Arcora International ArTech PRO1.1 User manual

Dear Customers
Thank you for choosing ARCORA. We sure you want to know your new vacuum cleaner as quickly as possible and
operate it safely. Please read this user manual before using the device. To avoid accidents and damage, start with the
chapter >> Safety instructions << and always follow the instructions given here.
Table of contants
Technical details ................................................................................................................................................................................. Section 1
Operating elements ........................................................................................................................................................................... Section 2
Handling ................................................................................................................................................................................................... Section 3
Safety Instructions ............................................................................................................................................................................ Section 4

Section 1 Technical Details
The PRO1.1 vacuum cleaner can be used as a dry vacuum cleaner for cleaning large areas in offices, hotels,
restaurants, doctors' practices, shops. The vacuum cleaner can be used to clean hard floors (stone, parquet, plastic) as
well as soft floors (carpets, upholstered furniture, curtains). The vacuum cleaner is equipped with a filter system
consisting of a foam, a motor protection and an exhaust filter. Due to its surface design, the dust filter effectively
retains almost all dust particles. Through the use of electrostatic layers, a high efficiency of the motor protection filter
against pollen, mold and other microorganisms is achieved and the exhaust filter prevents the escape of carbon brush
dust. The robust and modern construction guarantees a long service life and convenient operation with low usage
costs.
Technical Details
Netzanschluss: 230V, 50 Hz
Cable: ca. 15 m
Max. Leistung: 900 W
Suction: 2700 mm H2O
Features: insulated (Class II), interference-suppressed, CE-sign

Section 1 Technical Details
crevice nozzle
brush nozzle
paper filter bags
nozzle
vacuum
cleaner
suction hose
metal plug tube
upholstery
nozzle

Section 2 Operating elements
The flexible suction hose with rotating end pieces facilitates the
operation of the accessories. The bleed valve is on the handle of
the suction hose.
With the slider of the valve you can adjust the suction power,
especially recommended for curtain cleaning.
Connect the metal tube with the handle of the suction hose and
the accessory to the pipe.
Upholstery nozzle
With the upholstery nozzle
you can dust off upholstered
furniture, mattresses, pillows,
curtains, etc.
Brush nozzle
The brush nozzle is suitable
for extracting uneven
surfaces, such as profile
strips.
Crevice nozzle
The crevice nozzle is suitable
for the suction of wrinkles,
joints and corners or niches
that you can’t reach with the
floor nozzle.

Section 2 Operating elements
Nozzle
The floor nozzle is the most commonly used element of the
accessory. It is suitable for large flat surfaces such as carpets or
floors. For vacuuming smooth
floors such as PVC, parquet or
stone, the floor nozzle is
additionally equipped with a brush.
If necessary, press your foot on the
rocker arm to extend or lower the
brush. Carpets and carpets should
be vacuumed without a brush. To
do this, push the toggle switch forwards.
Paper filter bag
The vacuum cleaner works with a paper dust bag, which has to
be changed as soon as it gets full. The cardboard reinforcement
of the bag must be inserted into the guide below the opening for
the suction hose.

Section 3 Handling
lid holder
handle
connection
opening for the
suction hose
switch
locking lever
lid
power cable
case

Section 3 Handling
Before switch on the vacuum cleaner:
Please make sure that the paper bag is correctly
inserted in the housing inlet. Do not use the vacuum
cleaner if no dust bag is inserted.
Insert the suction hose into the connection opening and
turn it slightly to the right or to the left to lock.
Insert metal pipes into each other and put them
together with the handle of the hose. Place the
necessary nozzle on the lower end of the suction pipe.
Plug the power plug into the socket.
Press the switch button to switch on the device.
After vacuum
Once cleaning is complete, turn off the power. To switch
off, tap on switch button. Disconnect the power plug from
the socket.
Wrap the cable around the case and push the connector
into the clip on the cable.
Replacing the dust bag
Turn off the vacuum cleaner and pull out the plug.
Remove the suction hose from the device.
Unlock the dust bag chamber with the cover lever,
remove the cover.
Grasp the dust bag on the cardboard reinforcement
and carefully pull it out.
Insert a new dust bag into the dust bag chamber. The
cardboard reinforement of the bag must be inserted
into the guide below the opening for the suction
hose.
Close the lid again, check before commissioning
whether all components are properly installed.

Section 3 Handling
Replacing the foam and motor protection filter.
From time to time, the foam and motor protection filters
must be changed. In the event of visible contamination, you
can clean them by rinsing in lukewarm water with a little
detergent and after complete drying, replace the cover.
Turn off the vacuum cleaner and remove the cover.
Release the three cover clips and remove the cover insert
and the foam filter
release lid clips
foam filter

Section 3 Handling
Remove the engine protection filter fromthe grid of the
bonnet.
Please place new or cleaned motor protection filter on
the grid of the bonnet.
Place the lid insert on the vacuum cleaner housing –
with the grid on the motor protection filter. Put foam
filter in the circular nest.
Attach the lid to the handle and push the housing closed
until the clamps engage.
Close the cover with the cover lever.
motor protection filter

Section 4 Saftey Instructions
Saftey Instructions
Please note that improper handling of electrical
appliances may present hazards that may not be
detected by children. Have children work with the
device only under the supervision of an adult.
Repairs to electrical appliances may only be carried
out by authorized specialists. If the power cord of this
equipment is damaged, it must be replaced by the
manufacturer or service center or a similarly qualified
person to avoid hazards. Improper repairs can result
in serious danger to the user. In case of self-made
repairs, improper connection or incorrect operation
liability and warranty claims are excluded.
The vacuum cleaner may only be used with the
paper filter dust bags and filters approved for this
machine. Only then is the perfect suction
guaranteed. Used or damaged dust bags must not
be reused.
Never leave the appliance in damp rooms after use.
Never vacuum up water or other liquids or wet dirt.
Do not vacuum glowing ashes, burning cigarettes
or sharp objects, glass splinters, plaster, cement or
stone dust with the vacuum cleaner.
Disconnect the device from the power supply when
cleaning it, change the dust bag or filter or leave it
unattended.
