A/23 MFFI - A/27 MFFI
G.C.N. 47-116-18 / 47-116-19
Installation Instructions
Type C Boilers
LEAVETHESE INSTRUCTIONS
WITHTHE END USER
Country of destination: GB

Supplied By www.heating spares.co Tel. [phone]
2
TABLE OF CONTENTS 1. GENERAL INFORMATION
1.1 General Instructions
1.3 Overall View
2. INSTALLATION
2.1 Reference Standards
2.2 Siting the Appliance
2.3 Overall Dimensions
2.4 Clearances
2.5 Mounting the Appliance
2.6 Electrical Connection
2.7 Gas Connection
2.8 Water Connections
2.9 Flue Connection
2.10 Room Thermostat Connection
2.11 Electrical/System Diagrams
2.12 Water Circuit Diagrams
3. COMMISSIONING
3.1 Initial Preparation
3.2 Removing the Front Panel
3.3 Control Panel
3.4 Initial Start-up
3.5 Operational Adjustments
3.6 Combustion Analysis
3.7 Fume Discharge Monitoring
3.8 Boiler Safety Systems
3.9 Draining the System
4. GAS ADJUSTMENTS
Gas Adjustment Table
4.1 Changing the Type of Gas
5. MAINTENANCE
6. MISCELLANEOUS
6.1 Wiring Diagram for Two Heating Zones
6.2 Wiring Diagram for Connection to Ariston
Unvented Cylinderl
7 TECHNICAL INFORMATION

Supplied By www.heating spares.co Tel. [phone]
3
This manual is an integral and essential part of the product. It should be kept with the
appliance so that it can be consulted by the user and our authorised personnel.
Please carefully read the instructions and notices about the unit contained in this manu-
al, as they provide important information regarding the safe installation, use and mainte-
nance of the product.
For operating instructions please consult the separate User’s Manual.
Read the instructions and recommendations in these Installation Instructions carefully to
ensure proper installation, use and maintenance of the appliance.
Keep this manual in a safe place. You may need it for your own reference while our
Servicing Centre technicians or your installer may need to consult it in the future.
This is a combined appliance for the production of central heating (C.H.) and domestic
hot water (D.H.W.).
This appliance must be used only for the purpose for which it is designed.
The manufacturer declines all liability for damage caused by improper or negligent use.
No asbestos or other hazardous materials have been used in the fabrication of this prod-
uct.
Before connecting the appliance, check that the information shown on the data plate
and the table on pages 4-5 comply with the electric, water and gas mains of the property.
You will find the data plate on the reverse of the control panel.
The gas with which this appliance operates is also shown on the label at the bottom of
the boiler.
Do not install this appliance in a damp environment or close to equipment which spray
water or other liquids.
Do not place objects on the appliance.
Do not allow children or inexperienced persons to use the appliance without supervi-
sion.
If you smell gas in the room, do not turn on light switches, use the telephone or any
other object which might cause sparks.
Open doors and windows immediately to ventilate the room.
Shut the gas mains tap (on the gas meter) or the valve of the gas cylinder and call your
Gas Supplier immediately.
If you are going away for a long period of time, remember to shut the mains gas tap or
the gas cylinder valve.
Always disconnect the appliance either by unplugging it from the mains or turning off
the mains switch before cleaning the appliance or carrying out maintenance.
In the case of faults or failure, switch off the appliance and turn off the gas tap. Do not
tamper with the appliance.
For repairs, call your local Authorised Servicing Centre and request the use of original
spare parts.For in-guarantee repairs contact MTS (GB) Limited.
Check the following at least once a year:
1- Check the seal of water connections, replacing the gaskets if necessary.
2- Check the seal of the gas connections, replacing the gaskets if necessary.
3- Check the general condition of the appliance and of the combustion chamber visu-
ally.
4 - Visual check of the combustion:clean burners if necessary.
5- With reference to point 3, dismantle and clean the combustion chamber if neces-
sary.
6 - With reference to point 4, dismantle and clean the injectors if necessary.
7- Visual check of the primary heat exchanger:
- check for overheating of the exchangers fins;
- clean the exhaust side of the exchanger and fan if necessary.
1. GENERAL
INFORMATION
Users
Manual
A/23 MFFI
A/27 MFFI
1.1 General Instructions

Supplied By www.heating spares.co Tel. [phone]
4
A/23 MFFI - A/27 MFFI
Fig. 1.1
1.2 Overall View
8- Regulate the gas pressure, ignition pressure, partial flame, maximum flame.
9- Check proper operation of the heating safety system:
- maximum safety temperature;
- maximum safety pressure.
10 - Check the proper operation of the gas safety system:
- gas or flame safety device;
- gas valve safety device.
11 - Check that the electrical connections have been made in compliance with the
instructions shown in the installation instructions.
12 - Check the efficiency of the hot water supply (flow and temperature).
13 - Check general operation of the appliance.
14 - Check the exhaust system for the combustion products.
Legend:
1. Flue Connector
2. Combustion Chamber Hood
3. Main Heat Exchanger
4. Combustion Chamber Insulation Panel
5. Burner
6. Expansion Vessel
7. Overheat Thermostat
8. Spark Generator
9. Diverter Valve
10. Main Circuit Temperature Probe
11. Main Circuit Flow Switch
12. Diverter Valve Microswitch
13. Filter Seat
14. Drain Valve
15. Secondary Heat Exchanger
16. Safety Valve (3 bar)
17. Circulation Pump with Automatic Air Release Valve
18. Gas Valve
19. Detection Electrodes
20. Ignition Electrodes
21. Fan
22. Venturi
23. Air Pressure Switch

Supplied By www.heating spares.co Tel. [phone]
5
The technical information and instructions provided herein below are intended for the
installer so that the unit may be installed correctly and safely.
The installation and initial start up of the boiler must be by a CORGI Approved Installer
in compliance with the installation standards currently in effect, as well as with any and
all local health and safety standards i.e. CORGI .
This appliance must be installed by a competent installer in accordance with the
1984 Gas Safety (installation & use) Regulations (as amended)
The installation of this appliance must be in accordance with the relevant requirements
of the 1984 Gas Safety (installation & use) Regulations, the Local Building Regulations,
the current I.E.E. Wiring Regulations, the byelaws of the local water authority, and in
Scotland, in accordance with the Building Standards (Scotland) Regulation and Health
and Safety document No.635 “Electricity at work regs.1989”.
Installation should also comply with the following British Standard Codes of Practice:
The appliance may be installed in any room or indoor area, although particular attention
is drawn to the requirements of the current I.E.E. Wiring Regulations, and in Scotland,
the electrical provisions of the Building Regulations applicable in Scotland, with respect
to the installation of the combined appliance in a room containing a bath or shower.
Where a room-sealed appliance is installed in a room containing a bath or shower
the boiler and any electrical switch or appliance control, utilising mains electricity
should be situated so that it cannot be touched by a person using the bath or
shower.
The location must permit adequate space for servicing and air circulation around the
appliance as indicated in paragraph 2.4.
The location must permit the provision of an adequate flue and termination.
For unusual locations special procedures may be necessary.
BS 6798-1987 gives detailed guidance on this aspect.
A compartment used to enclose the appliance must be designed specifically for this pur-
pose. No specific ventilation requirements are needed for an installation within a cup-
board
This appliance is not suitable for outdoor installation.
The type C appliances (in which the combustion circuit, air vent intake and com-
bustion chamber are air-tight with respect to the room in which the appliance is
installed) can be installed in any type of room.
There are no limitations with respect to ventilation and the volume of the room itself.The
boiler must be installed on a solid, permanent wall to prevent access to the electrical
parts (when live) through the aperture on the back frame.
2.1 Reference Standards
Low pressure
pipes BS 6891 1988
Boilers of rated input
not exceeding 60 kW BS 6798 1987
Forced circulation hot
water system BS 5449 1990
Installation of gas hot water
supplies for domestic purposes
( 2nd family gases) BS 5546 1990
Flues BS 5440-1 1990
Air supply BS 5440-2 1989
2. INSTALLATION
2.2 Siting the Appliance

Supplied By www.heating spares.co Tel. [phone]
6
Legend:
A = Central Heating Flow (3/4”)
B = Domestic Hot Water Outlet (1/2”)
C = Gas Inlet (3/4”)
D = Domestic Cold Water Inlet (1/2”)
E = Central Heating Return (3/4”)
2.3 Overall Dimensions
890
365
(A-B-D-E)
(C)
465
Fig. 2.1
In order to allow for access to the interior of the boiler for maintenance purposes, the
boiler must be installed in compliance with the minimum clearances indicated in the dia-
gram below.
2.4 Clearances
400
300
450
60 60
40 50 60 70 80
C C
A/23 MFFI - A/27 MFFI
Fig. 2.2

Supplied By www.heating spares.co Tel. [phone]
7
Fasten the boiler in place using the template and anchors supplied with the
unit. It is highly recommended that a spirit level be used to position the boiler so
that it is perfectly level.
For additional information, please consult the instructions contained in the con-
nection kit and the flue kit.
For safety purposes, have a competent person carefully check the electrical
system in the property, as the manufacturer will not be held liable for damage
caused by the failure to earth the appliance properly or by anomalies in the
supply of power. Make sure that the residential electrical system is adequate for
the maximum power absorbed by the unit, which is indicated on the rating plate.
In addition, check that the section of cabling is appropriate for the power
absorbed by the boiler.
The boiler operates with alternating current, as indicated in the technical data
table (1.2), where the maximum absorbed power is also indicated. Make sure
that the connections for the neutral and live wires correspond to the indications
in the diagram.The appliance electrical connections are situated on the reverse
of the control panel (see the servicing manual for further information)
2.5 Mounting the Appliance
2.6 Electrical Connection
Important!
In the event that the power supply cord must be changed, replace it with one
with the same specifications. Make the connections to the terminal board locat-
ed within the control panel, as follows:
- The yellow-green wire should be connected to the terminal marked with the
earth symbol; make sure to re-use the ferrule mounted on the other supply
cord;
- The blue wire should be connected to the terminal marked “N”;
- The brown wire should be connected to the terminal marked “L”.
Note:The diagrams for the electrical system are indicated in section 2.11.
Warning, this appliance must be earthed.
External wiring to the appliance must be carried out by a qualified technician
and be in accordance with the current I.E.E. Regulations and applicable local
regulations. The EuroCombi range of boilers are supplied for connection to a
230 V~ 50 Hz supply.
The supply must be fused at 3 A.
The method of connection to the electricity supply must facilitate complete elec-
trical isolation of the appliance, by the use of a fused double pole isolator hav-
ing a contact separation of at least 3 mm in all poles or alternatively, by means
of a 3 A fused three pin plug and unswitched shuttered socket outlet both
complying with BS 1363.
The point of connection to the electricity supply must be readily accessible and
adjacent to the appliance unless the appliance is installed in a bathroom when
this must be sited outside the bathroom.
2.7 Gas Connection The local gas region contractor connects the gas meter to the service pipe.
If the gas supply for the boiler serves other appliances ensure that an adequate
supply is available both to the boiler and the other appliances when they are in
use at the same time.
Pipe work must be of an adequate size. Pipes of a smaller size than the boiler
inlet connection should not be used.
Fig. 2.3

Supplied By www.heating spares.co Tel. [phone]
8
Legend
A = Central Heating Flow
B = Domestic Hot Water Outlet
C = Gas Inlet
D = Domestic Cold Water Inlet
E = Central Heating Return
I = Safety Valve
Central Heating
Detailed recommendations are given in BS 6798:1987 and BS 5449-1:1990,
the following notes are given for general guidance.
Pipe Work:
Copper tubing to BS EN 1057:1996 is recommended for water pipes. Jointing
should be either with capillary soldered or compression fittings.
Where possible pipes should have a gradient to ensure air is carried naturally
to air release points and water flows naturally to drain taps.
The appliance has a built-in automatic air release valve, however it should be
ensured as far as possible that the appliance heat exchanger is not a natural
collecting point for air.
Except where providing useful heat, pipes should be insulated to prevent heat
loss and avoid freezing.
Particular attention should be paid to pipes passing through ventilated spaces
in roofs and under floors.
By-pass:
The appliance includes an automatic by-pass valve, which protects the main
heat exchanger in case of reduced or interrupted water circulation through
the heating system, due to the closing of thermostatic valves or cock-type
valves within the system.
System Design:
This boiler is suitable only for sealed systems.
Drain Cocks:
These must be located in accessible positions to permit the draining of the
whole system.The taps must be at least 15mm nominal size and
manufactured in accordance with BS 2870:1980.
Safety Valve Discharge:
The discharge should terminate facing downwards on the exterior of the
building in a position where discharging (possibly boiling water & steam) will
not create danger or nuisance, but in an easily visible position, and not cause
damage to electrical components and wiring.
The discharge must not be over an entrance or a window or any other type of
2.9 Water Connections
A
C
B D E
I
A/23 MFFI - A/27 MFFI
Fig. 2.4

Supplied By www.heating spares.co Tel. [phone]
9
public access.
Air Release Points:
These must be fitted at all high points where air naturally collects and must
be sited to facilitate complete filling of the system.
The appliance has an integral sealed expansion vessel to accommodate the
increase of water value when the system is heated.
It can accept up to 7 l (1.5 gal) of expansion water.If the heating circuit has
an unusually high water content, calculate the total expansion and add an
additional sealed expansion vessel with adequate capacity.
Mains Water Feed - Central Heating:
There must be no direct connection to the mains water supply even through a
non-return valve, without the approval of the Local Water Authority.
Filling:
A temporary method for initially filling the system and replacing lost water
during servicing in accordance with Water Supply Byelaw 14 must be
provided.
Domestic Water
The domestic water must be in accordance with the relevant recommendation
of BS 5546:1990. Copper tubing to BS EN 1057:1996 is recommended for
water carrying pipe work and must be used for pipe work carrying drinking
water.
2.9 Flue Connections Flue System
The provision for satisfactory flue termination must be made as described
in BS 5440-1.
The appliance must be installed so that the flue terminal is exposed to outdoor air.
The terminal must not discharge into another room or space such as an out-
house or lean-to.
It is important that the position of the terminal allows a free passage of air
across it at all times.
The terminal should be located with due regard for the damage or discoloura-
tion that might occur on buildings in the vicinity.
In cold or humid weather water vapour may condense on leaving the flue termi-
nal.
The effect of such "steaming" must be considered.
If the terminal is less than 2 metres above a balcony, above ground or above a
flat roof to which people have access, then a suitable terminal guard must be
fitted.When ordering a terminal guard, quote the appliance model number.
A suitable terminal guard is available from:
TOWER FLUE COMPONENTS
Morley Road
Tonbridge
KentTN9 1RA
The minimum acceptable spacing from the terminal to obstructions and ventila-
tion openings are specified in Fig. 2.5.
Residual Head of the Boiler

Supplied By www.heating spares.co Tel. [phone]
10
TERMINAL POSITION mm
A - Directly below an open window or other opening 300
B - Below gutters, solid pipes or drain pipes 75
C - Below eaves 200
D - Below balconies or car-port roof 200
E - From vertical drain pipes and soil pipes 75
F - From internal or external corners 300
G - Above ground or below balcony level 300
H - From a surface facing a terminal 600
I - From a terminal facing a terminal 1200
J - From an opening in the car port
( e.g.door, window ) into dwelling 1200
K - Vertically from a terminal in the same wall 1500
L - Horizontally from a terminal in the same wall 300
A
BC
D
E
F
G
J
K
HI
L
GF
Fig. 2.5
Ø60/100 mm
The boiler is designed to be connected to a coaxial flue discharge system.
A
Ø80 mm
Ø80 mm
In addition, it is also possible to use a twin-pipe (split) system by fitting a special
adaptor to the flue discharge collar and using one of the apertures for the air
vent intake located on the top part of the combustion chamber (A).
A
A
Fig. 2.7
Fig. 2.6

Supplied By www.heating spares.co Tel. [phone]
11
This procedure must be done as follows:
1- Remove the air vent intake you want to use, in the area indicated in
Fig. 2.8, by breaking the perforated ring.
2 - Use a tool to grasp the lid and remove it completely.
3 - Clean any burrs or sharp edges with a knife or an appropriate tool.
In Fig. 2.10 below, several different types of flue systems are shown.
For additional information regarding the flue accessories, please consult the
Flue Pipe Accessories manual.
A
Fig. 2.8 Fig. 2.9
Fig. 2.10

Supplied By www.heating spares.co Tel. [phone]
12
In calculating the lengths of the pipes, the maximum length must also take into
consideration the values for the exhaust/air intake end terminals, as well as 90°
elbows for coaxial systems.
The C52 types must comply with the following requirements:
1. The discharge/intake vent pipes must have the same diameter of ø80 mm.
2. If an elbow is inserted into the discharge/ventilation system, the calculation
of the overall extension must take into consideration the values for each
curve, as indicated in the table.
3. The exhaust pipe must extend at least 0.5 m above the ridge of the roof if it is
located on a side other than that for the air intake (this is not obligatory if
the exhaust and air intake pipes are located on the same side of the build-
ing).
(*) L = Length of Piping
C12 (xx) 4 m ø60 /100 L* < 0.5 m
Coaxial
System C32 (xx) 4 m ø60 /100 L* < 0.5 m
C42 (xx) 4 m ø60 /100 L* < 0.5 m
23 kW 27 kW
C12 (xy) 54 m 46 m ø80 L < 7 m (23 kW) L < 5 m (27 kW) L > 4 9 m (23 kW) L > 6.5 m (27 kW)
C32 (xy) 54 m 46 m ø80 L < 7 m (23 kW) L < 5 m (27 kW) L > 4.9 m (23 kW) L > 6.5m (27 kW)
Twin Pipe
Systems C42 (xy) 54 m 46 m ø80 L < 7 m (23 kW) L < 5 m (27 kW) L > 4.9m (23 kW) L > 6.5m (27 kW)
C52 (xy) 17 m 17 m ø80 L < 7 m (23 kW) L < 5 m (27 kW) L > 4.9m (23 kW) L > 5.3m (27 kW)
ExhaustType Diameter of Pipes
(mm) Use of a Restrictor
on the Discharge Side Risk of Condensation Forming
Maximum Extension
Exhaust/Air

Supplied By www.heating spares.co Tel. [phone]
13
5Remove the grommet “D”shown in photo 5, make a hole in it and pass
the room thermostat wire through.
6Remove the link located on the terminal and connect the wire.
7Replace the grommet and the terminal to their original positions, close the
cover on the grommet compartment and fasten the wire-clamp “C”in place.
8If a remote time clock is to be fitted, disconnect the integral time clock plug
from the P.C.B.
9Using a volt-free switching time clock, connect the switching wires from the
time clock following points 1-7 above.
10If using a time clock and room thermostat, these must be connected in
series as per points 1-9 above.
Note: Only a two-wire type room thermostat can be used.
2.10 Room Thermostat
Connection
34
567
D
C
B
C
1
A
2
In order to perform this procedure, remove boiler cover as indicated in section
3.2.Then proceed as follows:
1Remove the screws “A”located on the bottom part of the boiler;
2Widen the sides so that the control panel can be rotated.
3Open the cover “B”on the left hand side of the compartment.
4Insert the wire for the connection of the room thermostat into the wire
holder “C”, as indicated in photo 3.

Supplied By www.heating spares.co Tel. [phone]
14
2.11 Electrical Diagram Legend:
AT= High Voltage P.C.B.
BT = Low Voltage P.C.B.
B = Flame Failure L.E.D.
C = Insufficient Water Pressure L.E.D.
D = WaterTemperature Indicator L.E.D.s
E = Overheat Thermostat Warning L.E.D.
F = System Reset Button
G = Selector Knob for Operating Mode
H = Domestic Hot Water Temp. Adjustment
I = Central Heating Temp. Adjustment
J = Wire Connector for RoomThermostat
K = Antifreeze feature selector.
L = Connector for Total Check System
M = Anti-cycling Device Adjustment for Heating
N = Soft-light Adjustment
O = Max Heating Temperature Adjustment
Q = On/Off L.E.D.
R = On/Off Switch
S = Interface Wire for P.C.B.s
T = Relay Motorised Valve
U = Ignitor Relay
V = Gas Valve Relay
W = Fan Relay
X = Circulation Pump Relay
Y = Selector TCS
A01 = Air Pressure Switch
A02 = Fan
A03 = Gas Valve
A04 = Ignitor
A05 = Motorised Valve
A06 = Circulation Pump
A07 = Flame Detector
A08 = Earth Terminal
A09 = Flame Detection Circuit
A10 = Flame Indicator L.E.D.
A11 = Transformer
A12 = Filter
B01 = Over Heat Thermostat
B02 = Room Thermostat
B03 = Gas Valve Modulator
B05 = Heating Sensor
B06 = Pressure Switch for Heating Circuit
B07 = Microswitch for Diverter Valve
Colours
Gry = Grey
Rd = Red
Bl = Blue
Grn/Yll = Yellow/Green
Wh = White
Brn = Brown
Blk = Black
Wh/Rd = White/Red

Supplied By www.heating spares.co Tel. [phone]
15
A/23 MFFI - A/27 MFFI

Supplied By www.heating spares.co Tel. [phone]
16
2.12 Water Circuit Diagram
A/23 MFFI - A/27 MFFI
Legend
1. Air Pressure Switch
2. Fan
3. Main Heat Exchanger
4. Main Burner
5. Ignition Electrodes - Detection Electrode
6. Gas Valve
7. Overheat Thermostat
8. Main Circuit Temperature Probe
9. Diverter Valve
10. Main Circuit Flow Switch including Safety
Pressure Switch for Primary Circuit
11. Automatic By-pass
12. Microswitch for Diverter Valve
13. Secondary Heat Exchanger
14. Domestic Water Inlet Filter
15. Boiler Drain Valve
16. Safety Valve
17. Water Pressure Gauge
18. Circulation Pump with Automatic Air Release Valve
19. Expansion Vessel

Supplied By www.heating spares.co Tel. [phone]
17
3 COMMISSIONING
3.1 Initial Preparation MTS (GB) Limited support the initiative. Within the information pack
you will find a copy of the logbook. It is important that this is complet-
ed in the presence of your customer, they are shown how to us it, and it is
signed by them.Please instruct your customer that they must have their
logbook with them whenever they contact a service engineer or us.
Preliminary electrical system checks to ensure electrical safety must be carried out by a
competent person i.e.polarity, earth continuity, resistance to earth and short circuit.
Filling the Heating System:
Remove the panels of the case and lower the control panel (see point 3.2.for further
information).
Open the central heating flow and return cocks supplied with the connection kit.
Unscrew the cap on the automatic air release valve one full turn and leave open per-
manently.
Close all air release valves on the central heating system.
Gradually open valve(s) at the filling point (filling-loop) connection to the central heat-
ing system until water is heard to flow, do not open fully.
Open each air release tap starting with the lower point and close it only when clear
water, free of air, is visible.
Purge the air from the pump by unscrewing anticlockwise the pump plug and also
manually rotate the pump shaft in the direction indicated by the pump label to ensure
the pump is free.
Close the pump plug.
Continue filling the system until at least 1 bar registers on the pressure gauge.
Inspect the system for water soundness and remedy any leaks discovered.
Filling of the D.H.W.System:
Close all hot water draw-off taps.
Open the cold water inlet cock supplied with the connection kit.
Open slowly each draw-off tap and close it only when clear water, free of bubbles, is
visible
Gas Supply:
Inspect the entire installation including the gas meter, test for soundness and purge,
all as described in BS 6891:1988.
Open the gas cock (supplied with the connection kit) to the appliance and check the
gas connector on the appliance for leaks.
When the installation and filling are completed turn on the central heating system (sect.
3.4) and run it until the temperature has reached the boiler operating temperature. The
system must then be immediately flushed through.
The flushing procedure must be in line with BS 7593:1992 Code of practice for treat-
ment of water in domestic hot water central heating systems.
During this operation, we highly recommend the use of a central heating flushing deter-
gent (Fernox Superfloc or equivalent), whose function is to dissolve any foreign matter
that may be in the system.
Substances different from these could create serious problems to the pump or
other components.
The use of an inhibitor in system such as Fernox MB-1 or equivalent is strongly recom-
mended to prevent corrosion (sludge) damaging the boiler and system.
Failure to carry out this procedure may invalidate the appliance warranty.

Supplied By www.heating spares.co Tel. [phone]
3.4 Initial Start-up The checks to be run before initial start-up are as follows:
1. Make sure that:
- the screw on the automatic air valve has been loosened when the system is full;
- If the water pressure in the system is below 1 bar, bring it up to the appropriate level;
- Check to see whether the gas cock is closed;
- Make sure that the electrical connection has been made properly and that the earth
wire is connected to an efficient earthing system;
- Supply power to the boiler by pressing the On/Off switch <L> - the L.E.D. “I”will
turn on - turn the selector knob “C”to the <winter> setting.This will start the circula-
tion pump. After 7 seconds, the boiler will signal a shut-down due to failure ignition.
Leave the boiler as it is until all of the air has been bled from the lines.
18
3.2 Removing the
Front Panel
21 F
To remove the front panel of the casing, proceed as follows:
1. Remove the screw “F”located on the top edge of the panel.
2. Lift and unhook the panel.
3.3 Control Panel
A - Ignition Lockout Reset Button/Safety (Overheat)Thermostat Reset
B - Ignition Lockout L.E.D.
C - Selector Knob for Summer/Winter/Flue Analysis Modes*
D - Low System Water Level L.E.D.
E - Temperature Adjustment Knob for Domestic Hot Water
F - Heating System Thermometer
G - Safety (Overheat)Thermostat Intervention L.E.D.
H - Adjustment Knob for Heating Temperature
I - On/Off L.E.D.
L - On/Off Switch
O - System Pressure Gauge
* Warning the flue analysis mode must only be selected by a qualified service engineer.
40 50 60 70 80
CC
A/23 MFFI - A/27 MFFI

Supplied By www.heating spares.co Tel. [phone]
19
3.5 Operational
Adjustments
The boiler was designed to make it easy to regulate and check the various features. To
access the areas where the adjustment and control devices are located, simply remove
the plugs by pressing from the inside, unscrew the screws “A”and remove the bottom
part of the instrument panel, rotating it upward.
Right hand side service panel also provides access to:
- the power supply cord connector;
- the fuses.
Left hand side:
- the jumper for regulating the ignition delay (anti-
cycling) feature, which can be set from 0 to 2
minutes (factory set at 1 minute);
- the potentiometer for regulating the soft-light feature,
the setting for whichcan range from the minimum ther-
mal power to the maximum:
- the potentiometer for the maximum thermal power for
the heating system, maximum thermal power setting
(factory set at the maximum value, unless
indicated otherwise on the adhesive sticker located in
proximity to the potentiometer);
- The connection for the diagnostic device (TCS).
G20 5.5 mm c.a.
G25 4.5 mm c.a.
G30-31 1.8 mm c.a.
A
- Loosen the cap on the head of the pump to eliminate any air pockets;
- Repeat the procedure for bleeding the radiators of air;
- Open the taps for a brief period;
- Check the system pressure and, if it has dropped, open the filling-loop again to
bring the pressure back up to 1 bar.
2. Check the exhaust flue for the fumes produced by combustion.
3. Make sure that all gate valves are open;
4. Turn on the gas cock and check the seals on the connections,
including the one for the burner, making sure that the meter does not signal the pas-
sage of gas.Check the connections with a soap solution and eliminate any leaks.
5. Press the reset button “A”for the lighting system; the spark will light the main burner.
If the burner does not light the first time, repeat the procedure.
6. Check the minimum and maximum pressure values for the gas going to the burner;
adjust it if needed using the values indicated in the table in section 4.
(See the relative section for burner pressure adjustment within the servicing manual).
The boiler is designed to make it easy to analyse the combustion by-products.
Using the especially designed apertures, readings can be taken on the temper-
ature of the combustion by-products and of the combustion air, as well as of the
concentrations of O2and CO2, etc.
The best maximum-power test conditions for the heating system are when the
selector “C”is turned to the flue analysis setting.
3.6 Combustion Analysis

Supplied By www.heating spares.co Tel. [phone]
20
The boiler is equipped with the following safety systems (see section 3.3 for references):
1 - Ignition Failure
This control signals an ignition failure on the burner 7 seconds after a lighting failure.
The L.E.D.“B”.will turn on to signal the shutdown status.
The system can be reset by pressing and releasing the button “A”after checking to
make sure that the gas valve is open.Repeat this process until the burner lights.
2 - Circulation Failure
This control signals that the safety pressure switch on the primary circuit has not
sensed a pressure of at least 1 bar within 40 seconds of the activation of the circulation
pump, it shuts off the boiler and lights the L.E.D.“D”.The system can be reset (after the
pressure has been brought up to the proper level) by using the On/Off switch “L”.
3 - Overheating
This control shuts off the boiler in the case where the primary circuit reaches a tempera-
ture in excess of 110°C.The L.E.D.“G”will come on to signal this shut off status. After the
system has been allowed to cool, the system can be reset by pressing the button“A”.
4 - The boiler is provided with a device that, should the temperature of the water for the
heating system fall to below 3°C, is activated until a temperature of 55°C is reached
(still for heating purposes).
This device can only be activated with a perfectly operating boiler:
- The pressure of the system is sufficient,
- The boiler is well supplied electronically,
- The gas is supplied.
5- Limescale Build-up
This is an indirect control (actuated through the regulation of the temperature in the
primary heat exchanger) on the formation of limescale in the secondary heat
exchanger. Regardless of the flow rate and the temperature in the circuit for the
domestic hot water, the temperature is limited to 62°C.
6- Safety Shut-off
At the start of every lighting phase, the P.C.B.performs a series of internal controls.If
a malfunction occurs, the boiler will shutdown until the problem has been resolved.
The discharge/ventilation of the exhaust fumes can be monitored to check for
losses in general pressure in the system.This is done to eliminate the cause of
lighting failure with the main burner not indicated by a shutdown status.
With a differential manometer connected to the test socket
on the combustion chamber, the DP value for the air pres-
sure switch can be taken. The measured value should not
be less than 10 mbar under maximum thermal power condi-
tions (with the knob “C”on the flue test setting) in order for
the unit to function properly and without interruption.
3.7 Fume Discharge
Monitoring
3.8 Boiler Safety Systems
3.9 Draining the System Draining the heating system.
The heating system must be emptied as follows:
- Turn off the boiler;
- Open the drain valve for the system and place a container below to catch the
water that comes out;
- Empty the system at the lowest points (where present). If you plan on not
using the heating system for an extended period of time, it is recommended
that you add antifreeze with an ethylene glycol base to the water in the
heating lines and radiators if the ambient temperature drops below 0°C during
the winter.
This makes repeated draining of the entire system unnecessary.
Draining the domestic hot water system.
Whenever there is the danger of the temperature dropping below the freezing
point, the domestic hot water system must be drained as follows:
- Turn off the general water valve for the household plumbing system;
- Turn on all the hot and cold water taps;
- Empty the remaining water from the lowest points in the system (where
present).
