Hydra DI - Operation & Maintenance Manual
High Capacity Deionization System
For Model: HY-122B-DI-HC

M-0221201114
Revision 3
Page 2of 4
TECHNICAL SPECIFICATIONS:
Pressure Range: 10-100 psi
Temperature Range: 40 - 100 °F
Maximum Flowrate: 1.25 Gallons per minute
Resistivity Output 50 KOhm to 200 KOhm
Resistivity DI Light Set Point: 20 KOhm
Voltage 120 VAC
SYSTEM DIMENSIONS
INSTALLATION
1. Install system on a wall that will support 55 lbs, within 5 feet of a water supply.
2. Connection to water supply should include a shut off valve before the Hydra-DI system.
3. Use your choice of inlet fitting provided with the system to connect the tubing to the water supply valve.
Attach the other end of the tubing to the OUTLET fitting of the DI system. NOTE: You may need to cut
the tubing in ½.
4. Install quality monitor in horizontal end of gray tee fitting.
5. Install the outlet assembly to the vertical end of the tee. This fitting should have several wraps of white
Teflon tape.
START UP
1. Before installing the deionization bed cartridges and carbon cartridge, make sure the sealing gaskets are in
place.
2. Remove the blue housing bowls and place the 10” carbon cartridge in the 10” housing. Place the 20”
deionization cartridges in the (2) 20” housings.
3. Fasten blue bowls back in place, HAND TIGHT.
4. Plug in the quality monitor. The light will be green.
5. Open the inlet water supply valve to allow water to enter the system.
6. Starting on the left, press each of the red pressure relief buttons at the top of the filter housing to expel
trapped air. Release the button once water trickles out. Repeat for housings #2 and #3.
7. Open the system outlet valve and drain approximately 1 gallon of water.
8. At this point, the quality indicator monitor should have a green light indicating the system is ready for use.

M-0221201114
Revision 3
Page 3of 4
9. If the quality indicator light is red, press the red pressure relief button to check that all the air has been
purged from the system. Then open the outlet valve and let water run out until the indicator light turns
green.
OPERATION
1. Turn off the water feed supply when the system is not in use.
2. When the system is not active, the quality light may turn red. This is normal condition. As you draw
water from the system, the light will turn green again.
3. If the light remains red in a flowing condition, this is an indication that the deionization cartridges are
exhausted and need to be replaced.
4. NOTE: Feedwater mineral content (total dissolved solids) and chemistry have a direct impact on the
life of the cartridge. For TDS above 500 ppm, please contact Aries Filterworks for additional
pretreatment options.
CARTRIDGE REPLACEMENT
1. Turn off the inlet water feed supply.
2. Depressurize the system by pushing the red pressure relief button on the top of the filter housing
3. Place a container under the filter housing to collect and excess water.
4. Unscrew the filter bowl housing. The included spanner wrench may be needed.
5. Remove the old cartridges and discard
6. Inspect the o-rings and add lubrication if needed.
7. Install the cartridges per the START UP procedure
REPLACEMENT PARTS
HYK-010 Cartridge Kit, Hydra High Purity Deionization System (4-1/2” Diameter)
Includes 10-inch Carbon Prefilter & (2) 20-inch High Capacity DI cartridges
TROUBLESHOOTING
Problem Cause Solution
DI light Red No Flow During a non-flow condition, the DI light may turn from green
to red. Verify that flow is going across the DI light sensor.
Air Trapped Make sure sensor is installed in horizontal run of Tee fitting.
Ensure system has been properly vented per instructions.
Exhausted Cartridges Replace cartridges as described in earlier section.
High flowrate Reduce the flowrate to the specified range. Higher flowrates
will diminish the performance of the deionization resins.
Cartridge improperly Make sure all old cartridge gaskets are removed. The primary
installed sealing surface is on the top gasket. Improper installation will
cause bypass and compromise water quality.

M-0221201114
Revision 3
Page 4of 4
Short Cartridge Life High mineral feed Check feedwater supply to determine total dissolved solids
(TDS) level. Elevated levels due to changes in supply or
seasonal changes may reduce cartridge life. Contact Aries
Filterworks for other pretreatment options.
CUSTOMER SERVICE
Aries Filterworks technical and customer service are available 9:00 AM to 5:00 PM EST.
Phone: [phone]
E-mail: [e-mail]
WARRANTY
Systems and options have a one-year limited warranty from the date of purchase. If determined that a failure was
due to defects in materials or workmanship, a repair or replacement will be made without charge. Aries Filterworks /
ResinTech, Inc. assume no other responsibility or liability.
This warranty does not cover any product which has been subject to misuse, neglect, accident or used in violation of
operating instructions nor does it extend to any units altered or repaired for warranty defects by anyone other than
Aries Filterworks.
IN NO EVENT SHALL ARIES / RESINTECH, INC. BE LIABLE FOR ANY INCIDENTAL,CONSEQUENTIAL,
SPECIAL, INDIRECT, PUNITIVE OR EXEMPLARY DAMAGES OR LOST PROFITS FROM ANY BREACH
OF THIS WARRANTY OR OTHERWISE.
Aries Filterworks / ResinTech, Inc., reserves the right to make changes in design, specifications and prices without
notice.
