Ariens Imperial RM1028 Owner's manual

ENGLISH
FRANÇAIS
ESPAÑOL
Owner/Operator Manual
Models
927046 - RM1028
927053 - RM9028
927054 - RM9030
927055 - RM1332
927056 - RM1330
02758400A 11/99
Supercedes 02757500D
Printed in USA
Imperial
™
Rear-Engine Riders

i
ENGLISH
1. Throttle Control
2. Mower Clutch Lever
3. Parking Brake
4. Clutch Pedal
5. Brake Pedal
6. Mower Height Lever
7. Ignition Key Switch
8. Speed Indicator
9. Speed Selector
10. Engine Oil Fill
11. Fuel Tank Fill
12. Mower Pan
13. Roller
FRANÇAIS
1. Manette des gaz
2. Embrayage de l'unité de
coupe
3. Fein de stationnement
4. Pédale d'embrayage
5. Pédale de frein
6. Levier de hauteur de coupe
7. Contacteur d'allumage
8. Indicateur de vitesse
9. Sélecteur de vitesse
10. Bouchon d'huile moteur
11. Bouchon du réservoir
d'essence
12. Carter de l'unité de coupe
13. Roulette
ESPAÑOL
1. Control del acelerador
2. Palanca del embrague del
cortacésped
3. Freno de mano
4. Pedal del embrague
5. Pedal del freno
6. Palanca de la altura del
cortacésped
7. Interruptor de la llave de la
ignición
8. Indicador de la velocidad
9. Selector de la velocidad
10. Llenado de aceite del motor
11. Llenado del tanque de
combustible
12. Recolector del cortacésped
13. Rodillo
C
ONTROLS AND
F
EATURES
1
7
8
5
4
2
9
10
11
12
6
3
13
R
N
1
2
3
4
5
6
Speed
Selector
Located on
right hand
side of
driver's seat
Depress clutch pedal
and push latch to set.
P
WARNING
Figure 1
The engine exhaust from this product
contains chemicals known to the State
of California to cause cancer, birth
defects or other reproductive harm.
WARNING

GB
11/99 © Copyright 1999 Ariens Company 1
E
NGLISH
S
ECTION
1: I
NTRODUCTION
Controls and Features ............................................................................................................................i
The Manual............................................................................................................................................2
Service and Replacement Parts ............................................................................................................2
Product Registration ..............................................................................................................................2
Disclaimer..............................................................................................................................................2
S
ECTION
2: S
AFETY
Safety Alert Symbol ...............................................................................................................................3
Signal Words..........................................................................................................................................3
Practices and Laws................................................................................................................................3
Required Operator Training....................................................................................................................3
Safety Decals and Locations .................................................................................................................3
Unit, Operational, Personal, Service and Maintenance Safety Rules....................................................5
S
ECTION
3: O
PERATION
Standard Controls..................................................................................................................................8
Pre-Starting, Starting and Shut-Off........................................................................................................9
Stopping...............................................................................................................................................10
Parking.................................................................................................................................................10
Mowing Tips.........................................................................................................................................10
S
ECTION
4: G
ENERAL
M
AINTENANCE
Service Position ...................................................................................................................................11
Filling Fuel Tank...................................................................................................................................11
Engine..................................................................................................................................................11
Mower Blade........................................................................................................................................14
Battery .................................................................................................................................................14
Jump Starting.......................................................................................................................................15
Tires, Seat ...........................................................................................................................................16
General Lubrication .............................................................................................................................16
Maintenance Schedule ........................................................................................................................17
Adjustments.........................................................................................................................................17
Cleaning and Storage..........................................................................................................................20
Trouble Shooting..................................................................................................................................20
Riding Mower Specifications................................................................................................................21
Attachments and Accessories .............................................................................................................22
Warranty ............................................................................................................................................. 23
OL1800
OL1253
OL4150
OL2160
OWNER / OPERATOR MANUAL – TABLE OF CONTENTS
Model Number 927046
RM1028
Model Number 927053
RM9028
Model Number 927054
RM9030
Model Number 927055
RM1332
Model Number 927056
RM1330
R IDING M OWER M ODELS

2
Ariens
®
Riding Mower 11/99
T
HE
M
ANUAL
Before operation of unit, carefully
and completely read your manuals.
The contents will provide you with an
understanding of safety instructions
and controls during normal operation
and maintenance.
All reference to left, right, front, or rear are given from
operator standing in operation position and facing the
direction of forward travel.
S
ERVICE AND
R
EPLACEMENT
P
ARTS
When ordering replacement parts or
making service inquiries, know the
Model and Serial numbers of your unit
and engine.
Numbers are located on the product
registration form in the unit literature
package. They are printed on a serial
number label, located on the frame of
your unit (Figure 2).
• Record Unit Model and Serial numbers here.
• Record Engine Model and Serial numbers here.
P
RODUCT
R
EGISTRATION
A warranty registration card must be
filled out by the Ariens dealer, signed,
and returned at time of sale. This form
activates the warranty. The replacement
of any part on this vehicle with anything
other than an Ariens authorized replacement part may
adversely affect the performance, durability, or safety of
this unit and may void the warranty. Claims meeting
requirements during limited warranty period will be
honored. To guarantee full warranty service, make sure
your registration card has been returned to Ariens
Company.
D
ISCLAIMER
Ariens Company is hereinafter referred to as Ariens.
Ariens reserves the right to discontinue, make changes
to, and add improvements upon its products at any time
without public notice or obligation. Ariens disclaims
liability for any claims or damages, whether regarding
property, personal injury or death arising out of the use of
unauthorized replacement parts. The descriptions and
specifications contained in this manual were in effect at
printing. Equipment described within this manual may not
be identified as either standard or optional. Illustrations
may not be applicable to your unit.
Publication and Service Parts List
Order the following parts through your dealer:
OL1800
OL2160
Transfer
model & serial
number
label from
product
registration
here.
Figure 2
Serial Number
Label
OT0550
Part No. Qty. Description
02758600 1 Parts Manual
00012400 1 Service Manual
02749400 1 Battery
07216900 1 PTO Belt (Engine to 28”, 30” Decks)
07215500 1 PTO Belt (Engine to 32” Deck)
07211200 1 Transmission Belt
00300300 1 Friction Disk
02749351 1 Blade 28”
02728751 1 Blade 30”
02747051 1 Blade 32”
OL1010
SECTION 1: INTRODUCTION

11/99 Ariens
®
Riding Mower
3
E
NGLISH
S
AFETY
A
LERT
S
YMBOL
This is a safety alert symbol. It means:
• ATTENTION!
• YOUR SAFETY IS INVOLVED!
When you see this symbol:
• BECOME ALERT!
• OBEY ITS MESSAGE!
S
IGNAL
W
ORDS
The safety alert symbol is used with the signal words
DANGER, WARNING and CAUTION and colors to
alert you to safety messages.
They are used in safety decals on the unit and with
proper operation and procedures in this manual. They
alert you to the existence and relative degree of hazards.
Understand the safety message. It contains important
information about personal safety on or near the unit.
P
RACTICES AND
L
AWS
Practice usual and customary safe working precautions,
for the benefit of yourself and others. Understand and
follow all safety messages. Be alert to unsafe conditions
and the possibility of minor, moderate, or serious injury or
death. Learn applicable rules and laws in your area.
R
EQUIRED
O
PERATOR
T
RAINING
Original purchaser of this unit was instructed by the seller
on safe and proper operation. If unit is to be used by
someone other than original purchaser; loaned, rented or
sold, ALWAYS provide this manual and any needed
safety training before operation.
S
AFETY
D
ECALS AND
L
OCATIONS
ALWAYS replace missing or damaged Safety Decals.
Refer to Figure 3 for Safety Decal locations.
1. WARNING
A. Be sure speed selector is in
Neutral (N) and Mower Clutch is
disengaged ( ) before starting
engine ( ).
2. DANGER
A. Always keep feet and hands away from rotating
parts.
B. Always stand clear of discharge area.
C. Keep people away from unit while operating.
D. Shut off engine, remove key, read manual before
you unplug, adjust or repair unit.
E. NO STEP! Always keep feet away from rotating
parts.
3. WARNING
A. Attention! Your safety is involved!
B. Always stand clear of discharge area.
C. Do not operate mower unless guards are in
operating position or bagger is attached.
DANGER
IMMINENTLY HAZARDOUS SITUATION! If not
avoided, WILL RESULT in death or serious injury.
WARNING
POTENTIALLY HAZARDOUS SITUATION! If not
avoided, COULD RESULT in death or serious injury.
CAUTION
POTENTIALLY HAZARDOUS SITUATION! If not
avoided, MAY RESULT in minor or moderate injury. It
may also be used to alert against unsafe practices.
OL1253
OA0031
Depress clutch pedal
and push latch to set.
P
WARNING
DANGER/DANGER/PELIGRO
DANGER/DANGER/PELIGRO
Figure 3
1
2
3
4
2
WARNING
DANGER/DANGER/PELIGRO
AB C D
E
ABC
SECTION 2: SAFETY
