ARGtek Power King-Plus ARG-1320 User manual

ARGtek Communication Inc. www.argtek.com
E-Mail:[email protected] Tel:+ 886-2-2999-6958 Fax :+ 886-2-2999-7742

ARGtek Communication Inc. www.argtek.com
E-Mail:[email protected] Tel:+ 886-2-2999-6958 Fax :+ 886-2-2999-7742
Part I: External Installation Direction
Package Content
AP Router
1
DC 12V Power Adapter
1
Antenna
1
Paper QIG
1
Manual/QIG CD
1
Front Panel
LED
Light Status
Description
ON
Router power on.
ON
Wireless LAN is active.
Off
Wireless LAN is disabled.
Flashing
Wireless LAN is sending or receiving data.
ON
WAN is connected and active.
Off
WAN is disconnected or inactive.
Flashing
WAN port is sending or receiving data.
ON
Wired LAN port(s) is connected and active.
Off
Wired LAN port(s) is disconnected or inactive.
Flashing
Wired LAN port(s) is sending or receiving data.

ARGtek Communication Inc. www.argtek.com
E-Mail:[email protected] Tel:+ 886-2-2999-6958 Fax :+ 886-2-2999-7742
Rear Panel
Item
Description
DC-Jack
Power connector, connect to power adapter.
WAN Port
WideArea Network port, for connecting Cable Modem or ADSL
modem.
LAN Port
Local Area Network port. Connect your network devices including
computers, printers, game consoles, hubs, or switches.
USB Port
Connect your 3G USB modem.
Reset Button
Reset router to manufacture default configurations or start WPS
function.
Antenna
Connector
RP-SMA connector for connecting antenna.
Network Setup

ARGtek Communication Inc. www.argtek.com
E-Mail:[email protected] Tel:+ 886-2-2999-6958 Fax :+ 886-2-2999-7742
provides two types of Internet connection:
wireless(3G/3.5G USB modem) or wired (xDSL / cable modem) connection.
You can access internet via USB 3G/3.5G modem card, or via wired xDSL / cable modem
connection. However, only one connection can be used at the same time.
You will need to configure your network for the very first time and whenever you want to
change configurations via web interface. To make the network configurations, you have to
connect computer to one of the LAN port and open your web browser.
The AP Router is delivered with the following factory default parameters on the Ethernet LAN
interfaces.
Default IP Address: 10.10.10.254
Default IP subnet mask: 255.255.255.0
Web login User Name: admin
Web login Password: admin
The device has two operation modes (Gateway/Bridge).
The default IP addresses for the device are 10.10.10.254,
so you need to make sure the IP address of your PC is in the same subnet as the device,
such as 10.10.10.X.
It will take about 55 seconds to complete the boot up sequence after power on.
You can refer to user manual for the details of how to configure your network.

ARGtek Communication Inc. www.argtek.com
E-Mail:[email protected] Tel:+ 886-2-2999-6958 Fax :+ 886-2-2999-7742
Part II: Internal Web Management
AP Model Setup (ADSL)
1、Install the antenna & power adapter, and then connect the LAN cable with LAN port of
this equipment. Another side of cable line connects with network card of computer.
Waiting for booting around 20 seconds.
2、Open the IE ( Internet Explorer) and type 10.10.10.254 on Website to enter the setup
frame. If you can’t enter to setup frame, you can try to set the IP address for
10.10.10.XXX and try to connect again. Otherwise, please press Reset button around 10
seconds to restore AP and try to enter again
Select the Operation Mode on the left side of setup frame
1. In Operation Mode, select Gateway and press Apply

ARGtek Communication Inc. www.argtek.com
E-Mail:[email protected] Tel:+ 886-2-2999-6958 Fax :+ 886-2-2999-7742
2a. In Internet Settings / WAN /, select PPPoE (ADSL) for your WAN Connection Type and
enter your User Name & Password which were presented by your ISOP company.And
then press Apply
2b. In Internet Setting/LAN/, you may change the setting of IP address, DHCP and etc. then
press Apply
3. In Wireless Settings / Basic, you may change the setting of SSID, and then press Apply

ARGtek Communication Inc. www.argtek.com
E-Mail:[email protected] Tel:+ 886-2-2999-6958 Fax :+ 886-2-2999-7742
4. In Wireless Settings / Security, you may change the setting of password, and then press
Apply
Finish setting and press Apply, the setting will be completed after rebooting around 20
seconds.
Note: You have to connect ADSL cable with WAN port of this equipment.
==============================================================

ARGtek Communication Inc. www.argtek.com
E-Mail:[email protected] Tel:+ 886-2-2999-6958 Fax :+ 886-2-2999-7742
AP Model Setup (IP Share)
1、Install the antenna & power adapter, and then connect the LAN cable with LAN port of
this equipment. Another side of cable line connects with network card of computer.
Waiting for booting around 20 seconds.
2、Open the IE ( Internet Explorer) and type 10.10.10.254 on Website to enter the setup
frame. If you can’t enter to setup frame, you can try to set the IP address for
10.10.10.XXX and try to connect again. Otherwise, please press Reset button around 10
seconds to restore AP and try to enter again
Select the Operation Mode on the left side of setup frame
1. In Operation Mode, please select Bridge. Select AP or Main AP in Wireless Operation
Mode and press Apply

ARGtek Communication Inc. www.argtek.com
E-Mail:[email protected] Tel:+ 886-2-2999-6958 Fax :+ 886-2-2999-7742
2. In Internet Setting/LAN/, you may change the setting of IP address, DHCP and etc. then
press Apply
3. In Wireless Settings / Basic, you may change the setting of SSID, and then press Apply
4. In Wireless Settings / Security, you may change the setting of password, and then press
Apply
Finish setting and press Apply, the setting will be completed after rebooting around 20
seconds. tNote: You have to connect cable line with LAN port of this equipmen

ARGtek Communication Inc. www.argtek.com
E-Mail:[email protected] Tel:+ 886-2-2999-6958 Fax :+ 886-2-2999-7742
.
3G Model Setup (3G Network Card)
1、Install the antenna & power adapter & your 3G network card in USB port of this
equipment, and then connect the LAN cable with LAN port of this equipment. Another
side of cable line connects with network card of computer. Waiting for booting around
20 seconds.
2、Open the IE ( Internet Explorer) and type 10.10.10.254 on Website to enter the setup
frame. If you can’t enter to setup frame, you can try to set the IP address for
10.10.10.XXX and try to connect again. Otherwise, please press Reset button around 10
seconds to restore AP and try to enter again
Select the Operation Mode on the left side of setup frame
1. In Operation Mode, please select Gateway. And then press Apply

ARGtek Communication Inc. www.argtek.com
E-Mail:[email protected] Tel:+ 886-2-2999-6958 Fax :+ 886-2-2999-7742
2a. In Internet Settings / WAN /, select 3G Mode for your WAN Connection Type and choice
your USB 3G modem type. And then press Apply
2b. In Internet Setting/LAN/, you may change the setting of IP address, DHCP and etc. then
press Apply
3. In Wireless Settings / Basic, you may change the setting of SSID, and then press Apply

ARGtek Communication Inc. www.argtek.com
E-Mail:[email protected] Tel:+ 886-2-2999-6958 Fax :+ 886-2-2999-7742
4. In Wireless Settings / Security, you may change the setting of password, and then press
Apply
Finish setting and press Apply, the setting will be completed after rebooting around 20
seconds.
Note: You have to connect cable line with LAN port of this equipment.
=============================================================
