Ariston ACT60E User manual

ASC60AX-L | ASC90AX-L
ACT60AX-L | ACT90AX-L
SERVICE MANUAL
600 CERAMIC HOB - TOUCH
ACT60E

ACT60E
2/6
Exploded View
16
76
63
64
267
263
211
270
262
216
214
420
421
306
85

Parts List
ACT60E
3/6
ID Part Number Factory ID Description
16 5291802 YOA60-12SC-041-065 Ceramic Glass Assembly - No Logo
63 5291502 H35-30-300-007 Hot Plate 1200W/230V
64 5291503 H35-30-300-008 Hot Plate 1800W/230V
211 5291501 H35-30-180-004 Terminal Block
213 5291505 H35-10-200-003 Flexible Power Cord
262 5291504 H35-30-400-029 Main PCB & Display Board Assembly *Obsolete*
*5291521 TBC *Main PCB & Display Board Assembly (EGO)
263 5291933 YORTK-4000-010-038 Installation kit
267 5291200 YOA60-4000-010-071 Clips for Hotplate
421 5291932 H25-55-100-040 Spring x for hotplate clips
* New PCB board 5291521 is suitable for all serial numbers.

ACT60E
4/6
Wiring Diagram
4
2
4
2
4
2
blue/mavi
1
brown/kahve1
4
2
THERMINAL BLOCK
L
L
L
N
N
E
2
3
4
5
6
7
8
9
10
11
12
blue/mavi
brown/kahve
brown/kahve
black/siyah
2
3
4
DGT 2018 STANDARD HOB CARD
black/siyah
black/siyah
red/kırmızı
Superseded PCB
Please refer to the next page for current wiring diagram
Part Number 5291504

ACT60E
5/6
Wiring Diagram
Part Number 5291521
Updated PCB
Please refer to this diagram for installation of the new PCB
