AREBOS AR-HE-SDTB User manual

User’s Manual – A REBO S Solar Shower
1
Solar shower
AR-HE-SDTB
Please follow all securit measures in this user’s manual to ensure a secure use.
Thank you for trusting
i
n AREBOS.

User’s Manual – A REBO S Solar Shower
2
List of contents
1. Safety instructions .............................. 3
1.1 Explanation of the s mbols ........................................................................................................... 3
1.2 General instructions ...................................................................................................................... 3
2. Parts list ..............................................
3. Assemble instructions ......................... 5
. Use ..................................................... 6
4.1 Initial set up of the shower ............................................................................................................ 6
.2 Notes on use ................................................................................................................................. 6
.3 After use ........................................................................................................................................ 6
4.4 Winterization ................................................................................................................................. 6
5. Technical specifications ....................... 7
6. Disposal instruction ............................ 7
6.1 Disposal of the packaging .............................................................................................................. 7
6.2 Disposal of waste equipment ........................................................................................................ 7
6.3 Meaning of the "dustbin" .............................................................................................................. 7
EU Declaration of Conformity ................. 8

User’s Manual – A REBO S Solar Shower
3
Please read and save these instructions. Read through this user’s manual carefully before using
product. Protect yourself and others by observing all safety information, warnings and cautions.
Failure to comply with instructions could result in personal injury and/or damage to product or
property. Please retain instructions for future reference.
1. Safety instructions
1.1 Explanation of the symbols
1.2 General instructions
 Chose a position for the shower where solar irradiation is a high as possible.
 Attach the shower to a concrete slab or a wooden foundation using the four threaded
sleeves, four screws and four washers.
 Do not use road salt or other antifreeze, which might damage the shower. If ou do use
antifreeze, our warrant will be void.
 Recommended water pressure: 3.5 bar
 In order to avoid scald, alwa s set the shower handle on cold water (blue) before taking a
shower.
 Children should alwa s be supervised b adults so that the do not scald themselves.
 Water temperature can reach up to 60°C at high solar irradiation. In order to avoid scald,
make sure that shower handle is alwa s set on cold water (blue) before taking a shower. That
is wh children should alwa s be supervised b adults when using the shower so that the do
not scald themselves
B mea
ns of a CE marking, it can be recognized that a product complies with the
legal requirements of European legal standards and therefore ma be traded
within the European Communit .
Caut
ion!
R
ead the safet in
structio
ns carefull . Failure t
o follow the safe
t
precautions could result in serious injur or damage. Keep the manual well!
Caution
!
Hot
surface!
Caution!
H
ot wat
er!

User’s Manual – A REBO S Solar Shower
4
2. Parts list

User’s Manual – A REBO S Solar Shower
5
3. Assemble instructions
1. Choose a location which will receive as much sunlight as possible.
2. Mount the shower base to concrete slab or wood base with four bolts and nuts. Using a
wrench is recommended (Fig. 1).
3. Attach shower head to extension pipe. Then connect extension pipe to the upper tube with
an adjust nut. Do not use a wrench (Fig. 2).
NOTE: Do not forget gaskets when connection the shower head and extension pipe.
4. Put 0-Ring on the slot of the lower tube (Fig. 3).
5. Lift upper tube on lower tube (Fig. 3).
6. Turn locking ring clockwise to securel connect upper tube to lower tube (Fig. 3).
NOTE: Handle and shower head need to face the same direction.
7. Put some teflon tape on the thread of thermometer. Then connect thermometer to shower
b hand.

User’s Manual – A REBO S Solar Shower
6
. Use
.1 Initial set up of the shower
1. Turn the handle to FULL ON HOT position.
NOTE: Filling in the water with the handle on the “full on hot” position ensures no air pockets
are trapped in shower.
2. Attach garden hose to hose connector. Turn on water suppl to the garden hose to fill the
shower. It will take 4-6 minutes to fill up the shower.
3. When water flows from shower head, turn handle off. Turning the handle off makes the
water begin to heat up in the tubes.
4. Depending on the sunlight and outside temperature, the shower will take about two hours to
full heat up water.
5. Water temperature in shower can reach up to 60°C in strong sunshine.
 WARNING: To avoid scald, pa attention to turn the handle to COOL WATER (blue) position
before using the shower. Then set to desired temperature.
.2 Notes on use
 Attention: If ou have not used the solar shower for more than 3 da s, we recommend that
ou run the water for 2 minutes before use to replace the water in the solar tank. Standing
water in a warm environment can be a centre for dangerous bacteria!
Attention: Standing water in the tank no longer corresponds to drinking water qualit !
 Caution: The water in the solar tank can become hot due to sunlight. We therefore
recommend that the cold/warm single-lever mixer tap is alwa s positioned in the middle
position (between hot and cold) at the beginning. Then it can be turned to the desired
temperature.
1. Turn the cold/warm single-lever mixer tap to the "ON" position and ou can enjo our
"solar" heated water. Note: The water suppl must be turned on for the shower to work.
2. turn off the water suppl to the shower when ou are finished.
.3 After use
 The shower does not have an aqua-stop. Accordingl , the suppl must be turned off after
use.
. Winterization
1. Turn off and disconnect garden hose.
2. Open the handle to “full on hot” position and allow water to drain from hose connector
(approximatel 8-10 minutes).
NOTE: Do not tough or turn handle while draining the water, otherwise water will stop
draining out.
3. Turn locking ring counter clockwise to unthread upper tube and lower tube.
4. Unbolt lower tube and pour remaining water out of the tube.
5. Clean and dr the shower parts.
6. Store the shower indoors in a dr place during winter season. Prevent the shower from
frostbite.
NOTE:
 Do not use salt or other anti-freezing methods.
 Recommended water pressure: 3.5 bars.

User’s Manual – A REBO S Solar Shower
7
 Always start your shower from cool to avoid injury.
 When initially using the shower please let water run for several minutes and clean the
inner parts of the shower with running water in order to get rid of plastic and oil smell.
5. Technical specifications
Model
AR
-
HE
-
SD
T
B
T
ank capacit
35 l
Max.
Water temperature
60°C
M
aterial
Plastic chromed
Size mounting pla
te
of the shower
7.09 x 5.71 in (
18 x 14
.
5 cm
)
Height
of the shower head
76.8 in (
195 cm
)
He
ig
ht of the sh
ower
8
6.6
in
(
2
20
cm
)
Diameter shower head
5.9 in (
15 cm
)
Water pressure
3
.
5 bar
Net weigth
19.90
lbs (
9
.
0
kg
)
Colour
Black
6. Disposal instruction
6.1 Disposal of the packaging
 Please make reference to the guidelines and standards for appropriate disposal of the packaging
valid in our region. In part, the package ma consist of plastic bags - watch this respect, with
special care to ensure that this is not out of the reach of children. There is a risk of suffocation!
6.2 Disposal of waste equipment
 Equipment must be disposed of in accordance with the rules and regulations of the local waste
disposal.
 At the end of the long life of our article, please dispose of the valuable raw materials for proper
disposal so that proper rec cling can take place. If ou are not sure how to proceed, the local
waste disposal companies or rec cling centers are happ to help.
6.3 Meaning of the "dustbin"
Protect our environment; electrical appliances do not belong in household waste.
Use the provided for the disposal of electrical equipment collection points and
enter our electrical and electronic equipment that ou no longer use. The help
ensure that the potential effects of incorrect disposal on the environment and
human health to be avoided. So, do our part to rec cle, rec cling and other
forms of recover of waste electrical and electronic equipment. Information on
where the devices are disposed of, please contact our local authorities or local
Governments.
Our customer service number: + 9 (0) 931- 5232700
Canbolat Vertriebs GmbH • Gneisenaustraße 10-11 • 97074 Würzburg

User’s Manual – A REBO S Solar Shower
8
EU Declaration of Conformity
We,
Canbolat Vertriebs GmbH, Gneisenaustraße 10-11, 97074 Würzburg, German ,
Hereb declare that the product named below, seen its design and construction as well as according
to our sales, has been complied with the relevant and basic health and safet EU-requirements.
Name of the product: AREBOS Solar Shower
Model Nr.: AR-HE-SDTB
Art. Nr.: 4260627426270
If the product has an modification not allowed b us, this declaration loses its validit .
Tested acc. to:
EU Standard
2001/95/EC
Date/Manufacturer Signature/Location: Würzburg, 12/11/2021
Identification of the signator :
Korhan Canbolat, head of the compan
Authorised representative for the technical documentation:
Korhan Canbolat
Office address:
Canbolat Vertriebs GmbH
Gneisenaustraße 10-11
D-97074 Würzburg
TEL: [phone]
FAX: [phone]
Email: [email protected]
Return address can be found in the imprint: https://www.arebos.de/impressum/
VAT identification number: DE 263752326
Court of the Commercial Register is Würzburg, HRB 10082
WEEE Reg.-No. DE 61617071
