detergents ..............................14
Rinse aid...........................................15
Items not suitable for washing in the
dishwasher .......................................16
Placing the dishes into the
dishwasher .......................................16
Silverware basket piece....................19
Silverware basket .............................19
Cutlery basket ..................................20
Cutlery basket ..................................20
Collapsible lower basket wires (6
pieces) ..............................................21
Collapsible lower basket wires (4
pieces) ..............................................22
Collapsible lower basket wires (2
pieces) ..............................................22
Collapsible lower basket tines ..........23
Collapsible lower basket tines ..........24
Lower basket bottle wire ...................24
SoftTouch Accessory ........................25
Lower Basket Glass Holder ..............25
Tray Wash Supports .........................25
Lower basket multipurpose / height
adju󰀬able service rack .....................26
Upper basket height adju󰀬able rack 27
Upper basket drawer ........................27
Upper basket glass support piece ....27
Upper basket glass support piece ....28
Collapsable upper basket wires........28
Collapsible upper basket tines..........29
Collapsible upper basket tines..........29
Collapsible upper basket wires .........30
Adju󰀬ing the height of the upper
basket ...............................................30
Adju󰀬ing the height of loaded upper
basket ...............................................31
Height setting with empty basket ......32
Adju󰀬ing the height of the upper
basket ...............................................32
Upper basket multipurpose service
rack ...................................................33
Ceiling cutlery basket .......................34
Ceiling cutlery basket .......................34
Upper cutlery basket.........................35
5 
 
Cleaning the outer surface of the
product..............................................36
Cleaning the interior of the machine . 36
Cleaning the filters ............................36
Cleaning the hose filter .....................37
Cleaning the impellers ......................38
Lower impeller ..................................38
Upper impeller .................................38
 

4Dishwasher / User’s Manual/43 EN

1
This section contains safety
instructions that will help to
get protected from risk of
personal injury or property
damage. Failure to follow
these instructions shall void
all warranties.

•Never place the product
on a carpet-covered floor;
otherwise, lack of airflow
beneath the product will
cause electrical parts
to overheat. This will
cause problems with your
product.
•Do not operate the product
if the power cable / plug is
damaged! Call the
•Connect the product to a
grounded outlet protected
by a fuse complying
with the values in the
“Technical specifications”
table. Do not neglect
to have the grounding
installation made by a
qualified electrician. The
manufacturer shall not be
liable for any damages
that will arise when the
product is used without
grounding in accordance
with the local regulations.
•The water supply and
draining hoses must be
securely fastened and
remain undamaged.
•Unplug the product when
not in use.
•Never wash the product by
spreading or pouring water
onto it! There is the risk of
electric shock!
•Never touch the plug
with wet hands! Never
unplug by pulling on the
cable, always pull out by
grabbing the plug.
•The product must
be unplugged during
installation, maintenance,
cleaning and repairing
procedures.
•Always have the
installation and repairing
procedures carried out by
the Authorised Service
Agent. Manufacturer
shall not be held liable for
damages that may arise
from procedures carried
out by unauthorised
persons.
•Never use chemical
solvents in the product.
They bring forth the risk of
explosion.
•When you pull the upper
and lower baskets out
completely, the door of
the product will bear all
the weight of the baskets.
Do not put other loads on
the door; otherwise, the
product may tilt.
•Never leave the door
of the product open
apart from loading and
unloading procedures.
•Do not to open the door
of the product when it is
running unless necessary.
Be careful for the rush of
hot steam when you open
the door.

Dishwasher / User’s Manual 5 / 43 EN
instructions for safety and environment

•This product has been
designed for domestic
use.
•It must be used to do the
domestic type dishes only.
•This appliance is intended
to be used in household
and similar applications
such as:
- Staff kitchen areas in shops,
offices and other working
environments;
- Farm houses;
- By clients in hotels, motels
and other residential type
environments;
- Bed and breakfast type
environments
•Only dishwasher safe
detergents, rinse aids and
additives must be used.
•The manufacturer waives
any responsibility arisen
from incorrect usage or
transportation.
•This appliance can be
used by children aged
from 8 years and above
and persons with reduced
physical,sensory or
mental capabilities or
lack of experience and
knowledge if they have
been given supervision or
instruction concerning use
of the appliance in a safe
way and understand the
hazards involved. Children
shall not play with the
appliance. Cleaning and
user maintenance shall
not be made by children
without supervision.

•Electrical products are
dangerous for the children.
Keep children away from
the product when it is in
use. Do not let them to
tamper with the product.
•Do not forget to close the
door of the product when
leaving the room where it
is located.
•Store all detergents and
additives in a safe place
away from the reach of the
children.


Packaging materials are
dangerous to children. Keep
packaging materials in a safe
place away from reach of the
children.
Packaging materials of the
product are manufactured
from recyclable materials.
Dispose of them properly
and sort in accordance with
recycled waste instructions.
Do not dispose of them with
normal domestic waste.

6Dishwasher / User’s Manual/43 EN
instructions for safety and environment


AIf you need to move
the product, do it
in upright position
and hold from the
rear side. Slanting
the product onto its
front side may cause
the electronic parts
in it get wet and
damaged.
1. Unplug the product before
transporting it.
2. Remove water drainage
and water supply
connections.
3. Drain the remaining water
in the product completely.


󰀬
This product complies
with EU WEEE Directive
(2012/19/EU). This
product bears a
classification symbol for
waste electrical and electronic
equipment (WEEE).This
product has been
manufactured with high
quality parts and materials
which can be reused and are
suitable for recycling. Do not
dispose of the waste product
with normal domestic and
other wastes at the end of its
service life. Take it to the
collection center for the
recycling of electrical and
electronic equipment. Please
consult your local authorities
to learn about these collection
centers.


The product you have
purchased complies with EU
RoHS Directive (2011/65/EU).
It does not contain harmful
and prohibited materials
specified in the Directive.

Packaging materials of the
product are manufactured
from recyclable materials in
accordance with our National
Environment Regulations. Do
not dispose of the packaging
materials together with the
domestic or other wastes.
Take them to the packaging
material collection points
designated by the local
authorities.

Dishwasher / User’s Manual 7 / 43 EN

2

1. Upper basket
2. Upper impeller
3. Lower impeller
4. Silverware basket
5. Door
6. Rating Label
7. Control panel
8. Detergent dispenser
9. Lower basket
10. Filters
11. Salt reservoir lid
12. Upper basket rail
13. Upper cutlery basket (depends on
model)
14. Tabletop (depends on model)

8Dishwasher / User’s Manual/43 EN
Dishwasher


This product complies with the following EU directives;
Development, production and sales stages of this product comply with the
safety rules included in all pertaining European Community regulations.
2014/35/EU, 2014/30/EU, 93/68/EC, IEC 60436/DIN 44990, EN 50242
Power input 220-240 V, 50 Hz (see rating label)
Total power consumption 1800-2100 W (see rating label)
Heater power consumption 1800 W (see rating label)
Total current (depends on the model) 10 A (see rating label)
Drain pump power consumption 30 W (see rating label)
Water pressure 0.3 –10 bar (= 3 – 100 N/cm² = 0.01-
1.0 Mpa)
CTechnical specifications may be changed without prior notice to
improve the quality of the product.
CFigures in this manual are schematic and may not match the product
exactly.
CValues stated on the markings of the product or in the printed
documents accompanying the product are obtained in the laboratory
on basis of the relevant standards. Depending on operational and
environmental conditions of the product, these values may vary.

Data required for performance tests shall be provided upon request. Requests
can be e-mailed to the following address:

Do not forget to provide the code, stock and serial numbers of the product to be
tested in your request e-mail along with your contact information. Code, stock and
serial numbers of the product may be found on the type label attached to the side
wall of the door.

Dishwasher / User’s Manual 9 / 43 EN
3
Refer to the nearest Authorised
Service Agent for installation of your
product. To make the product ready
for use, make sure that the electricity,
tap water supply and water drainage
systems are appropriate before calling
the Authorised Service Agent. If they
are not, call a qualified technician
and plumber to have any necessary
arrangements carried out.
CPreparation of the location
and electrical, tap water and
waste water installations at
the place of installation is
the customer's responsibility.
BInstallation and electrical
connections must be carried
out by the Authorised
Service Agent. Manufacturer
shall not be held responsible
for damages arising from
processes carried out by
unauthorised persons.
APrior to installation, visually
check if the product has any
defects on it. If so, do not
have it installed. Damaged
products cause risks for
your safety.
CMake sure that the water
inlet and discharge hoses
are not folded, pinched or
crushed while pushing the
product into its place after
installation or cleaning
procedures.
When placing the product, pay
attention not to damage the floor, walls,
piping, etc. Do not hold the product by
its door or panel to move it.
󰀬

•Place the product on a solid and
flat floor that has sufficient load
carrying capacity! The product
must be installed on a flat surface
in order for the door to be closed
comfortably and securely.
•Do not install the product at places
where temperature may fall below
0ºC.
•Place the product at least 1 cm
away from the edges of other
furniture.
•Place the product on a rigid floor.
Do not place it on a long pile rug
or similar surfaces.
BDo not place the product on
the power cable.
•Make sure that you select a
location that will allow you to load
and unload the dishes in a fast
and comfortable manner.
•Install the product in a place close
to the tap and the drain hole.
Select the installation location
by considering that it will not be
changed after the connections are
made.

10 Dishwasher / User’s Manual/43 EN
Installation

CWe recommend attaching
a filter on the house/
apartment supply water
inlet to protect the machine
from damages that may
arise from impurities (sand,
dirt, rust, etc.) coming from
the urban water supply
system or from your own
water system as well as to
prevent complaints such
as yellowing or sludge
accumulation at the end of
washing.


•Do not use old or used water inlet
hose on the new product. Use the
new water inlet hose supplied with
the product.
•Connect the water inlet hose
directly to the water tap. Pressure
coming from the tap should be
minimum 0.3 and maximum
10 bars. If the water pressure
exceeds 10 bars, a pressure
relief valve should be installed in
between.
•Open the taps completely after
making the connections to check
for water leaks.

Water discharge hose can directly be
connected to the drain hole or sink’s
drainage. The length of this connection
must be min. 50 cm and max. 100 cm
from the floor. A discharge hose longer
than 4 meters causes dirty washing.
Attach the water discharge hose
to the drainpipe without bending it.
Tightly fix the water discharge hose to
the drainpipe in order to prevent any
dislocation of the water discharge hose
during operation of the product.
min 300
min 120
max 1000
min 500
CUse a screw-on hose
connector to connect the
water inlet hose to a water
tap with a ¾ inch external
thread. If required, use a
filter insert to filter deposits
from the pipes.

Dishwasher / User’s Manual 11 / 43 EN
Installation
CDrainpipe must be
connected to the sewage
system and it should not be
connected to any surface
water.
󰀬
If the door of the product cannot be
closed properly or if the product swings
when you push it slightly, then you need
to adjust the feet of the product. Adjust
the feet of the product as illustrated in
the installation manual supplied with the
product.
ADishwashers door must be
aligned properly otherwise
hot steam can escape!
Danger of serious burns,
other injury or may damage
furniture.

Connect the product to a grounded
outlet protected by a fuse complying
with the values in the “Technical
specifications” table. The manufacturer
shall not be liable for any damages
that will arise when the product is used
without grounding in accordance with
the local regulations.
•Connection must comply with
national regulations.
•Power cable plug must be within
easy reach after installation.
BUnplug the product after the
washing programme is over.
•The voltage and allowed fuse or
breaker protection are specified
in the “Technical specifications”
section. If the current value of the
fuse or breaker in the house is less
than 16 Amps, have a qualified
electrician install a 16 Amp fuse.
•The specified voltage must be
equal to your mains voltage.
•Do not make connections via
extension cables or multi-plugs.
BDamaged power cables
must be replaced by the
Authorised Service Agent.
BIf your dishwasher is
equipped with internal
illumination, lamp should
only be replaced by the
Authorised Service Agent
in case of failures that may
occur on the lamp.
BIf the product has a failure,
it should not be operated
unless it is repaired by the
Authorised Service Agent!
There is the risk of electric
shock!

Before starting to use the product,
make sure that all preparations
are made in accordance with the
instructions in sections “Important
safety instructions” and “Installation”.
•To prepare the product to do the
dishes, perform first operation
in the shortest programme with
detergent while the machine is
empty.
AThere might be a small
amount of water left in the
product after factory quality
control tests. This has no
harm on the product.

12 Dishwasher / User’s Manual/43 EN

4

Following information will help you use
the product in an ecological and energy-
efficient manner.
Wipe away any coarse food remnants
on the dishes before putting them in the
product.
Operate the product after filling it
completely.
When selecting a programme, consider
the table of "Programme data and
average consumption values".
Do not put more detergent than
suggested on the detergent package.
󰀬
The product is equipped with a water
softening system which reduces the
hardness of incoming water. This system
softens the supply water to a level that
will allow washing the dishes with the
required quality.
CThe mains water hardness
must be softened if it is over
7°dH. Otherwise, hardness
ions will accumulate
on the dishes that are
washed and may affect
the washing, rinsing and
drying performances of the
machine.
󰀬
󰀬
Washing performance will increase
when water softening system is adjusted
properly.

Water softening system needs to be
regenerated in order for the product
operates with the same performance
continuously. Dishwasher salt is used
for this purpose.
CUse only special softening
salts produced particularly
for the dishwashers in your
machine.
CIt is recommended to use
granule- or powder-formed
softening salts in the
water softening system.
Do not use salts that do
not completely dissolve in
water such as table salt or
rock salt. Otherwise the
performance of the system
may deteriorate in time.
CSalt reservoir will be filled
with water when you start
the product. For this reason,
add salt before operating the
machine.
1. Firstly, take the lower basket out to
add softening salt.
2. Turn the salt reservoir lid counter-
clockwise to open it (A).

Dishwasher / User’s Manual 13 / 43 EN
Preparation

You can use powder, liquid/gel or tablet
detergents in the machine.
AOnly use in the machine
the detergents produced
particularly for use
with dishwashers. We
recommend you not use
detergents that contain
chlorine and phosphate
as they are harmful for the
environment.

CPay attention to the
warnings on the detergent
packaging to get better
washing and drying results.
Contact the manufacturer
of the detergent for further
questions.
ADo not put solvents into the
detergent dispenser. There
is the risk of explosion!
Put the detergent into the detergent
dispenser just before operating the
machine as illustrated below.
1. Push the latch to right to open the
detergent dispenser lid (A).
2. Put suggested amount of powder,
liquid/gel or tablet detergent in the
reservoir.
3. Add 1 litre of water to salt reservoir
of your machine only in initial use.
4. Fill the salt reservoir with salt by
using the salt funnel (D). To speed
up dissolution rate of salt in water,
stir it with a spoon.
CYou can put about 2 kg of
softening salt into the salt
reservoir.
5. Replace the lid and tighten it when
the reservoir is full.
CYou need to add salt right
before starting the machine.
Thus, the overflowing
salty water will be flushed
immediately, preventing
the risk of corrosion in
machine. In cases where
you would not start washing
immediately, run your
machine empty in the
shortest program.
CSince different salt brands
in the market have different
particle sizes and since the
water hardness may vary,
dissolution of the salt in
water may take a couple
of hours. Therefore, Salt
Indicator remains on for a
while after adding salt into
the machine.

14 Dishwasher / User’s Manual/43 EN
Preparation
1
2
3
CUse powder or liquid/
gel detergent in short
programmes without
prewash since the solubility
of the tablet detergent
changes depending on the
temperature and time.

In addition to the conventional
tablet detergents, there are also
commercially available detergent
tablets that show water softening salt
and/or rinse aid effect. Some types
of these detergents contain special-
purpose components such as glass
and stainless steel protectors. These
tablets show their effects up to a
certain water hardness level (21°dH).
Water softening salt and rinse aid
must also be used together with the
detergent if the water hardness level is
above the mentioned level.
CInside the detergent
dispenser there are level
markings that help you
use appropriate amount of
powder detergent. When
brimful, detergent dispenser
will contain 45 cm³ of
detergent. Fill detergent up
to 15 cm³ or 25 cm³ level
marks in the detergent
dispenser according to
fullness of the machine and/
or soiling degree of the
dishes. One tablet is enough
if you are using detergent
tablets.
3. Push the lid of the detergent
dispenser to close it. A "click" will
be heard when the lid is closed.

Dishwasher / User’s Manual 15 / 43 EN
Preparation
CThe best washing
performance in dishwashers
is obtained by using
detergent, rinse aid and
water softening salt
individually.
CObserve the instructions of
the detergent manufacturer
on the package when using
tablet detergents.
CContact the detergent
manufacturer if your dishes
are wet and/or if you notice
limescale spots particularly
on your glasses after the
washing programme is
over when using a tablet
detergent.


1. Make sure that salt and rinse aid
reservoirs are full.
2. Set the water hardness to the
highest level and perform an empty
run.
3. After the empty washing cycle,
review the user manual and
readjust the water hardness level
so as to suit the water supply.
4. Make the appropriate rinse aid
settings.

CThe rinse aid used in
dishwashers is a special
combination that aims to
increase drying efficiency
and prevent water or lime
stains on the washed items.
For this reason, care must
be paid to have rinse aid in
the rinse aid reservoir and
to use rinse aids produced
specially for dishwashers
only.
1. Open the lid of the rinse aid
reservoir with the help of the latch.
2. Fill the reservoir until “MAX” level.
3. Slightly press the point (B) of the
reservoir lid to close it.

16 Dishwasher / User’s Manual/43 EN
Preparation
4. If there are stains on tableware
items after washing, level must
be increased and if there is a blue
trace after wiping them by hand, it
must be decreased. This is set to
position 3 as factory default.
CThe rinse aid adjustment is
described under "Adjusting
the amount of rinse aid" in
the section for operating the
machine.
CWipe clean any spilled
rinse aid outside the
reservoir. Rinse aid that
spilled accidentally will
cause foaming and it will
eventually decrease washing
performance.
󰀬

1. When the product is off, press
Time Delay and On/Off keys
simultaneously.
2. Press and hold it until the End
indicator starts flashing.
3. Set to the appropriate level with
the Time Delay key.
4. Press Programme Start/Pause/
Cancel key to store.
5. Press the On/Off key to exit the
setting.
If the 9-hour time delay indicator is on,
no rinse air is dispensed in the washing
programme.
If the 6-hour time delay indicator is on,
1 dose of rinse aid is dispensed.
If the 3-hour time delay indicator is on,
2 doses of rinse aid is dispensed.
If the washing indicator is on, 3 doses
of rinse aid is dispensed.
If the drying indicator is on, 4 doses of
rinse aid is dispensed.

Dishwasher / User’s Manual 17 / 43 EN
Preparation


•Never wash dishes soiled by
cigarette ash, candle remnants,
polish, dyestuff, chemicals, etc. in
your dishwasher.
•Do not wash silverware and
cutlery with wooden or bone
stems, glued pieces, or pieces that
are not resistant to heat, as well as
copper and tin-plated containers in
the dishwasher.
CDecorative prints of
chinaware as well as
aluminium and silver items
may get discoloured or
tarnished after washing in
the dishwasher just as it
happens in handwashing as
well. Some delicate glass
types and crystals may
become dull in time. We
strongly recommend you
to check if the tableware
you are going to purchase
is suitable for washing
especially in the dishwasher.


You can use your dishwasher in the
optimum way with respect to energy
consumption and washing and drying
performance only if you place the
dishes in an orderly way.
•Wipe away any coarse food
remnants (bones, seeds, etc.) on
the dishes before placing them in
the dishwasher.
•Place thin, narrow pieces in the
middle sections of baskets if
possible.
•Place the heavily soiled and bigger
items in the lower basket and
smaller, delicate and light items in
the upper basket.
•Place the hollowed dishes such as
bowls, glasses and pans upside
down in the dishwasher. Thus,
accumulation of water in deep
hollows is prevented.
ATo prevent possible injuries,
always place the sharp and
pointed dishes such as
service fork, bread knife,
etc. upside down so as their
pointed ends will face down
or they will lie horizontally in
the dish basket.
Unload dishes in the lower basket
first and then the dishes in the upper
basket.

18 Dishwasher / User’s Manual/43 EN
Preparation
Suggestions for loading the dishwasher
Lower basket
Upper basket
Improper Loading Of Dishware
Improper Loading Of Dishware
