Argom Tech T9021 User manual

0
USER MANUAL

1
Content
1 Foreword....................................................................................................................3
1.1 Acknowledgements..................................................................................... 3
1.2 Announcements............................................................................................3
1.3 Safety Tips..................................................................................................... 3
1.4 Acronym/terms............................................................................................. 4
2 Brief Description of MID Series of Products..................................................... 5
2.1 MID Overall Drawing.................................................................................... 5
2.2 MID Accessories Introduction................................................................... 6
2.3 MID Use and preparation............................................................................ 6
2.4 MID State and information..........................................................................7
3 Quick start................................................................................................................. 9
3.1 Button function............................................................................................. 9
3.2 Boot and shut down.....................................................................................9
3.3 Screen of opening and closing............................................................... 10
3.4 The use of touch screen........................................................................... 10
3.5 Page interface............................................................................................. 11
3.6 Status bar describe....................................................................................12
3.7 Use touch panel..........................................................................................12
3.8 Equipment basic settings.........................................................................13
3.9 APPS install and uninstall........................................................................17
3.10 Input text.................................................................................................... 18
4 Establish connections..........................................................................................18
4.1 USB connection..........................................................................................18
4.2 WIFI connection..........................................................................................20
4.3 3G connection.......................................................................................... 21
5 Communication......................................................................................................21
5.1 E-MAIL...........................................................................................................21
6 Multimedia...............................................................................................................22
6.1 Support the file format.............................................................................. 22
6.2 Music............................................................................................................. 23

2
6.3 Camera..........................................................................................................24
6.4 Gallery........................................................................................................... 25
6.5 HDMI.............................................................................................................. 27
7 Internet..................................................................................................................... 28
7.1 Browser........................................................................................................ 28
8 Other applications................................................................................................. 29
8.1 Alarm clock.................................................................................................. 29
8.2 Calculator..................................................................................................... 30
8.3 Explorer........................................................................................................ 30
9 Troubleshooting.................................................................................................... 32
Appendix 1 Specifications......................................................................................32
Appendix 2 The optional parts and models....................................................... 35

3
1 Foreword
1.1 Acknowledgements
Thank you for choosing our products. Product MID (Mobile Internet Device) is
a kind of mobile Internet equipment, delicate and cabinet, easy to carry.
Equipped with a high resolution 1024x600 capacitive 5- touch screen， this MID
supports high-definition videos and images, installation of multiple Office Micro
Software, entertainment and other applications.
The dazzle cruel interface can provide you new user experience.
This manual introduces the various functions, using skills and announcements.
Please read the manual carefully before using MID.
1.2 Announcements
Packing List
Please keep MID dry. Keep the equipment and battery charger away from
water, vapor and wet hand in case of short circuit, corrosion or equipment
failure.
Keep the equipment, battery and charger away from strongly impact or
vibration in case of equipment/battery/charger fault, fire or explosion.
Keep the equipment, battery and charger away from very high/low
temperature region in case of equipment/battery/charger fault, fire or
explosion.
Do not hit, throw or acupuncture product MID, and avoid dropping,
extruding and bending MID.
Keep the equipment and accessories authorized，otherwise the equipment
and accessories would not be under our company warranty scope.
1.3 Safety Tips
Before you use the MID, please read this section of information and keep your
child aware of this information. For detailed information, please refer to the
safety guidelines.
Do not use MID during driving for safety.

4
In medical sites, please follow the relevant regulations by turning off your
MID when you are in medical sites.
Please turn off your MID or turn on planes mode when you are boarding, to
avoid wireless signals jamming aircraft control signal.
Please turn off your MID near the use of high precision electronic
equipment, otherwise it may lead to electronic equipment disability.
Do not take apart your MID or accessories without authorizing. Only
authorized institutions can repair this MID.
Please keep MID away from magnetic equipment. The radiation of MID will
erase the information of the magnetic storage device.
Please don’t use MID under high temperature or in flammable areas
(example: gas station).
Please keep your MID and accessories away from children without
supervising.
Please obey the relevant laws and regulations when you use your MID, and
respect others lawful rights and privacy.
Please obey the relevant specification of this manual when you use USB
cable. Otherwise it may damage your MID or personal computer.
Please don’t use your MID in the damp environment such as bathroom etc.
keep your MID from being soaked or flushed by the liquid.
Please choose the appropriate volume, use headphones should not be too
big voice, if feel tinnitus, lower the volume or stop using it.
1.4 Acronym/terms
Acronym/terms Full name Instruction
MID Mobile Internet Device Mobile Internet terminals
WIFI Wireless Fidelity Based on the IEEE 802.11B
standard wireless LAN
TF Trans Flash Also call ：Micro SD

5
HDMI High Definition Multimedia
Interface
High-resolution multimedia
interface
2 Brief Description of MID Series of Products
2.1 MID Overall Drawing
1
2
3
456 8
7 9 10
13
11 12

6
1. Front Camera
2. Speaker
3. Charger Indicator Light
4. Home Key
5. Charger Jack
6. TF Card Slot
7. Reset Key
8. HDMI port
9. Mic
10. Micro USB port
11. Earphone Jack
12. Power Key
13. Rear Camera
2.2 MID Accessories Introduction
Packing List
Your MID packing box includes the following items
MID complete machine
Power adapter
USB cable
OTG to Host Gender
Earphone
User manual
2.3 MID Use and preparation
Battery Management and charging
BeforeusingMID,pleasechargeupthebattery.
1. Use the AC adapter to charge up your MID battery.
This tablet adopt built-in lithium polymer battery, must be choose standard
adaptor for charging.

7
(Input: AC110~240V 50/60Hz 0.3A; Output: DC5.0V/2.0A).
2. The first two times charging please keep about 6 hours, after that please
charge for 4 hours at least.
Please charge in the following conditions:
A: The battery icons shows have no power.
B: The system automatically shut down, shut down after boot soon.
C: Press operation buttons have no response.
D: The top right corner of the device shows red icons.
【Remark】
1. If you haven’t use this tablet for a long time, in order to avoid power
consumption caused damage, please charge/play the battery once a month.
2. After low battery shut down, connect DC adaptor, device will remind low
battery, charging, need to wait some time until the battery is enough power
to enter into main menu.
3. Device charging should be in standby status for each normal charging time.
With device and screen consumption, it may cause longer charging time.
2.4 MID State and information
Notice Icon
Please click column frame and slide to right on the screen to unlock notice icon.
Click the requisite view options and check the detailed information. Later you
can click the information box and slide to shut up the information windows. The
icon illustration for status bar is as follows:
New instant messaging No SD card

8
New email Uploading/downloading
Matterstobehandled Download is completed
Use USB line to
connect computer with
MID
General notice (such as:
synchronization error)
Music playing Flight mode
Data synchronization Charging
Insufficient SD
card space More
WIFI service already
connected network
unavailable
Battery charging sign
Notice panel
Notice icon implies new messages, the settled alarm clock, schedule, and SD
card inserting etc. You can open the information panel to check specific
information.
Open notice panel
When new notice icons appear in notice bar, please hold notice bar and slide
down to open notice panel.

9
3 Quick start
3.1 Button function
Key functions illustration:
Power
key
Long press this button for booting
In booting condition, long press this button pop-up shutdown
options.
In booting condition, press this button to turn off the screen
Home
key
Press this button to return to the function interface from
arbitrary interface.
Reset
button
When the tablet is crash, use the small objects to short press
RESET button, tablet will force to shut down.
Suggest don’t use the RESET button unless tablet unable to
shut down normally. Otherwise, it will easy to damage the
tablet system.
3.2 Boot and shut down
Boot
After long pressing for 2 seconds on the power button, you can see the boot
logo.
The system access into screen locking status after opening, please press the
Power On/Off button to refresh, and slide up the unlock icon on the screen.
Power off
1. Long press the power On/Off button, then "Power off" options pop up.
2. There is silent mode in device options, Power off and Cancel.
3. Click Power off.
Reset
Press the reset button to reset the device. It will clear the all data, please be
careful with the function. (Note: you can’t restart your device after the current

10
reset function, your device can only be turned off. You need to press the power
button to restart the device after reset.)
3.3 Screen of opening and closing
It will be closed during the screen idling.
◆After idling period of time, screen will be automatically closed to save the
battery.
◆When the screen is on, you can press the power button to shut down the
screen immediately.
Tip:ifyouneedtofindouthowtosetthescreen timeout please refer to
chapter 3.8.1.
Opening in screen closed condition.
When the screen is off, you can long press Power On/Off button to activate it.
Enter locked condition after opening it, press "lock" icon and slide up for
unlocking.
3.4 The use of touch screen
MID operation mode
There are several ways you can browse screen, menu and application, etc on
the MID.
Click
When you want to use the screen keyboard for input, you can choose
applications on the homepage as long as you click a project with finger.
Press
If you want to open an available option (such as the text box or web link) or

11
move shortcut and main program menu on the homepage as long as you press
the items.
Fast sliding or sliding
Fast sliding or sliding said in his fingers making rapid vertical or horizontal drag
action.
Drag
Before you start to drag, you must use your finger to press strongly on it for a
short time. When dragging it to the position you want, you can loosen your
finger.
Rotating
For most pictures, you can only turn to MID then screen will translate from
lateral direction to straight. Such as in the input text, watch movies, etc.
3.5 Page interface
The main menu screen shows all the applications. You can use the application,
set shortcuts and customize your homepage interface wallpaper, etc.
In the main interface, you can management main interface software ICONS:
long press the icons for 3 seconds, after the icons become bigger, then you
can drag anywhere in the interface and loosen your finger.
Delete icons
long press the icons for 3 seconds, drag the icons to the top of tablet PC while
the icon turns red, loosen your hand, after that you can delete icon.

12
3.6 Status bar describe
The status bar is on the bottom of the screen.
In the lower center, display main interface software, home key, files running in
the background, reduce volume, increase volume, back key, Screenshot
capture. In the upper left corner, display USB connected, USB debugging
connected, In the upper right corner, current time, Wi-Fi signal strength, and
battery charging sign etc.
3.7 Use touch panel
Device equipped with a 7 inch touch screen. Following the main touch screen
area is described and describes some of the tips for how to use the touch
screen. No matter which interface you are on the screen, can go back to
home page through pressing the soft home key on the bottom icons.

13
3.8 Equipment basic settings
Settings: Click settings icons , enter settings interface.
3.8.1 Silent mode, volume, notification, ringtone, audible selection,
screen lock sounds.
3.8.2 Application
Manage applications

14
Unknown sources: Click “Unknown Sources”, then click “OK”.
Manage application: manager and uninstall application.
Remark】: When you firmware upgrade, please close the USB connect.
How to uninstall?
1. Enter “Settings”>”Application”>”Manage application” and then
there will be installed the program list.
2. Click you want to uninstall icon, will enter the following interface.
3. Click Uninstall, then you can delete the application.
3.8.3 Privacy
Restore to factory settings
When there are great errors in your MID or you forget the passwords, you
can use Restore to factory Settings to restore them to Initial State.

15
Methods:
1. On the homepage interface, press Menu key.
2. Click Settings.
3. Click Backup & reset.
4. Click Factory data reset.
5. Wait for the system to restart.
3.8.4 Storage
Remove TF card, view of the available storage space.
【Remark】: Please touch option “delete SD card”, so that can remove SD
card safety.
3.8.5 Language & Keyboard

16
Settings: Language, text input and automatic error correction options.
Select Language: 54 kinds of national languages are available.
Remark: Android system can support 54 kinds of languages, now menu
interface just support 14 kinds of languages.
Android keyboard: Android keyboard setting
Sound on Key-press
Auto-capitalization, Gesture keyboard
Show suggestions: Display suggested words while typing.
Auto-complete: Spec bar and punctuation automatically insert highlighted
word.
3.8.6 Date & time setting
Set date, set time, select time zone and select date format.
3.8.7 USB Mode Select

17
Choose USB work pattern: OTG/HOST/SLAVE……..
3.8.8 About tablet
3.9 APPS install and uninstall
3.9.1 APPS install
This Tablet can support Android APPS in market by third party, most APPS
can install in network, can copy to NAND FLASH or SD card.
Click ESFILEEXPLORE icon. It’s available for internal memory
disk and SD card disk. Select the APPS you would like to install, click
APPS icon and select “OK”, go back to main menu, it will display the
installed app you just selected.
Remark: Some 3rd APP must install properly by memory card, downloaded
3rd party app may not install properly on device.
3.9.2 APPS uninstall
Click Settings, choose Apps, select the Apps you would like to uninstall
then click “uninstall” ----click “OK” as follows:

18
3.10 Input text
Use the screen keyboard
When you start programs or select text edit box which needs to input text or
number, the screen keyboard will appear.
There is an optional input method of keyboard below:
1. Android keyboard
2.The third party input method（The user can install any input methods
independently）
Select the input method which you want to use.
For pre-installation, Android keyboard will be displayed when you want to input
word.
1. On the homepage interface, press menu button and click "Settings".
2. Click the Language& input.
3. List all installed input methods of MID in the text setup area.
4. Tick the input method you want.
Use and switch input method
1. On the text input interface, hold text edit box area until "edit text menu"
pop ups. Then click the input method.
2. Select the input method you want.
4 Establish connections
4.1 USB connection
1. Use USB cable to connect MID with computer. Notice massage will appear

19
in Notice bar.
2. Drag up the icon in the lower left corner.
3. In the notification panel, click on the USB connected, then click Turn on
USB storage.
4. Then the USB connection will be done successfully.
4.1.1 Copy files to memory cards.
1. Use a USB cable to connect MID with computer.
After setting the store setting, connect MID with computer
successfully.
2. Open My Computer of your computer, "portable disk (x)" can be
seen.
3. Select the intended files and copy to the "portable disk (x)".
4. After copying the files, click "safe deletion hardware"icon of
your computer task bar to unload.
4.1.2 Content of MID Storage Device
1. NAND FLASH storage device, MID itself has 4G storage space for
keeping files.
2. TF removable storage card.
3. The above mentioned two storage devices can connect your
computer by using USB.
Note: When you connect the USB cable with MID, enabling the USB
