Arctica HEA653 User manual

Portable Ice Maker
Instruction Manual
Model
HEA653

2
Thank you for purchasing your Arctica Ice Maker. To make full use of the
product please read this manual carefully before using the product and
keep it safe for future reference.
Safety Tips
• If you find any damage when the product is unpacked, contact your
Arctica supplier within 24 hours of receipt of goods
• Always position on a flat stable surface
• Repairs should always be carried out by a qualified technician
• Do not use with any other liquid apart from water
• ONLY USE WATER SUITABLE FOR DRINKING
• Do not use this product outside
• Always switch off and unplug the unit before cleaning
• Move by holding the product by the base
• Always store flat and do no store products on top of it
• If the power cord becomes damaged it must be replaced by a qualified
technician
• This product is not designed to be used by persons with reduced
physical or mental capabilities, lack of experience or knowledge, unless
they are given suitable supervision, this includes children.
Pack Contents
• 1 x Arctica Ice Maker
• 1 x Ice Basket
• 1x Ice Scoop
Operation
• Remove all outer and inner packaging and ensure there is an ice scoop
& basket – If not please contact your Arctica distributor.
• Clean the tank & ice basket
• Place the ice maker on a flat and level countertop out of direct sunlight
• Allow the unit to settle for 1 hour
• Remove the ice basket and fill with water to MAX line
• Press ON/OFF button to begin the ice making process
• Select the cube size by pressing the SELECT button
• Ice making cycle will last between 6 – 13 minutes

3
Cleaning & Maintenance
• Ensure the water is changed every 24 hours – If the unit is not being
used drain all the water from it using the plug on the base
• Clean the interior & exterior with warm soapy water
• Dry with a clean soft cloth
• DO NOT submerge the ice maker in water or use water sprays to clean
it
• Always clean your Arctica Ice Maker daily
• Periodically it is advised to run a full tank of water through the ice maker
with lemon juice to remove any smell that might build up
Troubleshooting
Fault
Possible Cause
Solution
Add Water indicator is on
Lack of water
Stop the ice maker, fill with
water, press ON/OFF to
restart the unit
Ice Full indicator is on
Ice basket is full
Empty the ice basket and
restart the unit
No ice being formed
Room or water temp is
too high
Pipe is blocked
Room temp should be
10-43c, water temp should
be 8-32c
Contact your Arctica
distributor
Transportation and Storage
Please handle your ice maker with care to prevent any damage to the unit and
internal parts. The ice maker should be stored somewhere which is ventilation
and non-corrosive gas.
Do not store any flammable objects near the equipment.
Technical Information
HEA653 – Arctica Ice Maker
Voltage ~230v 50/60Hz
Refrigerant : R134a/62g
Weight : 9.2 kg
Dimensions : 242 x 358 x 328mm

4
• Arctica Ice Maker is supplied with a 3 pin plug and lead with a 13 amp
fuse
• Appliance must be earthed
• If in doubt contact a qualified electrician or your Arctica distributor
Disposal
Under WEEE regulations this product must not be disposed of as household
waste. To prevent damage to the environment and humans this product must
be disposed of in an approved and environmentally friendly recycling process.
For more information on how to dispose of this correctly please contact your
Arctica distributor or local authority responsible for waste disposal.
Compliance
All Arctica parts and products have under gone a stringent testing process to
ensure that comply with all European standards and specifications.
All Arctica products carry the CE approval symbol.
