ALIVE SMART FITNESS TRACKER
User Manual
Model: AA-01
Welcome
Come Alive with Archon Smart Fitness Tracker !
Track your activity, sleep and health index to maintain
a healthy and low stress lifestyle. Have fun in sports.
All Archon fitness tracker can synchronize wirelessly
(BT 5.0) with your mobile phone that runs Android 6.0
or above, iOS 10.0 or above.
Please visit the official website to download latest
version of product manual:
https://www.archon.com.hk
https://www.archonglobal.net
https://www.archonglobal.cn
Package includes:
1. ALIVE Fitness Tracker x 1pc
2. USB Magnetic Charger x 1pc
3. User Manual x 1pc
4. Changeable Strap x 1pc
(only in two straps packaging)
Knowing your ALIVE
Swipe from top to bottom
Swipe from bottom to top
Single Click
Return
(Single Click or Long Press)
How to wear your ALIVE
Wear the ALIVE above your wrist bone. It should be
snug but comfortable, and it should not move
while running or exercise. Do not fasten too tightly.
If you have tattoos, avoid placing the sensor right
on it.
80
14:58
26 / 9
WED
80
14:58
26 / 9
WED
1. Active your ALIVE
Before using your Alive for the first
time, please connect the magnetic
charger to activate your ALIVE. After
activation, the device start charging
your ALIVE.
1.1 Battery Charge
Attach the magnetic charger to the back of your ALIVE.
Plug the charging cable into the USB port on your
computer or a certified USB charger. The screen will
display a charging icon and it takes around 1.5 hours to
fully charge your ALIVE.
Your ALIVE will show a “Full-charged battery” icon
when you charge it for around 1.5 hours. When
disconnect ALIVE from the magnetic charger, it will
display normal clock screen.
1.2 Low Battery
When the battery level is low, your ALIVE will vibrate and
will show an icon of low battery.
If the battery level is less than 5%, your ALIVE will
display an empty battery icon to remind you to charge.
* Battery life depends on screen-on time, no. of times PPG signal for
measurement and no. of times push notifications.
2. Download Archon App
The Archon app is available for iOS in the Apple
App Store and for Android in the Google Play
Store. Please search for “Archon“ to download
and install the app or scan below QR code for
latest version of app:
3. Bluetooth Pairing
Turn on Bluetooth on your mobile and start the
Archon app.
Sign up if you are a new member or log-in with
your existing account.
If you use iOS device, grant permission of
Archon app to access Bluetooth and Notification
of your mobile device.
If you use Android device, also turn on Location
on your mobile and grant permission of Archon
app to access Location, Location Sharing and
Notification of your mobile device.
The Bluetooth icon will be shown when ALIVE is
connected to your mobile phone. If it is
disconnected, the icon will not show up.
Disconnection can be due to poor signal
reception when your mobile phone is too far
away from the tracker, or when they are blocked
by your body or when you placed your mobile
phone inside your bag or pocket.
．
．
．
．
．
4. Fitness Tracker Display
4.1 Time, Date and Battery Status
Single click to turn on the screen of your ALIVE,
and it will show the time, date and battery status.
The ALIVE has raise to awake feature that
means when you raise and turn your hand with
ALIVE by 40 – 80 degree, the screen will turn on
automatically.
4.2 Step & Active Time
It show number of steps walked or run and active
time during the day.
4.3 Distance & Calories
It show distance walked or run and calories burnt
during the day.
4.4 More Settings
It include Find Phone, Camera, Timer and device
settings (include Time Format, Unit Format,
Wrist-on, Alarm and Silent).
Note : Optical heart rate tracking will be affected if your
skin is too dark or with tattoo or improper wearing.
Dual LED Optical heart rate sensor monitor your
heart rate periodically or continuously at Multisport
mode.
After you finished Multisport tracking, all details
can be synchronized to the Archon app.
．
．
Note : The results are for reference only, not the basis for
clinical diagnosis.
ALIVE can monitor your SPO2 level that measure
the amount of oxygen in the blood.
Swipe to “SPO2” page, and tap to measure, it will
take around 20 sec to track your SPO2 level
Historical data can be viewed after synchronizing
your ALIVE with the Archon app. Compare data at
different stages to assess your health condition
．
．
．
5. Heart Rate Monitoring
6. SPO2 Monitoring
Note:
．Sit properly and keep quiet during the
measurement.
．The results are for reference only, not the
basis for clinical diagnosis.
ALIVE can track your Stress and HRV
level that monitor your physical
condition.
Swipe to “HRV” page, and tap to
measure, it will take around 1 min to
track your Stress & HRV level.
Historical data can be viewed after
synchronizing your ALIVE with the
Archon app. Compare data at different
stages to assess your physical
condition.
．
．
．
7. Stress and HRV Monitoring
Notes: During the upgrade process, please do not
quit in the midway and wait until the upgrade is
completed.
7. Stress and HRV Monitoring
There are 12 Multisport mode available for
selection. Press any exercise icon to start.
End Activity: Long press Return key to end
the activity.
During Exercise, you can swipe up or down
to see different exercise data.
All result can be synchronized and view at
the Archon app.
．
．
．
．
8. Sport mode
ALIVE support OTA upgrade through Archon
app. Go to the “Setting” > “Devices” interface of
the Archon app. If “Update Available” icon is
available, click to upgrade your Archon ALIVE.
9. Firmware Upgrade
ALIVE is not a medical device, and is not intended to diagnose,
monitor, treat, cure or prevent any disease or condition. The heart
rate readings are for reference only, and no responsibility is
accepted for the consequences of any erroneous readings.
Do not look at the heart rate sensor’s lights directly, doing so may
impair your vision.
Do not expose the strap to very wet conditions. Wet straps can
cause skin irritations. Please clean the strap by water periodically
to keep it clean and dry, do not use abrasive cleaning that may
damage the strap.
If you feel discomfort while using the ALIVE, stop using it and
removed it from your wrist.
Do not use device in the environment of too high or too low
temperature, please don’t expose the device under strong
sunshine or too wet environment. The suitable temperature for
the device and accessories is 0°C - 45°C.
Keep the ALIVE away from fire or any objects that may cause
damage or scratch.
Please do not attempt to repair, modify or disassemble the ALIVE.
Please use the magnetic charger included in the package to
charge the ALIVE.
ALIVE is water-proof design. The device can not support hot
water shower, diving, surfing, etc. It does not have waterproof
effect on corrosive liquids such as seawater, acidic and
alkaline solutions, and chemical reagents. If you
inadvertently encounter corrosive liquid, please clean with clear
water and wipe it dry. The damage caused by abuse or improper
use is not covered by the warranty
This device complies with RED Directive 2014/53/EU
．
．
．
．
．
．
．
．
．
．
10. Safety and Care
ALIVE is not a medical device, and is not intended to diagnose,
monitor, treat, cure or prevent any disease or condition. The heart
rate readings are for reference only, and no responsibility is
accepted for the consequences of any erroneous readings.
Do not look at the heart rate sensor’s lights directly, doing so may
impair your vision.
Do not expose the strap to very wet conditions. Wet straps can
cause skin irritations. Please clean the strap by water periodically
to keep it clean and dry, do not use abrasive cleaning that may
damage the strap.
If you feel discomfort while using the ALIVE, stop using it and
removed it from your wrist.
Do not use device in the environment of too high or too low
temperature, please don’t expose the device under strong
sunshine or too wet environment. The suitable temperature for
the device and accessories is 0°C - 45°C.
Keep the ALIVE away from fire or any objects that may cause
damage or scratch.
Please do not attempt to repair, modify or disassemble the ALIVE.
Please use the magnetic charger included in the package to
charge the ALIVE.
ALIVE is water-proof design. The device can not support hot
water shower, diving, surfing, etc. It does not have waterproof
effect on corrosive liquids such as seawater, acidic and
alkaline solutions, and chemical reagents. If you
inadvertently encounter corrosive liquid, please clean with clear
water and wipe it dry. The damage caused by abuse or improper
use is not covered by the warranty
This device complies with RED Directive 2014/53/EU
FCC Statement
This equipment has been tested and found to comply with the limits
for a Class B digital device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment
generates uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If
this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and
on, the user is encouraged to try to correct the interference by one or
more of the following measures:
-- Reorient or relocate the receiving antenna.
-- Increase the separation between the equipment and receiver.
-- Connect the equipment into an outlet on a circuit different from that
to which the receiver is connected.
-- Consult the dealer or an experienced radio/TV technician for help.
This device complies with part 15 of the FCC Rules. Operation is
subject to the following two conditions:
(1) This device may not cause harmful interference, and (2) this
device must accept any interference received, including interference
that may cause undesired operation.
Changes or modifications not expressly approved by the party
responsible for compliance could void the user's authority to operate
the equipment.
AA-01
Color TFT
Lithium-ion polymer
130 mAh
Around 14 days
Up to 10 days
Water-proof Level
Bluetooth 5.0
0℃to 50℃
0℃to 45℃
Optical
USB Magnetic Charger
Model
Display
Battery Type
Battery Capacity
Battery life for stand-by
Battery life for working
Water resistant
Connectivity
Storage temperature
Operation temperature
Heart Rate Sensor
Charger
11. Specifications
Original purchaser of any Archon ALIVE Fitness Tracker can obtain 1 year
warranty service from Archon or Distributor starting from the date of
purchase. Original purchaser must deliver the faulty product in its
original package or packaging with equal degree of protection together
valid invoice to address specified by Archon. Details please refer to
Archon website.
https://www.archon.com.hk
https://www.archonglobal.net
https://www.archonglobal.cn
What is not included in Limited Warranty?
Built-in batteries.
Aesthetic damage where it does
not affect the operation or safety
of the product.
Repair costs that have not been
approved.
Damage or breakdown due to
flood, wind or other severe
weather conditions.
Damage or breakdown due to fire
or any natural disaster.
The symbol on the product or its packaging indicates that this product must not
be disposed of with your other household waste. Instead, it is your responsibility
to dispose of your waste equipment by handing it over to a designated collection
point for the recycling of waste electrical and electronic equipment. The separate
collection and recycling of your waste equipment at the time of disposal will help
conserve natural resources and ensure that it is recycled in a manner that
protects human health and the environment.
For more information about where you can drop off your waste for recycling,
please contact your local authority, or where you purchased your product.
．
．
．
．
．
．
．
．
．
AA-01
Color TFT
Lithium-ion polymer
130 mAh
Around 14 days
Up to 10 days
Water-proof Level
Bluetooth 5.0
0℃to 50℃
0℃to 45℃
Optical
USB Magnetic Charger
12. Warranty
The cost of repairing or replacing
a product which fails because
anyone neglects, abuses or
misuses the product.
The cost of repairing or replacing
a product which has been
exposed to insect infestation (or
similar phenomenon) or human or
animal fluid/matter.
Software or data.
Cost of Data Recovery.
Terms of use and Disclaimer
Unless otherwise specifically and expressly stated elsewhere, Archon hereby
disclaims all warranties, including without limitation all warranties of merchantabili-
ty, fitness for a particular purpose, title and non-infringement, and any warranties
arising out of course of dealing or usage of trade, whether such warranties are
express, implied or statutory. The Archon product, content and Archon service are
provided “as is,” without warranty of any kind.
Archon shall not be liable for (1) any inaccuracy, failure of or error in the product and
software; (2) any loss or damage (including without limitation any direct, indirect,
incidental, consequential, special or exemplary damages) arising from any
download or use made of the software, or occasioned by any such inaccuracy, error
or failure of the software.
We make no warranty that the Archon product, content or Archon service will meet
your requirements or be available on an uninterrupted, secure, or error-free basis.
We make no warranty regarding the accuracy, quality, timeliness, completeness,
truthfulness or reliability of the Archon product, service or any Archon content. You
acknowledge and agree that if you rely on any Archon product, content or the Archon
service, you do so solely at your own risk.
If you are dissatisfied with any of the product, content, service or other contents of
the Archon sites or with these terms and conditions, your sole remedy is to
discontinue use of the Archon product, sites, content and service. In no event will
Archon or any third parties mentioned at the Archon sites be liable for any damages
whatsoever (including, but not limited to, incidental, exemplary, and consequential
damages, lost profits, or damages resulting from business interruption or lost data)
resulting from the use or inability to use the Archon sites and the content, whether
based on contract, warranty, tort, or any other legal theory, and whether or not
Archon is advised of the possibility of such damages.
Archon makes no representations or warranties about the accuracy, reliability,
completeness, or timeliness of the content or about the results to be obtained from
using the Archon product, service and content. Any use of the Archon product,
service and content is at your own risk. Changes may be made to Archon sites at any
time. Some content on the Archon product, service and sites may be provided by
third parties and Archon will not be held responsible for any such content provided
by third parties.
Archon does not warrant that the Archon sites will operate error-free or that the
Archon sites or their servers are free of computer viruses or other harmful goods. If
your use of the Archon sites or the content results in the need for servicing or
replacing equipment or loss of profits or data, Archon will not be responsible for
those costs.
You agree to comply with all applicable laws when using Archon product, content
and service, and you will only use them for lawful purposes.
If any provision of these terms and conditions is held to be invalid or unenforceable,
such provision shall be removed and the remaining provisions shall be enforced to
the fullest extent under law. Archon's failure to enforce any right or provision in these
terms and conditions shall not constitute a waiver of such right or provision unless
acknowledged and agreed to by Archon in writing.
Account
Full use of the Archon product, content and service requires that you register an
account and agree to provide us with a valid email address and strong password.
You are responsible for all activity that occurs in association with your account.
Archon is not liable for any loss or damages caused by your failure to maintain the
confidentiality of your account credentials.
You agree not to impersonate any person or entity or misrepresent your identity or
affiliation with any person or entity, including using another person's username,
password or other account information, or another person's name, likeness, voice,
image or photograph.
You might authorize us to send status updates to your Facebook or twitter account.
Once you direct us to share your data with a third party, that data is governed by the
third-party’s privacy policy.
Designed by:
Archon Wellness Limited
https://www.archon.com.hk or https://www.archonglobal.net or
https://www.archonglobal.cn
Version: AA-01 V1.0 Eng
Table of contents
