Argos SY-3388A-P-C-600 Assembly Instructions

Glass Chimney Hood
Installation & User Instructions – Please keep for future reference 489/5778
These instructions contain important information which will help you get the best from your
appliance and ensure safe and correct installation, use and maintenance.
If you need help or have damaged or missing parts, call the Customer Helpline: 0845 600 4632
Important – Please read these instructions fully before installing or using
489/5785
Issue 2 – 23/04/2010

Contents
Safety Information 2
Parts 3
Guide to Wall Mounting and fixings 4
Installation 5-9
Vent outside 5-7
Vent inside 8
Electrical Connection 9
User Instructions 10
Care and Maintenance 11
General 11
Light bulb replacement 11
Trouble Shooting 12
Technical Specifications 13
Disposal information 13
Guarantee 14
Product codes
SY-3388A-P-C-600
SY-3388A-P-C-900
1

Safet
y
Information
Im
p
ortant
–
Please read these instructions full
y
before installation
Before use Durin
g
use
The installation of this appliance is best carried out
by 2 people.
yAny installation work must be carried out by a
qualified technician or competent person.
yDispose of all packaging carefully and responsibly.
yThe appliance is designed for indoor use only
and must be protected from rain, moisture and
extreme temperature variations.
yThis appliance is designed for household use.
yDo not use the appliance for industrial and
commercial use, or any other purpose.
yDo not modify the appliance as this could result in
danger.
yWhen installing the hood, ensure that the following
recommended distances are being observed
between the cooker top and the bottom of the
cooker hood:
Electric cookers: 70 cm
Gas cookers: 70 cm
Coal/ oil cookers: 80 cm
yIf the room where the cooker hood is to be used
contains a fuel burning appliance such as a central
heating boiler, the flue must be of a sealed or
balanced flue type.
yThe edges of the cooker hood are sharp – take
care when you handle your appliance, especially
during installation and cleaning. DO NOT CLEAN
IN BEHIND THE GREASE FILTERS!
yAlways disconnect the cooker hood from the
power supply before carrying out any work on the
hood, including light bulbs replacement.
yDo not connect the ducting system of this
appliance to any existing ventilation system which
is being used for any other purpose.
yDo not install above a cooker with a high level grill.
yCarry out fumes discharging in accordance with
the regulations in force by local laws for safety and
technical restrictions.
yThis appliance is not intended for use by persons
(including children) with reduced physical, sensory
or mental capabilities, or lack of experience and
knowledge, unless they have been given
supervision or instruction concerning use of the
appliance by a person responsible for their safety.
Children should be supervised to ensure that they
do not play with the appliance.
yThis appliance is not intended for use by young
children or infirm persons unless they have been
adequately supervised by a responsible person to
ensure that they can use the appliance safely.
Young children should be supervised to ensure
that they do not play with the appliance.
yAdequate ventilation must be provided when the
cooker hood and other non-electrical powered
appliances are used at the same time.
yEnsure proper ventilation measures are being
observed when hood is in extraction mode. Note
that it removes odours from your room, not steam.
yDo not cook food over open flames or operate gas
hobs without pots or pans under the hood as the
flames may sucked into the hood causing damage.
Always put lids on pots and pans when cooking on
a gas cooker.
yNever leave frying pans or deep frying unattended
during use as overheated fats and oils might catch
fire. Dirty oil is an even greater fire risk.
yNever flambé cook under this cooker hood.
yDo not attempt to use the cooker hood if it is
damaged in any way. Never attempt to use it
without the grease filters fitted or if the filters
are excessively greasy!
yThe manufacturer refuses to accept any
responsibility for damages arising to the hood or
it’s catching on fire from failure to observe safety
advice in these instructions.
yDo not attempt to repair the appliance yourself.
Contact the Customer Helpline: 0845 600 4632.
2

Parts
Please familiarize yourself with the parts and accessories listed below
1. Control panel
2. Light
3. Chimney
4. Glass
5. Filter
Instructions x 1 Glass x 1
(Fitted on SY-3388A-P-C-600)
One-way-valve x 1 Wall Bracket x 1
Screw x 7 Wall plug x 9
(4mm x 38mm)
Flat end Screw x 4 Screw x 2
(4mm x 22mm) (4mm x 30mm)
(Fitted on SY-3388A-P-C-600)
Chimney x 1 Exhaust Pipe x 1
Plate I x 1 Plate II x 1
Screw x 8 Rubber cushion for
(4mm x 8mm) glass x 4 (Fitted on SY-
3388A-P-C-600)
Mat x 4
(Fitted on Carbon filter (not
SY-3388A-P-C-600) included, purchase
separately)
If you have damaged or missing parts,
call the Customer Helpline: 0845 600 4632
Accessories included
3

4

Installation
Vent outside
Caution: 2 people are required to unpack
and handle the appliance, it is recommended that
gloves are worn.
Caution: The wall must be strong enough
to take the weight of the hood. Wall plugs are
provided to secure the hood to most types of
walls. However, a qualified technician must verify
the suitability of the materials in accordance with
the type of wall.
Do not tile, grout or silicone the appliance to the
wall. Surface mount only.
VENT OUTSIDE
If you have an outlet to the outside, your cooker
hood can be connected by means of a given
exhaust pipe or any suitable extraction duct
(enamel, aluminum, flexible pipe or inflammable
material with an interior diameter of 150mm)
yCarefully remove all packaging materials
including the foam base, dispose of correctly.
yBefore installation, ensure that the unit is
power off and unplug from the outlet.
1. The cooker hood should be placed at distance
of 65~75cm above the cooking plane for the
best effect.
2. Drill 3 holes to accommodate the wall bracket.
Screw and tighten the wall bracket onto the
wall with the screws (4mm x 38 mm) and wall
plugs provided.
5

Installation
Vent outside
3. Drill 2 holes to accommodate plate II. Screw
and tighten the bracket onto the wall with the
screws (4mm x 38 mm) and wall plugs provided.
The distance between the wall bracket and plate
II is suggested to be maximum 90cm.
Remark: Plate II is used to fix the chimney at
the end of installation. Therefore, it is
suggested that you refer to the whole
installation procedure to locate the proper
position of the plate II. The diagram at right is
for illustration only. Fixing the chimney to
wall plate is done at the end of installation.
4.Lift up the cooker hood and hang onto the wall
bracket hook.
5. Fix the one-way-valve to the air outlet of the
cooker hood by 4 screws (4mm x 8mm).
Remark: Sponge tape sometimes covers the 4
holes. If the 4 holes are located below the
sponge tape, simply insert the screw through the
sponge tape.
Then, attach the exhaust pipe onto the one-way-
valve as shown.
6. Place the rubber cushion into the holes of the
glass. Place the glass in appropriate position on
the top the cooker hood and fix with 4 flat end
screws (4mm x 22mm). In order to avoid the
glass cracking, please do not tighten the screws
too strongly. (Not applicable to model SY-3388A-
P-C-600)
When the hood is being used in extractor function,
ensure that the ducting is fire retardant and the
bends is not greater than 90 degrees as this will
reduce the efficiency of the hood.
6
3

Vent outside
Installation
7. Adjust the height of the chimney approximately
in according to your required height. Then, install
plate I on the chimney with two screws (4mm x
8mm). The procedure is as below.
a) Put the inner chimney into outer chimney.
Then pulling out the inner chimney upwards.
Adjust the chimney height as required
approximately. Fine adjustment can be done later.
b) Install plate I on the chimney with two screws
provided (4mm x 8mm).
NOTE: Remember not to fix the screw too tight,
so that later height adjustment can be done easily.
8. Put the chimney to the cooker hood. Fine
height adjustment can now be done.
9.Fix the chimney to plate II. Two screws (4mm x
8mm) are used.
10. Fix the body with safety screw. Two screws
(4mm x 30mm) and two wall plugs are used.
10
9
7

Vent inside
Installation
If you do not have an outlet to the outside,
exhaust pipe is not required and the installation is
similar to the one shown in section “VENT
OUTSIDE”.
Activated carbon filter (purchase separately) can
be used to trap odors. Contact the helpline for
details.
Fix the one-way-valve to the air outlet of the
cooker hood by 4 screws (4mm x 8mm).
In order to install the activated carbon filter, the
cartridge filter should be detached first. Press the
lock and pull it downward.
Put the activated carbon filter into the side of the
motor and turn it in anti-clockwise direction.
Repeat the same on the other side of motor.
NOTE:
•Make sure the filter is securely locked.
Otherwise, it would loose and cause danger.
•When activated carbon filter attached, the
suction power will be lowered.
•Contact helpline 0845 600 4632 to purchase the
carbon filter.
Carbon filters not included
– available separately
8

Installation
Electrical connection
Any electrical work that is required to
install this appliance MUST be carried out by a
qualified electrician.
Warning: THIS APPLIANCE MUST BE
EARTHED
Before making any electrical connections,
ensure that:
yElectrical safety is only guaranteed when the
earth system of your house is in accordance
with the related local regulations.
yDo not damage the refrigerant circuit.
yDo not bend, stretch or pull the supply cable to
avoid electric shock.
yDo not use electrical appliances inside the food
storage compartments of the appliance, unless
they are of the type recommended by the
manufacturer.
yEnsure the power socket is suitable for the
maximum power of the machine (fuses in the
power circuit must be 13 amp).
yThe supply voltage should be the same as that
indicated in the technical specifications and the
appliance rating plate.
yThe appliance should be earthed and in
compliance with the applicable law.
yWhen installed, the power socket must be within
easy reach.
yIf the socket outlets in your home are not
suitable for the plug supplied with this unit
check with a qualified electrician for
replacement.
yThe use of adapters, multiple connectors or
extension cables are not recommended.
yThe appliance must be connected to a 220-240
volt 50Hz AC supply by means of a three pin
socket, suitably earthed and protected by a 13
amp fuse.
yShould the fuse need to be replaced, a 13 amp
fuse approved to BS1363/A must be used.
yThe plug contains a removable fuse cover that
must be refitted when the fuse is replaced. If the
fuse cover is lost or damaged, the plug must not
be used until a replacement cover has been
fitted or the plug is replaced.
yA damaged plug should be cut off as close to
the plug body as possible, the fuse should be
removed and the plug disposed of safely.
Plug replacement (UK & Ireland only)
Should you need to replace the plug; the wires in
the power cable are coloured in the following way:
Blue – Neutral ‘N’
Brown – Live ‘L’
Green & Yellow – Earth ‘E’
As the colours of the wires in the power cable
may not correspond with the coloured markings
identifying the terminals in your plug, and proceed
as follows:
The green & yellow wire must be connected to the
terminal in the plug that is marked with the letter E
or by the earth symbol.
The blue wire must be connected to the terminal
that is marked with the letter N.
The brown wire must be connected to the terminal
that is marked with the letter L.
If power supply cord is damaged, it must replaced
by the manufacturer or its service agent or a
similar qualified person in order to avoid a hazard.
9

User Instructions
Using your appliance
Switch off button
Press this button to stop the motor operation.
Low Speed button
Press this button to operate at low speed.
Medium Speed button
Press this button to operate at medium speed.
High Speed button
Press this button to operate at high speed.
Light button
Press once, two lighting lamps will illuminate. Press again will turn all lights off.
It is recommended that the cooker hood is switched on for 5 minutes prior to cooking and to leave in
operation during cooking. Leave for another 10 minutes after finish the cooking.
10

Care and Maintenance
General
Important: Always unplug the appliance from the power socket during cleaning and
maintenance.
Never use any sharp instruments or abrasive substances, soap, household cleaner, detergent or wax
polish for cleaning.
Regular Cleaning
Use a soft cloth moistened with hand-warm mildly soapy water or household cleaning detergent. Never
use metal pads, chemical, abrasive material or stiff brush to clean the unit.
Monthly Cleaning for Cartridge Filter
ESSENTIAL: Clean the filter every month can prevent any risk of fire.
The filter collects grease, smoke and dust so the filter would directly affect the efficiency of the cooker
hood. If not cleaned, the grease residue (potential flammable) will saturate on the filter. Clean it with
household cleaning detergent.
Annual Cleaning for Activated Carbon Filter
Apply SOLELY to unit that installed as a recirculation unit (not vented to the outside). The filter traps
odours and must be replaced at least once a year depending on how frequent the cooker hood used.
Warning: Failure to carry out the basic standards of the cleaning of the appliance and replacement of
the filters may cause fire risks.
Light bulb replacement
1. Switch the unit off and pull out the plug first.
2. Wait until the light bulb is cooled down before
replacement.
3. Remove the chrome rims by turning in anti-
clockwise direction.
4. Pull out the halogen light bulb carefully and
replace by same type and same rated halogen
light bulb (12V G4 base 20W MAX).
5. Assembly the chrome rims back to the unit.
11

Trouble Shooting
In the unlikely event of difficulties with your appliance please follow the trouble shooting guide below. If
the problem persists, contact the retailer if the machine is still under guarantee. If the machine is out of
guarantee, contact an approved service agent on 0845 600 4632.
Problem Possible cause Solution
The hood does not
work yPower outage
ySpeed not selected
yCheck the power supply
yPress the speed button to activate
Suction performance
not good yToo long distance between the unit and the cooking top
yImproper motor speed
yDirty filter
yReadjust the distance to 65-75cm
ySelect the speed sufficient for the
quantity of fumes presented
yClean the filter under section “Care
and Maintenance”
No light yLight bulb burnt yReplace the bulb with correct rating
12

Technical Specifications
Disposal information
Model SY-3388A-P-C-600
SY-3388A-P-C-900
Product width SY-3388A-P-C-600 – 60CM
SY-3388A-P-C-900 – 90CM
Fan speed level 3
Maximum extraction 700 m3/hr
Lamps Halogen 20W X 2
Washable grease filters 5 layers
Adjustable chimney Yes
We apologise for any inconvenience caused by any minor inconsistencies in these instructions, which may
occur as a result of product improvements and development.
This appliance complies with the following EEC directives:
2006/95/EEC Low voltage directive
2004/108/EEC EMC directive
The symbol on the product or its packaging indicates that this product may not be treated as
household waste. Instead it should be handed over to the applicable collection point for the
recycling of electrical and electronic equipment. By ensuring this product is disposed of
correctly, you will help prevent potential negative consequences for the environment and
human health, which could otherwise be caused by inappropriate waste handling of this
product. For more detailed information about recycling this product, please contact your local
council office, your household waste disposal service or the shop where the product was
purchased.
13

Guarantee
PRODUCT GUARANTEE
This product is guaranteed against manufacturing defects for a period of
Year
This product is guaranteed for twelve months from the date of original purchase.
Any defect that arises due to faulty materials or workmanship will either be replaced,
refunded or repaired free of charge where possible during this period by the dealer from
whom you purchased the unit.
The guarantee is subject to the following provisions:
yThe guarantee does not cover accidental damage, misuse, cabinet parts, knobs or
consumable items.
yThe product must be correctly installed and operated in accordance with the instructions
contained in this manual.
yIt must be used solely for domestic purpose.
yThe guarantee will be rendered invalided if the product is re-sold or has been damaged by
inexpert repair.
ySpecifications are subject to change without notice.
yThe manufacturer disclaims any liability for the incidental or consequential damages.
yThe guarantee is in addition to, and does not diminish your statutory or legal rights.
yIn the event of a problem with the product within the guarantee period call the Customer
Helpline on 0845 600 4632.
Guarantor: Home Retail Group
489 - 499 Avebury Boulevard
Central Milton Keynes
MK9 2NW
