Argox PT-90 User manual

User’s Manual
PT-90 Mobile Computer
(WinCE 6.0 version)
DOC NO. UM-P9005-01
Mar . 2010
Version 1.0
Empower the Bar Code

User’s Manual II
NOTICE: This user’s manual may be revised or withdrawn at any time without prior notice.
Copyright 2009, Argox Information Co., Ltd.
All rights reserved.
This manual may not, in whole or in part, be copied, photocopied, reproduced, translated or
converted to any electronic or machine readable form without the prior written consent of
Argox.
Limited warranty and disclaimers
By opening the package of this product you agree to become bound by the liability and
warranty conditions as described below.
Under all circumstances this manual should be read attentively before installing and or using
the product. In no event, will Argox be liable for any direct, indirect, consequential or
incidental damages arising out of use or inability to use both the hardware and software, even
if Argox has been informed about the possibility of such damages.
A serial number appears on all Argox products. This official registration number is strictly
related to the device purchased. Make sure that the serial number appearing on your Argox
device has not been removed. Servicing by our service department can only be carried out
under warranty.
All Argox products are warranted for the legal warranty period after purchase, covering
defects in material and workmanship. Argox will repair or, at its opinion, replace products that
prove to be defective in material or workmanship under proper use during the warranty period.
Argox will not be liable in case modifications are made by the customer. In such case the
standard repair charge will be applicable. The standard charge for repair will also be
applicable in case no defect is found at all. These rules also apply for products that are still
under warranty. Therefore, you are advised to have the product specifications always at hand.
Trademarks used are property of their respective owners.

User’s Manual I
Table of Contents
1. INTRODUCTION............................................................................................................. 1
1.1 ABOUT THIS MANUAL ................................................................................................ 1
1.2 USER AND PRODUCT SAFETY..................................................................................... 2
1.3 SPECIFICATIONS......................................................................................................... 4
2. GETTING STARTED...................................................................................................... 6
2.1 CHECK THE PACKAGE................................................................................................ 6
2.1.1 Compact Package............................................................................................ 6
2.1.2 Cadle & Pistol grip Package (Optional)......................................................... 7
2.2 DETAILED VIEW......................................................................................................... 8
2.2.1 PT-90 Mobile Computer.................................................................................. 8
2.2.2 Cradle ............................................................................................................. 9
2.3 INSTALLING,REPLACING AND CHARGING BATTERIES ...........................................10
2.3.1 Installing / Replacing the Battery Pack..........................................................12
2.3.2 Charging the Battery Pack with a Power Adapter.........................................12
2.3.3 Charging the Battery Pack with Cradle.........................................................13
2.4 INSTALLING IN A SYSTEM .........................................................................................14
2.4.1 Via USB /RS-232 Cable .................................................................................14
2.4.2 Via CRD-90 Cradle........................................................................................14
3. OPERATION OF THE MOBILE COMPUTER..........................................................15
3.1 KEYPAD DESCRIPTION..............................................................................................15
3.2 FUNCTION KEY DESCRIPTION ..................................................................................16
3.3 INSTALL MICRO SD CARD INTO PT-90.....................................................................17
3.4 CONFIGURING PT-90 SETTINGS ...............................................................................18
3.4.1 Calibrating Touch Screen Alignment.............................................................18
3.4.2 Adjusting Brightness ......................................................................................19
3.4.3 Muting Sound.................................................................................................19
3.4.4 Using the Stylus..............................................................................................19
3.5 ENTERING INFORMATION .........................................................................................20
3.5.1 Entering Information Using a Keypad...........................................................20
3.5.2 Entering Information Using the Keyboard Input Panel.................................20
3.5.3 Entering Data via the Bar Code Scanner.......................................................20
3.6 POWER MANAGEMENT .............................................................................................21
3.6.1 Power Status Indication .................................................................................21
3.6.2 Saving Battery Power.....................................................................................23
3.6.3 Suspend Mode ................................................................................................24
3.6.4 Resume ...........................................................................................................25
3.7 RESETTING THE PT-90..............................................................................................25
3.7.1 Performing a Warm Boot...............................................................................26
3.7.2 Performing a Cold Boot.................................................................................26
3.7.3 Performing a Clean Boot ...............................................................................26
3.8 FLASH STORAGE........................................................................................................27
3.8.1 Flash Disk Location.......................................................................................27
3.8.2 Flash Disk Size...............................................................................................27
3.9 BLUETOOTH SETTING ...............................................................................................28
3.10 WLAN SETTING........................................................................................................34
4. SCANNING......................................................................................................................35
4.1 SCAN CONFIGURATION .............................................................................................35
4.2 SCAN DRIVER.............................................................................................................36

User’s Manual II
4.3 SCAN TEST .................................................................................................................37
4.4 READING BARCODE ...................................................................................................37
4.5 BARCODE READING PROBLEMS.................................................................................38
5. UTILITIES.......................................................................................................................39
5.1 FUNCTION KEY SETTING ..........................................................................................39
5.2 TIMEOUT &BRIGHTNESS .........................................................................................40
6. SOFTWARE APPLICATIONS......................................................................................41
6.1 INTERNET EXPLORER................................................................................................41
6.2 MEDIA PLAYER .........................................................................................................41
6.3 MICROSOFT WORDPAD ............................................................................................42
6.4 REMOTE DESKTOP CONNECTION.............................................................................42
6.5 TRANSCRIBER............................................................................................................42
6.6 WINDOWS EXPLORER ...............................................................................................43
7. COMMUNICATION.......................................................................................................44
7.1 MICROSOFT ACTIVESYNC ........................................................................................44
7.2 MICROSOFT MOBILE DEVICE CENTER ....................................................................44
8. OVERVIEW OF MICROSOFT WINDOWS CE 6.0...................................................45
8.1 MAIN WINDOWS........................................................................................................45
8.2 TASKBAR....................................................................................................................47
8.3 SETTING UP THE PT-90.............................................................................................49
8.3.1 Certificates.....................................................................................................50
8.3.2 Date/Time.......................................................................................................51
8.3.3 Dialing ...........................................................................................................52
8.3.4 Display ...........................................................................................................53
8.3.5 Hot Function Key...........................................................................................54
8.3.6 Input Panel.....................................................................................................54
8.3.7 Internet Options .............................................................................................55
8.3.8 Keyboard........................................................................................................56
8.3.9 Mouse.............................................................................................................57
8.3.10 Network and Dial-up Connection ..................................................................57
8.3.11 Owner.............................................................................................................58
8.3.12 Password........................................................................................................59
8.3.13 PC Connection...............................................................................................60
8.3.14 Power.............................................................................................................61
8.3.15 Regional Settings............................................................................................61
8.3.16 Remove Programs..........................................................................................62
8.3.17 Scan Configuration ........................................................................................63
8.3.18 Storage Manager............................................................................................63
8.3.19 Stylus..............................................................................................................64
8.3.20 System.............................................................................................................65
8.3.21 System Information.........................................................................................66
8.3.22 Timeout and Brightness..................................................................................66
8.3.23 Volume and Sounds........................................................................................66
9. TROUBLE SHOOTING .................................................................................................68
9.1 GENERAL CHECKS ....................................................................................................68
9.2 READ OPERATION PROBLEMS ..................................................................................68
9.3 MOBILE COMPUTER PROBLEMS...............................................................................68
10. APPENDIX: UPDATING THE OS VIA MICRO SD CARD......................................70

User’s Manual 1
1. Introduction
Congratulations on purchasing the PT-90, a Microsoft Windows®CE Mobile Computer. Its
special combination of features makes it perfect for use in a wide range of applications. These
features as:
Microsoft Windows CE. Net operating system
Robust expansion capability
Wireless mobility via 802.11b
Long battery life
Low Power Transflective type color LCD display
Backlight keypad
1.1 About this Manual
The chapters contained in this manual are:
Chapter 1: Introduction –Presents general information about the PT-90
Chapter 2: Getting started –Describes basic use of the PT-90
Chapter 3: Operating the Mobile computer –Describes customizing the PT-90
Chapter 4: Scanning
Chapter 5: Useful Utilities
Chapter 6: Software Applications
Chapter 7: Communication –Describes using the PT-90 for different types of communication
Chapter 8: Overview of Microsoft Windows CE 6.0
Chapter 9: Troubleshooting
Chapter 10: Appendix

User’s Manual 2
1.2 User and Product Safety
Never use strong pressure on the screen or subject it to severe impact, as the LCD
panel can crack and possibly cause personal injury. If the LCD panel is broken,
never touch the liquid inside, for such contact can irritate the skin.
Although the PT-90 mobile computer meets IP65 standards for water and dust
resistance, avoid prolonged exposure to rain or other concentrated moisture.
Conditions exceeding IP65 standards could result in water or other contaminants
entering the PT-90.
Use only the approved AC Adapter with the PT-90. Use of an unapproved AC
Adapter could result in electrical problems, or even cause a fire or an electrical
shock to the user.
Be sure that only authorized suppliers are allowed to disassemble and reassemble the
device. If the device or parts are damaged due to wrong handling, the product and
parts warranty is void.
Always make back-up copies of all important data. This is easily done using a cable
or single cradle (optional) to transfer data to the computer. The manufacturer is not
liable for any data damage or data loss caused by deletion or corruption while using
this device, or due to a drained battery.
Lithium-ion battery packs may get hot, explode, ignite and/or cause serious injury if
abused. Please follow the safety warnings listed below.
Warnings:
Do not place the battery pack in fire or heat the battery.
Do not install the battery pack backwards so the polarity is reversed.
Do not carry or store battery pack together with metal objects.
Do not pierce the battery pack with nails, strike the battery pack with a
hammer, step on the battery pack or otherwise subject it to strong impacts or
shocks.
Do not solder directly onto the battery pack.
Do not expose battery pack to liquid, or allow the battery contacts to get
wet.
Do not disassemble or modify the battery pack. The battery pack contains
safety and protection devices, which, if damaged, may cause the battery
pack to generate heat, explode or ignite.
Do not discharge the battery pack using any device except for the specified
device. When it is used in devices other than the specified devices, the
battery pack can be damaged or its life expectancy reduced. If the device
causes any abnormal current to flow, it may cause the battery pack to
become hot, explode or ignite and cause serious injury.
In the event the battery pack leaks and fluid gets into the eyes, do not rub the
eyes. Rinse well with water and immediately seek medical care. If left
untreated, the battery fluid could cause eye damage.

User’s Manual 3
To avoid malfunctions and to ensure years of trouble-free operation, pay attention to the
following:
General Use
Do not expose the mobile computer to areas subject to extreme heat such as direct
sunlight, near a heater, or in a car –or in areas that are very cold, humid, moist, or
dusty.
Do not expose the product to rain or water
Do not subject the product to strong impact, or throw or drop the mobile computer
from large heights. Do not allow other mechanical shocks to the product.
Cleaning Instructions
Clean the exterior by wiping it with a soft, dry cloth. Do not use much water.
Do not use thinner, white spirit or other solvents. These can discolor the case and
the keys and it has a negative effect on the lifetime of the keys.
Cleaning the Mobile Computer
Clean the scan window periodically for better reading performance, but pay
attention to not scratching the window
Cleaning the Cradle
Avoid touching the contacts in the cradle. The contacts must stay as clean as
possible to maintain optimal charging capacity. Do not use water when cleaning
the cradle. This can cause malfunction of the chargers.
Using the Mobile Computer
Avoid temperature changes. Sudden temperature changes can cause condensation
to form on the mobile computer. Using the mobile computer while condensation is
present can cause malfunction. Always wait until the condensation clears naturally
before attempting operation.
Do not leave the mobile computer in an area where static charge is accumulated or
near devices where electromagnetic emission is generated.
Do not place any object on top of the mobile computer. Do not lay the mobile
computer face down. Doing so can cause accidental operation of the power key or
[ENT] key, which can discharge your batteries or change settings you do not want
changed.
Using the Cradle
Do not place any product other than the PT-90 mobile computer in the cradle.
Maintenance
There are no user-serviceable parts inside the mobile computer or the cradle. So do
not try to take it apart. The manufacturer will not be liable for any damage caused
by customers. In case of a malfunction that can not be solved by the trouble-
shooting instructions in this manual, please consult our service department.

User’s Manual 4
1.3 Specifications
Performance
OS
Windows Embedded CE 6.0
CPU
MARVELL PXA310 (806 MHz)
RAM
256MB RAM
ROM
256MB
Display
LCD
3.5”Color TFT LCD with touch panel
Resolution
240 x 320
Scanner
Scanner system
Laser scan engine
Readable barcode
Code 11, Code 39, Code 93, Code 128, Codabar, EAN-8, EAN-
13, Industrial 2/5, Interleaved 2/5, MSI plessey, UK plessey,
Telepen, UPC-A, UPC-E, Matrix 2/5, UPC/EAN General, IATA
2/5, TRI-OPTIC and RSS
Keypad
29 keys /29 keys plus / 44 keys with backlight
Communication Interface
Standard Interface
USB 2.0 and RS-232
Wireless radio Options
WPAN :Bluetooth Class 2, version 2.0
WLAN: 802.11b/g Wi-Fi
WWAN: EDGE /GPRS (TBD)
RFID HF: ISO 15693R/W, ISO 1443A/B R/W(TBD)
GPS: SiRF star III(TBD)
Power supply
Main power
Terminal : Rechargeable Li-ion Battery 3900mAH, 3.7Vdc
Gun type : Rechargeable Li-ion Battery 4400mAH, 3.7Vdc
Power input
Via cradle or direct charging
* Batteries must be charged at a temperature ranging from 0~+40°C (+32°F to +104°F). At
temperatures below 0°C and above +40°C display or battery performance degradation may
occur.
Expansion slot
Micro SD card

User’s Manual 5
Physical and Environmental
Operation Temperature
-10~50°C
Storage Temperature
-20~70°C
Battery Charging
Temperature
0~40°C
Humidity
Max 80% RH <= 30°C
Weight
Approx. 380 g(battery included )
Drop test
1.8 meters to concrete (Handset)
0.9 meters to concrete (Cradle)
ESD
+/-15kVDC air discharge
+/- 8kVDC direct discharge (contact)
+/- 8kVDC indirect discharge (H & V)
Sealed standard
IP65
Agency Listing
CE, FCC, BSMI, NCC, CCC, SRRC
Win-CE AP
MS Web Browser(Internet Explorer), Media Player, Microsoft
WordPad, Remote Desktop Connection, Transcriber, Windows
Explorer
Developing Tools
Argox SDK
Microsoft Visual Studio for smart device programming

User’s Manual 6
2. Getting Started
This chapter describes the PT-90 physical characteristics, how to install and charge the
batteries, how to remove and replace the strap assembly and how to start the PT-90 for the first
time.
2.1 Check the package
Carefully remove all protective material from around the PT-90 and save the shipping
container for later storage and shipping.
Depending on the configuration ordered, the PT-90 shipping container may include:
2.1.1 Compact Package
PT-90
Quick Reference Guide
Battery pack
CD -ROM
USB Sync cable
Thread
Power supply
Stylus
Hand strap
Figure 2-1 Compact Package
Battery pack
Thread
USB Sync cable
Power supply
Hand strap
Stylus
Quick Reference
Guide
CD -ROM
PT-90
