Argo X3I ECO PLUS 27 HL WF Operating manual

Please read this manual carefully before installing and using the air conditioner, and retain for future reference.
V 03/23
USER and INSTALLATION MANUAL
X3I ECO PLUS
AIR CONDITIONERS
MONOSPLIT R32 WIFI
INDOOR UNIT OURDOOR UNIT
X3I ECO PLUS 27 HL WF X3I ECO PLUS 27 SH
X3I ECO PLUS 35 HL WF X3I ECO PLUS 35 SH
X3I ECO PLUS 52 HL WF X3I ECO PLUS 52 SH
X3I ECO PLUS 70 HL WF X3I ECO PLUS 70 SH

62
Contents
Information for use
The Refrigerant 65
Precautions for use 66
Description of components 70
Guide to the remote control and display
Remote control button and display icons 71
Getting to know the remote control buttons 71
Getting to know the button combination functions 76
Replacing the remote control batteries 78
WiFi Guide 79
Google Home Instruction 89
Emergency operation 96
Maintenance
Care and cleaning 97
Troubleshooting
Possible faults and solutions 98
Analysing faults and solutions 100
Installation instructions
Installation warnings 102
Choosing a location for installation 102
Electrical connection requirements 103
Installation
Indoor unit installation 104
Outdoor unit installation 108
Post-installation checks 112
Testing and operation
Functional testing 112
Appendices
Piping configuration 113
Safety operation of flammable refrigerant 113
Procedure for extending the piping 115
Warnings for the refrigeration system specialist 116
INFORMATION FOR CORRECT DISPOSAL OF THE PRODUCT IN ACCORDANCE WITH THE EUROPEAN
DIRECTIVE 2012/19/EU
At the end of its working life this equipment must not be disposed of as an household waste. It must be taken to
special local community waste collection centres or to a dealer providing this service. Disposing of electrical and
electronic equipment separately avoids possible negative effects on the environment and human health deriving
from an inappropriate disposal and enables its components to be recovered and recycled to obtain significant
savings in energy and resources. In order to underline the duty to dispose of this equipment separately, the product
is marked with a crossed-out dustbin.

63
This product is not intended for use by persons (including children) with reduced
physical, sensory or mental abilities or who do not possess adequate experience
and knowledge, unless they are supervised or instructed in the use of the product.
by a person responsible for their safety. Children must be supervised to ensure that
they do not play with the appliance. If you need to install, move or service the air
conditioner, please contact your dealer or local service center for the procedure
first. The air conditioner must be installed, moved or maintained by authorized
personnel. Failure to do so could result in serious damage, personal injury or death.
Radio equipment operating frequency band (s): 2400 MHz-2483 MHz
Maximum radio frequency power transmitted at the operating band frequencies of
the radio equipment: 20 dBm.
REQUIREMENTS FOR INSTALLATION AND MAINTENANCE PERSONNEL
All personnel who carry out installation and / or maintenance operations on
the units must be equipped with PEF (European Refrigerators License) as
required by the D.P.R. n. 146/2018 implementing Regulation (EU) no.
517/2014. If another technician is required to maintain and repair the
equipment, this will need to be supervised by the person who is qualified to
use flammable refrigerants.
The repair must be performed according to the methodology indicated by the
manufacturer of the equipment.
If you need to install, move or service the air conditioner, please contact your
dealer or local service center for the procedure first. The air conditioner must
be installed, moved or maintained by authorized personnel. Failure to do so
could result in serious damage, personal injury or death.

64
Explanation of symbols
WARNING
This symbol indicates the possibility of death or
serious injury.
CAUTION
This symbol indicates the possibility of injury or damage to
property.
NOTICE
Indicates important but not hazard
-related information, used
to indicate risk of property damage.
Indicates a hazard
generally marked with the word WARNING or
CAUTION
.
Exception Clauses
Manufacturer will bear no responsibilities when personal injury or property loss is caused by the following
reasons.
1.Damage the product due to improper use or misuse of the product;
2.Alter, change, maintain or use the product with other equipment without abiding by the instruction
manual of manufacturer;
3.After verification, the defect of product is directly caused by corrosive gas;
4.After verification, the defects are due to improper operation during transportation of product;
5.Operate, repair, maintain the unit without abiding by instruction manual or related regulations;
6.After verification, the problem or dispute is caused by the quality specification or performance of parts
and components that produced by other manufacturers;
7.The damage is caused by natural calamities, bad using environment or force majeure.

65
The Refrigerant
•To realize the function of the air conditioner unit, a special refrigerant circulates in the system. The
refrigerant is the fluoride R32 = GWP (Global warming potential). This refrigerant is flammable
and inodorous. It can lead to explosions under certain conditions, however the flammability of
this refrigerant is very low and it can be ignited only by fire.
•Compared to other common refrigerants, R32 is a non-polluting refrigerant with no harm to the
ozonosphere and a lower effect upon the greenhouse effect. R32 has very good thermodynamic
features which lead to a really high energy efficiency. The units therefore need less filling.
Warning:
Do not try to accelerate the defrosting process or to clean the appliance in different ways other than those
recommended by the manufacturer. Should repair be necessary, contact your nearest authorized
Argoclima Service Centre. Any repairs carried out by unqualified personnel may be dangerous. The
appliance has to be stored in a room that doesn’t have any continuously operating ignition sources. (for
example: open flames, an operating gas appliance or an operating electric heater.) Do not pierce or
burn.
Appliance has to be installed, operated and stored in a room with a floor area larger than X m2. (Please
refer to table "a" in section of " Safety Operation of Inflammable Refrigerant" for Space X.)
For repairs, strictly follow manufacturer’s instructions only for appliances filled with R32 flammable gas.
Be aware that refrigerants do not have any odour.
Appliance filled with flammable gas R32.
Before using the appliance, read the owner’s manual.
Before installing the appliance, read the installation manual.
Before repairing the appliance, read the service manual.

66
INFORMATION FOR USE
Precautions for use
WARNING
•This appliance can be used by children aged from 8 years and above
and persons with reduced physical, sensory or mental capabilities
or lack of experience and knowledge if they have been given
supervision or instruction concerning use of the appliance in a safe way
and understand the hazards involved.
•Children shall not play with the appliance.
•Cleaning and user maintenance shall not be made by children without
supervision.
•To prevent the risk of fire, do not connect the air conditioner to a
multifunction socket.
•Always disconnect the power before servicing or cleaning the unit.
•Do not use the appliance if the cord or plug is damaged. If the power
supply cable is damaged, it must be replaced by the manufacturer or
its technical assistance service, or in any case by a person with similar
qualifications, in order to prevent any risk.
•To prevent the risk of electric shock, do not spray water on the indoor
unit.
•Do not wash the air conditioner with water to avoid electric shocks or
malfunctions.
•After removing the filter, do not touch air flaps to avoid injury.
•Do not use fire or hair dryer to dry the filter to avoid deformation or fire
hazard.
•Installation or maintenance must be performed by qualified
professionals. Otherwise, there is a risk of damage or personal injury.
•Do not repair air conditioner by yourself. It may cause electric shock or
damage. Please contact dealer when you need to repair air conditioner.
•Do not put fingers or other objects in the air inlet/outlet grilles.
Otherwise, there is a risk of damage or personal injury.
•Do not obstruct the inlet or outlet. Otherwise, a fault may occur.

67
•Do not spill water on the remote controller, otherwise the remote
controller may be broken.
•When below phenomenon occurs, please turn off air conditioner and
disconnect power immediately, and then contact the dealer or qualified
professionals for service.
•Power cord is overheating or damaged.
•There’s abnormal sound during operation.
•Circuit breaker trips off frequently.
•Air conditioner gives off burning smell.
•Indoor unit is leaking.
•If the air conditioner operates under abnormal conditions, malfunctions,
electric shocks or fire hazards may occur.
•When turning the unit on or off using the auxiliary button, press this
switch with an insulating object made of a material other than metal.
•Do not climb or place heavy objects on the top panel of the outdoor
unit. Otherwise, you risk damage or personal injury.
Appendices
•Installation must be performed by qualified professionals. Otherwise,
you risk damage or personal injury. Electrical safety regulations must
be observed when installing the unit.
•According to the local safety regulations, use qualified power supply
circuit and circuit breaker.
•Always install the power switch. Otherwise, malfunctions may occur.
An omnipolar disconnector with contact separation of at least 3 mm in
all poles must be connected in the fixed wiring.
•Insert a power switch with sufficient power. Circuit breaker should be
included magnet buckle and heating buckle function. It can protect the
overload and circuit-short.
•Air conditioner should be properly grounded. Incorrect grounding may
cause electric shock.
•The yellow-green wire in air conditioner is grounding wire, which can't
be used for other purposes.
•Don't use unqualified power cord.

68
•Unstable power supply or incorrect wiring may result in electric shock,
fire hazard or malfunction. Please install proper power supply cables
before using the air conditioner.
•Correctly connect the phase, neutral and ground wires of the power
outlet.
•Be sure to disconnect the power supply before proceeding with any
work relating to the electrical circuit and safety.
•Do not put through the power before finishing installation.
•If the power cord is damaged, it must be replaced by the manufacturer,
its service agent or similarly qualified persons in order to avoid danger.
•The temperature of refrigerant circuit will be high, please keep the
interconnection cable away from the copper tube.
•The appliance must be installed in accordance with national wiring
regulations.
•The air conditioner is the first class electric appliance. It must be
properly grounder with specialized grounding device by a
professional. Please make sure it is always grounded effectively,
otherwise it may cause electric shock.
•The ground resistance must comply with national electrical safety
standards.
•The appliance must be positioned so that the plug is accessible.
•All wires of indoor and outdoor units must be connected by a
professional.
•If the length of power connection wire is insufficient, please contact the
supplier for a new one. Do not make extensions yourself.
•For the air conditioner with plug, the plug should be reachable after
finishing installation.
•For the air conditioner without plug, a circuit breaker must be installed
in the line.
•If you need to move the air conditioner to another location, contact
qualified personnel. Otherwise, you risk damage or personal injury.
•Choose a location out of the reach of children and away from animals
or plants. If this is not possible, install a safety fence.
•The indoor unit should be installed close to the wall.

69
•Bear in mind that the appliance is filled with flammable gas R32.
Improper handling of the device creates the risk of serious injury to
persons and damage to materials. Details of this refrigerant can be
found in the "refrigerant" chapter.
•Check that the maintenance area or room surface meets the
requirements of the identification plate.
•Use is only permitted in premises that meet the requirements indicated
on the identification plate.
•Check that the maintenance area is adequately ventilated.
•Continuous ventilation conditions must be maintained during the
operation process.
•Check that the area intended for maintenance does not present any
sources of ignition, even potential ones.
•The introduction of naked flames in the maintenance area is
prohibited, while the posting of the "no smoking" sign is mandatory.
•Check that the equipment markings are in good condition.
•Replace any unclear or damaged warning marks.
•Check for the presence of flammable gases with the appropriate
detector before unloading and opening the container.
•Do not introduce combustion sources and do not smoke.
•Comply with local laws and regulations.
•The use of the air conditioner is not allowed in rooms with an open
flame (for example, combustion sources, coal gasification systems, gas
heating systems).
•It is not allowed to drill holes or burn the connecting pipe.
•The air conditioner must be installed in a room larger than the
minimum area of the room. Check the minimum area of the room on
the identification plate or on the table a.
•At the end of the installation it is necessary to perform a leak test.
•Instructions for installing and using this product are provided by the
manufacturer.
Operating limits
Cooling mode: from -15°C to +43°C (outdoor temperature)
Heating mode: from -15°C to +24°C (outdoor temperature)

70
Description of components
Indoor unit
The display may vary from the graphic above. Please refer to the purchased product for the actual
display content and positions).
Outdoor unit
